Samsung SM-R750B User manual

English (SEA). 10/2014. Rev.1.0 www.samsung.com
User Manual
SM-R750B

2
Table of Contents
Read me first
Getting started
7 About the Gear S
7 Package contents
8 Device layout
10 Using the SIM card
15 Wearing the Gear
16 Replacing the strap
18 Turning the Gear on and off
18 Connecting the Gear to a mobile
device
21 Notices for using Bluetooth
22 Turning on or off the screen
22 Adjusting the brightness of the display
23 Adjusting the volume
23 Switching to silent mode
Basics
24 Using the touchscreen
27 Basic controls
29 Home screen layout
33 Setting the privacy lock
34 Using notifications
35 Entering text
37 Motions
38 Power saving feature
39 Transferring files between the Gear
and a computer
40 Upgrading the Gear
Network & communication
42 Mobile data
42 Wi-Fi
43 Remote connection
43 Phone
48 Contacts
49 Messages
50 Email
Useful apps
51 S Health
62 S Voice
64 Schedule
64 Navigator
65 Running
66 Music Player
68 News Briefing
68 Weather
68 Alarm
69 Gallery
70 Find My Device

Table of Contents
3
Appendix
90 Troubleshooting
Settings
71 An introduction
71 Customising settings
71 Style
72 Call
73 Sound
73 Display
74 Connections
76 Notifications
76 Messages
76 Do not disturb
76 Double press
77 Privacy lock
77 Motions
77 Language & input
79 Power saving
79 Reset Gear
80 Gear info
Samsung Gear app
81 Samsung Gear
82 Home screen styler
82 Music
83 Image
83 Notifications
84 Samsung Gear Apps
84 Find My Gear
85 Settings
89 User manual

4
Read me first
Please read this manual before using this Gear to ensure safe and proper use.
•
Descriptions are based on the Gear’s default settings.
•
Some content may differ from the Gear depending on the region, service provider, or
device’s software.
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.
•
Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the Gear or apps to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this Gear
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
•
You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services depending on your data plan. For
large data transfers, it is recommended to use the Wi-Fi feature.
•
Default apps that come with the Gear are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the Gear, contact a Samsung Service Centre. For user-installed apps, contact service
providers.
•
Modifying the Gear’s operating system or installing softwares from unofficial sources may
result in Gear malfunctions and data corruption or loss. These actions are violations of
your Samsung licence agreement and will void your warranty.

Read me first
5
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Note: notes, usage tips, or additional information
Maintaining water and dust resistance
The device may be damaged if water or dust enters the device. Follow these tips carefully to
prevent damage to the device and to maintain the water- and dust-resistant performance of
the device.
•
Do not immerse the device in water deeper than 1 m and keep it submerged for more
than 30 minutes.
•
Do not expose the device to water moving with force, such as water running from a tap,
ocean waves, or waterfalls.
•
If the device or your hands are wet, dry them thoroughly before handling the device.
•
The rubber seal fitted to the SIM card cover is an important component of the device.
Take care when opening and closing the SIM card cover to avoid damaging the rubber
seal. Also, ensure that the rubber seal is free from debris, such as sand or dust to prevent
damage to the device.
•
If the device is exposed to freshwater, dry it thoroughly with a clean, soft cloth. If the
device is exposed to any liquid other than freshwater, rinse the device with freshwater
immediately and dry it thoroughly with a clean, soft cloth. Failure to rinse the device
in freshwater and dry it as instructed may cause the device to suffer from operability
or cosmetic issues.
•
If the device is dropped or receives an impact, the water-and dust-resistant features of
the device may be damaged.

Read me first
6
•
If the device has been immersed in water or the microphone or the speaker is wet,
sound may not be heard clearly during a call. Ensure that the microphone or the speaker
is clean and dry by wiping it with a dry cloth.
•
The touchscreen and other features may not work properly if the device is used in water
or in other liquids.
•
Your device has been tested in a controlled environment and certified to be water-
and dust-resistant in specific situations (meets requirements of classification IP67 as
described by the international standard IEC 60529 - Degrees of Protection provided
by Enclosures [IP Code]; test conditions: 15 - 35°C, 86 - 106 kPa, 1 metre, 30 minutes).
Despite this classification, your device is not impervious to water damage in any
situation.
Overheat precautions
To avoid device malfunction, skin discomfort or damage, and battery draining, an initial
warning will appear on the device if it reaches a specific temperature. If the device
temperature continues to rise, a second warning will appear, at which time all calls and device
functions will be disabled until the device cools down to a specific temperature, except for
outgoing emergency calls.
If you are on an emergency call when the second warning appears, the call will remain active
until terminated. If the device temperature rises further, a third warning will appear; at this
time, the entire device will shut down. Any emergency call that is connected at the time will
remain active until you terminate the call. However, no new calls, including emergency calls,
may be made until device cools down to a specific temperature.
If you feel discomfort while using the device, stop using it and remove it from your wrist.

7
Getting started
About the Gear S
Connecting the Gear S(also referred to as Gear) to your mobile device allows you to check
mobile device notifications, answer or make calls, view messages, and more.
After connecting the Gear to the mobile device via Bluetooth for the first time, you
can use the following features of the Gear, even when it is not connected to the
mobile device:
•
Receive mobile device notifications.
•
Use calling and messaging features.
Package contents
Check the product box for the following items:
•
Gear
•
Charging dock
•
Quick start guide
•
The items supplied with the Gear and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this Gear and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the Gear before purchase.
•
Some accessories, such as docking devices, may not have the same water- and
dust-resistance certification.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.

Getting started
8
Device layout
Gear
UV sensor
Light sensor
Power/Home key
Charging terminal
SIM card cover
Speaker
Heart rate sensor
Microphone
•
Humidity and liquids may damage your Gear. Keep your Gear dry.
•
Ensure that the strap is kept clean. Contact with contaminants, such as dust and
dye, can cause stains on the strap that may not be fully removed.
•
The UV sensor may not be supported in some regions.
•
If the speaker is wet, sound may be distorted. Ensure that the speaker is dry.
•
Make sure the microphone at the bottom right of the Gear is not covered by your
sleeve when speaking into the Gear.
•
The colours on the curved screen may look different depending on your viewing
position.

Getting started
9
Charging dock with battery
Multipurpose jack
LED indicator
Charging terminals
•
The charging dock also can be used as a supplementary battery. Charge the Gear
by connecting it to the charging dock.
•
Charging the Gear using the charging dock without a charger charges the battery
to less than half of the battery’s capacity. To fully charge the Gear, use the charger.
•
The charging dock can be independently charged when it is connected to the
charger. When the charging dock is connected with the Gear, both devices will
charge.
Key
Key Function
Power/Home
•
Press and hold to turn the Gear on or off.
•
Press to move to the Clock screen.
•
Press to turn on the screen.
•
Press and hold for more than 7 seconds to restart the Gear.

Getting started
10
Using the SIM card
Installing the SIM card
Insert the SIM card provided by the mobile telephone service provider.
•
Only nano-SIM cards work with the device.
•
The available features may differ depending on whether or not a SIM card is
installed.
1 Remove the SIM card cover.
SIM ejector tool
•
Use the SIM ejector tool when you open the SIM card cover to avoid damaging
your fingernail.
•
Use caution not to lose the SIM card cover and the SIM ejector tool.
2 Insert the SIM card on the inside of the SIM card cover with the gold-coloured contacts
facing outwards.

Getting started
11
3 Place the SIM card cover on the Gear and press the cover to close it.
Ensure that the SIM card cover is closed tightly to prevent water and dust entering
the device. Open or loose the cover may allow water and dust to enter the device and
cause damage.
After you install the SIM card, restart the Gear.
Removing the SIM card
1 Open the SIM card cover.
2 Pull out the SIM card.

Getting started
12
Charging the battery
Use the charger to charge the battery before using it for the first time. A computer can be also
used to charge the Gear by connecting them via the USB cable.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the Gear.
•
When the battery power is low, the battery icon appears empty.
•
If the battery is completely discharged, the Gear cannot be turned on immediately
when the charger is connected. Allow a depleted battery to charge for a few
minutes before turning on the Gear.
•
The charging dock provided with the Gear is used for charging the Gear’s battery.
Take care not to lose the dock.
•
Before charging the battery ensure that the charging terminals of the Gear and the
charging dock are free of foreign material, such as sweat, liquid, or dust. Clean the
charging terminals with a soft dry cloth.
1 Confirm the location of the charging terminals on the Gear and the charging dock.
Charging terminals
Charging dock with battery

Getting started
13
2 Connect the Gear to the charging dock with the charging terminals facing each other.
1
2
3 Plug the USB cable into the multipurpose jack of the charging dock.
4 Connect the USB cable to the USB power adaptor and plug it into an electric socket.
Connecting the charger improperly may cause serious damage to the Gear. Any
damage caused by misuse is not covered by the warranty.
•
While charging, some features are not available.
•
If the Gear receives an unstable power supply while charging, the touchscreen may
not function. If this happens, unplug the charger from the Gear.
•
While charging, the Gear may heat up. This is normal and should not affect the
Gear’s lifespan or performance. If the battery gets hotter than usual, the charger
may stop charging.
•
If the Gear is not charging properly, contact to a Samsung Service Centre.

Getting started
14
After fully charging, disconnect the Gear from the charging dock. Then, disconnect the
charging dock from the USB cable and unplug the USB power adapter from the electric
socket.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
Checking the charging dock’s battery level
When you connect the Gear and the charging dock, the LED indicator flashes one of the
colours listed below to indicate the battery level.
Battery level Indicator light colour
100–80% Blue
80–20% Green
20–5% Red
5–0% Red blinking
•
When a charging dock error occurs, the LED indicator flashes yellow. Contact a
Samsung Service Centre for service support.
•
To check the Gear’s battery level, view the Gear’s screen.

Getting started
15
About using battery
•
Battery operating time is affected by device usage patterns and the condition of the
battery.
•
The battery is a consumable item. Battery life can be reduced when multiple apps or
features are running simultaneously. Also, even if the device is not being used, battery life
may be reduced.
•
The battery is consumable and the useful charge will get shorter over time.
Reducing the battery consumption
Your Gear provides various options that help you conserve battery power.
•
When you are not using the Gear, switch to sleep mode by pressing the Home key.
•
Activate power saving mode.
•
Deactivate the Wi-Fi feature when not in use.
•
Decrease the backlight time.
•
Decrease the screen brightness.
•
Deactivate the clock always on feature.
•
Deactivate the voice wake-up feature in S Voice .
•
Customise the notification settings in Samsung Gear on the mobile device.
Wearing the Gear
1 Release the buckle.

Getting started
16
•
Be careful not to damage your fingernails when you release the clasp.
•
Do not bend the strap excessively. Doing so may damage the Gear.
2 Open the clasp and place the strap around your wrist. Fit the strap to your wrist, secure it
with the pin, and then press the buckle to close it.
1
2
Pin
To measure your heart rate more accurately with the Gear, wear the Gear firmly
around your lower arm just above the wrist. Refer to Wearing the Gear for details.
Replacing the strap
Detach the strap from the Gear to replace it with a new one.
1 Hold the Gear and pull the strap upwards to detach the Gear.

Getting started
17
2 Insert one end of the Gear into the mounting hole of a new strap. Then, insert the other
end of the Gear into the hole and pull the strap up at the same time.
1
2
3 Ensure that the Gear is sitting securely in the mounting hole and that it is properly
aligned with the strap.
3

Getting started
18
Turning the Gear on and off
When you turn on the Gear for the first time, follow the on-screen instructions. The
instructions describe how to connect the Gear to a mobile device and to set up the Gear.
Press and hold the Home key for a few seconds to turn on the Gear. A pop-up window
appears providing on-screen instructions that prompt you to download and install the
Samsung Gear app. You can use the Gear only after the Samsung Gear app is installed on the
mobile device. Refer to Connecting the Gear to a mobile device for details.
To turn off the Gear, press and hold the Home key, and then tap
Power off .
Follow all posted warnings and directions from authorised personnel in areas where
the use of wireless devices is restricted, such as aeroplanes and hospitals.
Connecting the Gear to a mobile device
Install the Samsung Gear app on the mobile device and connect the Gear to the device via
Bluetooth.
You cannot install the Samsung Gear app on the mobile devices that do not support
Gear syncing. Ensure that your mobile device is compatible with a Gear.
1 Gear Turn on the Gear.
2 Gear Read the download information in the pop-up window and tap
Next . The Gear’s
model details appear.

Getting started
19
3 Mobile device Download the Samsung Gear app from
GALAXY Apps .
You can also visit apps.samsung.com/gear to download the Samsung Gear app.
4 Mobile device On the All apps screen, tap
Samsung Gear .
5 Mobile device Select the Gear model name (for example, Gear S(0000)) that appeared
in Step 2.
6 Mobile device When the
Bluetooth pairing request window appears, tap OK .

Getting started
20
7 Gear When the connection window appears, tap
OK .
8 Mobile device When the legal notice window appears, follow the on-screen
instructions and tap
Finish .
9 Mobile device Tick items to receive notifications from and tap
OK .
When the devices are connected, the Samsung Gear app launches on the mobile device
and the Clock screen appears with a tutorial on the Gear.
When you establish the connection, the mobile device requests for you to sign in using
your Samsung account. If you sign in to your Samsung account, you can use the remote
connection feature when the Gear is not connected to the mobile device via Bluetooth.
