Samsung WISENET SCO-5081R User manual

SCO-5081R
User Manual
High Resolution Weatherproof IR Camera

High Resolution Weatherproof IR Camera
User Manual
Copyright
©2016 Hanwha Techwin Co., Ltd. All rights reserved.
Trademark
Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the
registered trademark of their respective company.
Restriction
Copyright of this document is reserved. Under no circumstances, this document shall be reproduced, distributed or changed,
partially or wholly, without formal authorization.
Disclaimer
Hanwha Techwin
makes the best to verify the integrity and correctness of the contents in this document, but no formal
guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.
Hanwha Techwin
reserves the right to change the contents of this document without prior notice.
Design and specications are subject to change without prior notice.

Before operating the camera, confirm the camera model and correct input power voltage. To
help you understand this manual thoroughly, we'll introduce our model description.
■ SCO-5081R SERIES
• NTSC MODEL • PAL MODEL
SCO-5081RN SCO-5081RP
■ MODEL DESCRIPTION
• SCO-5081RX
_
 •SIGNAL SYSTEM
N→NTSC MODEL
P→PAL MODEL
SIGNAL SYSTEM

4_ safety information
safety information
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates that dangerous voltage consisting a risk of electric
shock is present within this unit.
This exclamation point symbol is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING
• To prevent damage which may result in fire or electric shock hazard, do not expose this
appliance to rain or moisture.
• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with
the installation instructions.
WARNING
1. Be sure to use only the standard adapter that is specified in the specification sheet.
Using any other adapter could cause fire, electrical shock, or damage to the product.
2. Incorrectly connecting the power supply or replacing battery may cause explosion, fire,
electric shock, or damage to the product.
3. Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause
abnormal heat generation or fire.
4. Securely plug the power cord into the power receptacle. Insecure connection may cause
fire.
5. When installing the camera, fasten it securely and firmly. The fall of camera may cause
personal injury.

English_5
●safety information
6. Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers
filled with water on top of the camera. Doing so may cause personal injury due to fire, electric
shock, or falling objects.
7. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or electric
shock.
8. If any unusual smells or smoke come from the unit, stop using the product. In such case,
immediately disconnect the power source and contact the service center. Continued use in
such a condition may cause fire or electric shock.
9. If this product fails to operate normally, contact the nearest service center. Never
disassemble or modify this product in any way. (samsung is not liable for problems caused
by unauthorized modifications or attempted repair.)
10.
When cleaning, do not spray water directly onto parts of the product. Doing so may
cause fire or electric shock.
CAUTION
1. Do not drop objects on the product or apply strong shock to it. Keep away from a location
subject to excessive vibrationor magnetic interference.
2. Do not install in a location subject to high temperature (over 55°C), low temperature (below
-30°C), or high humidity. Doing so may cause fire or electric shock.
3. If you want to relocate the already installed product, be sure to turn off the power and then
move or reinstall it.
4. Remove the power plug from the outlet when then there is a lightning. Neglecting to do so
may cause fire or damage to the product.
5. Keep out of direct sunlight and heat radiation sources. It may cause fire.
6. Install it in a place with good ventilation.
7. Avoid aiming the camera directly towards extremely bright objects such as sun, as this may
damage the CMOS image sensor.
8. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
9. The Mains plug is used as a disconnect device and shall stay readily operable at any time.
10. Do not expose the camera to radioactivity. Radioactivity exposure may damage the
CMOS.

6_ safety information
safety information
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions :
1) This device may not cause harmful interference, and
2) This device must accept any interference received including interference that may cause
undesired operation.
CAUTION
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at
his own expense.
IC Compliance Notice
This Class A digital apparatus meets all requirements of the Canadian
Interference.-Causing Equipment Regulations of ICES-003.
Correct disposal of batteries in this product
(Applicable in the European Union and other European countries with separate battery return systems.)
This marking on the battery, manual or packaging indicates that the batteries in this product should not be
disposed of with other household waste at the end of their working life. Where marked, the chemical symbols
Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC
Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health
or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of waste
and recycle them through your local, free battery return system.
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories
(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal,
please separate these items from other types of waste and recycle them responsibly to promote the sustainable
reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

English_7
●safety information
important safety instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong is provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus.
13. Unplug this apparatus when a card is used. Use caution when
moving the cart/ apparatus combination to avoid injury from tip-
over.
14.Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as powersupply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15.This product is intended to be supplied by a Listed Power Supply Unit marked
"Class 2" and rated from 24 Vac (50/60Hz) min 0.8A or 12 Vac min 0.8A.
Apparatus shall not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on the apparatus.
Hanwha Techwin cares for the environment at all product manufacturing
stages to preserve the environment, and is taking a number of steps to
provide customers with more environment-friendly products.The Eco mark
represents Hanwha Techwin’s will to create environment-friendly products,
and indicates that the product satisfies the EU RoHS Directive.

8_ contents
contents
INTRODUCTION
9
9Features
10 Components and Accessories
11
Components names and Functions
13
Adjust the lens's zoom and focus
CONNECTION
14
14 Connecting to Monitor
14 Connecting to Power
15 Using Communications
CAMERA OPERATION
17
17 Menu Configuration
17 Menu Setup
TROUBLESHOOTING
33
33 Troubleshooting
SPECIFICATIONS
34
34 Specifications
36 Dimension

English_9
●introduction
introduction
FEATURES
yHigh Resolution
Use of a 1.3mega pixel CMOS device provides clear pictures with a horizontal resolution
of 1000TVL.
yExcellent Sensitivity
The built-in high sensitivity COLOR CMOS produces a clear image.
- Color : 0.05Lux (F1.4, 50IRE), 0.001Lux (1sec, F1.4, 50IRE)
0.02Lux (F1.4, 30IRE), 0.0006Lux (1sec, F1.4, 30IRE)
B/W : 0Lux (IR LED On)
yIntelligence
Without an external sensor, you can use this product to detect motion and generate
alarms and thus more efficient monitoring can be achieved.
ySSNR4 (Samsung Super Noise Reduction) Function
The high-performance W7 effectively removes low-light gain noise and afterimage to
provide clear images even in dark environments.
yDay&Night
This camera has a function that automatically selects the mode that is appropriate
for daytime or night-time conditions. The COLOR mode operates in daytime condi-
tions to provide optimum colors, and B/W mode operates in night-time conditions to
enhance the definition of the image.
ySSDR (Samsung Super Dynamic Range)
For images with high contrast between bright and dark areas from difficult lighting conditions
such as backlighting, this camera selectively illuminates darker areas while retaining the same
light level for brighter areas to even out the overall brightness.
yPROFILE
You can set a mode according to the camera installation conditions.
- BASIC, DAY/NIGHT, BACKLIGHT, ITS, INDOOR, USER
yDIS (Digital Image Stabilizer)
The DIS function compensates for any camera movement, to produce more stable
pictures.
yMiscellaneous Functions
HLC(High Light Compensation), REVERSE , D-ZOOM, SHARPNESS and PRIVACY
functions are provided.

10_ introduction
introduction
Communication
RS-485
, Coaxial communication methods are supported.
- Coaxial Communications : Pelco Coaxitron
RS-485: Samsung-T, Samsung-E, Pelco-D, Pelco-P, Panasonic, Bosch,Honeywell,
Vicon, AD, GE
OSD
The camera’s OSD is complimented by 17 languages.
- English, Chinese, Korean, Japanese, German, Italian, French, Spanish, Russian,
Czech, Polish, Romanian, Serbian, Swedish, Danish, Turkish, Portuguese
COMPONENTS AND ACCESSORIES
Check if the following items are included in the product package.
SCO-5081R Quick Manual Screws
Sunshield Template Wrench
Knob Sunshield
Video Output Cable
Cable Line
Mounting Template
SCO-5081R
UserManual
High Resolution Weatherproof IR Camera

English_11
●INTRODUCTION
➊ Camera Sunshield
2 Knob Sunshield : Fixing the sunshield onto the camera.
3 Focus lever : Set focus of lens by turn the focus lever.
4 Zoom lever : Set zoom magnification of lens by turn the zoom lever.
5 Front cover
➏ Function Setup Switch : Display the menu on the screen and move the cursor to four
directions to confirm status or after changing a selected item.
➐ Video Output Terminal to Monitor: Used for monitoring of video output When camera
installation.
M
`When you adjust to the ZOOM & FOCUS of the lens, Please remove the front cover from the
camera, by turning the cover counterclockwise.
`To adjust the zoom & focus loosen the individual levers before tightening them again.
`To ensure the weatherproof integrity is maintained, Before installation the front cover, it's necessary
to push tight first. and then turn it clockwise to locking indication.
COMPONENT NAMES AND FUNCTIONS
Front
➎
➊➋
▲
▲
➌
➍
➏➐

12_
introduction
Introduction
Back
❽ Function jack
G
REEN(485 –) : Signal port for RS-485-communication.
YELLOW(485+) : Signal port for RS-485+ communication.
BLUE (ALARM OUT) : Output port that signals when a motion is detected.
GRAY(EXT_D/N) : External signal input port for Day/Night mode setup.
BLACK(GND) : Earth-grounding port for external signal.
❾ Video output jack : Video signals are output through this port. Connect this port to the Video
IN port of a monitor.
❿ Power input terminal : Connect the power as specified for each model here.
➒
CAUTION:
Be ware of the
RatedVoltage a ndP olarity
ofthe power connection .
➑
❿

English_13
●Introduction
ADJUST THE LENS'S ZOOM AND FOCUS
1. Remove the sunshield from the camera.
2. Remove the front cover from the camera by turning it counterclockwise.
3. Unlock the Zoom or Focus lever before adjusting the lens.
4. Adjust the zoom & focus by moving the lever counterclockwise for (NEAR &
WIDE )
and clockwise for (TELE & FAR) position.
5. After adjustment, tighten the zoom or focus levers, taking care not to adjust the
zoom/focus position.
6. Please, close and tighten the front cover.
7. Replace the sunshield.
M
`If the front cover is cross threaded or not correctly tightened the camera housing will not be
weatherproof.
WIDE↔TELE
FAR↔NEAR
FRONT COVER
ZOOM LEVER
FOCUS LEVER

14_ connection
connection
CONNECTING TO MONITOR
Please connect the Video output jack located on the back of the camera to the monitor.
yAs the connecting method varies with the instruments, refer to the manual supplied
with the instrument.
yOnly connect the cable when the power is turned off.
CONNECTING TO POWER
You can connect power as shown in the following figure.
Camera Monitor
POWER

English_15
●connection
When the resistance value of copper wire is at [20°C(68°F)]
Copper wire size (AWG) #24 (0.22mm2)#22 (0.33mm2)#20 (0.52mm2)#18 (0.83mm2)
Resistance value(Ω/m) 0.078 0.050 0.030 0.018
Voltage Drop (V/m) 0.028 0.018 0.011 0.006
yAs shown in the table above, voltage decreases as the wire gets longer.
Therefore use of an excessively long adaptor output line for connection to the camera
may affect the performance of the camera.
Standard voltage for camera operation : DC 12V±10%, AC 24V±10%
There may be some deviation in voltage drop depending on the type of wire and the
manufacturer.
M
`Be sure to connect power only after all the installation is complete.
USING COMMUNICATIONS
yCoaxial Communications System
yOSD Control method
CAMERA DVR CONTROLLER
SET MENU/ENTER OSD KEY
UP UP KEY JOYSTICK UP
DOWN DOWN KEY JOYSTICK DOWN
LEFT LEFT KEY JOYSTICK LEFT
RIGHT RIGHT KEY JOYSTICK RIGHT
1234
5678
9101112
13 14 15 16
ALARMHDDNETWORKBACKUP REC
DVDRECORDER
REC
ZOOM
MODE
FREEZE
AUDIO
BACKUP
ALRAM
SEARCH
TELE WIDE VIEW PRESET
MENU
RETURN
USB
OPEN/CLOSE
MENU
SEARCH
MUL
TI
REC
MENU
PRESET
GROUP
TRACK
CAM
12345
67890
MON
CLOSEOPEN
NEAR FAR
WIDE TELE
PTZ DVRMTX SETUP
ESC
FUNCENTER
DVR
•: BNC
•---- : RS-485

connection
16_ connection
Distance
Recommended Cable
Specification
300m 3C2V(RG-59/U)
450m 5C2V(RG-6/U)
600m 7C2V(RG-11/U)
MM`It is recommended that pure copper coax cable is used and not copper coated steel, as this will
cause issues with the communication over the coaxial cable.
`To ensure picture quality, only single-channel video output connector can be used while camera
connected to other video equipments.
- Video Cable
The camera's video output port is connected to the monitor with a BNC coaxial
cable, shown below.If the distance between the camera and the monitor
exceeds the recommended maximum, please use an auxiliary video amp.
yRS-485 communications
Using RS-485 communication, the camera menu can be accessed using Samsung
Techwin’s System Controller or the DVR.
• for accessing the camera from a computer
Use a RS-485 converter to connect the camera’s control port with the computer’s
serial cable.
Ex) Serial port (COM1) of computer Serial Cable RS-485 Converter Camera’s
RS-485 control port.
• for accessing the camera from a Dvr or the System controller
connect the camera’s RS-485+ and RS-485– terminals to the RS-485 control
board’s terminals of desired device with a RS-485 cable.
Control ports of RS-485 Controller RS-485 ports of the camera
(+) CONNECTION TERMINAL 485+
(–) CONNECTION TERMINAL 485–
Default RS-485 communication settings
Item CAM ID BAUD RATE UART MODE RET PKT
Default
19600 8-N-1 ENABLE

English_17
●Camera OperatiOn
MENU CONFIGURATION
MAIN SETUP
PROFILE
● BASIC ● DAY/NIGHT ● BACKLIGHT
● ITS ● INDOOR ●USER
SSDR
● ON ●OFF
WHITE BAL
● ATW ● OUTDOOR ● INDOOR
● MANUAL ● AWC  SET
● MERCURY
EXPOSURE
● BRIGHTNESS ● LENS ● SHUTTER
● AGC ● SSNR4 ● RETURN
BACKLIGHT
●OFF ● USER BLC ● HLC
SPECIAL
● DISPLAY ● COMM ADJ ● IMAGE ADJ
● DAY/NIGHT ● DEFOG ● PRIVACY
● DIS ● VIDEO ANALYTICS ● RETURN
EXIT
● SAVE ● NOT SAVE ● RESET
MENU SETUP
For function setting, you can use the function setting switch inside the dome cover.
camera operation
Function Setup switch

18_ camera operation
camera operation
1. Press the Function Setup switch.
yMain SETUP menu is displayed on the monitor screen.
2. Select a desired function using the Function Setup switch.
yPlace the cursor over a desired item.
3. Set up a selected item by using the Function Setup switch.
4. To finish the setting, select ‘EXIT’ and press the Function Setup switch.
M
`An item with the icon also has sub menus. To select a sub menu, select an item with the
icon and press the Function Setup switch.
`An item with the --- icon is unavailable due to function settings.
PROFILE
1. When the SETUP menu screen is displayed, select ‘PROFILE’ by using the Function
Setup switch so that the arrow indicates ‘PROFILE’.
2. Select a desired mode using the
Function Setup switch according to
the picture display you want.
yBASIC : The most common envi-
ronment is set to meet.
yDAY/NIGHT : It will be set
automatically so it
optimizes to the day
or night conditions,
respectively.
yBACKLIGHT : It will be set automatically so you can distinguish the object from
the background in a severe backlighting scene.
yITS : It will be set automatically so you can easily check the traffic conditions.
MAIN SETUP
1. PROFILE BASIC
2. SSDR ON
3. WHITE BAL ATW
4. EXPOSURE
5. BACKLIGHT OFF
6. SPECIAL
7. EXIT SAVE
Change the status
using the Function
Setup switch.
Select the function
using the Function
Setup switch.
MAIN SETUP
1. PROFILE BASIC
2. SSDR ON
3. WHITE BAL ATW
4. EXPOSURE
5. BACKLIGHT OFF
6. SPECIAL
7. EXIT SAVE

English_19
●CAMERA OPERATION
yINDOOR : It will be set automatically to help you take a picture in a regular indoor
lighting condition.
yUSER : Automatically configures the camera to your custom settings.
1) Select USER for Simple Setup mode.
2) Configure the menu options to your USER settings.
3) The settings are automatically saved as USER mode.
4) Profile user mode don't initialize when menu resets.
3. In the PROFILE menu, you can confi gure the following camera settings at once.
BASIC DAY/NIGHT BACKLIGHT ITS INDOOR USER
SHUTTER 1/5~1/12000 1/5~1/12000 1/5~1/12000 1/200~1/12000 A.FLK -
AGC HIGH HIGH HIGH HIGH HIGH -
WHITE BAL ATW ATW ATW OUTDOOR INDOOR -
BACKLIGHT OFF OFF USER BLC OFF OFF -
SSNR4
ON ON ON ON ON -
DAY/NIGHT AUTO AUTO AUTO AUTO AUTO -
M
`If you select the ITS, the shutter will be set to 1/200 sec. Noise can be detected at
night.
SSDR (Samsung Super Dynamic Range)
If an object has a large variance between bright and dark areas, it will keep bright areas
bright and make selected dark areas bright, so that the overall brightness can be maintained.
1. When the SETUP menu screen is displayed, select ‘SSDR’ by using the Function
Setup switch so that the arrow indicates ‘SSDR’.
2. Use the Function Setup switch to
change the SSDR level in the sub menu
according to the contrast between bright
and dark areas.
SSDR SETUP

1. LEVEL
---

-----
12
Press Set To Return
SSDR OFF
SSDR ON

20_ camera operation
camera operation
White Bal (White Balance)
Use the White Balance function to adjust the screen color.
1. When the SETUP menu screen is
displayed, select ‘White Bal’ by
using the Function Setup switch so
that the arrow indicates ‘White Bal’ .
2. Select a desired mode using the
Function Setup switch.
 Select one of the following 6 modes, as appropriate for your purpose.
yATW : Select this when the color temperature is between 1,800K° and 10,500K°.
yOUTDOOR : Use it in a color temperature range of 1,800K° to 10,500K°.(including
Natrium). Auto adjustment is made to optimize the camera color to
the outdoor environment.
y
INDOOR : Select this when the color temperature is between 4,500K° and 8,500K°.
Automatically adjusts the camera color for optimization to the indoor
environment.
yMANUAL :
Select this to fine-tune White
Balance manually. Set White
Balance first by using the
ATW or AWC mode. After that
button to MANUAL mode,
fine-tune the White Balance
and the Function Setup switch.
yAWC
→
SET : To find the optimal luminance level for the current environment, point the cam-
era towards a sheet of white paper and press the Function Setup switch. If the
environment changes, readjust it.
yMercury : This is an auto compensation function that optimizes camera colors
for the environments such as mercury lamps.
M
`White Balance may not work properly under the following conditions. In this case select the
AWC mode.
➊ Select this When the color temperature of environment surrounding the subject is out of
the control range (e.g. clear sky, or sunset)
2 When the ambient illumination of the subject is dim.
`If the camera is directed towards a fluorescent light or is installed in a place where
illumination changes dramatically, the White Balance operation may become unstable.
WB MANUAL
1. RED GAIN --

------ 485
2. BLUE GAIN --

------ 535
3. RETURN
MAIN SETUP
1.
PROFILE BASIC
2. SSDR ON
 3. WHITE BAL ATW
