Samsung HW-J450-TK User manual

Wireless Audio - Soundbar
Imagine the possibilities
Thank you for purchasing this Samsung product.
To receive a more complete service, please register your product at
www.samsung.com/register
User manual
HW-J450
02805R HW-J450-TK ENG-0207.indd 1 2015/2/7 10:37:59

3
2
FEATURES
FEATURES
TV SoundConnect
TV SoundConnect lets you listen to audio from your TV on your Soundbar via a Bluetooth connection and lets you
control the sound.
HDMI
HDMI transmits video and audio signals simultaneously, and provides a clearer picture.
The unit is also equipped with the ARC function which lets you listen to sound from your TV through the Soundbar via
an HDMI cable. This function is only available if you connect the unit to an ARC compliant TV.
SURROUND SOUND
The SURROUND SOUND feature adds depth and spaciousness to your listening experience.
Wireless Subwoofer
Samsung’s wireless module does away with cables running between the main unit and the subwoofer.
Instead, the subwoofer connects to a compact wireless module that communicates with the main unit.
Special Sound Effects
You can select different Sound Effects - STANDARD (Original Sound)/MUSIC / VOICE / SPORTS / CINEMA / NIGHT
MODE - depending on the type of content you want to enjoy.
Multi-function Remote Control
You can use the supplied remote control to control various operations with the simple press of a button.
USB Host Support
You can connect and play music files from external USB storage devices such as MP3 players, USB flash memory,
etc. using the Soundbar's USB HOST function.
Bluetooth Function
You can connect a Bluetooth device to the Soundbar and enjoy music with high quality stereo sound, all without wires!
Using Samsung Audio Remote App
To control the product with your Smart Device via the Samsung Audio Remote app, download the Samsung Audio
Remote App by accessing the app through Google Play store.
LICENSES
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the
Symbol, & DTS and the Symbol together are registered trademarks, and DTS 2.0 Channel is a trademark of DTS, Inc.
© DTS, Inc. All Rights Reserved.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and other countries.
02805R HW-J450-TK ENG-0207.indd 2 2015/2/7 10:37:59

3
2
ENG
SAFETY INFORMATION
SAFETY INFORMATION
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates “dangerous voltage” inside
the product that presents a risk of electric shock or
personal injury.
This symbol indicates important instructions
accompanying the product.
WARNING : To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
• This apparatus shall always be connected to a AC outlet with a protective grounding connection.
• To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains plug
shall be readily operable.
CAUTION
• Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the apparatus.
• To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power plug
must be easily and readily accessible at all times.
02805R HW-J450-TK ENG-0207.indd 3 2015/2/7 10:37:59

5
4
SAFETY INFORMATION
PRECAUTIONS
Ensure that the AC power supply in your house complies with the power requirements listed on the identification
sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with
enough space around it for ventilation 7~10 cm. Make sure the ventilation slots are not covered. Do not place the
unit on amplifiers or other equipment which may become hot. This unit is designed for continuous use. To fully turn
off the unit, disconnect the AC plug from the wall outlet. Unplug the unit if you intend to leave it unused for a long
period of time.
99.1mm 99.1mm
68.6
mm
99.1mm
During thunderstorms, disconnect the AC plug from
the wall outlet. Voltage peaks due to lightning could
damage the unit.
Protect the product from moisture (i.e. vases), and
excess heat (e.g. a fireplace) or equipment creating
strong magnetic or electric fields. Disconnect
the power cable from the AC supply if the unit
malfunctions. Your product is not intended for industrial
use. It is for personal use only.
Condensation may occur if your product has been
stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until the
unit has reached room temperature before using.
Do not expose the unit to direct sunlight or other heat
sources.
This could lead to overheating and cause the unit to
malfunction.
The batteries used with this product contain chemicals
that are harmful to the environment. Do not dispose
of batteries in the general household trash. A warning
that batteries (battery pack or batteries installed) shall
not be exposed to excessive heat such as sunshine,fire
or the like. Do not short circuit, disassemble, or
overheat the batteries. Danger of explosion if battery
is incorrectly replaced. Replace only with the same or
equivalent type.
02805R HW-J450-TK ENG-0207.indd 4 2015/2/7 10:37:59

5
4
ENG
CONTENTS
CONTENTS
2 FEATURES
2 Licenses
3 SAFETY INFORMATION
3 Safety Warnings
4 Precautions
6 GETTING STARTED
6 Before reading the User’s Manual
6 What’s Included
7 DESCRIPTIONS
7 Top/Front Panel
8 Rear Panel
9 REMOTE CONTROL
9 Remote Control Buttons and Functions
11 CONNECTIONS
11 Installing the Wall Mount
12 Detaching the Wall Mount
12 Installing the bracket without referring to
the Wall-mount Installation Guide
13 Connecting the Wireless Subwoofer
15 Connecting an External Device using an
HDMI cable
16 Connecting an External Device using
Audio (analogue) cable or Optical (digital)
cable
17 FUNCTIONS
17 Input Mode
17 ARC (HDMI OUT)
18 Bluetooth
20 Using Samsung Audio Remote App
21 TV SoundConnect
22 USB
23 Software update
24 TROUBLESHOOTING
25 APPENDIX
25 Specifications
Figures and illustrations in this User Manual are
provided for reference only and may differ from actual
product appearance.
02805R HW-J450-TK ENG-0207.indd 5 2015/2/7 10:37:59

7
6
GETTING STARTED
GETTING STARTED
BEFORE READING THE USER’S MANUAL
Note the following terms before reading the user manual.
+Icons used in this manual
Icon Term Definition
Caution
Indicates a situation where a function does not operate or settings may be canceled.
Note
Indicates tips or instructions on the page that help you operate a function.
+Safety Instructions and Troubleshooting
1) Be sure to familiarise yourself with the Safety Instructions before using this product. (See page 3)
2) If a problem occurs, check Troubleshooting. (See page 24)
+Copyright
©2015 Samsung Electronics Co.,Ltd.
All rights reserved; no part of this user’s manual may be reproduced or copied without the prior written permission of
Samsung Electronics Co.,Ltd.
WHAT’S INCLUDED
Check for the supplied accessories shown below.
(Wall Mount L: 1EA)
(Wall Mount R: 1EA)
Remote Control / Lithium Battery
(3V : CR2032) User Manual Bracket-Wall Mount
(Holder-screw2: 2EA)
(Holder-screw1: 2EA)
Wall Mount Guide Holder-Screw Power Cord:2EA
DC Adapter Optical cable USB Cable
●The appearance of the accessories may differ slightly from the illustrations above.
●Use the dedicated USB cable to connect external USB devices to the unit.
02805R HW-J450-TK ENG-0207.indd 6 2015/2/7 10:38:00

7
6
ENG
DESCRIPTIONS
DESCRIPTIONS
TOP/FRONT PANEL
(Power) Button
Turns the power on and off.
VOL -/+
Controls the volume level.
The numeric value of the volume level appears in
the front panel display.
(SOURCE) Button
Selects the D.IN, AUX, HDMI, BT, TV, USB
input.
●While the unit is powered on, pressing
the ( ) button for more than 3
seconds sets the button to act as
MUTE button. To cancel MUTE button
setup, press the ( ) button for more
than 3 seconds again.
●When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.
●If you want to enjoy the sound only from the Soundbar, you must turn off the TV's speakers in the Audio
Setup menu of your TV. Refer to the owner's manual supplied with your TV.
Display
Displays the current mode.
●If there is no input from the product or
remote control for 25 seconds, the display
will dimmer automatically.
02805R HW-J450-TK ENG-0207.indd 7 2015/2/7 10:38:01

9
8
DESCRIPTIONS
REAR PANEL
HDMI OUT(TV)OPTICAL IN
HDMI IN
AUX IN
DC 24V (Power Supply In)
Connect the DC power adaptor to
the power supply jack, and then
connect the AC power adaptor
plug to a wall outlet.
(USB Port)
Connect USB devices such as
MP3 players here to play files on
the devices.
HDMI OUT (TV)
Outputs digital video and audio
signals simultaneously using an
HDMI cable.
OPTICAL IN
Connect to the digital (optical) output
of an external device.
HDMI IN
Inputs digital video and audio
signals simultaneously using an
HDMI cable. Use when
connecting a supported external
device.
AUX IN
Connect to the Analog output of
an external device.
●When disconnecting the power cable of the AC power adaptor from the wall outlet, pull the plug.
Do not pull the cable.
●Do not connect this unit or other components to an AC outlet until all connections between components
are complete.
02805R HW-J450-TK ENG-0207.indd 8 2015/2/7 10:38:02

9
8
ENG
REMOTE CONTROL
REMOTE CONTROL
REMOTE CONTROL BUTTONS AND FUNCTIONS
WOOFER (*Use the [ , ] button to adjust volume )
You can control the woofer volume.
Press the
[ , ] button to increase or decrease the subwoofer volume.
You can select SW (-12, -6,-5,-4,-3,-2,-1,0,+1,+2,+3,+4,+5,+6).
AUTO POWER
Auto Power Link: Synchronizes the Soundbar to a connected Optical source
via the Optical jack so it turns on automatically when you turn on your TV.
(Auto Power Link : Default OFF, ON-Anynet+ / OFF-POWER LINK or
OFF-Anynet+ / ON-POWER LINK ). The Anynet+ function lets you control
the Soundbar with the remote from an Anynet+ compatible Samsung TV.
The Soundbar must be connected to the TV via an HDMI cable.
* Anynet+: Press the AUTO POWER button to turn the Anynet+ function
on or off.
REPEAT
Press to set the REPEAT function during music playback from a USB
device.
OFF-REPEAT : Cancels Repeat Playback.
TRACK-REPEAT : Repeatedly play a track.
ALL-REPEAT : Repeatedly play all tracks.
RANDOM-REPEAT : Plays tracks in random order.
(A track that has already been played may be played again.)
MUTE
You can turn the volume down to 0 with the push of a button.
Press again to restore the sound to the previous volume level.
SOURCE
Press to select a source connected to the Soundbar.
Skip Forward
If there is more than one file on the device you are playing, and you press
the ]button, the next file is selected.
●Soundbar is a Samsung proprietary name.
●Operate the TV using the TV's remote control.
SOUND CONTROL (*Use the [ , ] buttons to adjust level.)
Press to select TREBLE, BASS, or AUDIO SYNC.Then, use the [ , ]
buttons to adjust the Treble, Bass volume from -6 to +6.
If the Soundbar is connected to a digital TV and the video appears out of
sync with the audio, press the SOUND CONTROL button to sync the
audio with the video. Use the [,]buttons to set the audio delay between
0 ms and 300 ms. In USB mode, TV mode, and BT mode, the Audio Sync
function may not work.
Press and hold the SOUND CONTROL button for about 5 seconds to
adjust the sound for each frequency band. 150Hz, 300Hz, 600Hz,
1.2KHz,2.5KHz, 5KHz and 10KHz are selectable and each can be adjusted
to a setting between -6 and +6.
02805R HW-J450-TK ENG-0207.indd 9 2015/2/7 10:38:02

11
10
REMOTE CONTROL
Bluetooth POWER
Press the Bluetooth POWER button on the remote to turn the Bluetooth
POWER on function on and off.
See pages 19 and 21 for details.
SOUND
Press the SOUND button on the remote to add depth and spaciousness to
the sound.
Press the SOUND on the remote control.
Each time the button is pressed, the selection changes as follows :
ON-SURROUND SOUND OFF-SURROUND SOUND
VOLUME
Adjusts the volume level of the unit.
POWER
Turns the Soundbar on and off.
SOUND EFFECT
You can select different sound modes - STANDARD,MUSIC, VOICE,
SPORTS, CINEMA, and NIGHT MODE - depending on the type of
sources you want to enjoy.
Press the SOUND EFFECT button on the remote control.
Select the STANDARD mode if you want to enjoy the original sound.
* Night Mode
This will regulate and stabilize the volume level against a drastic volume
change caused by a channel change or scene transition.
Play/Pause
Press the
+# button to pause playing the file temporarily.
Press the
+# button again to play the selected file.
Skip Back
If there is more than one file on the device you are playing, and you press
the
[ button, the previous file is selected.
+Installing the Battery in the Remote Control
1. Use a suitable coin to turn the
remote control's battery cover
counterclockwise to remove it
as shown in the figure above.
2. Insert a 3V lithium battery. Keep the
positive (+) pole facing up when inserting
the battery. Put the battery cover on and
align the '●' marks side by side as
shown in the figure above.
3. Use a suitable coin to
turn the remote control
battery cover clockwise
as far as it will go to fix it
in place.
02805R HW-J450-TK ENG-0207.indd 10 2015/2/7 10:38:02

11
10
ENG
CONNECTIONS
CONNECTIONS
INSTALLING THE WALL MOUNT
You can use the wall mount bracket to mount this unit on a wall.
+Installation Precautions
●Install on a vertical wall only.
●For the installation, avoid a location with high temperature or
humidity, or a wall that cannot sustain the weight of the set.
●Check the strength of the wall. If the wall is not strong enough to
support the unit, reinforce the wall or install the unit on a different
wall that can support the unit's weight.
●Purchase and use the fixing screws or anchors appropriate for the
kind of wall you have (plaster board, iron board, wood, etc.).
If possible, fix the support screws into wall studs.
●Purchase wall mounting screws according to the type and
thickness of the wall you will mount the Soundbar on.
-Diameter : M5
-Length: L 35 mm or longer recommended
●Connect cables from the unit to external devices before you install
it on the wall.
●Make sure the unit is turned off and unplugged before you install it.
Otherwise, it may cause an electric shock.
1. Place the installation guide against the wall surface.
•The installation guide must be level.
•Install at least 5 cm below the TV, if the TV is mounted on the
wall.
2. Mark the location where the screws will go through on the wall
using a pen, and then remove the installation guide.
3. Fasten the wall mounts and screws to the marked locations.
•The left and right mounts are different shapes.
4. Secure the two holder screws to the screw holes on the back of
the Soundbar's main body, one on the left and one on the right.
5. Insert the USB cable into the back of the Soundbar before installing
it on the wall.
6. Set the holder screws on the back of the Soundbar into the
grooves of the wall mount. For safe installation, make sure to push
the holder screws all the way to the bottom of the grooves.
5 cm or more
Using the Soundbar with Wall Mount
[Wall Mounting the Soundbar]
02805R HW-J450-TK ENG-0207.indd 11 2015/2/7 10:38:03

13
12
CONNECTIONS
DETACHING THE WALL MOUNT
1. Pull the Soundbar upwards as shown in the figure to separate it
from the wall mount.
●Do not hang onto the installed unit and avoid striking or dropping the unit.
●Secure the unit firmly to the wall so that it does not fall off. If the unit falls off, it may cause an injury or
damage the product.
●When the unit is installed on a wall, please make sure that children do not pull any of the connecting
cables, as it may cause it to fall.
●For the optimal performance of a wall mount installation, install the speaker system at least 5 cm below the
TV, if the TV is mounted on the wall.
●For your safety, if you do not mount the unit on the wall, install it on a secure, flat surface where it is unlikely to fall.
INSTALLING THE BRACKET WITHOUT REFERRING TO THE
WALL-MOUNT INSTALLATION GUIDE
5 cm or more5 cm or more
16 cm 17.5 cm
Minimum 32.8 ~ 33.5 cm
1. Place the “Wall Mount L” on the desired wall surface while paralleled to the floor as shown above, and fix a screw
through the hole on its right end.
2. Place the “Wall Mount R” on the desired wall surface while paralleled to the floor as shown above, and fix a screw
through the hole on its left end.
•If Wall Mount L/R are to be mounted beneath the TV, check their fixing hole positions in steps 1 and 2, so that
they are aligned appropriately to the center of the TV’s bottom.
3. Fix screws through the rest of holes.
Using the Soundbar with Wall Mount
[Detaching the Soundbar from the Wall Mount]
02805R HW-J450-TK ENG-0207.indd 12 2015/2/7 10:38:03

13
12
ENG
CONNECTIONS
CONNECTING THE WIRELESS SUBWOOFER
The Subwoofer's linking ID is preset at the factory and the main unit and subwoofer should link (connect wirelessly)
automatically when the main unit and subwoofer are turned on. If the Link indicator ( ) does not light when the
main unit and subwoofer are turned on, please set the ID by following the procedure below.
1. Plug the power cords of the main unit and subwoofer into an AC wall outlet.
2. Press the ID SET button on the back of the subwoofer with a small, pointed object for 5 seconds.
•The STANDBY indicator is turned off and the LINK indicator (Blue LED) blinks quickly.
3. While the main unit is powered off (in STANDBY mode), press and hold the MUTE ( ) on the remote control for
5 seconds.
4. The ID SET message appears on the Soundbar's display.
5. To finalize the link, turn the main unit’s power on while the subwoofer’s Blue LED blinks.
•The main unit and the subwoofer should now be linked (connected).
•The Link indicator (Blue LED) on the subwoofer should be on.
•If the Link indicator is not solid blue, the linking process has failed. Turn off the main unit and start again from
Step 2.
•You can enjoy better sound from the wireless subwoofer by selecting a Sound Effect. (See page 10)
02805R HW-J450-TK ENG-0207.indd 13 2015/2/7 10:38:04

15
14
CONNECTIONS
●Before moving or installing the product, be sure to turn off the power and disconnect the power cord.
●If the main unit is powered off, the wireless subwoofer will be in standby mode and the STANDBY LED on
the upper side will come on after the Link indicator (Blue LED) blinks for 30 seconds.
●If you use a device that uses the same frequency (2.4GHz) as the Soundbar near the Soundbar,
interference may cause some sound interruption.
●The transmission distance of the wireless signal between the main unit and subwoofer is about 10 m, but
may vary depending on your operating environment.
If a steel-concrete or metallic wall is between the main unit and the wireless subwoofer, the system may not
operate at all, because the wireless signal cannot penetrate metal.
●If the main unit doesn't make a wireless connection, follow steps 1-5 to re-set the connection between the
main unit and wireless subwoofer.
●The wireless receiving antenna is built into the wireless subwoofer. Keep the unit away from water and
moisture.
●For optimal listening performance, make sure that the area around the wireless subwoofer location is clear
of any obstructions.
02805R HW-J450-TK ENG-0207.indd 14 2015/2/7 10:38:04

15
14
ENG
CONNECTIONS
CONNECTING AN EXTERNAL DEVICE USING AN HDMI
CABLE
HDMI is the standard digital interface for connecting to such TVs, projectors, DVD players, Blu-ray players, set top
boxes, and more.
Because HDMI transmits the highest quality digital signal, you can enjoy superior video and audio - as it was originally
created at the digital source.
HDMI OUT (TV)HDMI IN
HDMI IN
AUX IN
HDMI OUT(TV)OPTICAL IN
HDMI Cable
(not supplied)
HDMI Cable
(not supplied)
Digital Devices
HDMI IN
Connect an HDMI cable (not supplied) from the HDMI
IN jack on the back of the product to the HDMI OUT
jack on your digital device.
and,
HDMI OUT (TV)
Connect an HDMI cable (not supplied) from the HDMI
OUT (TV) jack on the back of the product to the HDMI
IN jack on your TV.
●HDMI is an interface that enables the digital
transmission of video and audio data with
just a single connector.
ARC (HDMI OUT)
The ARC function allows digital audio to output via the
HDMI OUT (ARC) port.
It can be enabled only when the Soundbar is connected
to a TV that supports the ARC function.
●Anynet+ must be turned on.
●This function is not available if the HDMI
cable does not support ARC.
02805R HW-J450-TK ENG-0207.indd 15 2015/2/7 10:38:04

17
16
CONNECTIONS
CONNECTING AN EXTERNAL DEVICE USING AUDIO
(ANALOGUE) CABLE OR OPTICAL (DIGITAL) CABLE
This unit comes equipped with one optical in digital jack and one audio Analogue in jack, giving you two ways to
connect it to a TV.
AUX IN
AUDIO
OUT
OPTICAL IN
OPTICAL
OUT
HDMI IN
AUX IN
HDMI OUT(TV)OPTICAL IN
Audio Cable Optical Cable
BD/ DVD player/
Set-top box/
Game console
AUX IN
Connect AUX IN (Audio) on the main unit to the AUDIO
OUT jack of the TV or Source Device.
Change the function to AUX.
or,
OPTICAL IN
Connect OPTICAL IN (Audio) on the main unit to the
OPTICAL OUT jack of the TV or Source Device.
Change the function to D.IN.
●Do not connect the power cord of this
product or your TV to the wall outlet until all
connections between components are
complete.
●Before moving or installing this product, be
sure to turn off the power and disconnect the
power cord.
(Not supplied) (Supplied)
02805R HW-J450-TK ENG-0207.indd 16 2015/2/7 10:38:05

17
16
ENG
FUNCTIONS
(Not supplied)
FUNCTIONS
INPUT MODE
Press the ( ) button on the main unit’s top p anel or the ( SOURCE) button on the remote control to select the
mode you want.
Input mode Display
Optical Digital input D.IN
AUX input AUX
HDMI input HDMI
BLUETOOTH mode BT
TV SoundConnect TV
USB mode USB
The unit turns off automatically in the following situations.
●D.IN/HDMI/BT/TV/USB Mode
-If there is no audio signal for 25 minutes.
●AUX Mode
-If the AUX cable is disconnected for 25 minutes.
-In Auto Power Down ON mode,if there is no KEY
input for 8 hours when the AUX cable is connected.
-To turn the Auto Power Down function ON or OFF,
press and hold the p button for 5 seconds. OFF/
ON-AUTO POWER DOWN appears on the display.
ARC (HDMI OUT)
ARC (Audio Return Channel) transfers digital audio signal to the HDMI OUT (ARC) port.
HDMI Cable
1. Connect the TV supporting ARC to the Soundbar with an HDMI cable.
2. Turn on the TV, and turn on the Soundbar’s Anynet+.
3. Press the ( ) button on the main unit’s top panel or the (SOURCE) button on the remote control to select
the D.IN mode.
●If the HDMI cable does not support ARC feature, ARC may not work properly.
●To turn off the ARC function, turn Anynet+ off.
02805R HW-J450-TK ENG-0207.indd 17 2015/2/7 10:38:05

19
18
FUNCTIONS
BLUETOOTH
You can connect a Bluetooth device to the Soundbar and enjoy music with high quality stereo sound, all without wires!
+To connect the Soundbar to a Bluetooth device
Check if the Bluetooth device supports the Bluetooth compliant stereo headset function.
Bluetooth device
Connect
1. Press the ( ) button on the main unit’s top panel
or the (SOURCE) button on the remote control
to select the BT mode.
•You will see BT READY on the front display of the
Soundbar.
2. Select the Bluetooth menu on the Bluetooth device
you want to connect. (Refer to the Bluetooth device's
user manual.)
3. Select the Stereo headset menu on the Bluetooth
device.
•You will see a list of scanned devices.
4. Select "[Samsung] Soundbar J-Series" from the
list.
•When the Soundbar is connected to the Bluetooth
device, it will display [Bluetooth device name] 
BT on the front display.
•The device name can only be displayed in English.
An underline " _ " will be displayed if the name is not
in English.
•If the Bluetooth device has failed to pair with the
Soundbar, delete the previous "[Samsung]
Soundbar J-Series" found by the Bluetooth
device and have it search for the Soundbar again.
5. Play music on the connected device.
•You can listen to the music playing on the
connected Bluetooth device over the Soundbar.
•In BT mode, the Play/Pause/Next/Prev functions
are not available. However, these functions are
available in Bluetooth devices supporting AVRCP.
●If asked for PIN code when connecting a
Bluetooth device, enter <0000>.
●Only one Bluetooth device can be paired at a
time.
●The Bluetooth connection will be terminated
when you turn the Soundbar off.
●The Soundbar may not perform Bluetooth
search or connection correctly under the
following circumstances:
-If there is a strong electrical field around
the Soundbar.
-If several Bluetooth devices are
simultaneously paired with the Soundbar.
-If the Bluetooth device is turned off, not in
place, or malfunctions.
-Note that such devices as microwave
ovens, wireless LAN adaptors, fluorescent
lights, and gas stoves use the same
frequency range as the Bluetooth device,
which can cause electric interference.
●The Soundbar supports SBC data (44.1kHz,
48kHz).
●Connect only to a Bluetooth device that
supports the A2DP (AV) function.
●You cannot connect the Soundbar to a
Bluetooth device that supports only the HF
(Hands Free) function.
●Once paired the device,on D.IN/AUX/ HDMI/
USB mode, select "[Samsung] Soundbar
J-Series" from the list will automatically
change to BT mode.
02805R HW-J450-TK ENG-0207.indd 18 2015/2/7 10:38:06

19
18
ENG
FUNCTIONS
+Bluetooth POWER on (Bluetooth POWER)
When the Bluetooth Power On function is on and the Soundbar is turned off, if a previously paired Bluetooth device
tries to pair with the Soundbar, the Soundbar turns on automatically.
1. Press the Bluetooth POWER on the remote while the Soundbar is turned on.
2. ON-Bluetooth POWER appears on the Soundbar's display.
●Available only if the Soundbar is listed among the Bluetooth device’s paired devices. (The Bluetooth device
and the Soundbar must have been previously paired at least once.)
●Soundbar will appear in the Bluetooth device’s searched devices list only when the Soundbar is displaying
[BT READY].
●In the TV SoundConnect mode, the Soundbar cannot be paired to another Bluetooth device.
+To disconnect the Bluetooth device from the Soundbar
You can disconnect the Bluetooth device from the Soundbar. For instructions, see the Bluetooth device's user manual.
●The Soundbar will be disconnected.
●When the Soundbar is disconnected from the Bluetooth device, the Soundbar will display
BT DISCONNECTED on the front display.
+To disconnect the Soundbar from the Bluetooth device
Press the (SOURCE) button on the remote control or the ( ) button on the product's top panel to switch
from BT to another mode or turn off the Soundbar.
●The connected Bluetooth device will wait a certain amount of time for a response from the Soundbar before
terminating the connection. (Disconnection time may differ, depending on the Bluetooth device)
●In Bluetooth connection mode, the Bluetooth connection will be lost if the distance between the Soundbar
and the Bluetooth device exceeds 5m.
●The Soundbar automatically turns off after 25 minutes in the Ready state.
More About Bluetooth
Bluetooth is a technology that enables Bluetooth-compliant devices to interconnect easily with each other using a
short wireless connection.
●A Bluetooth device may cause noise or malfunction, depending on usage, when:
-A part of your body is in contact with the receiving/transmitting system of the Bluetooth device or the Soundbar.
-It is subject to electrical variation from obstructions caused by a wall, corner, or office partition.
-It is exposed to electrical interference from same frequency-band devices including medical equipment,
microwave ovens, and wireless LANs.
●Pair the Soundbar with the Bluetooth device while they are close together.
●The further the distance between the Soundbar and Bluetooth device, the worse the quality is.
If the distance exceeds the Bluetooth operational range, the connection is lost.
●In poor reception areas, the Bluetooth connection may not work properly.
●The Bluetooth connection only works when it is close to the unit. The connection will be automatically cut off if the
Bluetooth device is out of range. Even within range, the sound quality may be degraded by obstacles such as
walls or doors.
●This wireless device may cause electric interference during its operation.
02805R HW-J450-TK ENG-0207.indd 19 2015/2/7 10:38:06

21
20
FUNCTIONS
USING SAMSUNG AUDIO REMOTE APP
Install Samsung Audio Remote App
To control the product with your Smart Device via the Samsung Audio Remote app, download the Samsung Audio
Remote App by accessing the app through Google Play store.
Accessing the Samsung Audio Remote App
After you install the Samsung Audio Remote app, follow the instructions in the app.
●The APP function only supports Android mobile phone devices running Android OS 3.0 or later.
02805R HW-J450-TK ENG-0207.indd 20 2015/2/7 10:38:06
