1. INTRODUCTION
Thank you for purchasing a SLIM heat recovery unit. This product has been manufactured according to rigorous techni-
cal safety rules in full compliance with applicable EU standards.
Please read this instruction book carefully, as it contains important information for your safety during the installation,
use and maintenance of this product.
Keep it at hand for future reference. Please check that the appliance is in perfect condition when you unpack it, as all
factory defects are covered by the S&P guarantee.
The installation of this product (implementation, connections, commissioning, maintenance) and all other interventions must
be performed by a professional applying the recognized rules of good practice, standards and safety regulations in force. It
must conform to the prescriptions related to Electromagnetic Compatibility (EMC) and the Low Voltage Directive (LVD).
S&P shall not be held responsible for possible injuries and/or damages caused by the non-compliance with safety ins-
tructions or following a modification of the product.
2. SAFETY INSTRUCTIONS AND “CE” MARKING
S&P technicians are firmly committed to research and development of ever more efficient products and in compliance
with current safety regulations.
The instructions and recommendations given below reflect current regulations, principally regarding safety, and there-
fore are based on compliance with general regulations. Therefore, we recommend to strictly follow the safety regula-
tions in force in your country. S&P will not be held liable for any possible harm or damage caused by non-compliance
with the safety regulations, as well as caused by modifying the product.
• Wear appropriate IPE (Individual Protection Equipment) before any intervention.
• Before installing the air treatment unit, make sure that the support and placement are sufficiently resistant to withs-
tand the unit’s weight and that of the accessories.
• Do not open the access doors without first switching off the electrical power supply with the main power switch pre-
sent on the unit.
• If the work is to be performed inside the device, switch off the electrical power supply on the main circuit breaker and
make sure that no one can accidentally switch it on.Make sure that the moving parts are stopped.
• Make sure that the motor driven fans are not accessible from the connection taps (connection duct or screened pro-
tection).
Before starting, check the following points:
• Make sure that the device does not contain any foreign body.
• Make sure that all the components are attached in their original placements.
• Check manually that the fans do not rub or are not blocked.
• Check the earthing connection.
• Make sure that the access doors are properly closed.
• Make sure the mains voltage corresponds to the voltage indicated on the specifications plate of the unit.
The CE mark and the corresponding declaration of conformity are proof of the product’s conformity with current EU
regulations.
3. GENERAL INSTRUCTIONS
3.1. ACCEPTANCESTORAGE
In case of missing, non-conforming, or totally or partially damaged delivered products, the Purchaser must make writ-
ten reservation on the transporter’s receipt and confirm them within seventy-two (72) hours by sending a recommended
letter to the transporter, as well as a copy to S&P. Acceptance of the equipment without any reservation will deprive the
Purchaser of any subsequent recourse against us. The product must be stored in an area protected from bad weather,
shocks and stains due to splashings or splatterings of any kind during its transport from the supplier to the end custo-
mer and onto the worksite before installation.
3.2. APPLICATION
The SLIM heat recovery units are designed for double flow air ventilation and air treatment applications in public and
private buildings:
• Indoor installation.
• Outdoor air operating temperature limits (with preheater): -20ºC / +40ºC.

6
• Outdoor air operating temperature limits (without preheater): -10ºC / +40ºC.
• To avoid electronic damages the main switch has to be always «ON», except during maintenance.
• Relative humidity: max 95% non-condensing.
• Atmosphere not potentially explosive.
• Atmosphere with low salt content, without corrosive chemical agents.
3.3. WARRANTY
The equipment is guaranteed for 24 months from the invoice date. The warranty is limited to the replacement of parts or
equipment whose operation is recognized as defective by the maker, excluding any compensation or penalties. The costs
of labour, removal and rest, travel related to the replacement are the responsibility of the Customer. Excluded from our
warranty are defects linked to abnormal use or not in accordance with the recommendations in our instructions, de-
fects observed as a result of normal wear and tear, incidents caused by negligence, lack of monitoring or maintenance,
defects due to incorrect installation of devices or poor storage conditions prior to assembly. In any case, maker is not
responsible for transformed material, even partially repaired.
4. UNIT LABELLING
)LOWHUDFFHVV
)DQDFFHVV
)LOWHUDFFHVV
)DQDFFHVV
)LOWHUDFFHVV
)LOWHUDFFHVV
,'DQGWHFKQLFDOGDWD
6DIHW\LQGLFDWLRQV
5. HANDLING
SLIM units are delivered fixed with screws to the pallets. The unit can be handled by a pallet transporter, a forklift, or a
crane.The handling machines will be adapted to the load and the lifting conditions. In all cases, the lifting will be done
at the device’s base. The centre of gravity is located at the centre of the unit. The device must be carefully manipulated
only in the horizontal position.
&>dH/Z/D'E^KE>h//ME>^W>^ZdZ1^d/^

7
6. INSTALLATION
These models are designed to be installed hanging from the ceiling or located behind a false ceiling. It is mandatory to
distribute the unit weight between the 4 supports existing in the units:
Using studded rods (ø8 mm x 4), it can be secured to the ceiling and levelled:
B
A
Distance between supports (mm):
Model A B
SLIM 800 1652 1124
SLIM 1200 1652 1604
SLIM 1600 1652 1804
SLIM 2000 1952 1804
The installer must ensure that the ceiling structure and the securing elements can bear the weight of the device, taking
into account that it is a dynamic load. To prevent the transmission of vibrations, it is necessary that the installer use
specific isolation elements such as anti-vibrations elements and flexible connection between the unit and the ducts.
Model Weight
(kg)
Recommended
antivibration hangers KIT*
Recommended
flexible connection
SLIM 800 172 5130064900 KIT AM COMPACT/SLIM 5132810200 IAE-200
SLIM 1200 231 5130064900 KIT AM COMPACT/SLIM 5132811000 IAE-225
SLIM 1600 266 5130064900 KIT AM COMPACT/SLIM 5132813600 IAE-285
SLIM 2000 315 5130064900 KIT AM COMPACT/SLIM 5132814400 IAE-315
* These KITs include 4 x anti-vibrations pads.

8
7. DIMENSIONS
7.1. MAIN UNIT DIMENSIONS
SLIM L (Left hand version)
D
D1
E
E1
F F
GH
I
J
ØS
C
O
ØM
N
A1
A
B
B1
P
Q
ØM
VIEW FROM "A"
A
L
K
ELECTRICAL CABINET
OUTDOOR / FRESH AIR
SUPPLY AIR
EXTRACT AIR
EXHAUST AIR
DRAIN OUTLET
Module A A1 B B1 C D D1 E E1 F G H
SL-800 1700 1659 1080 1130 380 400 420 200 220 85 110 110
SL-1200 1700 1659 1560 1610 380 500 520 250 270 155 250 110
SL-1600 1700 1659 1760 1810 420 600 620 300 320 155 250 110
SL-2000 2000 1953 1760 1810 500 600 620 350 370 155 250 110
Module I J K L M N O P Q R S
SL-800 55 125 45 167 8 685 80 22 14,4 17 M8
SL-1200 55 75 45 167 8 685 80 22 14,4 17 M8
SL-1600 55 65 45 167 8 677 80 22 14,4 17 M8
SL-2000 55 95 45 167 8 785 86 22 14,4 17 M8

SLIM R (Right hand version)
C
O
ØM
N
A1
A
B
B1
P
Q
ØM
A
D
D1
E
E1
F F
GH
I
J
ØS
VIEW FROM "A"
L
K
ELECTRICAL CABINET
OUTDOOR / FRESH AIR
SUPPLY AIR
EXTRACT AIR
EXHAUST AIR
DRAIN OUTLET
Module A A1 B B1 C D D1 E E1 F G H
SL-800 1700 1659 1080 1130 380 400 420 200 220 85 110 110
SL-1200 1700 1659 1560 1610 380 500 520 250 270 155 250 110
SL-1600 1700 1659 1760 1810 420 600 620 300 320 155 250 110
SL-2000 2000 1953 1760 1810 500 600 620 350 370 155 250 110
Module I J K L M N O P Q R S
SL-800 55 125 45 167 8 685 80 22 14,4 17 M8
SL-1200 55 75 45 167 8 685 80 22 14,4 17 M8
SL-1600 55 65 45 167 8 677 80 22 14,4 17 M8
SL-2000 55 95 45 167 8 785 86 22 14,4 17 M8

10
7.2. EXTERNAL MODULES DIMENSIONS
AJ O NU
L
M
K P
Q
X
DETAIL Z
D
d
Z
FE H
B
G
IA
C
TR
W
S
V
AIR
SENSE
SL-DC Hot water coil
Version -R
SL-DC Hot water coil
Version -L
A J O N U
L
M
K P
Q
DETAIL Z
d
Z
FE H
B
G
IA
C
TR
S
D
AIR
SENSE
SL-DF/DFR/DX Cold water coil / Reversible / DX
Version -R
SL-DF/DFR/DX Cold water coil / Reversible / DX
Version -L
A
JO N U
L
M
K P
Q
X
F EH
B
G
IA
C
TR
W
S
V
AJ
ONU
L
M
K P
Q
F EH
B
G
IA
C
TR
S
DETAIL Z
D
d
DETAIL Z
d
D
Z
AIR
SENSE
Z
AIR
SENSE
Module A B C d D E F G H IA J K L
SL-800 700 540 380 17 22 73 145 584 482 685 400 200 420
SL-1200 700 780 380 17 22 73 145 824 482 925 500 250 520
SL-1600 700 880 420 17 22 73 145 924 482 1025 600 298 620
SL-2000 700 880 500 17 22 73 145 924 482 1025 600 350 620
Module M N O P Q R S T U V W X
SL-800 220 55 85 55 125 107,6 133 88,4 100 22,7 119,8 54
SL-1200 270 125 155 55 75 107,6 133 88,4 100 22,7 119,8 54
SL-1600 320 125 155 55 67 97,6 133 88,4 100 22,7 119,8 54
SL-2000 370 125 155 55 95 102,6 133 88,4 100 22,7 119,8 54

11
DETAIL Z
FE H
A J O N
KP
Q
L
M
C
B
G
IE
Z
d
D
AIR
SENSE
F EH
AJ
ON
KP
Q
L
M
C
B
G
IE
Z
AIR
SENSE
SL-DI Electric battery
Version -R
SL-DI Electric battery
Version -L
DETAIL Z
d
D
Module A B C d D E F G H IE J K L M N O P Q
SL-800 700 540 380 17 22 73 145 584 482 645 400 200 420 220 55 85 55 125
SL-1200 700 780 380 17 22 73 145 824 482 885 500 250 520 270 125 155 55 75
SL-1600 700 880 420 17 22 73 145 924 482 985 600 298 620 320 125 155 55 67
SL-2000 700 880 500 17 22 73 145 924 482 985 600 350 620 370 125 155 55 95
8. CONDENSATE PUMP  DRAINAGE SYSTEM
By default, SLIM units are delivered with an integrated silent running centrifugal pump. The pump will activate automa-
tically when the level of condensate grows over a set point.
If there is any problem related with the condensates drainage (defective pump, maximum level of condensates reached,
etc.) unit will display an alarm in the external touch display. The unit will stop working in case of major failure.
The condensate pump is available as a spare and very easy to replace (it is located inside the drainage tray). Look for the
spare part code of the condensate pump in section "34.2. Spare parts list".
Main characteristics:
• Electronic Energy Control System (EECS) with alarm circuit. All electronic components are encapsulated to protect
them from moisture.
• Max flow capacity: 12 l/h
• Max suction height: 1 m Max delivery height: 19,8 m Discharge tube: ø6 mm
Performance chart – condensate pump

9HUWLFDO OLIW P







)ORZ UDWH OK
P+RUL]RQWDO
P+RUL]RQWDO
P+RUL]RQWDO
0 m Horizontal
50 m Horizontal
100 m Horizontal
Vertical lift (m)
Flow rate (l/h)

12
8.1. HOW TO REPLACE THE CONDENSATE PUMP
1. Open the two sliding doors marked
on the image
Outdoor duct
connections
Indoor duct
connections
SLIM-R
ŽŽƌĚƵĐƚ
ĐƟŽŶƐ
/ŶĚŽŽƌĚƵĐƚ
ĐŽŶŶĞĐƟŽŶƐ
^>/D
2. Move the panels to access the condensate tray
SLIM-R
3. Turn the condensate tray to find the condensate
pump
SLIM-R
9. DIMENSIONS AND FREESPACE FOR MAINTENANCE
9.1. UNITS WITH NO EXTERNAL MODULE ASSEMBLED
SLIM can be installed close to the wall as long as no external module has been assembled. Maintenance will in any case
be done through bottom and side:
6/,05 6/,0/
ZDOO
$
%
ZDOO
$
%
6XSSO\DLUȍDQJH
Model A
(electrical cabinet and filters)
B
(heat exchanger, bypass, filters,
condensate tray and motors)
SLIM 800 600 380
SLIM 1200 800 380
SLIM 1600 900 420
SLIM 2000 950 500

13
9.2. UNITS WITH EXTERNAL MODULE ASSEMBLED
In case an external module has been added to the air handling unit:
ZDOO ZDOO
6/,05 6/,0/
$
%
$
%
6XSSO\DLUȍDQJH
&&
Model A
(electrical cabinet
and filters)
B
(core, bypass, filters,
condensate tray and
motors)
C*
(hydraulic connections
– external DX and water
modules)
C
(electrical connections –
external DI modules)
SLIM 800 600 380 650 200
SLIM 1200 800 380 900 200
SLIM 1600 900 420 1000 200
SLIM 2000 950 500 1000 200
* The coils can be removed from the external modules through the lateral or the bottom. If the removal of the coils is expected to be done through the bottom, C
dimension can be 500 mm for all sizes.

14
10. FILTER REPLACEMENT
The heat recovery unit is supplied within a F7 (ePM1 50%) filter in the supply side and M5 (ePM10 50%) filter in the ex-
tract side. There is no possibility to mount a second filter inside the unit.
The supplied filters can be removed both from bottom (1) and side (2):
10.1. REMOVING THE FILTER THROUGH THE BOTTOM
a) Open the specific hinged panel for
filter replacement.
b) Push from the fixation pieces to loose the filtration box.
c) Remove the filtration box. d) Remove the filter from the filtration box: first step is to push from the pie-
ces that fix the filter to the box. Then, the filter will be liberated.
Do not threw the filtration box away, you will
need it to put the spare filter inside the unit.
10.2. REMOVING THE FILTER THROUGH THE LATERAL
a) Remove the specific panel for filter
replacement.
b) Push from the fixation pieces.
c) Remove the filter. The filtration box remains inside the unit.

15
11. RANGE SPECIFICATIONS
11.1. MAIN UNIT
Version without preheater
Model Connection
(mm)
Nominal
airflow
(m³/h)
Efficiency heat
exchanger*
(%)
Power supply Max. abs.
Power
(kW)
Max. Current
(A)
Weight
(kg)
SLIM-800 400x200 800 92,4 1/230V, 50Hz 0,46 2,9 172
SLIM-1200 500x250 1200 92,4 1/230V, 50Hz 0,91 4,1 231
SLIM-1600 600x300 1600 91,7 1/230V, 50Hz 0,93 3,7 266
SLIM-2000 600x350 2000 93,8 1/230V, 50Hz 0,97 4,5 315
* EXT: -10ºC @ 90%RH
INT: 20ºC @ 50%RH
Version with integrated preheater
Model Connection
(mm)
Nominal
airflow
(m³/h)
Efficiency heat
exchanger*
(%)
Power supply Max. abs.
Power
(kW)
Max. Current
(A)
Weight
(kg)
SLIM-800 PH 400x200 800 92,4 1/230V, 50Hz 2,66 12,9 176
SLIM-1200 PH 500x250 1200 92,4 1/230V, 50Hz 3,91 17,8 236
SLIM-1600 PH 600x300 1600 91,7 3/400V + N, 50Hz 6,93 12,8 273
SLIM-2000 PH 600x350 2000 93,8 3/400V + N, 50Hz 8,47 15,9 323
* EXT: -10ºC @ 90%RH
INT: 20ºC @ 50%RH
11.2. EXTERNAL BATTERIES
In this section the technical characteristics of the preheater and post-treatment modules are described. For further
details see sections: "7.2. External modules dimensions", "30.1. Installation of an electrical preheater", and "30.2. Con-
figuration of an electrical preheater".
11.2.1. External module - electrical post heaters
ELECTRIC POST-HEATER
Type Outdoor
Air
(ODA)
Indoor
Air
(ETA)
Supply
Air
(SUP1)
before
the coil
Supply
power
(kW)
Absorved
current
(A)
Air Supply Air
(SUP2)
after
the coil
(ºC)
Voltage (V) Weight
(kg)
Flow
rate
(m3/h)
Pressure
drop
(Pa)
SL-DI 800 3 M
-10ºC
/ 90%
+20ºC /
50%
+11,2ºC /
19,3%
3 14 800 20 22 1/230V, 50Hz 34,5
SL-DI 1200 4 M 4 18 1200 20 20 1/230V, 50Hz 42
SL-DI 1600 7,5 T 7,5 34 1600 20 24 3/400V, 50Hz 51,6
SL-DI 2000 9 T 9 41 2000 20 24 3/400V, 50Hz 54,4
11.2.2. External module - hot water coils
HOT WATER COIL
Type Weight
(without
liquid)
(kg)
Outdoor
Air
(ODA)
Indoor
Air
(ETA)
Supply
Air
(SUP1)
before
the coil
Water
temp.
(ºC)
Heating
Power
(kW)
Supply
Air
(SUP2)
after
the coil
Air Water In/Out coil
connection
ø (“)
Recommended
3 way valve
Flow
rate
(m
3
/h)
Pressure
drop
(Pa)
Speed
(m/s)
Flow
(m
3
/h)
Pressure
drop
(kPA)
Intern
volume
coil (L)
SL-DC 800 2 7,6 -10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3%
50/40 4,48 +27,3ºC
/ 6,9% 800 59 2,96 0,4 11,50 0,4 1/2
5407037900 -
3WV DN15 KVS1
PROP 24V
70/60 7,53 +38,3ºC
/ 3,7% 800 59 2,96 0,7 27,85 0,4 1/2
5407038000 -
3WV DN15 KVS1,6
PROP 24V
SL-DC 1200 2 9,7 -10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3%
50/40 6,61 +27,1ºC
/ 7% 1200 53 2,78 0,6 11,44 0,7 1/2
5407038000 -
3WV DN15 KVS1,6
PROP 24V
70/60 11,32 +38,4ºC
/ 3,7% 1200 53 2,78 1 30,03 0,7 1/2
5407038000 -
3WV DN15 KVS1,6
PROP 24V

16
Type Weight
(without
liquid)
(kg)
Outdoor
Air
(ODA)
Indoor
Air
(ETA)
Supply
Air
(SUP1)
before
the coil
Water
temp.
(ºC)
Heating
Power
(kW)
Supply
Air
(SUP2)
after
the coil
Air Water In/Out coil
connection
ø (“)
Recommended
3 way valve
Flow
rate
(m
3
/h)
Pressure
drop
(Pa)
Speed
(m/s)
Flow
(m
3
/h)
Pressure
drop
(kPA)
Intern
volume
coil (L)
SL-DC 1600 2 11,4 -10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3%
50/40 9,31 +28ºC
/ 6,7% 1600 46 2,54 0,81 9,48 1 1/2
5407038100 -
3WV DN15 KVS2,5
PROP 24V
70/60 15,73 +39,5ºC
/ 3,5% 1600 46 2,54 1,4 23,98 1 1/2
5407038100 -
3WV DN15 KVS2,5
PROP 24V
SL-DC 2000 2 12,4 -10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3%
50/40 11,73 +28,1ºC
/ 6,6% 2000 43 2,44 1,02 13,55 1,1 1/2
5407038100 -
3WV DN15 KVS2,5
PROP 24V
70/60 19,83 +39,8ºC
/ 3,4% 2000 43 2,44 1,73 34,54 1,1 1/2
5407038100 -
3WV DN15 KVS2,5
PROP 24V
11.2.3. External module - reversible water coils
REVERSIBLE WATER COIL FOR 2 PIPES INSTALLATION - HEATING MODE
Type Weight
(without
liquid)
(kg)
Outdoor
Air
(ODA)
Indoor
Air
(ETA)
Supply
Air
(SUP1)
before
the coil
Water
temp.
(ºC)
Heating
Power
(kW)
Supply
Air
(SUP2)
after
the coil
Air Water Coil
connection
ø (“)
Recommended
3 way valve
Flow
rate
(m3/h)
Pressure
drop
(Pa)
Speed
(m/s)
Flow
(m3/h)
Pressure
drop
(kPA)
Volume
coil
(L)
SL-DFR 800 3 8,4 -10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3%
50/40 4,28 +26,6ºC
/ 7,2% 800 63 2,96 0,4 14,18 0,6 1/2
5407037900 -
3WV DN15 KVS1
PROP 24V
70/60 7,04 +36,6 /
4,1% 800 63 2,96 0,6 32,72 0,6 1/2
5407037900 -
3WV DN15 KVS1
PROP 24V
SL-DFR 1200 3 10,8 -10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3%
50/40 7,17 +28,4 /
6,5% 1200 61 2,78 0,62 12,50 1 1/2
5407038000 -
3WV DN15
KVS1,6 PROP
24V
70/60 11,77 +39,4 /
3,5% 1200 61 2,78 1,03 28,29 1 1/2
5407038000 -
3WV DN15
KVS1,6
PROP 24V
SL-DFR 1600 3 12,6 -10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3%
50/40 9,23 +27,8ºC
/ 6,7% 1600 52 2,54 0,8 4,42 1,3 3/4
5407038200 -
3WV DN20 KVS4
PROP 24V
70/60 15,61 +39,3ºC
/ 3,5% 1600 52 2,54 1,4 11,13 1,3 3/4
5407038200 -
3WV DN20 KVS4
PROP 24V
SL-DFR 2000 3 13,7 -10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3%
50/40 11,68 +28ºC /
6,7% 2000 49 2,44 1 5,90 1,7 3/4
5407038200 -
3WV DN20 KVS4
PROP 24V
70/60 19,75 +39,6ºC
/ 3,4% 2000 49 2,44 1,7 15,06 1,7 3/4
5407038200 -
3WV DN20 KVS4
PROP 24V
REVERSIBLE WATER COIL FOR 2 PIPES INSTALLATION - COOLING MODE
Type Weight
(without
liquid)
(kg)
Outdoor
Air
(ODA)
Indoor
Air
(ETA)
Supply
Air
(SUP1)
before
the coil
Water
temp.
(ºC)
Cooling
Power
(kW)
Supply
Air
(SUP2)
after
the coil
Air Water Coil
connection
ø (“)
Recommended
3 way valve
Flow
rate
(m
3
/h)
Pressure
drop
(Pa)
Speed
(m/s)
Flow
(m
3
/h)
Pressure
drop
(kPA)
Volume
coil
(L)
SL-DFR 800 3 8,4
+35ºC
/ 40%
+26ºC
/ 50%
+28ºC /
60%
7/12 3,41 +21ºC /
79% 800 85 2,96 0,6 38,07 0,6 1/2
5407037900 -
3WV DN15 KVS1
PROP 24V
SL-DFR 1200 3 10,8 7/12 5,8 +20ºC /
82% 1200 84 2,78 1 34,67 1 1/2
5407038000 -
3WV DN15
KVS1,6 PROP
24V
SL-DFR 1600 3 12,6 7/12 6,76 +21ºC /
79% 1600 71 2,54 1,2 9,98 1,3 3/4
5407038200 -
3WV DN20 KVS4
PROP 24V
SL-DFR 2000 3 13,7 7/12 8,58 +20ºC /
80% 2000 67 2,44 1,5 13,32 1,7 3/4
5407038200 -
3WV DN20 KVS4
PROP 24V

17
11.2.4. External module - cold water coils
CHILLED WATER COIL
Type Weight
(without
liquid)
(kg)
Outdoor
Air
(ODA)
Indoor
Air
(ETA)
Supply
Air
(SUP1)
before
the coil
Water
temp.
(ºC)
Cooling
Power
(kW)
Supply
Air
(SUP2)
after
the coil
Air Water Coil
connection
ø (“)
Recommended
3 way valve
Flow
rate
(m
3
/h)
Pressure
drop
(Pa)
Speed
(m/s)
Flow
(m
3
/h)
Pressure
drop
(kPA)
Volume
coil
(L)
SL-DF 800 5 10,5 7/12 4,76 +18ºC
/ 86% 800 146 2,96 0,8 30,86 1 1/2
5407038000 -
3WV DN15
KVS1,6 PROP
24V
SL-DF 1200 5 13,7 +35ºC
/ 40%
+26ºC
/ 50%
+28ºC
/ 60% 7/12 8,3 +16ºC / 89% 1200 143 2,78 1,4 30,86 1,6 1/2
5407038100 -
3WV DN15
KVS2,5 PROP
24V
SL-DF 1600 5 15,8 7/12 10,85 +17ºC
/ 88% 1600 114 2,54 1,9 36,97 2,3 1/2
5407038100 -
3WV DN15
KVS2,5 PROP
24V
SL-DF 2000 5 17,3 7/12 13,78 +17ºC
/ 88% 2000 107 2,44 2,4 38,63 3 3/4
5407038200 -
3WV DN20 KVS4
PROP 24V
11.2.5. External module - DX coils
DIRECT EXPANSION COIL
Type Weight
(empty)
(kg)
Outdoor
Air
(ODA)
Extract
Air
(ETA)
Supply
Air
(SUP1)
before
the coil
Cooling mode 7ºC EVAP. R-410A
Refrigerant*
Heating mode 39ºC COND. R-410A
Refrigerant* Air Volume
coil (L)
Liquid/gas
connection
Cooling
power
(kW)
(kg/h) (kPa) Supply
Air
(SUP2)
after
the coil
Heating
power
(kW)
(kg/h) (kPa) Supply
Air
(SUP2)
after
the coil
Flow
rate
(m
3
/h)
Pressure
drop
(Pa)
Speed
(m/s)
SL-DX 800 4 9,7
+35ºC
/ 40%
+26ºC
/ 50%
+28ºC
/ 60% 4,48 91,7 11,93 + 18ºC / 89% ----
800 133 2,9 0,8 1/2”
-10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3% - - - - 4,42 81,2 5,28 +27ºC / 7%
SL-DX 1200 4 12,7
+35ºC
/ 40%
+26ºC
/ 50%
+28ºC
/ 60% 7,38 150,9 16,47 +17ºC / 90% ----
1200 131 2,8 1,2 1/2”
-10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3% - - - - 7,17 131,6 6,47 +28ºC / 7%
SL-DX 1600 4 15,5
+35ºC
/ 40%
+26ºC
/ 50%
+28ºC
/ 60% 8,43 172,4 11,11 +18ºC / 91% ----
1600 118 2,5 1,7 1/2”
-10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3% - - - - 8,79 161,5 4,01 +27ºC / 7%
SL-DX 2000 4 16,6
+35ºC
/ 40%
+26ºC
/ 50%
+28ºC
/ 60% 11,55 236,4 22,72 +18ºC / 90% ----
2000 104 2,44 2,3 1/2”
-10ºC
/ 90%
+20ºC
/ 50%
+11,2ºC
/ 19,3% - - - - 11,59 212,9 7,73 +28ºC / 7%
* Subcooling: 0ºC; Overheating: 5ºC
11.3. ELECTRICAL PREHEATERS (delivered as accessories)
The SLIM PH is a version equipped with built-in preheater from factory. In units ordered without preheater it is also
possible to add the preheater on site.
ELECTRIC PRE-HEATER
Type Supply power
(kW)
Absorved
current
(A)
Voltage (V) Air Weight
(kg)
Flow rate
(m3/h)
Pressure drop
(Pa)
SL-PH 800 2,2 M 2,2 10 1/230V, 50Hz 800 20 1,8
SL-PH 1200 3 M 3 14 1/230V, 50Hz 1200 20 3,6
SL-PH 1600 6 T 6 9 3/400V, 50Hz 1600 15 5,4
SL-PH 2000 7,5 T 7,5 11,4 3/400V, 50Hz 2000 15 7,2

18
12. INTEGRATION IN “DX” DIRECT EXPANSION SYSTEMS
The SLIM controller does not allow to control the components of the refrigeration circuit. It is essential to provide the
rest of components of the refrigeration circuit (not supplied by S&P) such as:
• Refrigeration condensing unit (compressor-condenser)
• DX direct expansion valves
• DX system control
With regard to the selection of components, verify the following:
• The condensing unit allows to obtain the required thermal capacity by the DX coil, considering the real working condi-
tions (Temperature and ambient relative humidity and evaporation temperature considered).
• DX coil pressure drop as well as internal coil volume are compatibles with the KIT DX VALVE (not supplied by S&P) and
the refrigeration condensing unit.
13. DUCTS AND PIPING CONNECTIONS
13.1. CONNECTION WITH AIR DUCT
Before making the ductwork connections, identify the labels in each inlet/outlet of the heat recovery unit.
Outdoor air
Aire exterior
Aria di rinnovo
Air neur
Aussenluft
Extract air
Aire de extracción
Estrazione dal locale
Air repris
Abluft
Exhaust air
Aire de expulsión
Espulsione all esterno
Air rejeté
Fortluft
Supply air
Aire de impulsión
Inmissione
Air Soufflé
Zuluft
Example: SLIM - Left handed

19
13.1.1. Schematic air duct connection (example)
Recommended accessories
(unit protection)
IJK (isolation damper)
+
LF (damper actuator)
Recommended accessories
(avoid vibration transmission)
IAE
(flexible connection)
Recommended accessories
(avoid vibration transmission)
IAE
(flexible connection)
Outdoor air
Aire exterior
Aria di rinnovo
Air neur
Aussenluft
Extract air
Aire de extracción
Estrazione dal locale
Air repris
Abluft
Exhaust air
Aire de expulsión
Espulsione all esterno
Air rejeté
Fortluft
Supply air
Aire de impulsión
Inmissione
Air Soufflé
Zuluft
Example: SLIM - Left handed
13.1.2. Isolation dampers (accessory)
We strongly recommend to install isolation dampers in the outdoor air connections ir order to protect the unit in winter,
during the night or during periods of prolonged unit stoppage. When talking about the indoor air connections, If the
ductwork is expected to pass through cold areas, it must be isolated.
Model Isolation damper Actuator (spring return)
SLIM 800 L 5416743800 IJK-200 5416762900 LF-230 S
SLIM 800 R
SLIM 1200 L 5416743900 IJK-225 5416762900 LF-230 S
SLIM 1200 R
SLIM 1600 L 5416744100 IJK-285 5416762900 LF-230 S
SLIM 1600 R
SLIM 2000 L 5416744200 IJK-315 5416762900 LF-230 S
SLIM 2000 R
13.1.3. Flexible connections (accessory)
Flexible connections are strongly recommended to avoid vibration transmission to the ductwork. Find the flange dimen-
sions and the recommended flexible-connection in the table below:
Model Flange dimensions (mm) Recommended flexible connection
SLIM 800 400 x 200 (4x) 5132810200 IAE-200
SLIM 1200 500 x 250 (4x) 5132811000 IAE-225
SLIM 1600 600 x 300 (4x) 5132813600 IAE-285
SLIM 2000 600 x 350 (4x) 5132814400 IAE-315

20
13.2. CONNECTION WITH COIL PIPING
• When connecting a coil to the water network:
− Maximum pressure: 10 bar
− Maximum temperature: 100ºC
− Minimum water temperature: -20ºC (with the addition of the corresponding
antifreeze)
• SLIM coils have threaded connections. Secure the coil manifold with the
appropriate tool when tightening the threads. This will prevent the force from
being transmitted to the manifold, damaging it.
• The following table indicates the size and type of thread used on each coil model:
Model/size SL-DC
(Heating water coil)
SL-DFR
(Reversible water coil)
SL-DF
(Chilled water coil)
SL-DX
(Direct expansion coil)
800 1/2” 1/2” 1/2” 1/2”
1200 1/2” 1/2” 1/2” 1/2”
1600 1/2” 3/4” 1/2” 1/2”
2000 1/2” 3/4” 3/4” 1/2”
• To ensure the good behaviour of the installation, it is essential that the installation includes the following elements:
− Unit intake pre-filter which traps suspended particulate matter.
− Bleed valves should be fitted at each of the high points in the installation.
− Self-filling valve to keep the appropriate water level.
− Pressure switch to detect the lack of water pressure.
− Shut-off valves must be installed at each connection on the water line to allow the unit to be isolated if necessary
(allowing filters cleaning, reparations and maintenance tasks) the need to completely drain the water circuit.
− Anti-vibration devices should be installed at the inlet and outlet from the unit to prevent the transmission of vibra-
tions that could damage the heat exchanger coil due to excess stress on the circuits.
• Once the installation is performed check that the heating water flow is adequate.
14. ELECTRICAL CONNECTIONS
All components integrated in the device are electrically wired into the electrical cabinet (fans, pressure transmitters,
pressure switches, temperature probes and by-pass damper).
The electrical connection is then limited to the connection of the external display (10 m. of supplied cable) and possible
electrical accessories such as CO2 sensors or control valves for water coils, and finally the connection of the power
supply line.
Make electrical connection in accordance to the described in the corresponding wiring diagram.
