Samsung YP-20T - YEPP Digital Player User manual

MP3 music file playback
Real time clock
4-mode equalizer
32MB Built-In Flash memory
Data transfer with USB
YP-20T
˙¥` ‚‚ (¿)-„`˙ 01.3.2010:58PM˘`2

What is MP3?
CD-quality sound.
MP3 refers to MPEG1 LAYER3. MP3 is a music file made of audio data from
compression technology with no degradation of the original sound.
“yepp’” is an advanced digital audio player which doesn’t need
a cassette tape or CD. You can download MP3 files
from the Internet or PC Communications and enjoy great sound
any time, any place.
FFeeaattuurreess
What is yepp’?
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`1

2
PREPARING FOR USE
LISENING TO THE SAMPLE MUSIC
SOFTWARE INSTALLATION AND OPERATION
CONTENTS Digital Sound-
Checking Parts..........................................................................................................4
Parts Description......................................................................................................5
Listening to music through yepp’
TM
........................................................................7
Searching the MP3 files at a faster speed..............................................................9
Changing the Time/Date.........................................................................................11
Setting the Mode.....................................................................................................13
Using the Equalizer................................................................................................15
Hold Function..........................................................................................................16
Connecting yepp’
TM
to PC.......................................................................................19
Installing software on PC.......................................................................................21
Installing USB Driver..............................................................................................23
Installing software on Mac.....................................................................................25
Formatting flash memory (PC)..............................................................................27
Listening to music on your PC..............................................................................28
Sending files to yepp’
TM
PC.....................................................................................31
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`2

3
CREATING AND DELETING MP3 FILES
Making MP3 files from an audio CD......................................................................33
Deleting files...........................................................................................................35
Formatting flash memory (Mac)............................................................................36
Sending files to yepp’
TM
(Mac)................................................................................37
Deleting files...........................................................................................................39
Safety Precautions.................................................................................................40
Troubleshooting.....................................................................................................41
Security....................................................................................................................42
Technical Specifications........................................................................................43
Safety Information..................................................................................................44
Warranty..................................................................................................................46
OTHERS
CONTENTS Digital Sound-
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`3

4
Player Software
Installation CD AAA alkaline
battery(1.5V)
User's Guide
User’s
Guide
Checking Parts Digital Sound-
yepp HolderEarphone PC connecting
USB port cable
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`4

5
Reverse button
(Volume Down)
LCD
Mode button
Play / Pause / Stop
button
Forward button
(Volume up)
Front Panel
Parts Description
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`5

6
2Insert the battery; paying
attention to the orientation of
the and ends of the
battery. Replace the battery
door.
1Remove the battery door
pushing on the thumb
recess in the direction of
the arrow.
Rear Panel Battery Installation
Earphone jack
Battery Cover
Lock
USB port
Battery Case
Digital Sound-
Main System
Main System
SAMSUNG
DIGITAL AUDIO PLAYER
YP-20T
SAMSUNG
DIGITAL AUDIO PLAYER
YP-20T
SAMSUNG
DIGITAL AUDIO PLAYER
YP-20T
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`6

7
SAMSUNG yepp
Insert the battery.
• Press the button once more while the
music that you selected is played back.
Then, appears on the display panel, and
the sound is paused for a moment.
Press the button again to resume playback.
Your yepp’ contains a few sample MP3 files. Insert the Battery in the Battery compartment,
and then connect the earphone correctly.
Turn on the Power
01
WHEN I DREAM.MP3
1
2
1
Press the button on
the front panel.
Playback
Listening to music through
TM
Press the button
to start playback.
12/30 12:00P
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`7

8
12
Press the button.
Control volume with the volume
control button / .
Press the Stop button to stop
playback.
01
20
0:20
01
Volume can be controlled from 0 to 20.
Press to move up or down by 1 step.
Press and hold to move continuously.
Control Volume Stop Music
WHEN I DREAM.MP3
01
0:20
01
Digital Sound-
Stop mode will automatically revert to clock
mode ifno buttons are pressed for
1 minute.
Basic Function
Basic Function
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`8

9
Press the and buttons to move to the next track.
Searching the MP3 files at a faster speed
Reverse button Foward button
1
To search within a song being
played back:
0:20
01
0:59
01
Press and hold the button while a song is being played
back to fast forward. Release the button to resume playback.
Press and hold the button while a song is played back to
move quickly backward.
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`9

10
2
To skip to the next song while a
song is being played:
0:50
01
Sky- .MP3
02
Press the button to move one track forward.
If the button is pressed before the first five seconds of the track has played, the previous
song will be played back. If the button is pressed after five seconds has played,
the current song will be played back.
3
To search a song in stop mode:
WHEN I DREAM.MP3
01
Sky- .MP3
02
Press thebutton to move one track forward.
To play back the song that you had chosen, press the
Play button ( ).
Press the button to move one track backward.
Digital Sound-
Basic Function
Basic Function
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`10

11
Changing the Time/Date
To check the Time/Date
• The battery will last approximately 30 days if the unit is left in clock mode.
12/30 12:00P
WHEN I DREAM.MP3
01
1
2
3
4
The time appears when the battery is
installed.
If no buttons are pressed when in the
MP3 Mode for one minute, the system
reverts to Clock Mode.
If the button is pressed
in the MP3 Mode, the system reverts
to Clock Mode.
Press the ( / ) buttons in
the clock Mode. The Date appears for
a short time.
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`11

12
• When selecting DATE - The year blinks first. Adjust using the / buttons, then use the button
to set the year.
• When selecting TIME - The AM/PM selection blinks first. Adjust by using the / buttons, then use
the button to set the time.
To Change Date/Time
Digital Sound-
1
2
Press and hold the ( ) button long in the clock Mode, The mode will be
changed to the [1] Date, [2] Time Set up mode.
First, the [1] Date will be shown.
Using the ( / ) buttons, move to
Set up ( ) mode.
Basic Function
Basic Function
12/30 12:00P
[1] Date
2000/12 /30
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`12

Each time the button is pressed and held in the MP3 mode, the
modes will be changed in the order of [1] Repeat ➔ [2] EQ ➔ [3] Hold
➔ [4] Erase
Repeat mode: Repeats current track.
EQ mode : To use the Equalizer.
Hold mode : No buttons on the yepp work.
Erase mode : Erase the file. (You can only erase files in the Stop mode.)
1
13
[1] Repeat
01
[2] EQ
01
[3] Hold
01
[4] Erase
01
Setting the Mode
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`13

14
Digital Sound-
•REPEAT Mode : Repeats current track.
•REPEAT All Mode : Repeats all the tracks.
•SHUFFLE Mode: Enables random playback.
•INTRO Mode: Enables you to repeat the first 10 seconds of the tracks saved.
•NORMAL Mode: Normal playback.
Press and hold the button in the MP3 Mode to change to set-up mode.
Press the / button to enter [1] REPEAT mode, then press the button.
Press the / button to choose between REPEAT → REPEAT ALL →
SHUFFLE →INTRO → NORMAL modes, then save it with the button.
Repeat Mode
REPEAT
REP
REPEAT ALL SHUFFLE
SHU
INT
INTRO
01 01 01 01 01
A
L
L
NORMAL
REP
1
2
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`14

15
Each time the button is pressed, the modes will be changed in the order of Jazz,
Classic, Rock and Normal.
Press the / button to choose EQ mode then press button.
Press the / button to cycle through NORMAL → CLASSIC → JAZZ → ROCK modes, then save
with the button.
NORMAL →CLASSIC →JAZZ →ROCK
1
2
Using the Equalizer
JAZZ
CLASSIC
NORMAL
ROCK
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`15

16
Press and hold the button in the MP3 mode. Press the /buttons to enter [3]
Hold mode, then press button.
When “HOLD ON?”appears on the display, press button.
1
2
[3] HOLD HOLD ON? 1:22
Hold Function
Digital Sound-
Buttons will be inoperable. Each time a button is pressed, Hold will appear and
then be cleared from the panel.
Press and hold the button to cancel “HOLD”.
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`16

17
[4] ERASE ERASE? ERASING..... ERASED
Erase Mode
Select a track to be erased.
1
Press and hold the button in the MP3 Mode to change to setup mode.
Press the / button to select Erase, then press the button.
The message “ERASE?”will appear, then press the button.
2
• After erasing a track, the next track will be shown on the display.
• Erasing is not possible in the play mode.
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`17

When the Time mode comes
on, it means your yepp is turned
Off. Your yepp battery can last
for about 30 days in Time mode
without button operation. Please
take the battery out when the
player will not be used for
awhile.
Turning off the power.
Digital Sound-
18
Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`18

Connect the USB cable to the USB port of the computer.
1
Turn the player on and connect the other end of the
cable to the download connector.
2
19
Connecting
TM
to your PC or Mac
Minimum PC System
Requirements.
Pentium 133 MHz
Windows 98/ME/2000
20MB Free Hard Disk Space
CD-ROM Drive
(Optimum:8 X and more)
Built-in USB Port
Mac OS 8.6~9.0.4
Be sure to install the yepp’
TM
Audio Manager for the PC and
Yepp Explorer for the Mac before connecting your yepp’
TM
to
your PC or Mac. When the message “Add new hardware
wizard” appears on the screen, click [Cancel] and then
install the yepp Audio Manager.
If the USB driver is not installed automatically, refer to page
23 (PC only).
