Samsung The Freestyle User manual

Thank you for purchasing this Samsung product.
To receive more complete service, please registeryour product at www.samsung.com
Model Serial No.
USER MANUAL

Before Reading This User
Manual
This Projector comes with this User Manual and an
embedded e-Manual ( > Menu > Settings >
Support > Open e-Manual).
Warning! Important Safety
Instructions
Please read the Safety Instructions before usingyour
Projector. Referto the table below foran explanation
of symbols which may be on your Samsung product.
This symbol indicates that this
product has included important
literature concerning operation and
maintenance.
Class II product: This symbol indicates
that a safety connection to electrical
earth (ground) is not required. If this
symbol is not present on a product
with a mains lead, the product
MUST have a reliable connection to
protective earth (ground).
AC voltage: Rated voltage marked
with this symbol is AC voltage.
DC voltage: Rated voltage marked
with this symbol is DC voltage.
Caution. Consult instructions for use:
This symbol instructs the userto
consult the user manual for further
safety related information.
Contain with module complies with class1 LASER
product.
Power
•Do not overloadwall outlets, extension cords, or
adaptors beyond theirvoltage and capacity. It may
cause fire orelectric shock. Refer to the power
specifications section of the manual and/orthe
powersupply label on the product forvoltage and
amperage information.
•Power-supply cords should be placed so that
they are not likely to be walked on or pinched by
items placed upon oragainst them. Pay particular
attention to cords at the plug end, at wall
outlets, and at the point where they exit from the
appliance.
•Neverinsert anything metallic into the open parts
of this apparatus. This may cause electric shock.
•To avoid electric shock, nevertouch the inside of
this apparatus. Onlya qualified technician should
open this apparatus.
English
English - 2

•Be sure to plug in the power cable until it is firmly
seated. When unplugging the powercable from a
wall outlet, always pull on the power cable's plug.
Neverunplug it by pulling on the power cable. Do
not touch the power cable with wet hands.
•If this apparatus does not operate normally - in
particular, if there are anyunusual sounds or smells
coming from it - unplug it immediately and contact
an authorised dealer or Samsung service centre.
•To protect this apparatus from a lightning storm,
or to leave it unattended and unused for a long
time, be sure to unplug it from the wall outlet and
disconnect the antenna orcable system.
– Accumulated dust can cause an electric shock,
an electric leakage, ora fire by causing the
powercable to generate sparks and heat or by
causing the insulation to deteriorate.
•Use only a properly grounded plug and wall outlet.
– An improperground may cause electric shock
or equipment damage. (Class l Equipment only.)
•To turn off this apparatus completely, disconnect it
from the wall outlet. To ensure you can unplug this
apparatus quickly if necessary, make sure that the
wall outlet and powerplug are readily accessible.
Installation
•Do not place this apparatus near or over a radiator
or heat register, orwhere it is exposed to direct
sunlight.
•Do not place vessels (vases etc.) containing water
on this apparatus, as this can result in a fire or
electric shock.
•Do not expose this apparatus to water (rain) or
moisture.
•Do not install your Projector in a location with
heavy dust, chemical substances, too high orlow
temperature or high humidity, an automotive or
othervehicle used fortransportation, or a location
where the Projectorwill operate continuouslyfor
an extended period of time, such as an airport or
train station. If installed in such locations, a serious
quality problem may occur due to the surrounding
environment.
•Do not expose this apparatus to dripping or
splashing.
•Do not expose this apparatus to oil oroil mist.
•Do not use oils or lubricants. This may cause this
apparatus to crack.
English - 3

•CAUTION: There is dangerof an explosion if you
replace the batteries used in the remotewith the
wrong type of battery. Replace onlywith the same
or equivalent type.
•WARNING - TO PREVENT THE SPREAD
OF FIRE, KEEP CANDLES AND OTHER
ITEMS WITH OPEN FLAMES AWAY
FROM THIS PRODUCTATALL TIMES.
•Do not drop orstrike the product. If the product is
damaged, disconnect the powercable and contact
a Samsung service centre.
Caring forthe Projector
•To clean this apparatus, unplug the power cable
from the wall outlet and wipe the product with
a soft, dry cloth. Do not use any chemicals such
as wax, benzene, alcohol, thinners, insecticide,
aerial fresheners, lubricants, or detergents. These
chemicals can damage the appearance of the
Projector orerase the printing on the product.
•The exteriorof the Projector can get scratched
during cleaning. Be sure to wipe the exterior
carefully using a soft cloth to prevent scratches.
•Do not spray water or any liquid directly onto the
Projector. Any liquid that goes into the product may
cause a failure, fire, orelectric shock.
Providing proper ventilation for your Projector
When you install your Projector, maintain a distance of
at least10 cm between the Projector and other objects
(walls, cabinet sides, etc.) to ensure properventilation.
Failing to maintain properventilation may result in
a fire ora problem with the product caused by an
increase in its internal temperature.
Operation
•Move the product by holding the body. Do not hold
the Lens Cap.
•This apparatus uses batteries. In your community,
there might be environmental regulations that
requireyou to dispose of these batteries properly.
Please contact your local authorities for disposal or
recycling information.
•Store the accessories (remote control, oretc.) in a
location safely out of the reach of children.
•When you need to turn off the Projector
completely,wait until the fan stops completely so
that the Projector can cool down completely.
•Do not dispose of remote control orbatteries in
a fire.
•Do not short-circuit, disassemble, or overheat the
batteries.
English - 4

01 Product Overview
•To supply powervia an external battery, ensure
that the battery supports PD (PowerDelivery) and
its single port has output of 50 Wor more.
•Please be advised that the pogo pin on the
bottom of the Projector is a feature only intended
forcertain socket adapterfeatures that are not
available/supported in your country. Please do not
attempt to use orconnect the pogo pin with any
other accessories.
1Touch Keys
(Power)
(Volume)
(Mobile)
Directlyconnect to the SmartThings app on
your mobile device.
2Distance sensor
3Lens
4Remote control sensor / LED Indicator
5Ventilation
6MIC On/Off switch
7Micro HDMI Port
8USB Port (ForPower)
9Cradle
0Speaker
•The product colourand shape mayvary depending
on the model.
•Do not block Projector intake and exhaust vents.
•When operating the Projector in an enclosed space,
allow at least 50 cm clearance around the intake
and exhaust vents.
•When the Projector is not used, cover it with the
Lens Cap to protect the lens and distance sensor.
If the distance sensoris contaminated by dust, the
Focus or Keystone function may not work properly.
Setting the MIC On/Off
You can turn the MIC on oroff by
using the MIC switch on the side
of the Projector.
•During analysis using data
from the MIC, the data is not
saved.
MIC
English - 5

(Power)
Press to turn the Projector on or off.
1MIC / LED
Used as MIC when using voice recognition with the
remote control.
When charging the remote controlvia the USB
port, the LED is lit if charging is in progress. When
charging is complete, the LED is turned off.
•Do not impact the MIC hole oruse a sharp
object to poke into the hole.
(Voice Assistant)
Runs Voice Assistant. Press and hold the button,
say a command, and then release the button to run
Voice Assistant.
•The supported Voice Assistant's languages and
features may differby geographical region.
2Directional button (up, down, left, right)
Moves the focus and changes the values seen on
the Projector's menu.
3Select
Selects orruns a focused item.
(Return)
Press to return to the previous menu.
(Smart Hub) + (Control PAD)
Press to switch to the Media Home. From the
Ambient screen, press to switch to the Ambient
Home.
•When pressed for1 second or more, the Control
PAD appears. You can use Settings menu /
virtual numeric pad / Option pad with Colour
buttons by using Control PAD.
02 The Samsung Smart Remote
5
2
3
4
1
English - 6

– It is recommended to use an original Samsung
charger. Otherwise, it may cause performance
degradation orfailure of the product. In this case,
the warranty service is not applicable.
– When the remote control does not work due to low
battery, charge it by using the USB-C type port.
Fire orexplosion mayoccur, resulting in
damage to the remote control or personal
injury.
•Do not apply shock to the remote
control.
•Be careful not to let foreign substances
such as metal, liquid, or dust come in
contact with the charging terminal of
the remote control.
•When the remote control is damaged
oryou smell smoke orburning fumes,
immediately stop operation and then
repairit at the Samsung service centre.
•Do not arbitrarily disassemble the
remote control.
•Be careful not to let infants orpets
suck or bite the remote control. Fire
or explosion may occur, resulting
in damage to the remote control or
personal injury.
(Play/pause)
Using these controls, you can control the media
content that is playing.
(Volume)
Move the button up or down to adjust the volume.
To mute the sound, press the button. When pressed
for1 second or more, the Accessibility Shortcuts
menu appears.
(Channel)
Move the button up or down to change the
channel. To see the Guide screen, press the button.
•When pressed for1 second or more, the Channel
List screen appears.
4Launch app button
Launch the app indicated bythe button.
•App availability may vary by country or contents
provider.
+ (Pairing)
If the Samsung Smart Remote does not pair to the
Projector automatically, point it at the front of the
Projector, and then press and hold the and
buttons simultaneouslyfor 3 seconds or more.
5USB port (C-type) forcharging
Used forquick charging. The LED on the front will
light when charging. When the battery is fully
charged, the LED will turn off.
•The USB Cable is not provided.
– Use the Samsung Smart Remote less than 6 m
from the Projector. The usable distance mayvary
with the wireless environmental conditions.
– The images, buttons, and functions of the Samsung
Smart Remote may differwith the model or
geographical area. English - 7

03 Initial Setup
When you turn on your Projector forthe first time,
it immediately starts the Initial Setup. Followthe
instructions displayed on the screen and configure
the Projector's basic settings to suit yourviewing
environment.
04 Troubleshooting and
Maintenance
Troubleshooting
Formore information, see "Troubleshooting" in the
e-Manual.
> Menu > Settings > Support > Open e-Manual
> Troubleshooting
If none of the troubleshooting tips apply, please visit
"www.samsung.com" and click Support orcontact the
Samsung service centre.
•To keep your Projector in optimum condition,
upgrade to the latest software. (> Menu >
Settings > Support > Software Update).
The Projectorwon’t turn on.
•Make sure that the powercable is securely plugged
in to the Projector and the wall outlet.
•Make sure that the wall outlet is working and the
remote control sensor of the Projector is lit and
glowing a solid white.
•Try pressing the Power button of the Projector to
make sure that the problem is not with the remote
control. If the Projector turns on, referto "The
remote control does not work".
The remote control does not work.
•Check if the remote control sensorof the Projector
blinks when you press the button on the remote
control.
– When the remote's battery is discharged,
charge the batteryusing the USB charging port
(C-type).
•Try pointing the remote directly at the Projector
from 1.5-1.8 m away.
•Make sure to pairthe remote to the Projector.
English - 8

05 Specifications and Other
Information
Specifications
Model Name SP-LSP3BLA
Display Resolution 1920 x 1080
Lens Throw Ratio 1.2
Image Size (Diagonal) 30 - 100 inches
(76.2 - 254.0 cm)
Sound (Output) 5 W
Dimensions (W x H x D)
With Cradle
With Cradle, Lens Cap
102.4 x 157.8 x 95.2 mm
102.4 x 172.8 x 95.2 mm
Weight
With Cradle
With Cradle, Lens Cap
785 g
830 g
Operating Temperature
10 °C to 40 °C (50 °F to104 °F)
Operating Humidity
10 % to 80 %, non-condensing
Storage Temperature
-20 °C to 45 °C (-4 °F to 113 °F)
Storage Humidity
5 % to 95 %, non-condensing
Notes
•This device is a Class B digital apparatus.
•Forinformation about the powersupply, and more
information about powerconsumption, referto the
information on the label attached to the product.
– Forthe label-rating, see the surface of the
bottom of the Projector.
•The images and specifications of the Quick Setup
Guide may differfrom the actual product.
•Overall Standby Power Consumption: 2.0 W
•(Wi-Fi Port deactivation method: > Menu >
Settings > All Settings > Connection > Network
> Network Status > Disconnect)
* Figures and illustrations in this User Manual are
provided forreference only and may differ from the
actual product appearance. Product design and
specifications may change without notice.
An administration fee may be charged in the following
situations:
(a) An engineer is called out at yourrequest, but it
is found that the product has no defect (i.e., where
the user manual has not been read).
(b) You bring the unit to the Samsung service centre,
but it is found that the product has no defect (i.e.,
where the usermanual has not been read).
Youwill be informed of the administration fee amount
before a technician visits.
Following the repairby a non-authorised service
provider, self-repair or non-professional repair of the
product, Samsung is not liable for any damage to the
product, any injury or any otherproduct safety issue
caused by any attempt to repairthe product which
does not carefully followthese repair and maintenance
instructions. Any damage to the product caused by
an attempt to repairthe product by any person other
than a Samsung certified service providerwill not be
covered by the warranty.
English - 9

Please visit samsung.com/support to find futher
information about external poweradapter and remote
control associated with EU Ecodesign directive - ErP
regulation
Decreasing power consumption
When you shut the Projector off, it enters Standby
mode. In Standby mode, it continues to draw a small
amount of power. To decrease powerconsumption,
unplug the powercable when you don't intend to use
the Projector for a long time.
Hereby, Samsung declares that this radio equipment
is in compliance with Directive 2014/53/EU and the
relevant UK statutory requirements.
The full text of the declaration of conformity is available
at the following internet address: http://www.samsung.
com go to Support and enterthe model name.
This equipment may be operated in all EU countries
and in the UK.
The 5 GHz WLAN(Wi-Fi) function of this equipment
may only be operated indoors.
BT max transmitter power : 100mW at 2.4GHz –
2.4835GHz
Wi-Fi max transmitter power : 100mW at 2.4GHz-
2.4835GHz, 200mW at 5.15GHz-5.25GHz, 100mW
5.25GHz-5.35GHz & 5.47GHz - 5.725GHz
Correct Disposal of This Product
(Waste Electrical & Electronic
Equipment)
(Applicable in countries with
separate collection systems)
This marking on the product, accessories or literature
indicates that the product and its electronic
accessories (e.g. charger, headset, USB cable) should
not be disposed of with otherhousehold waste at the
end of theirworking life. To prevent possible harm to
the environment orhuman health from uncontrolled
waste disposal, please separate these items from
other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Household users should contact eitherthe retailer
where they purchased this product, or their local
government office, fordetails of where and how
they can take these items forenvironmentally safe
recycling.
Business users should contact theirsupplier and check
the terms and conditions of the purchase contract.
This product and its electronic accessories should not
be mixed with other commercial wastes for disposal.
English - 10

Correct disposal of batteries in this
product
(Applicable in countries with
separate collection systems)
The marking on the battery, manual or packaging
indicates that the battery in this product should not
be disposed of with other household waste. Where
marked, the chemical symbols Hg, Cd orPb indicate
that the battery contains mercury, cadmium or lead
above the reference levels in EC Directive 2006/66.
The battery incorporated in this product is not user
replaceable. Forinformation on its replacement,
please contact your service provider. Do not attempt
to remove the battery or dispose it in a fire. Do not
disassemble, crush, orpuncture the battery. If you
intend to discard the product, the waste collection site
will take the appropriate measures forthe recycling
and treatment of the product, including the battery.
Removing the battery
•To remove the battery, contact an authorised
service centre. To obtain battery removal
instructions, please visit www.samsung.com/
global/ecodesign_energy.
•Foryour safety, you must not attempt to remove
the battery. If the battery is not properly removed,
it may lead to damage to the battery and device,
cause personal injury, and/or result in the device
being unsafe.
Licences
•These licences may not be supported depending
on the model or geographical area.
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks orregistered trademarks of HDMI
Licensing Administrator, Inc. in the United States and
other countries.
English - 11

Warranty Card
United Kingdom Republic of Ireland (EIRE)
This Samsung product is warranted forthe period of twelve (12) months from the original date of purchase, against
defective materials andworkmanship. In the event that warranty service is required, you should return the product
to the retailer from whom it was purchased. However, Samsung Authorised Dealers and Authorised Service Centres
in the countries listed in Warranty Conditions will complywith the warranty on the terms issued to purchasers in the
country concerned. In case of difficulty, details of ourAuthorised Service Centres are available from:
Samsung Electronics U.K. Ltd.
Samsung Customer Support Centre
Selectapost 38, Sheffield, S97 3FJ,
United Kingdom
United Kingdom: Tel. [phone]
www.samsung.com/uk/support
EIRE: Tel. [phone]
www.samsung.com/ie/support
WARRANTY CONDITIONS
1. The warranty is onlyvalid if, when warranty service is required, the warranty card is fully and properly
completed and is presented with the original invoice orsales slip or confirmation, and the serial numberon the
product has not been defaced.
2. Samsung’s obligations are limited to the repairor, at its discretion, replacement of the product orthe defective
part. Repaired orreplaced products may include new and orrefurbished components and equipment.

3. Warranty repairs must be carried out byAuthorised Samsung Dealers orAuthorised Service Centres. No
re-imbursement will be made for repairs carried out by non-Samsung Dealers and, any such repairwork and
damage to the products caused by such repairwork will not be covered bythis warranty.
4. This product is not considered to be defective in materials norworkmanship by reason that it requires
adaptation in orderto conform to national or local technical orsafety standards in force in any Country other
than the one forwhich the product was originally designed and manufactured.
This warrantywill not cover, and no re-imbursement will be made for such adaptation nor any damage which
may result.
5. This warranty covers none of the following:
a) Periodic check-ups, maintenance and repairor replacement of parts due to normal wear and tear.
b) Cost relating to transport, removal orinstallation of the product.
c) Misuse, including the failure to use this product forits normal purposes or incorrect installation.
d) Use of this product in a commercial/ business environment, which shall include, but is not limited to, the
following: any use forprofit orfinancial gain, public display or events such as clubs, bars and restaurants
including continuous statistical orgraphical display, orany commercial use of continuous orintentional
long term display of News reels (“tickers”), static or fixed images such as timetables and 4:3 pictures or
video content displaying permanent black bars.
e) Damage caused by Lightning, Water, Fire, Acts of God, War, Public Disturbances, incorrect mains voltage,
improperventilation or anyother cause beyond the control of Samsung.
f) Spillage of food or liquid or use of any other hazardous substances, which may affect the product.
g) Performance due to differences in broadcasting method between countries.
6. This warranty is valid for any person who legally acquired possession of the product during the warranty period.
7. The consumers’ statutory rights in any applicable national legislation whether against the retailerarising from
the purchase contract or otherwise are not affected by this warranty. Unless there is national legislation to
the contrary, the rights underthis warranty are the consumers’ sole rights and Samsung, its subsidiaries and
distributors shall not be liable forindirect orconsequential loss orany damage to disc based media, removable
memory or any other related equipment or material.
8. Some products maydifferfrom these guidelines. Please check with yourdealeror the local Samsung web-site.
9. Samsung shall honourwarranties for all EU specification products purchased by a consumerwithin the
following European countries listed.
–UK, Republic of Ireland, Germany, France, Italy, Malta, Spain, Portugal, The Netherlands, Belgium,
Luxembourg, Denmark, Sweden, Finland, Poland, Hungary, Czech Republic, Slovakia, Austria, Slovenia,
Croatia, Estonia, Latvia, Lithuania, Greece, Cyprus, Romania, Bulgaria, Switzerland, Norway, Lichtenstein
and Iceland.
SAMSUNG ELECTRONICS CO LTD.

This page is intentionally
left blank.

This page is intentionally
left blank.

© 2022 Samsung Electronics Co., Ltd. All rights reserved.
-01
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the Samsung service
centre.
Country Samsung Service Centre Web Site
IRELAND
(EIRE) 0818 717100 www.samsung.com/ie/support
UK 0333 000 0333 www.samsung.com/uk/support
