Samsung Wingo MY-MP200 User manual

ELECTR
MP3 PLAYER
MY-MP200
Instruction Manual

2
MP3 PLAYER
CLASS 1 LASER PRODUCT
This Compact Disc player is classified as a
CLASS 1 LASER product.
Use of controls, adjustments or performance
of procedures other than those specified here-
in may result in hazardous radiation exposure.
CAUTION-Invisible laser radiation
when open and interlocks
defeated, avoid exposure to
beam.
This symbol indicates that dangerous voltage which can cause electric
shock is present inside this unit.
This symbol alerts you to important operating and maintenance instruc-
tions accompanying the unit.
WARNING: To reduce the risk of fire or electric shock, do not expose this appli-
ance to rain or moisture.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully
insert.
Attention: FCC Regulations state that unauthorized changes or modifications to
this equipment may void the user’s authority to operate it.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LASER CLASE 1
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE REAR COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
Safety Warnings
SAFETY WARNINGS

3
MP3 PLAYER
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful inter-
ference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio
communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be deter-mined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables and I/O cords must be used for this equipment to com-
ply with the
relevant FCC regulations.
Changes or modifications not expressly approved in writing by Samsung may
void the user’s authority to operate this equipment.
Safety Warnings
FCC COMPLIANCE

4
MP3 PLAYER
Table of Contents
Accessories Supplied
◆Safety Warnings ................................................................................................. 2
◆Accessories Supplied ........................................................................................ 4
◆Location of controls........................................................................................... 5
◆Getting Started................................................................................................... 6
◆MP3 Player
•Connecting to PC.............................................................................................. 7
•Installing the MP3 programs on your PC..................................................... 8
•Using MP3 program......................................................................................... 9
•MP3 playback.................................................................................................. 11
•Special features ............................................................................................... 12
◆Recommendations for Use
•Troubleshooting Guide.................................................................................. 14
•Specifications................................................................................................... 14
•Warranty Card ................................................................................................ 15
NoteImportantPushPress
Symbols
Owner's Manual
(Including Warranty) CD-ROM DISC Parallel Cable
Earphone Smart Card Recording Protect Sticker

5
MP3 PLAYER
Repeat Button
Volume Increase Button
Volume Decrease Button
SmartMedia Card Slot
Hold Switch
SmartMedia Card Eject Switch
DISPLAY
UNIT
Volume Decrease Button
Headphone Terminal
Skip/Search( )
Data I/O Connector
Repeat
Recording
MP3
Channel
Volume Increase Button
Play/Stop Button
Skip/Search( )
S. bass Button
Total File
Delete Files
S. bass
Display Digits
Battery
Location of controls

6
MP3 PLAYER
Getting Started
1
Insert a SmartMedia Card into the Unit
2
Downloading MP3 files.
• Refer to pages 7~13.
3
To remove the SmartMedia Card.
• Push the SmartMedia Eject Switch.
Setting the SmartMedia Card
SmartMedia Card Erase Protection Feature
SmartMedia Card Eject Switch
(Front) (Back)
(Recording protect sticker)
• To prevent an MP3 file from being erased, attach the memory erasing protection
sticker to the memory protection tab.
• Be sure to protect SmartMedia Card from magnet, humidity, shock, etc.
• Be sure to power off before inserting or removing the SmartMedia Card. Otherwise, the MP3
files stored in the player may be damaged.
• Only 16MB and 32MB SmartMedia Cards can be used with this product.
☛

7
MP3 PLAYER
Connecting to a PC
• To download an MP3 file to your MP3 Player, the parallel port should be available
on your computer.
• If a printer is connected to the parallel port of your PC, disconnect it temporarily to
connect your MP3 Player.
• If your PC does not have a parallel port, inquire with the dealers where you
purchased your PC and have a parallel port installed.
• For best results, your system requirements should be as follows:
Taking the steps shown below will prepare your Wingo for downloading MP3 files.
PARALLEL PARALLEL PORT
• Connect the MP3 Player to a PC using a parallel cable.
MP3 Player
PC
- Pentium 120MHz or higher
- Windows 95/98
- At least 20MB Hard Disk space
- Parallel Port supporting ECP
- CD-ROM Drive
- 32MB RAM or higher
PARALLEL DATA I/O
CONNECTOR

8
MP3 PLAYER
Installing the MP3 programs on your PC
In order to download MP3 files to the MP3 Player, you must install programs contained
on the CD-ROM supplied for your PC.
• This program may not be installed correctly if MS EXPLORER version 4.01 or higher has
not been installed on your PC.
• The computer should be set while booting as shown below.
1) Turn on the computer.
2) While testing the RAM, press the F2 or Del key to enter the Setup screen.
3) Move to the Peripheral setting screen to set the Printer port.
4) Set the Printer port to the ECP mode.
5) Save the setting and reboot the computer.
Check the “Environment ➔options” menu of unit, set to the ECP mode by check.
• Refer to page 9.
1
Load the supplied software CD into the CD-ROM
drive of your PC and click on the "NEXT" Button.
• The MP3 Player setup program will start automatically.
• If the setup does not start automatically, find the
"setup.exe" file using the File Finder, then double click
on it to execute the program.
•
To install in another directory, use the Browse Button to select.
2
Check the program path icon and then
press the "NEXT" Button.
• An icon will be created automatically.
3
After installation procedures are completed,
click the "Finish" Button to exit the setup
program.

9
MP3 PLAYER
Using MP3 program
To copy files from PC to the Flash Memory of MP3 Player
To copy files from MP3 Player to PC
To delete all the data on the Flash Memory of MP3 Player
To stop all the current jobs
To restore the updated data on PC or MP3 Player
To adjust the screen font of the program
To select options to show files in the File Window
To move to
Option screen
* Communication: When error occurs, to set "Standby Time" (Unit: millisecond (1 sec. = 1000 millisecond)
When erasing all the data on MP3 Player
Standby time at initial
connection
To delete the
selected file
To finish all jobs
and exit the program
When reading data by PC
When writing on MP3 Player
When deleting files
Not used
Not used
Check these when the
computer supports
ECP mode
To backup files
To update files
To read file information
Not used
Not used
Not used
• When the MP3 Player is off and the connection cable is disconnected while using this program,
an error may occur. If this happens, turn off the MP3 Player and turn it on again, make the correct
connection, and run this program again.
• If you stop this program during the downloading or uploading of a file, an error will occur.
Select "REFRESH" menu to initialize the program, and reconnect the communication.
Data transmission progress window
File Window
Press the right
button of the mouse,
then the menu
window will open.
To show the progress of file
copying
To show the files stored in the
MP3 Player
To select options to see files in the File Window
To stop the current job
To copy files from PC to MP3 Player
To delete selected file
To copy files from MP3 Player to PC

10
MP3 PLAYER
Using MP3 program
2
3
4
Double click on “MP3 Player Explorer icon” to execute the program.
Then choose "External Memory" command from "Copy to" command.
Alternately, press the Button on the screen.
From the PC window, choose the "File" menu either by clicking
the left button of the Mouse or by using (ins) key.
Press the OPEN button on the screen.
From the MP3 Player window, choose the "File" menu either
by clicking the left button of the Mouse or by using (Ins) key.
Then choose "Flash Memory" command from "Copy to"
command. Alternately, press the Button on the screen.
From the PC window, choose the “Directory”, Press the
“SAVE” Button.
From the MP3 Player window, choose the "File" menu either by
clicking the left button of the Mouse or by using (ins) key.
Then choose the "Delete" command from the File menu.
Alternately, press the Button on the screen.
2
3
2
1
1
1
Choose the "File" menu. Then choose the "Format"
command from the "File" menu to delete all the files.
• Your unit (MP3 Player) can download up to 32 Mbytes. Hence, depending on the size of
MP3 file, the number of files to be downloaded may be limited.
• The number on the Total Space of the Data transmission progress window indicates the
remaining space for download.
Transferring files from PC to MP3 Player
Transferring files from MP3 Player to PC
Deleting files
Deleting all files in the MP3 Player
