S&P CADB HE ECOWATT Series User manual

EN
CADB/T-HE ECOWATT 2018

3
INDEX
1. INTRODUCTION ....................................................................................................................................................4
2. SAFETY REGULATIONS AND “CE” MARKING ......................................................................................................4
3. GENERAL INSTRUCTIONS ...................................................................................................................................4
4. UNIT LABELLING .................................................................................................................................................4
5. HANDLING............................................................................................................................................................5
6. INSTALLATION......................................................................................................................................................6
6.1. Introduction....................................................................................................................................................6
6.1.1. Outdoor installation...........................................................................................................................10
6.2. Dimensions and free space for maintenance .............................................................................................11
6.3. Mounting process of an additional supply filter..........................................................................................13
6.4. Range specifications....................................................................................................................................14
6.5. Connections .................................................................................................................................................15
6.5.1. Connection with air duct ...................................................................................................................15
6.5.2. Connecting the water coil piping. DC versions.................................................................................15
6.5.3. Condensate drainage ........................................................................................................................16
6.6. Electrical connection...................................................................................................................................16
6.6.1. Connecting the motors......................................................................................................................16
6.6.2. Connecting the By-pass ....................................................................................................................20
6.6.3. Connecting the electric batteries......................................................................................................21
6.6.4. Connecting electrical accessories ....................................................................................................26
6.6.4.1. Manual VAV control (variable airflow) ..................................................................................27
6.6.4.1.1. 04 to 27 models: Manual adjustment by REB-ECOWATT (accessory) .................27
6.6.4.1.2. 33 to 100 models: Manual adjustment by REB-ECOWATT (accessory) ...............28
6.6.4.2. VAV Control (variable airflow), with CO2sensor or similar..................................................29
6.6.4.3. CAV control (Constant airflow) .............................................................................................29
6.6.4.4. COP Control (Constant pressure).........................................................................................31
6.6.4.5. Pressure switch connection.................................................................................................33
6.7. Reverse supply air/extract air side (only -D version)..................................................................................34
6.8. Configurations .............................................................................................................................................34
6.9. Control of cooling external batteries ..........................................................................................................36
6.9.1. Accesssories assembly .....................................................................................................................37
6.9.2. Coils characteristics..........................................................................................................................41
6.9.2.1. Cold water coils for 2 pipes installation...............................................................................41
6.9.2.2. Cold water coils for for 4 pipes installation.........................................................................41
6.9.2.3. Expansion coils for integration in DX systems.....................................................................42
7. INSPECTION, MAINTENANCE AND CLEANING.................................................................................................42
7.1. Filters...........................................................................................................................................................42
7.2. Filter installation .........................................................................................................................................44
7.3. Heat exchanger............................................................................................................................................45
7.4. Condensation drainpipe...............................................................................................................................46
8. OPERATION ANOMALIES ...................................................................................................................................47
8.1. General anomalies ......................................................................................................................................47

4
1. INTRODUCTION
Thank you for purchasing this appliance. It has been manufactured in full compliance with applica-
ble safety regulations and EU standards.
Please read this instruction book carefully, as it contains important information for your safety
during the installation, use and maintenance of this product.
Keep it at hand for future reference.
Please check that the appliance is in perfect condition when you unpack it, as all factory defects are
covered by the S&P guarantee.
2. SAFETY REGULATIONS AND “CE” MARKING
S&P technicians are firmly committed to research and development of ever more efficient products
and in compliance with current safety regulations.
The instructions and recommendations given below reflect current regulations, principally regar-
ding safety, and therefore are based on compliance with general regulations. Therefore, we recom-
mend all people exposed to hazards to strictly follow the safety regulations in force in your country.
S&P will not be held liable for any possible harm or damage caused by non-compliance with the
safety regulations, as well as caused by modifying the product.
The CE mark and the corresponding declaration of conformity are proof of the product’s conformity
with current EU regulations.
3. GENERAL INSTRUCTIONS
A hazard analysis of the product has been carried out as provided in the Machine Directive. This
manual contains information for all personnel exposed to these hazards, with the aim of preventing
possible harm or damage due to faulty handling or maintenance.
All maintenance operations (ordinary and extraordinary) must be carried out with the machine
switched off and the electrical power supply disconnected.
To avoid a possible accidental start up, place a warning notice on the electrical control panel with
the following text:
“Attention: control disconnected for maintenance operations”
Before connecting the power supply cable to the terminal strip, make sure the mains voltage co-
rresponds to the voltage indicated on the specifications plate of the unit.
Regularly check the product labels. If, due to the passing of time, they are no longer legible, they
must be replaced.
4. UNIT LABELLING
The machine may come with several pictograms that must not be removed. These signs are divided
into:
• Prohibition signs: Do not repair or adjust when in operation.
• Danger signs: Warning of the presence of live elements inside the container bearing the sign.
• Identification signs: CE card, indicating product information and manufacturer’s address. The
CE mark indicates the product’s conformity with EEC standards.

5
Danger signs Prohibition signs
5. HANDLING
The CADB/T-HE models 04 to 33 are delivered fixed with screws to the pallets.
The models 45 to 100 are equipped with a bed, due to its weight are supplied without pallets. The
unit can be handled by a pallet transporter, a forklift, or a crane.
The handling machines will be adapted to the load and the lifting conditions. In all cases, the lifting
will be done at the device’s base. The centre of gravity is located at the centre of the unit. The device
must be carefully manipulated only in the horizontal position.
Models 04 to 33
Models 45 to 100

6
6. INSTALLATION
6.1. INTRODUCTION
Horizontal models size 04, 08, 12, 16, 21, 27 and 33
These models are designed to be installed hanging from the ceiling or located behind a false ceiling.
When installing the unit, is mandatory to distribute the unit weigh between all the supports existing
in the units:
• CADB-HE 04: 4 supports (one in each corner)
• CADB/T-HE 08 to 33: 6 supports (one in each corner and 2 centered in each side)
Using studded rods (Ø 8 mm), it can be secured to the ceiling and levelled.
BdYZa%) BdYZah%-id((
B
C
AA
Ø12
Model A B C
4- 1558 798
8894 1788 948
12 869 1738 1088
16 994 1988 1278
21 1169 2338 1678
27 1169 2338 1678
33 1169 2338 1678
The model 04 does not have central support
The installer must make sure that the ceiling structure and the securing elements can bear the
weight of the device, taking into account that it is a dynamic load.
To prevent the transmission of vibrations from the unit to the rest of the installation, it is necessary
that the installer use specific isolation elements, such as antivibration devices in the supports,
flexible sleeves between the unit and the ducts, and flexible couplings between the water connec-
tions and the pipelines.
Model Weight (kg)
4 137
8 173
12 180
16 225
21 323
27 360
33 410

7
Vertical models
The models size 4 to 33 are supplied with support feet, while the models size 45 to 100 are supplied
with a perimetral bed. This bed must be in contact with the ground or with a fl at surface. It is es-
sential that the weight of the equipment is distributed between all points of support to prevent unit
deformation.
The installer must make sure that the ceiling structure and the securing elements can bear the
weight of the unit, taking into account that it is a dynamic load.
Models 04 to 33
Model Weight (kg)
4 139
8 175
12 182
16 227
21 325
33 412
Models 45, 60 and 100
Model Weight (kg)
45 577
60 710
100 842
Horizontal models of sizes 45 and 60
IMPORTANT!
Particularities in the installation of horizontal versions LH and RH
For a correct evacuation of condensation generated into the heat exchanger, it is necessary to ins-
tall the unit with a minimum slope of 3º to the side where the extraction fan is placed:

8
SUPPLY FAN EXHAUST FAN
Horizontal models size 45 and 60 are supplied with a perimetral bed. This bed must be in contact
with the ground or with a flat surface. It is essential that the weight of the equipment is distributed
between all points of support to prevent unit deformation.
The installer must make sure that the ceiling structure and the securing elements can bear the
weight of the unit, taking into account that it is a dynamic load.
Model Weight (kg)
45 577
60 710
For all configurations
Once secured the device in correct position, the installer have to realise the connection with air
duct, connection to the electric supply, and in the case of versions with water coil, the connection
with closed circuit of hot water coil.
Inside of the unit are supplied the following accessories:
Drain*
a)
b) c)
x2 x2 x2 x1
Manual
* In the models 45 and 60 the drain is installed by default in the unit.

9
The drain is composed by 3 pieces:
a) Drainpipe
b) Female screw
c) Joint ring (posar aquesta frase a sota d’aquest punt)
a) Horizontal versions of CADB/T HE 04 to 33
b) Horizontal versions of CADB/T HE 45 and 60
c) Vertical versions of CADB/T HE 04 to 33

10
d) Vertical versions of CADB/T HE 45, 60 and 100
In these versions, the drainpipe and the siphon are supplied mounted in the unit.
6.1.1. Outdoor installation
Whenever possible, it is advisable to be mounted indoors. When it is installed outdoors,it is
preferable to place the unit under a cover which offers enough protection to prevent rain falling
directly to the unit, or install the corresponding rain canopy (TPP accessory). Due to its design
and the position of its registers, it is preferable to use vertical versions (LV / RV) for outdoor
installation. In addition, these versions have feet that allow direct placement on the ground.
In horizontal version, models 04 to 33, ensure the sufficient space below the unit, to install
a siphons in the drain pipe. If installed on the ground, sufficient space must be guaranteed
under the unit so that it is possible to install the corresponding siphons in the condensate
outlets of the unit.
Drain pipe connexion
Connected to the condensate line
There is a Kit composed of 6 feet, which facilitates the assembly on floor of these versions:
5407067200 - KIT PIES CADB-HE
2x Central supports
4x Corner supports
Detail of a CADB-HE 04 to 33 after the assembly of the KIT PIES CADB-HE

11
Both in the case that the Kit feet is used, and if the unit is based on vibrators or supports
made on site, it is essential that the heat exchanger’s support is guaranteed on the 6 existing
support points and that all of them are in a same plane.
In the case of not supporting the unit on the central supports it is possible that deformation
occurs in the structure of the unit, making it impossible to disassemble the panels.
Rain protection canopy available, according to the heat recovery unit model:
Heat recovery unit model Rain protection cowl model
Horizontal (LH / RH) Vertical (LV / RV)
CADB-HE D/DI/DC 04 TPP-HE-H 04 TPP-HE-V 04
CADB-HE D/DI/DC 08 TPP-HE-H 08 TPP-HE-V 08
CADB-HE D/DI/DC 12 TPP-HE-H 12 TPP-HE-V 12
CADB-HE D/DI/DC 16 TPP-HE-H 16 TPP-HE-V 16
CADB/T-HE D/DI/DC 21 TPP-HE-H 21/27/33 TPP-HE-V 21/27
CADB/T-HE D/DI/DC 27 TPP-HE-H 21/27/33 TPP-HE-V 21/27
CADT-HE D/DI/DC 33 TPP-HE-H 21/27/33 TPP-HE-V 33
CADT-HE D/DI/DC 45 TPP-HE-H 45 TPP-HE-V 45
CADT-HE D/DI/DC 60 TPP-HE-H 60 TPP-HE-V 60
CADT-HE D/DI/DC 100 – TPP-HE-V 100
Avoid condensations in electrical cabinet
In units located in outdoor installation where the heat recovery units stop during the night or
during long intervals of time, it is necessary to:
a) Install isolation dampers in air inlet and air outlet.
b) Add anticondensation devices in the electrical cabinet as: cabinet heating elements that
prevent condensation formation on cabinet surfaces and electronic components.
6.2. DIMENSIONS AND FREE SPACE FOR MAINTENANCE
a) Horizontal versions of CADB/T HE 04 to 33 (False ceiling installation)
Distances for maintenance in installations with access by the lateral panels
EXHAUST AIR
FRESH AIR
Conf. LH
Conf. RH
Access to filters and heat exchanger
Access to control panel, motors and coils/
battery connections (DI/DC versions)

12
Distances for maintenance in installations with access by the inferior panels
Conf. LH
Conf. RH
Access to filters and heat exchanger Access to filters
Access to control panel, motors and coils/
battery connections (DI/DC versions) Access to heat exchanger
False ceiling installation
Model W H L A B C D Ø E F Weight
(kg)
04 760 375 1520 400 400 700 350 200 350 920 137
08 910 425 1750 450 400 860 400 250 400 950 173
12 1050 425 1700 500 400 1000 400 315 400 900 180
16 1240 450 1950 600 500 1190 425 315 400 1150 225
21/27 1640 550 2300 800 700 1590 525 400 500 1300 323
33 1640 650 2300 800 700 1590 325 400 500 1300 410
b) Horizontal versions of CADB/T HE 45 and 60 (Ground installation)
Conf. LH
Conf. RH
Access to filters and heat exchanger
Access to control panel, motors and coils/
battery connections (DI/DC versions)
Ground installation
Model W H L A B C D Weight
(kg)
45 1500 1200 2100 400 600 400 600 597
60 1550 1580 2250 400 750 500 700 730
EXHAUST AIR
FRESH AIR

13
c) Vertical versions
Access to filters and heat exchanger
Access to control panel, motors and coils/
battery connections (DI/DC versions)
Conf. LV
Conf. RV
Model W H L A B Ø C D Weight
(kg)
4540 920 1125 400 400 200 - - 139
8610 1020 1275 400 400 250 - - 175
12 770 1020 1325 400 400 315 - - 182
16 770 1070 1475 400 400 315 - - 227
21 970 1270 1750 400 500 400 - - 325
33 1170 1270 1750 400 500 400 - - 412
45 1120 1580 2100 400 600 - 600 400 577
60 1500 1630 2250 400 800 - 700 500 710
100 2050 1630 2250 400 1000 - 1100 650 842
6.3. MOUNTING PROCESS OF AN ADDITIONAL SUPPLY FILTER
The heat recovery unit is supplied with the filters already installed. F7 (ePM1 70%) in exhaust air
and M5 (ePM10 50%) in supply air. In addition, it is possible to mount a second filter in the unit (ac-
cessory) (for more information see section “Replacing filters”).

14
6.4. RANGE SPECIFICATIONS
D Versions: without heater battery
Model Complete unit Fan
Air connections
diameter
(mm)
Nominal
airflow
(m3/h)
Efficiency*
(%) Electrical supply Speed (r.p.m.) Maximum current
(A)
CADB-HE D 04 ECOWATT 200 450 87 1/230V, 50Hz 3700 0,95
CADB-HE D 08 ECOWATT 250 800 86,4 1/230V, 50Hz 2650 1,3
CADB-HE D 12 ECOWATT 315 1.200 85,3 1/230V, 50Hz 2550 1,6
CADB-HE D 16 ECOWATT 315 1.600 85,5 1/230V, 50Hz 2845 2,0
CADB-HE D 21 ECOWATT 400 2.100 86,5 1/230V, 50Hz 1580 2,2
CADB-HE D 27 ECOWATT 400 2.700 83,8 1/230V, 50Hz 2450 3,6
CADT-HE D 33 ECOWATT 400 3.300 88,4 3/400V, 50Hz 2600 2,0
CADT-HE D 45 ECOWATT 400x600 4.500 88,9 3/400V, 50Hz 2200 3,0
CADT-HE D 60 ECOWATT 500x700 6.100 87,9 3/400V, 50Hz 2200 3,0
CADT-HE D 100 ECOWATT 1100x650 10.000 87,9 3+N/400V, 50Hz 2160 5,8
* Wet efficiency referring to nominal airflow, outdoor conditions (-5ºC / 80% RH) and indoor (20ºC / 50% RH).
DC Versions: with built-in hot water coil
Model Complete unit Fan Hot water coil
Air
connections
diameter
(mm)
Nominal
airflow
(m
3
/h)
Efficiency*
(%) Electrical supply
Speed
(r.p.m.)
Maximum
current
(A)
Heat power
T
WATER
80/60ºC
(kW)
Heat power
T
WATER
50/45ºC
(kW)
CADB-HE DC 04 ECOWATT 200 450 87 1/230V, 50Hz 3700 0,95 2,7 1,6
CADB-HE DC 08 ECOWATT 250 800 86,4 1/230V, 50Hz 2650 1,3 5,1 3,1
CADB-HE DC 12 ECOWATT 315 1.200 85,3 1/230V, 50Hz 2550 1,6 7,1 4,3
CADB-HE DC 16 ECOWATT 315 1.600 85,5 1/230V, 50Hz 2845 2,0 8,6 5,3
CADB-HE DC 21 ECOWATT 400 2.100 86,5 1/230V, 50Hz 1580 2,2 12,6 7,8
CADB-HE DC 27 ECOWATT 400 2.700 83,8 1/230V, 50Hz 2450 3,6 16,2 10,0
CADT-HE DC 33 ECOWATT 400 3.300 88,4 3/400V, 50Hz 2600 2,0 18,2 11,1
CADT-HE DC 45 ECOWATT 400x600 4.500 89,0 3/400V, 50Hz 2200 3,0 25,6 15,5
CADT-HE DC 60 ECOWATT 500x700 6.100 88,9 3/400V, 50Hz 2200 3,0 34,7 21,1
CADT-HE DC 100 ECOWATT 1100x650 10.000 87,9 3+N/400V, 50Hz 2160 5,8 58,9 35,4
* Wet efficiency referring to nominal airflow, outdoor conditions (-5ºC / 80% RH) and indoor (20ºC / 50% RH).
DI Versions: with built-in electric battery
Model Complete unit Fan Electrical heater battery
Air
connections
diameter
(mm)
Nominal
airflow
(m
3
/h)
Efficiency*
(%) Electrical supply Speed (r.p.m.) Maximum current
(A)
Electrical
supply Power (kW) Maximum current
(A)
CADB-HE DI 04 ECOWATT 200 450 87 1/230V, 50Hz 3700 0,95 1/230V, 50Hz 1 4,5
CADB-HE DI 08 ECOWATT 250 800 86,4 1/230V, 50Hz 2650 1,3 1/230V, 50Hz 2 9,1
CADB-HE DI 12 ECOWATT 315 1.200 85,3 1/230V, 50Hz 2550 1,6 1/230V, 50Hz 3 11,4
CADB-HE DI 16 ECOWATT 315 1.600 85,5 1/230V, 50Hz 2845 2,0 1/230V, 50Hz 3,5 15,9
CADT-HE DI 21 ECOWATT 400 2.100 86,5 1/230V, 50Hz 1580 2,2 3/400V, 50Hz 6 9,1
CADT-HE DI 27 ECOWATT 400 2.700 83,8 1/230V, 50Hz 2450 3,6 3/400V, 50Hz 6 9,1
CADT-HE DI 33 ECOWATT 400 3.300 88,4 3/400V, 50Hz 2600 2,0 3/400V, 50Hz 7,5 11,4
CADT-HE DI 45 ECOWATT 400x600 4.500 89,0 3/400V, 50Hz 2200 3,0 3/400V, 50Hz 9 13,7
CADT-HE DI 60 ECOWATT 500x700 6.100 88,9 3/400V, 50Hz 2200 3,0 3/400V, 50Hz 12 18,2
CADT-HE DI 100 ECOWATT 1100x650 10.000 87,9 3+N/400V, 50Hz 2160 5,8 3/400V, 50Hz 24 36,4
* Wet efficiency referring to nominal airflow, outdoor conditions (-5ºC / 80% RH) and indoor (20ºC / 50% RH).

15
6.5. CONNECTIONS
6.5.1. Connection with air duct
The fans are always blowing out with regard to the machine. Before making the connection of
air lines, verify existing identification labels in each mouth of the heat recovery units.
Outdoor air
Aire exterior
Aria di rinnovo
Air neur
Aussenluft
Extract air
Aire de extracción
Estrazione dal locale
Air repris
Abluft
Exhaust air
Aire de expulsión
Espulsione all esterno
Air rejeté
Fortluft
Supply air
Aire de impulsión
Inmissione
Air Soufflé
Zuluft
6.5.2. Connecting the water coil piping. DC Versions
Connecting the unit to the water network
- Maximum pressure: 31.62 bar
- Maximum temperature: 150°C
• Water coils of DC versions have threaded con-
nections. Secure the coil manifold with the ap-
propiate tool when tightening the threads. This
will prevent the force from being transmitted to
the manifold, which can damage it.
• The following table indicate the size and type o thread used on water coils for DC versions:
CADB/T-HE MODEL THREAD
04, 08, 12, 16, 21, 27 and 33 1/2”
45, 60 and 100 1”
• To ensure the installation on a hand, it is essential that the installation includes the fo-
llowing elements:
- Unit intake pre-filter that traps suspended particulate matter.
- Bleed valves should be fitted at each of the high points in the installation.
- Auto-filter valve to keep water in the hydraulic system at all times.
- Pressure to detect the lack of water pressure.
- Shut-off valves must be installed at each connection on the water line to allow the unit to
be isolated if necessary (to clean filters, make repairs, replace parts, etc) and avoid the
need to completely drain the water circuit.
- Anti-vibration bellows should be installed at the inlet and outlet from the unit to prevent
the transmission of vibrations that could result in damage to the heat exchanger coil due
to excess stress on the circuits.
Once the installation is performed check that the heating water flow is adequate.

16
6.5.3. Condensate drainage
The units are supplied with 2 drains (one for each circuit). For added security it has to con-
nect two drains to the condensate discharge pipe. This connection must be made through a
pipe of 22 mm of inner diameter and a flange for secure fixation.
Drainage system
• To ensure the removal of draining condensate from the tray a siphon must be installed with
pressure head difference in mmWG greater than the pressure provided by the fan.
• The horizontal sections should have a minimum slope of 2%.
Condensation connection
6.6. ELECTRICAL CONNECTIONS
The CADB/T-HE ECOWATT range are supplied without a complete operating control integrated in
the unit, however the units include the electronic to control fan speed. The electrical components
included in the unit are supplied wired in a terminal box or in a terminal board located inside the
unit (depending on the version).
6.6.1. Connecting the motors
Horizontal versions CADB/T-HE 04 to 27 LH/RH
In these sizes the units have plug-fans with EC motors 230V supply voltage.
,

9 , & 
!
W #,! $!#
! $#!,$# ,
",#%$! ,
,,$!",
,,'%,
S ",

K ,, J %"#,$ W  ,
, ,,$!,!$ ,'

17
,
,
& ,
!
W #,! $!#
! $#!,$# 
",#%$! ,
,,$!",
,,'%,
S ",

K ,, J %"#,$ W  ,
, ,,$!,!$ ,'
Vertical versions CADB/T-HE 04 to 27 LV/RV
In these sizes the units have plug-fans with EC motors 230V supply voltage.
OUTDOOR SWITCH
ELECTRICAL SUPPLY
230V/1/50Hz
Control connector
Speed regulation:
0V = Stop
10V = max. speed
Make the bridge between OUT and IN for Vmax.
Control connector
Speed regulation:
0V = Stop
10V = max. speed
Make the bridge between OUT and IN for Vmax.

18
Horizontal version CADB/T-HE 33 LH/RH
In this size the units have plug-fans equipped with EC motors with power supply to three-
phase 400V.

19
Vertical versions CADB/T-HE 33 LV/RV
In this size the units have plug-fans equipped with EC motors with power supply to three-
phase 400V.
OUTDOOR SWITCH
ELECTRICAL SUPPLY
400V/III/50Hz
Control connector
Speed regulation:
0V= Stop
10V= max. speed
Make the bridge between OUT and IN for Vmax.
Control connector
Speed regulation:
0V= Stop
10V= max. speed
Make the bridge between OUT and IN for Vmax.

20
CADB/T-HE 45, 60 and 100 models
The models of sizes 45 to 100 have three phase motors EC. Three-phase power EC. All ver-
sions include a cut-out switch to which the fan power is wired.
In the case of -DI versions equipped with resistances of post electric heating. The current
cut-out control of the resistances must be carried out by the electric installer.
6.6.2. Connecting the By-pass
All heat recovery units of the CADB/T-HE ECOWATT range have an internal by-pass. The
by-pass damper is supplied with its actuator mounted (Supply voltage 230V). The actuator is
wired to an external terminal box or to the electrical board (depending on the version).
With the FC-REG accessory is possible to control the by-pass in free-cooling mode.
MARRON/ BROWN
BLANCO/ WHITE
AZUL / BLEU
Open BY-PASS
Close BY-PASS
