Samsung GT-I8700 User manual

GSM TELEPHONE
GT-i8700
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1Repair
7. Disassembly and Assembly
Instructions
8. Chart of Troubleshooting
9. Reference data
Notice :
All functionality, features, specifications and other
product information provided in this document inclu
ding, but not limited to, the benefits, design, pricing,
components, performance, availability, and capabiliti
-es of the product are subject to change without
notice or obligation. Samsung reserves the right to
make changes to this document and the product
described herein, at anytime, without obligation on
Samsung to provide notification of such change.
GSM TELEPHONE CONTENTS

SAMSUNG Proprietary-Contents may change without notice
1. Safety Precautions
1-1
This Document can not be used without Samsung's authorization
1-1. Repair Precaution
―Repair in Shield Box, during detailed tuning. Take specially care of tuning or test, because
specipicty of cellular phone is sensitive for surrounding interference(RF noise).
―Be careful to use akind of magnetic object or tool, because performance of parts is damaged by
the influence of magnetic force.
―Surely use astandard screwdriver when you disassemble this product, otherwise screw will be
worn away.
―Use athicken twisted wire when you measure level.
Athicken twisted wire has low resistance, therefore error of measurement is few.
―Repair after separate Test Pack and Set because for short danger (for example an overcurrent
and furious flames of parts etc) when you repair board in condition of connecting Test Pack and
tuning on.
―Take specially care of soldering, because Land of PCB is small and weak in heat.
―Surely tune on/off while using AC power plug, because arepair of battery charger is dangerous
when tuning ON/OFF PBA and Connector after disassembling charger.
―Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.

SAMSUNG Proprietary-Contents may change without notice
Safety Precautions
1-2
This Document can not be used without Samsung's authorization
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
―Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity prevention
string on wrist.
―Use earthed soldering steel when you connect or disconnect ESD.
―Use soldering removing tool to break static electricity. ,otherwise ESD will be damaged by static
electricity.
―Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum plate to have conductive power,they are prevented from static electricity.
―You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or acircuit board.

2. Specification
2-1
2-1. GSM General Specification
EGSM
850
EGSM
900
DCS
1800
PCS
1900
WCDMA
900
WCDMA
1900
WCDMA
2100
Freq.
Band[MHz]
Uplink/Downlink
824~849
869~894
880~915
925~960
1710~1785
1805~1880
1850~1910
1930~1990
880~915
925~960
1850~1910
1930~1990
1920~1980
2110~2170
ARFCN range 128~251 0~124 &
975~1023 512~885 512~810 UL:2712~2863
DL:2937~3088
UL:9262~9538
DL:9662~9938
UL:9612~9888
DL:10562~10838
Tx/Rx spacing 45MHz 45MHz 95MHz 80MHz 45MHz 80MHz 190MHz
Mod. Bit rate/
Bit Period
270.833
Kbps
3.692 us
270.833
Kbps
3.692 us
270.833
Kbps
3.692 us
270.833
Kbps
3.692 us
3.84Mcps/s 3.84Mcps 3.84Mcps/s
Time Slot
Period/
Frame Period
576.9 us
4.615 ms
576.9 us
4.615 ms
576.9 us
4.615 ms
576.9 us
4.615 ms
Frame
length:10ms
Slot
length:0.667ms
Frame length:
10ms
Slot length:
0.667ms
Frame
length:10ms
Slot
length:0.667ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK QPSK
HPSK
QPSK
HQPSK
QPSK
HPSK
MS Power 33dBm
~5dBm
33dBm
~5dBm
30dBm
~0dBm
30dBm
~0dBm
24dBm
~-50dBm
24dBm ~
-50dBm
24dBm
~-50dBm
Power Class 4(max
+33dBm)
4(max
+33dBm)
1(max
+30dBm)
1(max
+30dBm)
3(max
+24dBm)
3(max
+24dBm)
3(max
+24dBm)
Sensitivity -102dBm -102dBm -100dBm -100dBm -103.7dBm -106.7dBm -106.7dBm
TDMA Mux 8 8 8 8 - - -
Cell Radius 35Km 35Km 2 Km 2 Km 2Km 2Km 2Km

Speclflcation
2-2
2-2. GSM Tx Power Class
TX Power
control level
GSM850
GSM900
533±3
dBm
631±3
dBm
729±3
dBm
827±3
dBm
925±3
dBm
10 23±3 dBm
11 21±3 dBm
12 19±3 dBm
13 17±3 dBm
14 15±3 dBm
15 13±3 dBm
16 11±5 dBm
17 9±5 dBm
18 7±5 dBm
19 5±5 dBm
TX Power
control level DCS1800
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control level PCS1900
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm

Speclflcation
2-3
TX Power
control level
GSM900
GSM850
827±3
dBm
925±3
dBm
10 23±3 dBm
11 21±3 dBm
12 19±3 dBm
13 17±3 dBm
14 15±3 dBm
15 13±3 dBm
16 11±5 dBm
17 9±5 dBm
18 7±5 dBm
19 5±5 dBm
TX Power
control level DCS1800
2 26±3 dBm
3 24±3 dBm
4 22±3 dBm
5 20±3 dBm
6 18±3 dBm
7 16±3 dBm
8 12±3 dBm
9 10±3 dBm
10 14±3 dBm
11 12±4 dBm
12 10±4 dBm
13 8±4dBm
14 6±4 dBm
15 4±4 dBm
2-3. GSM EDGE TX power class
TX Power
control level PCS1900
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
812±3
dBm
910±3
dBm
10 14±3 dBm
11 12±4 dBm
12 10±4 dBm
13 8±4dBm
14 6±4 dBm
15 4±4 dBm
Only in Master

SAMSUNG Proprietary-Contents may change without notice
3. Operation Instruction and Installation
3-1
This Document can not be used without Samsung's authorization
Main Function
-GSM 850 / 900 / 1800 / 1900
-GPRS EDGE 850 / 1900 Rx/Tx
-WCDMA 900 / 1900 / 2100
-HSDPA (Cat.8)
-HSUPA (Cat.6)
-FM Radio
-Bluetooth v2.1 +EDR
-WLAN b/g/n
-On Cell TSP Amoled 4.0" 800x480 16M Color
-5.0MCMOS Camera
-MP3 Player

SAMSUNG Proprietary-Contents may change without notice
4. Exploded View and Parts List
4-1
This Document can not be used without Samsung's authorization
4-1. Cellular phone Exploded View
QAN02
QVK03
QVK02
QCR12
QCR101
QCR101
QFR01
QVK01
QCA01
QMP01
QSP01
QRE01
QBA01
QMI03
QSC18
QSC17
QAR01
QFR04
QFR02
QBC00
QDC04 QDC01
QCR101
QCK02
QCK01
QVO01
QRF06

SAMSUNG Proprietary-Contents may change without notice
Exploded View and Parts List
4-2
This Document can not be used without Samsung's authorization
Design LOC Description SEC CODE
QCR12 SCREW-MACHINE 6001-001530
QCR101 SCREW-MACHINE 6001-002005
QCR101 SCREW-MACHINE 6001-002005
QAN02 INTENNA-MAIN (GT_I8700) GH42-02755A
QBA01 INNER BATTERY PACK-1500MAH,BLK,UNI,MAIN GH43-03369A
QCA01 CAMERA MODULE-CMOS 5M I/4" GH59-09928A
QSP01 KEY FPCB-SIM+SPK,GTI8700 GH59-10241A
QVK01 KEY FPCB-SIDE KEY/MOTOR GH59-10305A
QVK02 KEY FPCB-CAM KEY(GTI8700) GH59-10318A
QVK03 KEY FPCB-PWR KEY(GTI8700) GH59-10319A
QBC00 NPR COVER-BATT GH71-09627A
QMP01 A/S ASSY-PBA MAIN(FTM)GT_I8700 GH82-05260A
QFR04 ASSY COVER-BOTTOM_ORANGE GH98-18186A
QDC04 ASSY DECO-TOP GH98-18192A
QFR01 MEA FRONT-OCTA LCD ASSY GH97-11612A
QAR01 MODULE-RCV+SENSOR FPCB(GTI8700) GH59-10239A
QRE01 ASSY CASE-REAR GH98-18185A
QMI03 ASSY COVER-MIC HOLDER GH98-18189A
QSC17 ASSY RUBBER-DAMPER HOOK GH98-18525A
QSC18 ASSY RUBBER-DAMPER BATT GH98-18535A
QDC01 ASSY COVER-TOP GH98-18187A
QRF06 PMO COVER-USB GH72-61434A
QFR02 ASSY CASE-BODY EXTRUSION GH98-18188A
QCK01 PMO KEY-CAM GH72-61435A
QCK02 PMO KEY-POWER GH72-61436A
QVO01 PMO KEY-VOL GH72-61437A
4-2. Cellular phone Parts list

SAMSUNG Proprietary-Contents may change without notice
5. MAIN Electrical Parts List
5-1
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
0403-001688 ZD705 DIODE-ZENER
0404-001172 D400 DIODE-SCHOTTKY
0404-001250 D520 DIODE-SCHOTTKY
0404-001514 ZD800 DIODE-SCHOTTKY
0406-001223 ZD522 DIODE-TVS
0406-001223 ZD600 DIODE-TVS
0406-001223 ZD601 DIODE-TVS
0406-001223 ZD700 DIODE-TVS
0406-001223 ZD701 DIODE-TVS
0406-001223 ZD702 DIODE-TVS
0406-001223 ZD706 DIODE-TVS
0406-001369 U602 DIODE-TVS
0406-001413 ZD520 DIODE-TVS
0406-001413 ZD521 DIODE-TVS
0406-001413 ZD523 DIODE-TVS
0406-001413 ZD524 DIODE-TVS
0406-001413 ZD525 DIODE-TVS
0406-001413 ZD526 DIODE-TVS
0406-001413 ZD527 DIODE-TVS
0407-001002 D401 DIODE-ARRAY
0501-000225 TR403 TR-SMALL SIGNAL
0504-000168 TR401 TR-DIGITAL
0505-001995 TR402 FET-SILICON
0505-002703 TR400 FET-SILICON
0801-003013 U801 IC-CMOS LOGIC
0801-003130 U221 IC-CMOS LOGIC
0801-003130 U222 IC-CMOS LOGIC
0801-003200 U802 IC-CMOS LOGIC
1001-001488 U606 IC-ANALOG SWITCH
1001-001645 U601 IC-ANALOG MULTIPLEX
1003-002047 U412 IC-MOTOR DRIVER
1107-001962 UME800 IC-FLASH MEMORY
1108-000369 UME801 IC-MCP
1201-002830 PAM101 IC-POWER AMP
1201-003057 PAM100 IC-POWER AMP
1201-003060 PAM102 IC-POWER AMP
1201-003134 U521 IC-AUDIO AMP
1201-003139 F220 IC-RF AMP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-2
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
1202-001068 U405 IC-VOLTAGE COMP.
1202-001079 U523 IC-VOLTAGE COMP.
1203-004644 U409 IC-POWER SUPERVISOR
1203-004792 U413 IC-POSI.FIXED REG.
1203-004793 U411 IC-POSI.FIXED REG.
1203-004802 U408 IC-POSI.FIXED REG.
1203-004806 U414 IC-POSI.FIXED REG.
1203-005069 U404 IC-POSI.FIXED REG.
1203-005092 U401 IC-POWER SUPERVISOR
1203-005396 U520 IC-POSI.FIXED REG.
1203-005396 U522 IC-POSI.FIXED REG.
1203-005503 U410 IC-DC/DC CONVERTER
1203-005512 U407 IC-POSI.FIXED REG.
1203-005772 U406 IC-VOL. DETECTOR
1203-006074 U400 IC-DC/DC CONVERTER
1203-006182 U604 IC-VOL. DETECTOR
1203-006372 U605 IC-RESET
1203-006638 U403 IC-POSI.FIXED REG.
1204-003176 U220 IC-TUNER
1205-003297 U101 IC-TRANSCEIVER
1205-004081 UCP800 IC-MODEM
1209-001766 U603 IC-SENSOR
1209-001877 U600 IC-SENSOR
1301-002012 U800 IC-FPGA
1404-001221 TH400 THERMISTOR-NTC
2007-000137 R850 R-CHIP
2007-000138 R424 R-CHIP
2007-000138 R534 R-CHIP
2007-000138 R600 R-CHIP
2007-000138 R606 R-CHIP
2007-000138 R607 R-CHIP
2007-000138 R611 R-CHIP
2007-000138 R613 R-CHIP
2007-000138 R707 R-CHIP
2007-000139 R400 R-CHIP
2007-000141 R813 R-CHIP
2007-000141 R819 R-CHIP
2007-000141 R820 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-3
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
2007-000141 R824 R-CHIP
2007-000141 R825 R-CHIP
2007-000141 R828 R-CHIP
2007-000141 R829 R-CHIP
2007-000141 R830 R-CHIP
2007-000141 R831 R-CHIP
2007-000141 R834 R-CHIP
2007-000141 R835 R-CHIP
2007-000143 R401 R-CHIP
2007-000147 R409 R-CHIP
2007-000148 R412 R-CHIP
2007-000148 R420 R-CHIP
2007-000148 R444 R-CHIP
2007-000148 R445 R-CHIP
2007-000148 R800 R-CHIP
2007-000148 R802 R-CHIP
2007-000148 R816 R-CHIP
2007-000148 R840 R-CHIP
2007-000148 R841 R-CHIP
2007-000151 R432 R-CHIP
2007-000152 R422 R-CHIP
2007-000156 R405 R-CHIP
2007-000156 R408 R-CHIP
2007-000157 R230 R-CHIP
2007-000157 R231 R-CHIP
2007-000157 R232 R-CHIP
2007-000157 R233 R-CHIP
2007-000157 R234 R-CHIP
2007-000162 R406 R-CHIP
2007-000162 R410 R-CHIP
2007-000162 R423 R-CHIP
2007-000162 R434 R-CHIP
2007-000162 R447 R-CHIP
2007-000162 R448 R-CHIP
2007-000162 R601 R-CHIP
2007-000162 R604 R-CHIP
2007-000162 R605 R-CHIP
2007-000162 R612 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-4
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
2007-000162 R704 R-CHIP
2007-000170 R535 R-CHIP
2007-000170 R536 R-CHIP
2007-000172 R220 R-CHIP
2007-000242 R826 R-CHIP
2007-000242 R827 R-CHIP
2007-001119 R223 R-CHIP
2007-001285 R102 R-CHIP
2007-001285 R104 R-CHIP
2007-001298 R100 R-CHIP
2007-001298 R101 R-CHIP
2007-001298 R414 R-CHIP
2007-001298 R415 R-CHIP
2007-001301 R531 R-CHIP
2007-001301 R533 R-CHIP
2007-001313 R224 R-CHIP
2007-002797 R522 R-CHIP
2007-003015 R602 R-CHIP
2007-003015 R603 R-CHIP
2007-003015 R610 R-CHIP
2007-007014 R416 R-CHIP
2007-007014 R803 R-CHIP
2007-007014 R804 R-CHIP
2007-007014 R805 R-CHIP
2007-007014 R806 R-CHIP
2007-007014 R807 R-CHIP
2007-007014 R808 R-CHIP
2007-007014 R809 R-CHIP
2007-007014 R810 R-CHIP
2007-007107 R225 R-CHIP
2007-007107 R609 R-CHIP
2007-007107 R703 R-CHIP
2007-007132 R439 R-CHIP
2007-007136 R700 R-CHIP
2007-007139 R419 R-CHIP
2007-007306 R226 R-CHIP
2007-007306 R229 R-CHIP
2007-007306 R402 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-5
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
2007-007306 R853 R-CHIP
2007-007307 R428 R-CHIP
2007-007307 R429 R-CHIP
2007-007318 R228 R-CHIP
2007-007318 R608 R-CHIP
2007-007468 R417 R-CHIP
2007-007480 R451 R-CHIP
2007-007528 R524 R-CHIP
2007-007529 R427 R-CHIP
2007-007538 R441 R-CHIP
2007-007573 R430 R-CHIP
2007-007589 R404 R-CHIP
2007-007590 R431 R-CHIP
2007-007698 R418 R-CHIP
2007-007798 R435 R-CHIP
2007-007798 R437 R-CHIP
2007-007875 R450 R-CHIP
2007-008044 R114 R-CHIP
2007-008045 R113 R-CHIP
2007-008045 R115 R-CHIP
2007-008045 R116 R-CHIP
2007-008045 R532 R-CHIP
2007-008045 R614 R-CHIP
2007-008045 R706 R-CHIP
2007-008045 R847 R-CHIP
2007-008046 R108 R-CHIP
2007-008046 R109 R-CHIP
2007-008047 R111 R-CHIP
2007-008047 R112 R-CHIP
2007-008052 R817 R-CHIP
2007-008052 R818 R-CHIP
2007-008055 R527 R-CHIP
2007-008055 R615 R-CHIP
2007-008055 R811 R-CHIP
2007-008055 R848 R-CHIP
2007-008213 R440 R-CHIP
2007-008391 R855 R-CHIP
2007-008403 R438 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-6
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
2007-008403 R442 R-CHIP
2007-008403 R443 R-CHIP
2007-008403 R446 R-CHIP
2007-008419 R221 R-CHIP
2007-008420 R851 R-CHIP
2007-008486 R421 R-CHIP
2007-008516 R838 R-CHIP
2007-008588 R106 R-CHIP
2007-008588 R526 R-CHIP
2007-008588 R812 R-CHIP
2007-008739 R449 R-CHIP
2007-008780 R236 R-CHIP
2007-008780 R413 R-CHIP
2007-008798 R433 R-CHIP
2007-008806 R107 R-CHIP
2007-009155 R425 R-CHIP
2007-009157 R222 R-CHIP
2007-009157 R426 R-CHIP
2007-009157 R436 R-CHIP
2007-009201 R110 R-CHIP
2007-009212 R105 R-CHIP
2007-009420 R103 R-CHIP
2203-000233 C225 C-CER,CHIP
2203-000233 C246 C-CER,CHIP
2203-000233 C453 C-CER,CHIP
2203-000254 C231 C-CER,CHIP
2203-000254 C245 C-CER,CHIP
2203-000254 C464 C-CER,CHIP
2203-000254 C532 C-CER,CHIP
2203-000254 C534 C-CER,CHIP
2203-000254 C881 C-CER,CHIP
2203-000386 C528 C-CER,CHIP
2203-000386 C537 C-CER,CHIP
2203-000386 C542 C-CER,CHIP
2203-000425 C451 C-CER,CHIP
2203-000425 C452 C-CER,CHIP
2203-000438 C235 C-CER,CHIP
2203-000438 C447 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-7
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
2203-000438 C479 C-CER,CHIP
2203-000438 C879 C-CER,CHIP
2203-000466 C184 C-CER,CHIP
2203-000466 C228 C-CER,CHIP
2203-000725 C480 C-CER,CHIP
2203-000812 C103 C-CER,CHIP
2203-000812 C112 C-CER,CHIP
2203-000812 C117 C-CER,CHIP
2203-000812 C118 C-CER,CHIP
2203-000812 C224 C-CER,CHIP
2203-000812 C700 C-CER,CHIP
2203-000812 C701 C-CER,CHIP
2203-000812 C702 C-CER,CHIP
2203-000812 C704 C-CER,CHIP
2203-000812 C905 C-CER,CHIP
2203-000995 C221 C-CER,CHIP
2203-001153 C529 C-CER,CHIP
2203-001153 C538 C-CER,CHIP
2203-001153 C543 C-CER,CHIP
2203-001383 C109 C-CER,CHIP
2203-001383 C201 C-CER,CHIP
2203-001383 C238 C-CER,CHIP
2203-001385 C175 C-CER,CHIP
2203-002668 C116 C-CER,CHIP
2203-002668 C177 C-CER,CHIP
2203-002668 C185 C-CER,CHIP
2203-002668 C191 C-CER,CHIP
2203-002677 C180 C-CER,CHIP
2203-002709 C540 C-CER,CHIP
2203-002709 C541 C-CER,CHIP
2203-002709 C545 C-CER,CHIP
2203-002709 C554 C-CER,CHIP
2203-002709 C886 C-CER,CHIP
2203-002709 C887 C-CER,CHIP
2203-005052 C226 C-CER,CHIP
2203-005056 C222 C-CER,CHIP
2203-005234 C189 C-CER,CHIP
2203-005682 C114 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-8
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
2203-005682 C140 C-CER,CHIP
2203-005682 C142 C-CER,CHIP
2203-005682 C143 C-CER,CHIP
2203-005682 C144 C-CER,CHIP
2203-005682 C145 C-CER,CHIP
2203-005682 C147 C-CER,CHIP
2203-005682 C173 C-CER,CHIP
2203-005682 C183 C-CER,CHIP
2203-005682 C195 C-CER,CHIP
2203-005682 C206 C-CER,CHIP
2203-005719 C901 C-CER,CHIP
2203-005725 C101 C-CER,CHIP
2203-005725 C104 C-CER,CHIP
2203-005725 C120 C-CER,CHIP
2203-005725 C125 C-CER,CHIP
2203-005725 C127 C-CER,CHIP
2203-005725 C136 C-CER,CHIP
2203-005725 C156 C-CER,CHIP
2203-005725 C159 C-CER,CHIP
2203-005725 C160 C-CER,CHIP
2203-005725 C161 C-CER,CHIP
2203-005725 C164 C-CER,CHIP
2203-005725 C165 C-CER,CHIP
2203-005727 C174 C-CER,CHIP
2203-005732 C123 C-CER,CHIP
2203-005732 C131 C-CER,CHIP
2203-005736 C100 C-CER,CHIP
2203-005736 C119 C-CER,CHIP
2203-005736 C122 C-CER,CHIP
2203-005736 C137 C-CER,CHIP
2203-005736 C150 C-CER,CHIP
2203-005736 C151 C-CER,CHIP
2203-005736 C155 C-CER,CHIP
2203-005736 C158 C-CER,CHIP
2203-005736 C162 C-CER,CHIP
2203-005736 C204 C-CER,CHIP
2203-005736 C424 C-CER,CHIP
2203-005740 C129 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-9
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
2203-005740 C132 C-CER,CHIP
2203-005777 C187 C-CER,CHIP
2203-005777 C193 C-CER,CHIP
2203-005777 C197 C-CER,CHIP
2203-005777 C199 C-CER,CHIP
2203-005779 C194 C-CER,CHIP
2203-005779 C203 C-CER,CHIP
2203-005789 C141 C-CER,CHIP
2203-005792 C135 C-CER,CHIP
2203-005792 C146 C-CER,CHIP
2203-005806 C107 C-CER,CHIP
2203-005806 C170 C-CER,CHIP
2203-005806 C192 C-CER,CHIP
2203-005806 C207 C-CER,CHIP
2203-005806 U805 C-CER,CHIP
2203-006047 C902 C-CER,CHIP
2203-006048 C233 C-CER,CHIP
2203-006048 C239 C-CER,CHIP
2203-006048 C240 C-CER,CHIP
2203-006048 C404 C-CER,CHIP
2203-006048 C405 C-CER,CHIP
2203-006048 C406 C-CER,CHIP
2203-006048 C407 C-CER,CHIP
2203-006048 C408 C-CER,CHIP
2203-006048 C409 C-CER,CHIP
2203-006048 C410 C-CER,CHIP
2203-006048 C411 C-CER,CHIP
2203-006048 C414 C-CER,CHIP
2203-006048 C426 C-CER,CHIP
2203-006048 C448 C-CER,CHIP
2203-006048 C450 C-CER,CHIP
2203-006048 C470 C-CER,CHIP
2203-006048 C520 C-CER,CHIP
2203-006048 C522 C-CER,CHIP
2203-006048 C602 C-CER,CHIP
2203-006048 C603 C-CER,CHIP
2203-006048 C607 C-CER,CHIP
2203-006048 C608 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-10
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
2203-006048 C610 C-CER,CHIP
2203-006048 C703 C-CER,CHIP
2203-006048 C800 C-CER,CHIP
2203-006048 C801 C-CER,CHIP
2203-006048 C802 C-CER,CHIP
2203-006048 C815 C-CER,CHIP
2203-006048 C842 C-CER,CHIP
2203-006048 C849 C-CER,CHIP
2203-006048 C850 C-CER,CHIP
2203-006048 C851 C-CER,CHIP
2203-006048 C856 C-CER,CHIP
2203-006048 C857 C-CER,CHIP
2203-006048 C863 C-CER,CHIP
2203-006048 C864 C-CER,CHIP
2203-006048 C870 C-CER,CHIP
2203-006048 C873 C-CER,CHIP
2203-006048 C875 C-CER,CHIP
2203-006048 C877 C-CER,CHIP
2203-006048 C882 C-CER,CHIP
2203-006048 C885 C-CER,CHIP
2203-006048 C895 C-CER,CHIP
2203-006048 C896 C-CER,CHIP
2203-006048 C899 C-CER,CHIP
2203-006048 C900 C-CER,CHIP
2203-006048 C903 C-CER,CHIP
2203-006048 C906 C-CER,CHIP
2203-006123 C133 C-CER,CHIP
2203-006123 C134 C-CER,CHIP
2203-006194 C108 C-CER,CHIP
2203-006194 C130 C-CER,CHIP
2203-006194 C198 C-CER,CHIP
2203-006194 C209 C-CER,CHIP
2203-006208 C420 C-CER,CHIP
2203-006257 C466 C-CER,CHIP
2203-006257 C467 C-CER,CHIP
2203-006257 C489 C-CER,CHIP
2203-006257 C490 C-CER,CHIP
2203-006260 C874 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-11
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
2203-006348 C454 C-CER,CHIP
2203-006348 C486 C-CER,CHIP
2203-006399 C220 C-CER,CHIP
2203-006399 C223 C-CER,CHIP
2203-006399 C440 C-CER,CHIP
2203-006399 C441 C-CER,CHIP
2203-006399 C449 C-CER,CHIP
2203-006399 C455 C-CER,CHIP
2203-006399 C463 C-CER,CHIP
2203-006399 C465 C-CER,CHIP
2203-006399 C484 C-CER,CHIP
2203-006399 C803 C-CER,CHIP
2203-006399 C804 C-CER,CHIP
2203-006399 C805 C-CER,CHIP
2203-006399 C806 C-CER,CHIP
2203-006399 C807 C-CER,CHIP
2203-006399 C808 C-CER,CHIP
2203-006399 C809 C-CER,CHIP
2203-006399 C810 C-CER,CHIP
2203-006399 C811 C-CER,CHIP
2203-006399 C824 C-CER,CHIP
2203-006399 C828 C-CER,CHIP
2203-006399 C838 C-CER,CHIP
2203-006399 C843 C-CER,CHIP
2203-006399 C844 C-CER,CHIP
2203-006399 C852 C-CER,CHIP
2203-006399 C853 C-CER,CHIP
2203-006399 C854 C-CER,CHIP
2203-006399 C855 C-CER,CHIP
2203-006399 C858 C-CER,CHIP
2203-006399 C865 C-CER,CHIP
2203-006399 C866 C-CER,CHIP
2203-006399 C867 C-CER,CHIP
2203-006399 C876 C-CER,CHIP
2203-006399 C878 C-CER,CHIP
2203-006399 C880 C-CER,CHIP
2203-006399 C883 C-CER,CHIP
2203-006399 C884 C-CER,CHIP
