Samsung HM-1300 User manual

Headset
HM1300

English......................................................................................... 1
Español......................................................................................31

1
English
Getting started
Your headset overview........................................................................................... 4
Button functions....................................................................................................... 5
Charging the headset............................................................................................. 6
Wearing the headset............................................................................................... 8
Using your headset
Turning the headset on or off............................................................................10
Turning the indicator light on or off ..............................................................10
Pairing and connecting the headset..............................................................11
Using call functions ...............................................................................................15
Resetting the headset...........................................................................................18
Appendix
Frequently asked questions...............................................................................19
Certification and Safety approvals .................................................................21
UL certified travel adapter..................................................................................22
STANDARD LIMITED WARRANTY......................................................................23
Specifications...........................................................................................................29
Contents
English

2
Please read this manual before operating your headset, and keep it for future reference. Graphics
used in this manual are for illustration purposes. The actual products may vary.
Copyright
Copyright © 2012 Samsung Electronics
This user manual is protected under international copyright laws.
No part of this user manual may be reproduced, distributed, translated, or transmitted in
any form or by any means, electronic or mechanical, including photocopying, recording, or
storing in any information storage and retrieval system, without the prior written permission
of Samsung Electronics.
Trademarks
SAMSUNG, and the SAMSUNG logo are registered trademarks of Samsung Electronics.•
Bluetooth® is a registered trademark of the Bluetooth SIG, Inc. worldwide. More information•
about Bluetooth is available at www.bluetooth.com.
All other trademarks and copyrights are the property of their respective owners.
•

3
English
Please read all Safety precautions before using your headset to ensure safe and proper use.
Safety precautions
When using your headset while driving, follow local regulations in the region you are in.•
Never disassemble or modify your headset for any reason. Doing this may cause the•
headset to malfunction or become combustible. Bring the headset to an authorized service
center to repair it.
Keep your device and all accessories out of the reach of small children or animals. Small•
parts may cause choking or serious injury if swallowed.
Avoid exposing your device to very cold or very hot temperatures (below 0 °C or above•
45 °C). Extreme temperatures can cause the deformation of the device and reduce the
charging capacity and life of your device.
Do not allow your device to get wet — liquids can cause serious damage. Do not handle•
your device with wet hands. Water damage to your device can void your manufacturer’s
warranty.
Avoid using your device’s light close to the eyes of children or animals.•
Do not use the device during a thunderstorm. Thunderstorms can cause the device•
to malfunction and increase the risk of electric shock.
Excessive exposure to loud sounds can cause hearing damage. Exposure to loud
sounds while driving may distract your attention and cause an accident. Use only
the minimum volume setting necessary to hear your conversation.

4
Getting started
Your headset overview
Make sure you have the following items: headset, travel adapter and
user manual. The supplied items may vary.
Power switch
Indicator light
Microphone
Earpiece
Volume button
Ear hook
Charging socket
Talk button

5
English
Button functions
Button Function
Power
switch Slide up or down to turn the headset on or off.•
Talk
Press and hold for 3 seconds to enter Pairing mode.•
Press to answer or end a call.•
Press and hold to reject an incoming call.•
Press and hold to place a call on hold.•
Press and hold to switch between calls.•
Volume
Press to adjust the volume.•
Press and hold to turn the microphone on or off during•
a call.

6
Charging the headset
This headset has a rechargeable internal battery which is non-removable. Make sure
the headset is fully charged before using it for the first time.
Connect the travel adapter to the charging socket1
on the headset.
Plug the travel adapter in to the wall outlet. During2
charging, the indicator light will turn red. If charging
does not begin, unplug the travel adapter and plug
it in again.
When the headset is fully charged, the red indicator3
light changes to blue. Unplug the travel adapter from
the wall outlet and the headset.
Use only Samsung-approved chargers. Unauthorized or non-Samsung•
chargers could cause damage to the headset or in extreme circumstances an
explosion, it could also invalidate any warranty on the product.
To save energy, unplug the travel adapter when not in use. The travel adapter•
does not have a power switch, so you must unplug the travel adapter from
the outlet when not in use to avoid wasting power. The travel adapter should
remain close to the socket when in use.

7
English
Repeatedly charging and discharging of the headset, over time will cause the•
battery performance to diminish. This is normal for all rechargeable batteries.
Never make or receive calls while charging, always disconnect your headset•
from the charger and answer the call.
When the headset battery is low
The headset beeps and the indicator light flashes red. If the headset powers off during
a call, the call will be automatically transferred to the phone.
Checking the battery level
To check the battery level, press and hold the Talk button and the Volume down
button at the same time. Depending on the battery level, the indicator light flashes 5
times in one of the following colors:
Battery level Indicator light color
Above 80% Blue
80 ~20% Violet
Below 20% Red

8
Wearing the headset
Depending on which ear you are going to wear the headset, simply adjust the ear
hook accordingly.
RightLeft 

9
English
Using your headset
This section explains how to turn the headset on or off, pair and connect the headset
to the phone, and use various functions.
Activated functions and features may differ depending on the phone type.•
Some devices, especially those that are not tested or approved by the•
Bluetooth Special Interest Group (SIG), may be incompatible with your
headset.
To ensure you get the best performance from your headset
Keep the distance between your headset and device as small as possible and avoid•
placing your body or other objects in the signals path.
If you usually use your mobile phone with your right hand, wear the headset on your•
right ear.
Covering your headset or device could effect its performance so keep contact to a•
minimum.

10
Turning the headset on or off
To turn the headset on
Slide up the power switch. The blue indicator light flashes 4 times.
Turning the headset on for the first time, it will automatically enter pairing mode
for approx. 3 minutes.
To turn the headset off
Slide down the power switch. The indicator light flashes blue and red then turns off.
Turning the indicator light on or off
The Headset status light is there to show you the current status of your headset,
but if it bothers you at night, you can turn it off.
Press and hold both Volume buttons simultaneously to turn the indicator light on•
or off.
You cannot switch the indicator off while in pairing mode.•
The indicator light will always work when the headset is turned on or off,•
when a call is received, in Pairing mode and when the battery is low.

11
English
Pairing and connecting the headset
Pairing means unique and encrypted wireless connection between two Bluetooth
devices when they agree to communicate with each other.
In Pairing mode, two devices should be placed close enough to each other.
Pairing and connecting the headset with a phone
Enter Pairing mode. (The blue indicator light stays lit and stays for 3 minutes.)1
With the headset turned on, press and hold the Talk button for 3 seconds.•
Activate the Bluetooth feature on your phone and search for the headset (see your2
phone’s user manual).
Select the headset (HM1300) from the list of devices found by your phone.3
If requested, enter the Bluetooth PIN 0000 (4 zeros) to pair and connect4
the headset to your phone. Once pairing is completed, the headset will attempt to
reconnect each time you turn it on.
Your headset supports the Simple Pairing feature which allows the headset to be
paired with a Bluetooth device without requesting a PIN. This feature is available
for devices that are compliant with Bluetooth version 2.1 or higher.

12
Pairing via the Active pairing feature
With the Active pairing feature, your headset automatically looks for a Bluetooth
device within range and tries to make a connection with it.
Make sure the phone’s Bluetooth visibility option is set on.
In Pairing mode, press and hold the Talk button on the headset. The indicator light•
color changes to violet from blue. The headset will attempt active pairing for up to
20 seconds.
The Bluetooth phone you want to connect with must not be paired with•
other devices. If the phone is already connected to another device, end the
connection and restart the Active pairing feature.
This feature may not be supported on some devices.•

13
English
Connecting with two Bluetooth phones
With the Multi-point feature activated, your headset can be connected to 2 Bluetooth
phones at the same time.
To turn Multi-point feature on
In Pairing mode, press and hold the
Volume up button. The blue indicator
light flashes twice and you will hear a
beep.
To turn Multi-point feature off
In Pairing mode, press and hold the
Volume down button. The red indicator
light flashes twice and you will hear
a beep.
After connecting with the first Bluetooth phone, enter Pairing mode again.1
Activate the Bluetooth feature on the second Bluetooth phone and search for the2
headset.
Select the headset (HM1300) from the list of devices found by the second3
Bluetooth phone.
If requested, enter the Bluetooth PIN 0000 (4 zeros) to connect the headset to the4
second Bluetooth phone.
Reconnect to the headset from the first Bluetooth phone.5
Some phones may not be able to connect as a second Bluetooth phone.

14
Reconnecting the headset
If the connection is lost while in use:
Press the Talk button on the headset or use the Bluetooth menu on your phone.•
When the headset is paired with a phone, it will attempt to automatically
reconnect each time you turn it on. If the Multi-point feature is activated, your
headset will attempt to reconnect to the two most recently connected devices.
This feature may not be supported on some devices.
Disconnecting the headset
Turn off the headset or use the Bluetooth menu on your phone.

15
English
Using call functions
Available call functions may differ from phone to phone.•
Some functions are only available when using the Hands-Free profile.•
Making a call
Redialing the latest number
To redial the last number dialed on the primary phone:
Press and hold the Talk button.•
To redial the last number dialed on the secondary phone:
Press the Talk button twice.•
Some phones open the call log list. Press the Talk button again to dial the
selected number.
Dialing a number by voice
Press the Talk button.
This function is only available on the primary phone.

16
Answering a call
Press the Talk button to answer a call when a call comes in.
Rejecting a call
Press and hold the Talk button to reject a call when a call comes in.
If you receive calls on both connected phones at the same time you can only
answer or reject the call on the primary phone.
Ending a call
Press the Talk button to end a call.
Options available during a call
You can use the following functions during a call.
Adjusting the volume
Press the Volume up or down button to adjust the volume.
You will hear a beep when the volume level of the headset reaches it’s lowest or
highest level.

17
English
Muting the microphone
Press and hold the Volume up or down button to turn the microphone off so that the
person with whom you are speaking cannot hear you. When the microphone is turned
off, the headset beeps at regular intervals. Press and hold the Volume up or down
button again to turn the microphone back on.
Transferring a call from the phone to the headset
Press the Talk button to transfer a call from the phone to the headset.
Placing a call on hold
Press and hold the Talk button to place the current call on hold.
When the headset is connected with two phones, this function is not available.
Answering a second call
Press the Talk button to end the first call and answer a second call.•
Press and hold the Talk button to place the first call on hold and answer a second•
call. To switch between the current call and the held call, press and hold the Talk
button.
When the headset is connected with two Bluetooth phones, you cannot answer
a second call from the same phone. It may vary depending on your phone.

18
Resetting the headset
When the headset is paired with a device, it automatically saves connection and
feature settings, such as the Bluetooth address or device type of the mobile phone.
If you want to reset the connection settings in the headset:
In Pairing mode, press and hold both Volume buttons and Talk button at the same•
time for 3 seconds. The headset will turn on automatically.
When you reset the headset, all connection settings in the headset will be
deleted and the connection with your phone will be lost. In order to use the
headset, you will have to pair it again.
