Samsung SM-R381 User manual

www.samsung.com
User Manual
SM-R381

2
About this manual
You can use this Gear as a companion device to some Samsung Android™mobile devices.
This user manual is specially designed to explain applications and features that are available
when the Gear is connected to a mobile device.
•
Please read this manual before using the Gear to ensure safe and proper use.
•
Descriptions are based on the Gear’s default settings.
•
Images and screenshots may differ in appearance from the actual product.
•
Content may differ from the final product, or from software provided by service providers
or carriers, and is subject to change without prior notice. For the latest version of the
manual, refer to the Samsung website,
www.samsung.com .
•
Available features and additional services may vary by Gear, software, or service provider.
•
Applications and their functions may vary by country, region, or hardware specifications.
Samsung is not liable for performance issues caused by applications from any provider
other than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the Gear or applications to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this Gear
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
•
Default applications that come with the Gear are subject to updates and may no longer
be supported without prior notice. If you have questions about an application provided
with the Gear, contact a Samsung Service Centre. For user-installed applications, contact
service providers.
•
Modifying the Gear’s operating system or installing softwares from unofficial sources may
result in Gear malfunctions and data corruption or loss. These actions are violations of
your Samsung licence agreement and will void your warranty.

About this manual
3
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Note: notes, usage tips, or additional information
Copyright
Copyright © 2014 Samsung Electronics
This guide is protected under international copyright laws.
No part of this guide may be reproduced, distributed, translated, or transmitted in any form or
by any means, electronic or mechanical, including photocopying, recording, or storing in any
information storage and retrieval system, without the prior written permission of Samsung
Electronics.
Trademarks
•
SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics.
•
Bluetooth®is a registered trademark of Bluetooth SIG, Inc. worldwide.
•
All other trademarks and copyrights are the property of their respective owners.

4
Table of Contents
Getting started
6 About Gear 2 Neo
6 Package contents
7 Device layout
8 Button
10 Charging the battery
13 Wearing the Gear
14 Replacing the strap
17 Turning the Gear on and off
18 Notices for using Bluetooth
19 Connecting the Gear to a mobile
device
21 Locking and unlocking the Gear
21 Adjusting the brightness of the display
21 Adjusting the volume
21 Switching to silent mode
Basics
22 Viewing mobile device connection
status and battery status
22 Using the touch screen
26 Viewing the Home screen
30 Apps screen
30 Using applications
31 Securing the Gear
31 Using calling features
33 Using notifications
35 Transferring files
35 Upgrading the Gear
Applications
37 S Voice
38 WatchON Remote
39 Gallery
40 Weather
40 Find My Device
41 Health Management Applications
44 Pedometer
45 Sleep
47 Heart Rate
48 Exercise
52 Messages
53 Music Player
54 Media Controller
55 Stopwatch
55 Contacts
56 Voice Memo
57 Email
58 Schedule
58 Controls
58 Logs
58 Timer

Table of Contents
5
Settings
59 Clock
59 Wallpapers
59 Notifications
60 Sound
60 Display
61 Bluetooth
61 Blocking mode
61 Double press
61 Privacy lock
62 Profile
62 Reset Gear
62 Gear info
Gear Manager
63 Launching Gear Manager
63 Connecting a new Gear
63 Configuring the Gear settings
64 Home screen styler
64 S Health
65 Notifications
65 My apps
66 Samsung Apps
67 Find my Gear
67 Settings
69 Help
Troubleshooting

6
Getting started
About Gear 2 Neo
When you connect the Gear 2 Neo (also referred to as Gear) to your mobile device, you can
use the Gear to view call logs or set alarms. You can use mobile devices more conveniently by
connecting to various applications with the Gear. Set your exercise programme and manage
your health by connecting the Gear to a mobile device.
To connect your Gear to a mobile device, install Gear Manager on the mobile device. Search
for
Gear Manager from Samsung Apps or visit apps.samsung.com/gear2 to download it.
Package contents
Check the product box for the following items:
•
Gear
•
Charging dock
•
Quick start guide
•
The items supplied with the Gear and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this Gear and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the Gear before purchase.
•
Other accessories may not be compatible with your Gear.
•
Use only Samsung-approved accessories. Malfunctions caused by using
unapproved accessories are not covered by the warranty service.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.

Getting started
7
Device layout
Gear
Infrared LED
Power button
Speaker
Heart rate sensor
Charging terminals
Microphone
•
Humidity and liquids may damage your Gear. Keep your Gear dry.
•
Ensure that the strap is kept clean. Contact with contaminants, such as dust and
dye, can cause stains on the strap that may not be fully removed.
•
Do not use a screen protector. This causes touch screen sensor malfunctions.
•
Do not allow water to contact the touch screen. The touch screen may malfunction
in humid conditions or when exposed to water.
•
If the speaker is wet, sound may be distorted. Ensure that the speaker is dry.

Getting started
8
Charging dock
Multipurpose jack
Charging terminals
Button
Button Function
Power
•
Press and hold to turn the Gear on or off.
•
Press to move to the Clock screen.
•
Press to lock the Gear on the Clock screen.
•
Press and hold for more than 7 seconds to reset the Gear.

Getting started
9
Maintaining water and dust resistance
The device may be damaged if water or dust enters the device. Follow these tips carefully to
prevent damage to the device and to maintain the water- and dust-resistant performance of
the device.
•
Do not immerse the device in water deeper than 1 m and keep it submerged for more
than 30 minutes.
•
Do not expose the device to water moving with force, such as water running from a tap,
ocean waves, or waterfalls.
•
If the device or your hands are wet, dry them thoroughly before handling the device.
•
If the device is exposed to freshwater, dry it thoroughly with a clean, soft cloth. If the
device is exposed to any liquid other than freshwater, rinse the device with freshwater
immediately and dry it thoroughly with a clean, soft cloth. Failure to rinse the device
in freshwater and dry it as instructed may cause the device to suffer from operability
or cosmetic issues.
•
If the device is dropped or receives an impact, the water- and dust-resistant features of
the device may be damaged.
•
If the device has been immersed in water or the microphone or the speaker is wet,
sound may not be heard clearly during a call. Ensure that the microphone or the speaker
is clean and dry by wiping it with a dry cloth.
•
The touch screen and other features may not work properly if the device is used in water
or in other liquids.
•
Your device has been tested in a controlled environment and shown to be water- and
dust-resistant in certain circumstances (meets requirements of classification IP67 as
described by the international standard IEC 60529 - Degrees of Protection provided by
Enclosures [IP Code]; test conditions: 15 - 35 °C, 86 - 106 kPa, 1 metre, for 30 minutes).
Despite this classification, your device is not impervious to water damage in any
situation.

Getting started
10
Charging the battery
Charge the battery before using the Gear for the first time. A computer can be also used to
charge the Gear by connecting them via the USB cable.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the Gear.
•
When the battery power is low, the battery icon appears empty.
•
If the battery is completely discharged, the Gear cannot be turned on immediately
when the charger is connected. Allow a depleted battery to charge for a few
minutes before turning on the Gear.
•
The charging dock provided with the Gear is used for charging the Gear’s battery.
Take care not to lose the dock.
1 Confirm the location of the charging terminals on the Gear and the charging dock.
Charging terminals
Charging dock

Getting started
11
2 Place the Gear on the charging dock with the charging terminals facing each other.
3 Plug the small end of the charger cable into the multipurpose jack of the charging dock.
Then, plug the large end of the charger into an electric socket.

Getting started
12
After fully charging, disconnect the Gear from the charging dock.
Connecting the charger improperly may cause serious damage to the Gear. Any
damage caused by misuse is not covered by the warranty.
•
While charging, some features are not available.
•
If the Gear receives an unstable power supply while charging, the touch screen
may not function. If this happens, unplug the charger from the Gear.
•
While charging, the Gear may heat up. This is normal and should not affect the
Gear’s lifespan or performance. If the battery gets hotter than usual, the charger
may stop charging.
•
If the Gear is not charging properly, take the Gear and the charger to a Samsung
Service Centre.
•
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.

Getting started
13
About using battery
•
Battery operating time is affected by device usage patterns and the condition of the
battery.
•
The battery is a consumable item. Battery life can be reduced when multiple applications
or features are running simultaneously. Also, even if the device is not being used, battery
life may be reduced.
•
The battery is consumable and the useful charge will get shorter over time.
•
Battery power can also be affected when you play high-definition video. The affects on
battery power may vary depending on the situation.
Wearing the Gear
1 Release the buckle.
•
Be careful not to damage your fingernails when you release the clasp.
•
Do not bend the strap excessively. Doing so may damage the device.

Getting started
14
2 Open the clasp, fit the strap to your wrist with the pin, and press the buckle to close.
1
2
Pin
To measure your heart rate more accurately with the Gear, wear the Gear firmly
around your lower arm just above the wrist. Refer to‘Wearing the Gear’for details.
Replacing the strap
Detach the strap from the Gear to replace it with a new one.
1 Slide the latch on the strap inwards.

Getting started
15
2 Detach the end of the strap from the Gear.
3 On the new strap, insert one side of the pin into the recess at the side of the Gear.

Getting started
16
4 Slide the latch on the strap inwards. Then, insert the pin into the recess at the other side
of the Gear.
1
2
If you are fitting a strap that is not manufactured by Samsung refer to the image below.
Insert one end of the pin into a recess and press the other end of the pin inwards. Press
the pin inwards using your finger or a tool, such as a small flat-tip screwdriver. Then, while
pressing the pin inwards move the strap into position between the device’s recesses.
Release you finger or remove the tool when the pin is held in place between the device
and the strap. Adjust the strap until the pin is sitting inside each recess.
1
2

Getting started
17
Turning the Gear on and off
When you turn on the Gear for the first time, follow the on-screen instructions. The
instructions describe how to connect the Gear to a mobile device and to set up the Gear.
Press and hold the Power button for a few seconds to turn on the Gear. A pop-up window
appears providing on-screen instructions that prompt you to download and install Gear
Manager. You can use the Gear only after Gear Manager is installed on the mobile device.
Refer to‘Connecting the Gear to a mobile device’for details.
Follow all posted warnings and directions from authorised personnel in areas where
the use of wireless devices is restricted, such as aeroplanes and hospitals.
To turn off the Gear, press and hold the Power button, and then tap
Power off .

Getting started
18
Notices for using Bluetooth
•
To avoid problems when connecting your Gear to another mobile device, place the
devices close to each other.
•
Ensure that your Gear and the other Bluetooth device are within the Bluetooth
connection range (10 m). The distance may vary depending on the environment the
devices are used in.
•
Ensure that there are no obstacles between your Gear and a connected mobile device,
including human bodies, walls, corners, or fences.
•
Do not touch the Bluetooth antenna of a connected mobile device.
•
Bluetooth uses the same frequency as some industrial, scientific, medical, and low power
products and interference may occur when making connections near these types of
products.
•
Samsung is not responsible for the loss, interception, or misuse of data sent or received
via the Bluetooth feature.
•
Always ensure that you share and receive data with devices that are trusted and properly
secured. If there are obstacles between the devices, the operating distance may be
reduced.
•
Some devices, especially those that are not tested or approved by the Bluetooth SIG, may
be incompatible with your Gear.
•
Do not use the Bluetooth feature for illegal purposes (for example, pirating copies of files
or illegally tapping communications for commercial purposes).
Samsung is not responsible for the repercussion of illegal use of the Bluetooth feature.

Getting started
19
Connecting the Gear to a mobile device
Install Gear Manager on the mobile device and connect the Gear to the device via Bluetooth.
•
You cannot install Gear Manager on mobile devices that do not support Gear
syncing. Ensure that your mobile device is compatible with a Gear.
•
You can connect only one mobile device to one Gear. You cannot use multiple
Gears at the same time.
1 Gear Turn on the Gear.
2 Gear Read the download information in the pop-up window and tap
Next . The Gear’s
model details appear.
3 Mobile device Download
Gear Manager from Samsung Apps .
You can also visit
apps.samsung.com/gear2 to download Gear Manager .
4 Mobile device On the Apps screen, tap
Gear Manager .
5 Mobile device Select the Gear model name (e.g. Gear 2 Neo (0000)) that appeared in
Step 2.
6 Mobile device When the
Bluetooth pairing request window appears, tap OK .

Getting started
20
Gear When the connection window appears, tap OK .
7 Mobile device The
Install window opens.
8
Mobile device Read and agree to the terms and conditions, and follow the on-screen
instructions.
•
When the devices are connected, Gear Manager launches on the mobile device. Then,
on the Gear, read the on-screen information about the pedometer and tap
OK . The
Clock screen appears on the Gear.
•
The Gear Manager application guide opens.
•
You can adjust the Gear’s configuration in Gear Manager.
•
Connection methods and screenshots may vary depending on the type of device
and the device’s software version.
•
When connecting the Gear to another mobile device
If you want to connect the Gear to a newly purchased mobile device or to another
mobile device for the first time, reset the Gear. Resetting the Gear will remove the
data from the memory. After the reset, you can connect the Gear to a different
mobile device.
