Samsung SPC-6000 User manual

SYSTEM CONTROLLER
User Manual SPC-6000

Copyright
©2011 Samsung Techwin Co., Ltd. All rights reserved.
Trademark
is the registered logo of Samsung Techwin Co., Ltd.
The name of this product is the registered trademark of Samsung Techwin Co., Ltd.
Other trademarks mentioned in this manual are the registered trademark of their respective company.
Restriction
Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document
shall be reproduced, distributed or changed, partially or wholly, without formal authorization of Samsung Techwin.
Disclaimer
Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no
formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s
own responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice.
Design and specifications are subject to change without prior notice.
The default password can be exposed to a hacking thread so it is recommended to change the
password after installing the product.
Note that the security and other related issues caused by the unchanged password shall be responsible
for the user.
System Controller
User Manual

English _3
●OVERVIEW
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety pu rpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety, If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience recep-
tacles, and the point where they exit from the apparatus.
11. Only use attachments/ accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lighting storms or when unused for long periods of
time.
14.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
overview

overview
4_overview
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PROCUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT
THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT.
Apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the product.

English _5
●OVERVIEW
Please read the following recommend safety precautions carefully.
User’s Manual is a guidance book on how to use the product.
Below is a key to the following signs that are used in this manual.
yReference : Providing useful information for the user.
yNotice : If the instructions are not followed correctly damage to the goods or person
may occur.

For safety please read this manual for the before using of goods and keep it in the safe place.
Do not Place this apparatus on an uneven surface. Do not install on a surface where it is exposed to direct
sunlight, near heating equipment or heavy cold area.
Do not place this apparatus near. Do not attempt to service this apparatus yourself.
Do not place a glass of water on the product. Do not install near any magnetic sources.
Do not block any ventilation openings. Do not place heavy items on the product.

overview
6_overview
Samsung Techwin cares for the environment at all product manufacturing stages, and is taking
measures to provide customers with more environmentally friendly products.
The Eco mark represents Samsung Techwin’s devotion to creating environmentally friendly products,
and indicates that the product satisfies the EU RoHS Directive.
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic
accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste
at the end of their working life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local
government office, for details of where and how they can take these items for environmentally safe
recycling.
Business users should contact their supplier and check the terms and conditions of the purchase
contract. This product and its electronic accessories should not be mixed with other commercial
wastes for disposal.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at
his own expense.

English _7
●OVERVIEW
CONTENTS
OVERVIEW
3
3Important Safety Instructions
7Contents
9Key Features
10 What’s Included
11 System Controller at a Glance
INSTALLATION
14
14 Precautions
15 Before Installation
15 Adjusting the Screen Angle of the System
Controller
16 Switching the Layout of Joystick and Jog
Shuttle
CONNECTING TO AN EXTERNAL
DEVICE
17
17 To Connect a RS-485 Device
23 Connecting to other System Controller
USING THE MENU
24
24 Getting Started
24 Controlling the PTZ Camera
30 Controlling DVR
32 Controlling MATRIX

overview
8_overview
MENU SETTING
34
34 To Access the Main Menu
34 PTZ setting
35 DVR Setting
35 Controller Setting
40 Firmware Update
42 To Check the Controller Information
APPENDIX
43
43 Specifications
44 Q & A
45 GPL/LGPL Software License

English _9
●OVERVIEW
KEY FEATURES
SPC-6000 system controller enables you to control external devices such as PTZ camera, DVR,
MATRIX using RS-485 communications.
It provides a user-friendly interface with onscreen menu, touch screen and joystick.
• Long-distance remote control
•
With RS-485 communications, the control distance is a maximum of 1km.
• Integrated system control
• With a single system controller, you can control all cameras (receiver unit), DVRs and MATRIX.
• Multiple system controllers can be connection.
• You can control different sites and connect up to 16 controllers simultaneously.
• Switch the joystick and jog shuttle module positions.
• For the user’s convenience, the positions of the joystick and jog shuttle module can be switched between
left and right.
• User-friendly interface
The operation status of the system control is displayed on the screen; the touch-screen enables you to
select a menu with ease; the joystick makes your control simple and easy.
❖Compatibility List
• Camera
• MATRIX
SMX-25632
• DVR
SRD-XXXX series, SHR-8/7/6XXX series, SVR-1670, SRD-480D
❖Adapter Specifications
• Voltage : 1) Input (AC) : 100~240V
2) Output (DC) : 12V
• Capacity (output current) : 4A
• Continuous standard load : 48W
• Temperature : 1) Operating Temperature : 0 ~+40°C
2) Storage : -20 ~+60°C

overview
10_overview
WHAT’S INCLUDED
Unpack the product package and place the product on the floor or a flat surface.
Check if the following components are all included in the product package.
Main Unit User Manual Power Adaptor 1EA
Power Cable 1EA Terminal Block 1EA

English _11
●OVERVIEW
SYSTEM CONTROLLER AT A GLANCE
Front Side
Item Description
aDVR Play Bar Play/Pause, Fast Forward/Fast Backward, Stop, Record
bDVR Control Bar Access the selected menu, search, select a split mode, or control the alarm.
cLCD Display Display the operation status and the setup menu of the system controller.
dSETUP Bar Press the [FUNC] button and press [SETUP] to enter the Setup menu.
eCamera Operation Bar Access the selected PTZ menu, or execute Preset, Group or Track.
fJoystick Controller
You can manipulate the Pan/Tilt operation up or down in connection with the PTZ
camera or receiver unit.
Turn the joystick clockwise or counter clockwise to control zooming.
You can control the direction of the connected controller from the menu screen of the
controller.
a b c d e
fi h gk j

overview
12_overview
Item Description
gCamera Lens Bar
IRIS Control Iris (CLOSE/OPEN)
FOCUS Adjust the focus (NEAR/FAR)
ZOOM Zoom In/Out (WIDE/TELE)
hNavigate, ENTER, ESC
Navigate Navigate through menu items.
ENTER Move to a desired item using the navigation buttons and select it.
ESC Cancel the current operation.
iNumber (0-9) Buttons Used to specify numeric characters for camera, monitor, DVR or Preset settings.
jController Selection Bar Used to select a camera, monitor or DVR.
kJog Shuttle
Jog
Used to search for forward /reverse frame in DVR play mode.
Shuttle Forward/Reverse /Play/FF/REW in DVR play mode.

English _13
●OVERVIEW
Rear Side
Item Description
aVideo In/Out Video input/output port
bMATRIX Matrix connection port
cRS-485
PORT 1 Connected to a controller such as camera or DVR through RS-485
communications.
PORT 2 Connect to other SPC-6000 system controller.
dUSB Port Used for backup of the system controller settings or upgrading the firmware.
ePower DC 12V input port ( )
fCable Hook To prevent the power cable from being loose.
M
`Be sure to use the cable hook when installing and using the controller.
M
`The MATRIX port contains the power line so you don’t need to supply DC 12V separately if using the MATRIX port.
`The MATRIX port contains a single line controlling the main and subsidiary control signals.
`The MATRIX signal is of TTL level.
Use the extension cable in less than 10 meters.
cba d e f

14_installation
PRECAUTIONS
Before you install the product, read through and comply with the following instructions.
• The product is designed for indoor use only.
• Keep it away from water or moisture.
• Do not put excessive force on it.
• Do not pull out the power cable forcibly.
• Do not dismantle it at your own.
• Use only the rated I/O range.
• Use only the provided power cable.
• Use the power plug containing the earth wire if available.
• Install the system controller on a flat table.
• The layout of the main unit and the wiring system are critical for a proper system operation.
• If the devices are too close with each other or in a poor-ventilating environment, the system may not work
properly.
Inaccessibility to the system makes the repair difficult or even impossible.
• To prevent a system failure or to reduce the system shutdown, make enough room for ventilation and
close the cover firmly.
• Do not dismantle the system controller at will as a high voltage runs inside the system controller.
- Operation Temperature : 0°C ~ 40°C
- Storage Temperature : -20°C ~ 60°C
- Operation Humidity : 10%~70% RH
- Storage Humidity : 10% ~ 90% RH
- Power Consumption : DC 12V, Max 4W (
)
installation

English _15
●INSTALLATION
BEFORE INSTALLATION
• You must turn off the product before installing it.
• A severe impact or vibration may cause a system failure.
•
Keep it away from a strong magnetic field or electric interference, or wireless devices such as radio or TV set.
• Keep the installation site clean and dust-free all the time while or after you have installed the product.
• Place it on an unsealed, flat surface at an optimal temperature.
Install it at least 15cm away from the wall.
• Do not close the ventilation hole or put a conductive object in it.
• Do not expose it to the direct sunlight. Keep the accessories or tools out of people’s reach in an attempt
to prevent a risk of physical damage.
• Leaving an abnormal smoke or smell as it is may lead to a fire or electric shock.
If this is the case, turn off the product immediately and contact us for a technical assistance.
• Take an appropriate action if you find: damp floor, unearthed power extension cord, peeled-off power
cable, or absence of safety grounding.
J
`Use a dry cloth to wipe it out. If badly dirty or stained, use a cloth soaked into neutral detergent to wipe it out.
Do not use volatile solvents such as alcohol, benzene or thinner that may damage the product surface.
`
Do not operate the LCD monitor at a high temperature; recommended to use the screen saver for power conversation.
ADJUSTING THE SCREEN ANGLE OF THE SYSTEM
CONTROLLER
You can pull the screen forward for a better view.

installation
16_installation
SWITCHING THE LAYOUT OF JOYSTICK AND JOG SHUTTLE
For convenience you can switch the position of joystick and jog shuttle module.
J
`
To switch between left and right, turn off the system controller and switch the modules manually. Or, press <Change>
in the controller setup menu and switch the modules manually. (► page 38)
1. Press down both hooks on the bottom of the system controller to remove the module.
2. Remove both joystick and jog shuttle modules from the controller and switch the position.
When done, insert them until you hear a click.
<Bottom>
주의 : 전원을 끄고 모듈을 탈착하십시오.
Caution : Turn the power off
and separate the module.

English _17
●
CONNECTING TO AN EXTERNAL DEVICE
SPC-6000 system controller can be used in connection with an external device such as
camera or DVR.
TO CONNECT A RS-485 DEVICE
With the system controller, you can control the PTZ camera or DVR that supports RS-485 communication
protocols.
1. Connect the rear PORT 1 with RS-485 port of the PTZ camera or DVR.
2. According to the external device connected, select Half Duplex or Full Duplex connection.
M
`For the Half Duplex system, use TX +/- terminals.
`For RS-485 communications, pay special attention to the polarity (+/-).
`Use the provided terminal block in the product package.
`Check if the RS-485 device is compatible with SPC-6000.
connecting to an external device

connecting to an external device
18_connecting to an external device
If connecting the keyboard without using MATRIX
Main Controller
Sub1 Controller
Sub2 Controller
Sub16 Controller

English _19
●
CONNECTING TO AN EXTERNAL DEVICE
If connecting the keyboard using MATRIX
1. Connect the [MATRIX] port of the main controller to the [KEYBOARD] port of the matrix.
The MATRIX port contains the power line so you don’t need to supply DC 12V separately.
2. Connect TX+ and TX- of the sub controller to T+ and T- of the matrix, respectively.
`The baud rate between sub controllers in sync with MATRIX will be fixed to 9600 bps.
`The MATRIX ID is fixed to <SUB 09>.
3. Connect DVR and PTZ camera to MATRIX.
Main Controller
PTZ Camera / DVR
PTZ Camera / DVR
Sub Controller

connecting to an external device
20_connecting to an external device
Connecting the PTZ Camera
By connecting RS-485 port on the rear of the PTZ camera with PORT 1 of SPC-6000, you can
control the camera.
M
`Depending on the camera, the polarity may differ.
For more information, refer to the user manual of the PTZ camera.
For the half duplex system
- Connect RX (+) of RS-485 port of the PTZ camera with
TX (+) of PORT 1 of SPC-6000.
- Connect RX (–) of RS-485 port of the PTZ camera with
TX (–) of PORT 1 of SPC-6000
For the full duplex system
- Connect RX (+) of RS-485 port of the PTZ camera with
TX (+) of PORT 1 of SPC-6000.
- Connect RX (–) of RS-485 port of the PTZ camera with
TX (–) of PORT 1 of SPC-6000.
- Connect TX (+) of RS-485 port of the PTZ camera with
RX (+) of PORT 1 of SPC-6000.
- Connect TX (–) of RS-485 port of the PTZ camera with
RX (–) of PORT 1 of SPC-6000.
