Samsung AWEP700JBE User manual

Printed in Korea
Code No.:GH68-17676A
02/2008. Rev. 1.0
World Wide Web
http://www.samsungmobileusa.com
http://www.samsungmobile.com
http://www.samsung.com/ca
http://www.samsung.com.br

English /

English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1
English
Contents
Getting started
Your headset overview ..................................................... 3
Button functions ............................................................. 4
Charging the headset ...................................................... 4
Wearing on the headset ................................................... 6
Using your headset
Turning the headset on or off............................................ 7
Pairing with your Bluetooth phone ..................................... 7
Using call functions ......................................................... 8
Appendix
Frequently asked questions ............................................ 11
Certification and Safety approvals ................................... 13
UL certified travel adapter .............................................. 14
Warranty and parts replacement ..................................... 15
Correct disposal of this product ....................................... 16
Specifications ............................................................... 17

2
Take the time to read through this user’s guide before you start
to use it.
Bluetooth
®
is a registered trademark of the Bluetooth SIG, Inc.
worldwide—Bluetooth QD ID: B013701
More information about Bluetooth is available at
www.bluetooth.com.
• Never disassemble or modify your headset for any reason.
Doing this may cause the headset to malfunction or become
combustible. Bring the headset to an authorized service
center to repair it or replace the battery.
• When using your headset while driving, follow local
regulations in the country or region you are in.
• Avoid storage at high temperatures (above 50° C/122° F),
such as in a hot vehicle or in direct sunlight, as this can
damage performance and reduce battery life.
• Do not expose the headset or any of its supplied parts to
rain or other liquids
.
Safety precautions
At very high volumes, prolonged listening to the
headset can damage your hearing.

3
English
Getting started
This section explains what to remember for the proper use of
your Bluetooth headset.
Your headset overview
Make sure you have the following items with your headset :
Travel Adapter, User’s Guide
The items supplied with your headset may vary depending
on your region.
Multi-function
button
Volume up
button
Indicator light
Primary
microphone
Ear hook
Secondary
microphone
Earpiece
Volume
down button
Adapter jack

4
Multi-function button
• Press and hold to turn the headset on or off.
• Press to make or answer a call.
• Press to end a call.
• Press and hold to enter Pairing mode.
/ Volume up/down buttons
• Press to adjust the volume.
• Press and hold at the same time to turn the indicator light
on or off.
• Press and hold to turn the microphone on or off
This headset has a rechargeable internal battery which is non-
removable. Ensure that you fully charge the battery before
using the headset for the first time.
1 Put the travel adapter into the jack on the headset and into
a power outlet.
Button functions
Charging the headset

5
English
2 Disconnect the travel adapter from the power outlet and the
headset when the indicator light changes to blue.
• Use only a Samsung-approved travel adapter.
Unauthorized adapters may cause an explosion or
damage to the headset.
• The battery will gradually wear out while charging or
discharging because it is a consumable part.
• The headset is not able to operate while charging. Try
connecting after charging is completed.

6
When the battery charge gets low
A warning sound beeps and the indicator light flashes red. If
you are on a call, transfer the call from the headset to the
phone before the headset automatically turns off.
Place the headset on your ear.
Ensure to put the correct (Left,
Right) earpiece on each ear.
Depending on what ear you are going to wear the headset,
simply adjust the ear hook accordingly.
Wearing on the headset
Left Right

7
English
Using your headset
This section explains how to turn the headset on, pair with the
phone, and use various functions.
• To turn the headset on, press and hold [ ] until the blue
indicator light flashes 4times.
• To turn the headset off, press and hold [ ] until both blue
and red indicator lights flash.
Pairing will create a unique and encrypted wireless link
between two Bluetooth enabled devices, such as a Bluetooth
phone and a Bluetooth headset. To use the headset with other
Bluetooth devices, both devices must be paired. When trying
to pair the two devices, keep the headset and the phone
reasonably close together.
• Activated functions may differ depending on the types of
your phone.
• Some devices, especially those that are not tested or
approved by Bluetooth SIG, may be incompatible with
your headset.
Turning the headset on or off
Pairing with your Bluetooth phone

8
1 Enter Pairing mode.
• Turn off your headset and press and hold the [ ] until
the indicator light turns on blue and stays lit after
blinking.
• If you turn the headset on for the first time, it proceeds
into Pairing mode immediately.
2 Search for and connect with your phone according to your
phone user’s guide. (Bluetooth PIN: 0000, 4 zeros).
Making a call
Redialing the last number
Press [ ] to redial the last number.
For some phones, pressing the key opens the call log list.
Press [ ] to dial the selected number.
Dialing a number by voice
Press and hold [ ] to dial a number by voice, and say a name.
When the headset and the phone are paired, the headset
attempts to reconnect automatically each time it turns on.
Otherwise, press [ ] to reconnect.
Using call functions

9
English
Answering a call
Press [ ] to answer a call when you hear incoming call tones.
Ending a call
Press [ ] to end a call.
Rejecting a call
Press and hold [ ] to reject a call when a call comes in.
Using options during a call
You can use the following functions to control your call during
a call.
Adjusting the volume
Press [ + ] or [ - ] to adjust the volume.
Muting the microphone
Press and hold [ + ] or [ - ] to turn the microphone off so that
the person with whom you are speaking cannot hear you.
Press and hold [
+ ] or [ - ] again to turn the microphone back
on.

10
Transferring a call from the phone to the headset
Press [ ] to transfer a call from the phone to the headset.
Placing a call on hold
Press and hold [ ] to place the current call on hold.
Answering a second call
Press [ ] to end the first call and answer a second call when
you hear call waiting tones.
Press and hold [ ] to place the first call on hold and answer a
second call when you hear waiting tones.
To switch between the current call and the held call, press and
hold [ ].

11
English
Appendix
Frequently asked questions
Will my headset
work with laptops,
PCs, and PDAs?
Your headset will work with devices that
support your headset’s Bluetooth version
and profiles. For specifications, see page
17.
Will anything
cause interference
with my
conversation when
I am using my
headset?
Appliances such as cordless phones and
wireless networking equipment may cause
interference with your conversation,
usually adding a crackling noise. To
reduce any interference, keep the headset
away from other devices that use or
produce radio waves.
Will my headset
interfere with my
car’s electronics,
radio, or
computer?
Your headset produces significantly less
power than a typical mobile phone. It also
only emits signals that are in compliance
with the international Bluetooth standard.
Therefore, you should not expect any
interference with standard consumer-
grade electronics equipment.

12
Can other
Bluetooth phone
users hear my
conversation?
When you pair your headset to your
Bluetooth phone, you are creating a
private link between only these two
Bluetooth devices. The wireless Bluetooth
technology used in your headset is not
easily monitored by third parties because
Bluetooth wireless signals are significantly
lower in radio frequency power than those
produced by a typical mobile phone.
The sound is
echoing while
talking.
Adjust the speaker volume, or move to
another area and try again.
How do I take care
of my headset?
Wipe it with a soft dry cloth.
The headset does
not fully charge.
The headset and the travel adapter may
not have been connected properly.
Separate the headset from the travel
adapter, reconnect, and charge the
headset.

13
English
FCC
FCC ID: A3LWEP700
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
The device and its antenna must not be co-located or
operating in conjunction with any other antenna or transmitter.
Users are not permitted to make changes or modify the device
in any way.
Changes or modifications not expressly approved by Samsung
will void the user’s authority to operate the equipment
.
Industry Canada
IC ID: 649E-WEP700
Operation is subject to the following two conditions: (1) This
device may not cause interference and (2) This device must
accept any interference, including interference that may cause
undesired operation of the device.
Certification and Safety approvals

14
The term “IC:” before the certification/registration number
only signifies that registration was performed based on a
Declaration of Conformity indicating that Industry Canada
technical specifications were met. It does not imply that
Industry Canada approved the equipment.
The travel adapter for this headset has met UL 1310 safety
requirements.
Please adhere to the following safety instructions per UL
guide-lines.
FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED
MAY LEAD TO SERIOUS PERSONAL INJURY AND POSSIBLE
PROPERTY DAMAGE.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.
THIS POWER UNIT IS INTENDED TO BE CORRECTLY
ORIENTATED IN A VERTICAL OR HORIZONTAL OR FLOOR
MOUNT POSITION.
UL certified travel adapter

15
English
Samsung warrants this product as free of defects in material,
design and workmanship for the period of one year from the
original date of purchase.
*
If during the period of warranty this product proves defective
under normal use and service you should return the product to
the retailer from whom it was originally purchased or qualified
service center. The liability of Samsung and its appointed
maintenance company is limited to the cost of repair and/or
replacement of the unit under warranty.
• The warranty is limited to the original purchaser
• A copy of your receipt or other proof of purchase is required
for a proper warranty service
• The warranty is void if the serial number, date code label or
product label is removed, or if the product has been subject
to physical abuse, improper installation, modification, or
repair by unauthorized third parties
• Specifically exempt from any warranty are limited-life
consumable components such as batteries and other
accessories
Warranty and parts replacement
* Depending on your country, the length of warranty may vary.

16
• Samsung will not assume any responsibility for any loss or
damage incurred in shipping. All repair work on Samsung
products by unauthorized third parties voids any warranty
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate
this from other types of wastes and recycle it responsibly
to promote the sustainable reuse of material resources.
Household users should contact either the retailer where
they purchased this product, or their local government
office, for details of where and how they can take this item
for environmentally safe recycling.
Business users should contact their supplier and check the
terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes
for disposal.

17
English
Specifications
Item Specifications and description
Bluetooth Version 2.0+EDR
Support Profile Headset Profile, Hands-Free Profile 1.5
Operating range Up to 30 feet (10 meters)
Standby time Up to 200 hours*
Talk time Up to 6 hours
*
* Depending on the phone type and usage, the actual time may
vary.
Charging time Approximately 2 hours*
