Samsung Gear Fit2 SM-R360 User manual

SM-R360
User Manual

Legal
WARNING! This product contains chemicals known to the State of California to cause cancer, birth defects, or other
reproductive harm. For more information, please call 1-800-SAMSUNG (726-7864).
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers
relating to the SAMSUNG mobile device, including but not limited to, accessories, parts, or software relating thereto (the“mobile
device”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual
Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software,
computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate
the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare
derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No
title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain
with SAMSUNG and its suppliers.
i
WEA_R360_EN_UM_TN_PDK_062016_FINAL WEA_R360_EN_UM_TN_PDK_062016_FINAL WEA_R360_EN_UM_TN_PDK_062016_FINAL WEA_R360_EN_UM_TN_PDK_062016_FINAL
WEA_R360_EN_UM_TN_PDK_062016_FINAL
Notice: Water-resistant and dust resistant based on IP68 rating, which tests submersion up to 5.0 feet for up to
30minutes.

Open Source Software
Some software components of this product, including but not limited to‘PowerTOP’ and‘e2fsprogs’, incorporate source code covered
under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other open
source licenses. To obtain the source code covered under the open source licenses, please visit: opensource.samsung.com
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT “AS IS”, AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER
WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR
ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT;
THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION
MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE
PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE
OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.
ii

iii
Modification of Software
SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS, OR
YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.
USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY. YOUR CARRIER
MAY NOT PERMIT USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH AS CUSTOM OS.
Samsung KNOX
Samsung KNOX™ is Samsung’s security platform and is a mark for a Samsung device tested for security with enterprise use in mind.
Additional licensing fee may be required. For more information about KNOX, please refer to: samsung.com/us/knox [041516]

Samsung Electronics America (SEA), Inc.
Address :
85 Challenger Road
Ridgefield Park,
New Jersey 07660
Phone:
1-800-SAMSUNG (726-7864)
Internet Address :
samsung.com
©2016 Samsung Electronics America, Inc. Samsung, Samsung Galaxy, and SHealth are all trademarks of SamsungElectronics Co., Ltd.
Other marks are the property of their respective owners.
Notice: Screen images are simulated. Appearance of device may vary.
iv

Do you have questions about your Samsung Mobile Device?
For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at: samsung.com/us/support
The actual available capacity of the internal memory is less than the specified capacity because the operating system and default
applications occupy part of the memory. The available capacity may change when you upgrade the device.
Legal Information
Important legal information can be accessed at samsung.com
READ THIS INFORMATION BEFORE USING YOUR MOBILE DEVICE.
v

Samsung Limited Warranty
Samsung Limited Warranty - This product is covered under the applicable Samsung Limited Warranty INCLUDING ITS DISPUTE
RESOLUTION PROCEDURE and your right to opt out of arbitration within 30 calendar days of the first consumer purchase. You
may opt out by either sending an email to [email protected].com with the subject line “Arbitration Opt-Out” or by calling
1-800-SAMSUNG (726-7864). For more detailed procedures, please refer to the “Dispute Resolution Procedures and Arbitration and
Opt-Out”section of the Limited Warranty.
The EULA for this device is found in the Gear Fit 2 Manager application, which is required for operation of your device.
You may also access this EULA at: samsung.com/us/Legal/SamsungLegal-EULAGear Fit 2
vi

Table of Contents
Basics
1 Read me first
5 Device layout
9 Battery
13 Wear the Gear
15 Replace the strap
18 Connect the Gear to a Smartphone
21 Use the Gear without a Smartphone
22 Remote connection
23 Turn the screen on and off
24 Touchscreen
28 Navigate the screen
30 Home screen
36 Status panel
40 Set the screen lock
41 Answer calls
43 Update the Gear
vii

59 Find My Phone
Applications
44 Music Player
47 Health management apps
48 24-hour Log
49 Exercise
51 Steps
52 Floors
53 Heart Rate
56 Together
57 Water
58 Caffeine
60 Timer
61 Stopwatch
Settings
62 Introduction
63 Display
64 Vibration
64 Device
65 Connections
viii

69 Screen lock 77 Apps layout
69 Power saving 78 Send Music to Gear
71 Profile 79 Settings
71 Health nudges 84 Find My Gear
72 Gear info 86 Galaxy Apps
ix
Samsung Gear App
73 Introduction
75 Watch faces
76 Notifications

Basics
Read me first
Please read this manual before using this device to ensure safe and proper use.
• Descriptions are based on the device’s default settings.
• Some content may differ from your device depending on the region, model specifications, or device’s software.
• Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device.
Apps related to the content may not work properly depending on the device’s specifications and the environment that it
is used in.
• Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung.
• Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating
system software. Attempting to customise the operating system may cause the Gear or apps to work improperly.
• Software, sound sources, wallpapers, images, and other media provided with this Gear are licensed for limited use.
Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are
entirely responsible for illegal use of media.
1

Basics
• Default apps that come with the Gear are subject to updates and may no longer be supported without prior notice. If you have
questions about an app provided with the Gear, contact a Samsung Service Centre. For user-installed apps, contact service
providers.
• Modifying the Gear’s operating system or installing software from unofficial sources may result in Gear malfunctions and data
corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty.
• Some functions may not work as described in this manual depending on the make and model of the smartphone you connect
to the Gear.
2

Basics
Maintaining Water and DustResistance
This device is rated IP68 using the Ingress Protection rating system.
Your device has been tested in a controlled environment and shown to be water and dust resistant in certain circumstances (meets
requirements of classification IP68 as described by the international standard IEC 60529 - Degrees of Protection provided by Enclosures
[IP Code]; test conditions: 15-35°C, 86-106 kPa, 5.0 feet, for 30minutes). Despite this classification, your device is not impervious to
water damage in any situation. It is important that all compartments are closed tightly.
Follow these tips carefully to prevent damage to the device.
• Whenever your device gets wet, dry it thoroughly with a clean, soft cloth.
• Do not expose the device to salt water or ionized water, or to water over 5.0 feet deep for more than 30 minutes. If your device is
exposed to fresh water, dry it thoroughly with a clean, soft cloth. If the device is exposed to any liquid other than fresh water, rinse
the device with fresh water immediately and dry it thoroughly with a clean, soft cloth. Failure to rinse the device in fresh water and
dry it as instructed may cause the device to suffer from operability or cosmetic issues.
• Do not expose the device to water at high pressure.
• If the device is dropped or receives an impact, the water and dust resistant features of the device may be damaged.
• The touchscreen and other features may not work properly if the device is used in water or in other liquids.
3
Water-resistant and dust resistant based on IP68rating, which tests submersion up to 5.0 feet for up to 30 minutes.

Basics
Instructional icons
Warning: Situations that could cause injury to yourself or others.
Caution: Situations that could cause damage to your device or other equipment.
Notice: Notes, usage tips, or additional information.
4

Back key
Home key
(Power key)
Basics
Device layout
Front
5

Charging terminal
Heart rate sensor
s
Basics
Back
6

Basics
Keys
Key Function
Home
• Press and hold to turn the device on or off.
• Press to turn on the screen.
• Press and hold for more than 7 seconds to restart the device.
• Press to open the Apps screen when you are on the Watch screen.
• Press to open the Watch screen when you are on any other screen.
Back • Press to return to the previous screen.
7

Charging terminals
Basics
Charger dock
Do not expose the Gear or the charger dock to water. The devices are not completely waterproof.
8

Basics
Battery
Charge the battery
Charge the battery before using it for the first time or when it sits unused for extended periods.
1 Connect the USB cable to the USB charger head. Then, connect the other end of the USB cable to the charger dock.
2 Plug the USB charger head into an electric socket.
9
Charging head for plugging in USB cable into wall outlet is not included. Use only Samsung charging devices rated with
an output voltage of 5v and an output current of over 150mA (sold separately). Samsung accessories are designed for your
device to maximize battery life. Using other accessories may invalidate your warranty and may cause damage.

Charger dock
Basics
3 Place the device on the charger dock with the charging terminals facing each other.
4 After fully charging your Gear, disconnect it from the charger dock. Unplug the charger from the charger dock, and then unplug
the charger from the electric socket.
10
