SGH-X650
User’s Guide
X650.book Page 2 Monday, April 17, 2006 3:33 PM

Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external
radio frequency energy. Follow any regulations or
rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their performance.
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
X650.book Page 3 Monday, April 17, 2006 3:33 PM

1
Important safety precautions
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency call
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables. Use
of any unauthorised accessories could damage you or
your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 70.
• The phone could explode if the battery is replaced with an
incorrect type.
• Dispose of used batteries according to the manufacturer’s
instructions.
At very high volumes, prolonged listening to a
headset can damage your hearing.
X650.book Page 1 Monday, April 17, 2006 3:33 PM

2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside of the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.

Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified option
and then select it.
[ ]
Indicates a key on the phone. For example,
[]
< >
Indicates a soft key, whose function is
displayed on the phone screen. For example,
<
Menu >
• Camera
Use the camera module on your
phone to take a photo.
Special features of your phone
•IrDA
Send and receive images, sounds,
other personal data via an infrared
port.
•Webbrowser
Access the wireless web to get up-
to-the-minute information and a
wide variety of media content.
X650.book Page 2 Monday, April 17, 2006 3:33 PM

3
Special features of your phone
• Phonebook
Store home, office, or cellular
phone numbers for your contacts.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, and audio.
•FMradio
Listen to your favourite FM radio
stations anytime, anywhere.
• Java game
Enjoy Java ™ -based embedded
games and download new games.
•Calendar
Keep track of your daily, weekly,
and monthly schedule.
• Voice recorder
Record memos or sounds.
•Alarm
Use your phone as an alarm clock
to wake you up in the morning or
notify you of an impending event.
•SOSmessage
Send SOS messages to your family or friends for help
in an emergency.
X650.book Page 3 Monday, April 17, 2006 3:33 PM

4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Keys, features, and locations
Get started 7
First steps to operate your phone
Install and charge the phone ................................... 7
Power on or off ...................................................... 8
Keys and display .................................................... 9
Access menu functions .......................................... 11
Customise your phone .......................................... 12
Make/Answer calls ................................................ 14
Step outside of the phone 14
Begin with your camera, the web, and other special features
Use the camera ................................................... 14
Listen to the FM radio ........................................... 15
Browse the web ................................................... 16
Use Phonebook .................................................... 16
Send messages .................................................... 17
View messages .................................................... 18
Use SOS messages ............................................... 19
Use infrared ........................................................ 20
Manage your schedule .......................................... 21
Enter text 22
ABC, T9, Number, and Symbol modes
Call functions 25
Advanced calling features
Menu functions 29
All menu options listed
Solve problems 68
Help and personal needs
Health and safety information 70
Index 77
X650.book Page 4 Monday, April 17, 2006 3:33 PM

5
Overview of menu functions
To access Menu mode, press < Menu > in Idle mode.
1 SIM-AT MENU  p.32
2 Call records  p.32
1 Missed calls
2 Received calls
3 Dialled calls
4 Delete all
5 Call time
6 Call costs*
 p.33
 p.33
 p.33
 p.33
 p.33
 p.34
3 Network services  p.34
1 Call diverting
2 Call barring
3 Call waiting
4 Network selection
5 Caller ID
6 Band selection
7 Active line*
 p.34
 p.35
 p.36
 p.36
 p.36
 p.36
 p.36
4 Sound settings  p.37
1 Incoming calls
2 Messages
3 Power on/off
4 Connection tone
5 Key tone
 p.37
 p.37
 p.37
 p.37
 p.38
4 Sound settings
(continued)
 p.37
6 Minute minder
7 Quiet mode
8 Alerts on call
 p.38
 p.38
 p.38
5 Messages  p.38
1 Short messages
2 Multimedia messages
3 Push messages
4 Preset messages
5 Voice mail
6 SOS message
7 Broadcast
8 Settings
9 Memory status
 p.38
 p.41
 p.43
 p.44
 p.44
 p.44
 p.45
 p.45
 p.47
6 Fun box  p.48
1 WWW services
2 Media box
3 JAVA world
4 FM radio
 p.48
 p.51
 p.52
 p.53
7 Organiser  p.55
1 New memo
2 Calendar
3 To do list
 p.55
 p.55
 p.56
7 Organiser
(continued)
 p.55
4 Clock
5 Alarm
6 Voice recorder
7 Calculator
8 Convertor
9 Timer
10 Stopwatch
 p.57
 p.57
 p.58
 p.59
 p.59
 p.60
 p.60
8 Camera  p.60
1 Take photos
2 My photos
3 My albums
4 Delete all
5 Settings
6 Memory status
 p.61
 p.63
 p.63
 p.63
 p.63
 p.64
9 Phone settings  p.64
1 Display
2 Greeting message
3 Language
4 Security
5 Auto redial
6 Voice clarity
 p.64
 p.65
 p.65
 p.65
 p.66
 p.66
Press < Phonebook > in Idle
mode.
Phonebook  p.29
1 Find name
2 Add entry
3 Speed-dial list
4 Copy all to phone
5 Delete all
6 Own number
7 Group setting
8 Memory status
9 Service directory
*
* Shows only if supported by your SIM
card.
 p.29
 p.29
 p.30
 p.31
 p.31
 p.31
 p.31
 p.32
 p.32
9 Phone settings
(continued)
 p.64
7 Anykey answer
8 Active folder
9 Volume key
10 Infrared activation
11 Reset settings
 p.67
 p.67
 p.67
 p.67
 p.67
X650.book Page 5 Monday, April 17, 2006 3:33 PM

6
Unpack
Make sure you have each item
You can obtain various accessories
from your local Samsung dealer.
Phone Travel Adapter
The items supplied with your phone
and the accessories at your
Samsung dealer may vary,
depending on your country or
service provider.
Battery User’s Guide
Your phone
Keys, features, and locations
Cancel/Delete
key
Special
function keys
Dial key
Web access/
Confirm key
Volume keys
Left soft key
Microphone
Right soft key
Alphanumeric
keys
Power on/off/
Menu exit key
Navigation keys
(Up/Down/Left/
Right)
Camera
key
Camera
lens
Earpiece
Headset jack
Display
Infrared
port
Service
light
X650.book Page 6 Monday, April 17, 2006 3:33 PM

7
Get started
First steps to operate your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery.
If the phone is already
on, first turn it off by
pressing and holding
[].
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card are face down.
Reattach the battery. Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
X650.book Page 7 Monday, April 17, 2006 3:33 PM

8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
Switch on
Do not turn on the
phone when
mobile phone use
is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn on
the phone.
3. If necessary, enter the PIN and
press < OK >.
Switch off 1. Open the phone.
2. Press and hold [ ].
X650.book Page 8 Monday, April 17, 2006 3:33 PM

9
Get started
Keys and display
Keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access the following menus
directly:
•Up:
Camera
•Down: FM radio
•Left: Create in Short messages
•Right: Calendar
In Menu mode, scroll through menu options.
In Idle mode, launch the web browser.
Make or answer a call.
In Idle mode, retrieve numbers recently
dialled, received, or missed.
Delete characters from the display.
In Menu mode, return to the previous menu
level.
In Idle mode, enter the
New memo menu
when held down.
Press and hold to switch the phone on and
off.
End a call.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1] to access
your voicemail server. Press and hold [
0 ] to
enter an international call prefix.
Enter special characters.
In Idle mode, press and hold [ ] to activate
or deactivate Quiet mode. Press and hold
[ ] to enter a pause between numbers.
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the keypad tone volume.
In Idle mode, press and hold to turn on the
camera.
In Capture mode, take a photo.
X650.book Page 9 Monday, April 17, 2006 3:33 PM

10
Get started
Display
Layout
Icons Received signal strength
Call in progress
Out of your service area; you
cannot send or receive calls
GPRS network
Home Zone, if you have
registered for the appropriate
service
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current functions
assigned to the soft keys.
Icons
display various icons.
Menu Phonebook
Office Zone, if you have
registered for the appropriate
service
New SMS message
New MMS message
New voicemail
SOS message
 p. 44
Alarm set  p. 57
Call diverting feature active
 p. 34
Infrared port active  p. 67
Set to vibrate call ringer
 p. 37
Quiet mode  p. 38
Battery power level
X650.book Page 10 Monday, April 17, 2006 3:33 PM

11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left
soft key to select
the highlighted
option.
Press the right
soft key to return
to the previous
menu level.
Select
Select an
option
1. Press a desired soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press < Select > or [] to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods:
•Press <> or [ C ] to move
up one level.
•Press [] to return to Idle
mode.
Use shortcuts Press the number key
corresponding to the option you
want. For the index numbers 10 and
11, press [ 0 ] and [ ] respectively.
X650.book Page 11 Monday, April 17, 2006 3:33 PM

12
Get started
Customise your phone
1. In Idle mode, press < Menu >
and select Phone settings →
Language → Text language .
2. Select a language.
1. In Idle mode, press < Menu >
and select Sound settings →
Incoming calls .
2. Select a ringtone category,
Default melodies or My
sounds .
3. Select a ringtone.
Display
language
Call ringer
melody
You can set wallpaper for the idle
screen on the display.
1. In Idle mode, press < Menu >
and select Phone settings →
Display → Wallpaper .
2. Select an image category,
Default wallpapers , Photos ,
or Downloaded images .
3. Select an image.
You can change the colour for the
display components, such as title
bars and highlight bars.
1. In Idle mode, press < Menu >
and select Phone settings →
Display → Skin .
2. Select a colour pattern.
Idle mode
Wallpaper
Menu mode
Skin colour
X650.book Page 12 Monday, April 17, 2006 3:33 PM

13
Get started
You can switch the phone to Quiet
mode to avoid disturbing other
people with your phone sounds.
Press and hold [] in Idle mode.
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press < Menu >
and select Phone settings →
Security → Change
password .
2. Enter the default password,
00000000 , and press < OK >.
3. Enter a new 4- to 8- digit
password and press < OK >.
Quiet mode
Phone lock
4. Enter the new password again
and press < OK >.
5. Select Phone lock .
6. Select Enable .
7. Enter the password and press
< OK >.
X650.book Page 13 Monday, April 17, 2006 3:33 PM

14
Make/Answer calls
Step outside of the phone
Begin with your camera, the web, and other special
features
Use the camera
1. Enter an area code and phone
number.
2. Press [] .
3. To end the call, press [] .
1. When the phone is ringing,
press [] .
2. To end the call, press [] .
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. In Idle mode, press and hold
[Up] or [ ] to turn on the
camera.
2. Aim the lens at the subject and
make any desired adjustments.
3. Press [], the left soft key, or
[ ] to take a photo. The photo
is saved automatically.
4. Press [ C ] to take another
photo.
1. In Idle mode, press [Up] and
select My photos .
2. Select the photo you want.
Take a photo
View a photo
X650.book Page 14 Monday, April 17, 2006 3:33 PM

15
Step outside of the phone
Listen to the FM radio
1. Plug the connector of the
supplied headset into the jack
on the left side of the phone.
2. In Idle mode, press [Down].
3. Press < Options > and select
Power on .
4. Press [Left] or [Right] to find
available radio stations.
5. To turn off the radio, disconnect
the headset from the phone.
Listening to the
radio
1. Plug the connector of the
supplied headset into the jack
on the left side of the phone.
2. From the FM Radio screen,
press < Options > and select
Power on .
3. Scroll to an empty location.
4. Press [Left] or [Right] to find
the radio station you want.
5. Press < Options > and select
Add .
6. Enter the title of the station and
press < OK >.
7. Press < OK > when the
frequency for the selected radio
station displays.
Storing a radio
station
X650.book Page 15 Monday, April 17, 2006 3:33 PM

16
Step outside of the phone
Browse the web
Using a built-in web browser, you can easily access the
wireless web to get a variety of up-to-date services
and information and to download web content.
Use Phonebook
In Idle mode, press [] .
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press < >.
• To return to the previous page,
press < Back > or [ C ].
• To use options, press [ ] or
select on the top of the
screen.
Launch the web
browser
Navigate the
web
To the phone’s memory:
1. In Idle mode, enter a phone
number and press < Save >.
2. Select Phone → a number type.
3. Enter a name and press < OK >
to save the contact.
4. To save additional information,
press < Options > and select
Edit number , press < Edit >, or
press < Options > in each field.
5. Enter a number or e-mail
address, or select a ringtone or
caller ID image.
6. Press < OK > or < Select >.
Add a contact
X650.book Page 16 Monday, April 17, 2006 3:33 PM

17
Step outside of the phone
Send messages
To the SI M c a r d:
1. In Idle mode, enter a phone
number and press < Save >.
2. Select SIM .
3. Enter a name and press < OK >.
4. If necessary, change a location
number.
5. Press < OK > to save the
contact.
1. In Idle mode, press
< Phonebook > and select Find
name .
2. Enter the first few letters of the
name you want.
3. Select an entry.
4. Scroll to a number and press
[] to dial.
Find a contact
1. In Idle mode, press < Menu >
and select Messages → Short
messages → Create .
2. Enter the message text.
3. Press [ ].
4. Enter destination numbers and
press < OK >.
5. Press < Send > to send the
message.
1. In Idle mode, press < Menu >
and select Messages →
Multimedia messages →
Create .
2. Select Subject .
3. Enter the message subject and
press < OK >.
Send a text
message (SMS)
Send a
multimedia
message (MMS)
X650.book Page 17 Monday, April 17, 2006 3:33 PM

18
Step outside of the phone
View messages
4. Select Picture and add an
image file.
5. Select Sound and add a sound
file.
6. Select Message and enter the
message text.
7. Press < Opt. > and select Done .
8. When you have finished, press
< Opt. > and select Send .
9. Select an empty location.
10. Select Number or E-mail and
enter destination numbers or
addresses.
Otherwise, select Phonebook
to retrieve one from your
Phonebook.
11. Press < Send > to send the
message.
Send a
multimedia
message (MMS)
(continued)
When a notification appears:
1. Press < View >.
2. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press < Menu >
and select Messages → Short
messages → Inbox .
2. Select a message.
View a text
message
X650.book Page 18 Monday, April 17, 2006 3:33 PM
