S&P CADB/T-HE PRO-REG Series User manual

CADB/T-HE PRO-REG
EN

3
ENGLISH
INDEX
1. INTRODUCTION ..........................................................................................................................................................5
2. SAFETY REGULATIONS AND “CE” MARKING ............................................................................................................5
3. GENERAL INSTRUCTIONS .........................................................................................................................................5
4. UNIT LABELLING .......................................................................................................................................................5
5. HANDLING..................................................................................................................................................................6
6. INSTALLATION............................................................................................................................................................7
6.1. Introduction..........................................................................................................................................................7
6.1.1. Outdoor installation .................................................................................................................................11
6.2. Dimensions and free space for maintenance ...................................................................................................12
6.3. Mounting process of an additional supply filter................................................................................................14
6.4. Range specifications..........................................................................................................................................14
6.5. Connections .......................................................................................................................................................15
6.5.1. Piping and duct connections....................................................................................................................15
6.5.1.1. Connection with air duct.............................................................................................................15
6.5.1.2. Connecting the water coil piping. DC Versions ..........................................................................15
6.5.1.3. Condensate drainage..................................................................................................................16
6.5.2. Electrical connection ...............................................................................................................................16
6.5.2.1. External Touch Display (ETD) control connection......................................................................16
6.6. Configurations ...................................................................................................................................................17
7. CONTROL FUNCTIONS.............................................................................................................................................19
8. CONTROL SCHEME ..................................................................................................................................................20
9. REMOTE CONTROL OPERATION..............................................................................................................................21
9.1. Change language...............................................................................................................................................21
9.2. Simplified menus / accesses.............................................................................................................................22
9.2.1. User level .................................................................................................................................................22
9.2.2. Installer level ...........................................................................................................................................22
9.3. Operation modes ...............................................................................................................................................24
9.3.1. Constant airflow operation (CAV).............................................................................................................24
9.3.2. Variable airflow operation (VAV) ..............................................................................................................27
9.3.3. Constant pressure operation (COP).........................................................................................................28
9.4. Postheater control.............................................................................................................................................32
9.4.1. Constant supply air temperature maintenance ......................................................................................32
9.4.2. Constant ambient temperature maintenance.........................................................................................32
9.4.3. Temperature set point adaptation vs. outdoor temperature...................................................................33
9.4.4. Automatic control mode ..........................................................................................................................33
9.5. Initial temperature setpoint ..............................................................................................................................33
9.6. Time programming............................................................................................................................................34
10. BOOST FUNCTION (ONLY AVAILABLE IN CAV AND COP MODES) ...........................................................................36
11. REMOTE STOP-START ..............................................................................................................................................37
12. FREE COOLING BY NIGHT ........................................................................................................................................37
13. WATER HEATER FROST PROTECTION......................................................................................................................39
14. PROTECTION OF HEAT EXCHANGER UNIT ..............................................................................................................40
15. FIRE FUNCTION (FIRE) .............................................................................................................................................40
16. CONTROL OF COOLING EXTERNAL BATTERIES......................................................................................................41
16.1. Accesssories assembly....................................................................................................................................42
16.2. Wiring between accessory and PRO-REG electrical board.............................................................................45
16.2.1. Coil module BA-AF HE, BA-AFC HE, BA-DX .........................................................................................45
16.2.2. Filtration modules FBL-CA HE y FBL-HE .............................................................................................46
16.3. Control reconfiguration ...................................................................................................................................47
16.3.1. Controller reconfiguration required to manage coil module BA-AF HE only as cooling coil...............48
16.3.2. Controller reconfiguration required to manage coil module BA-AF HE as reversible coil
(cooling and heating)..............................................................................................................................49
16.3.3. Controller reconfiguration required to manage coil module BA-AFC HE in 4 pipes systems
(cooling and heating)..............................................................................................................................50
16.3.4. Controller reconfiguration required to manage DX coil module BA-DX HE (cooling and heating) ......51
16.3.5. Controller reconfiguration required to manage external filter module FB-CA HE or FBL-HE............52
ENGLISH

17. RESET THE CORRIGO CONTROLLER .......................................................................................................................52
18. CONTROLLER RECONFIGURATION..........................................................................................................................54
19. CENTRALIZED TECHNICAL CONTROL (GTC) CONNECTION ...................................................................................54
19.1. Bacnet TCP/IP..................................................................................................................................................55
20. REPLACEMENT OF THE BATTERY FROM THE CORRIGO PROGRAMMABLE LOGIC CONTROLLER.......................55
21. INSPECTION, MAINTENANCE AND CLEANING .......................................................................................................56
21.1. Replacement of filters .....................................................................................................................................56
21.2. Filter installation .............................................................................................................................................57
21.3. Heat exchanger................................................................................................................................................58
21.4. Condensation drainpipe...................................................................................................................................59
22. OPERATION ANOMALIES..........................................................................................................................................60
22.1. General anomalies...........................................................................................................................................60
22.2. Failure list........................................................................................................................................................61
23. WIRING DIAGRAMS...................................................................................................................................................63
23.1. Main unit ..........................................................................................................................................................63
23.2. Rewiring to manage external modules (accessories).....................................................................................68

5
ENGLISH
1. INTRODUCTION
Thank you for purchasing this appliance. It has been manufactured in full compliance with applicable
safety regulations and EU standards.
Please read this instruction book carefully, as it contains important information for your safety during
the installation, use and maintenance of this product.
Keep it at hand for future reference.
Please check that the appliance is in perfect condition when you unpack it, as all factory defects are
covered by the S&P guarantee.
2. SAFETY REGULATIONS AND “CE” MARKING
S&P technicians are firmly committed to research and development of ever more efficient products
and in compliance with current safety regulations.
The instructions and recommendations given below reflect current regulations, principally regarding
safety, and therefore are based on compliance with general regulations. Therefore, we recommend all
people exposed to hazards to strictly follow the safety regulations in force in your country. S&P will not
be held liable for any possible harm or damage caused by non-compliance with the safety regulations,
as well as caused by modifying the product.
The CE mark and the corresponding declaration of conformity are proof of the product’s conformity
with current EU regulations.
3. GENERAL INSTRUCTIONS
A hazard analysis of the product has been carried out as provided in the Machine Directive. This ma-
nual contains information for all personnel exposed to these hazards, with the aim of preventing pos-
sible harm or damage due to faulty handling or maintenance.
All maintenance operations (ordinary and extraordinary) must be carried out with the machine swit-
ched off and the electrical power supply disconnected.
To avoid a possible accidental start up, place a warning notice on the electrical control panel with the
following text:
“Attention: control disconnected for maintenance operations”
Before connecting the power supply cable to the terminal strip, make sure the mains voltage corres-
ponds to the voltage indicated on the specifications plate of the unit.
Regularly check the product labels. If, due to the passing of time, they are no longer legible, they must
be replaced.
4. UNIT LABELLING
The machine may come with several pictograms that must not be removed. These signs are divided
into:
• Prohibition signs: Do not repair or adjust when in operation.
• Danger signs: Warning of the presence of live elements inside the container bearing the sign.
• Identification signs: CE card, indicating product information and manufacturer’s address. The CE
mark indicates the product’s conformity with EEC standards.
Danger signs Prohibition signs

6
ENGLISH
5. HANDLING
The CADB/T-HE models 04 to 33 are delivered fixed with screws to the pallets.
The models 40 and 54 are equipped with a bed, due to its weight are supplied without pallets. The unit
can be handled by a pallet transporter, a forklift, or a crane.
The handling machines will be adapted to the load and the lifting conditions. In all cases, the lifting will
be done at the device’s base. The centre of gravity is located at the centre of the unit. The device must
be carefully manipulated only in the horizontal position.
Models 04 to 33
Models 40 to 54

7
ENGLISH
6. INSTALLATION
6.1. INTRODUCTION
Horizontal models size 04, 08, 12, 16, 21 and 33
These models are designed to be installed hanging from the ceiling or located behind a false ceiling.
The 04, 08, 12, 16, 21 and 33 models have four metal brackets, one on each lower corner. Using studded
rods (Ø 8 mm), it can be secured to the ceiling and levelled.
The installer must make sure that the ceiling structure and the securing elements can bear the weight
of the device, taking into account that it is a dynamic load.
To prevent the transmission of vibrations from the unit to the rest of the installation, it is necessary
that the installer use specific isolation elements, such as antivibration devices in the supports, flexible
sleeves between the unit and the ducts, and flexible couplings between the water connections and the
pipelines.
Model Weight (kg)
4147
8183
12 190
16 235
21 333
33 420
Vertical models
The models size 4 to 21 are supplied with support feet, while the models size 40 and 54 are supplied
with a perimetral bed. This bed must be in contact with the ground or with a fl at surface. It is essential
that the weight of the equipment is distributed between all points of support to prevent unit deforma-
tion.
The installer must make sure that the ceiling structure and the securing elements can bear the
weight of the unit, taking into account that it is a dynamic load.

8
ENGLISH
Models 04 to 33
Model Weight (kg)
4149
8185
12 192
16 237
21 335
33 422
Models 40 and 54
Model Weight (kg)
40 597
54 730
Horizontal models of sizes 40 and 54
IMPORTANT!
Particularities in the installation of horizontal versions LH and RH
For a correct evacuation of condensation generated into the heat exchanger, it is necessary to install
the unit with a minimum slope of 3º to the side where the extraction fan is placed:
SUPPLY FAN EXTRACT FAN

9
ENGLISH
Horizontal models size 40 and 54 are supplied with a perimetral bed. This bed must be in contact with
the ground or with a flat surface. It is essential that the weight of the equipment is distributed between
all points of support to prevent unit deformation.
The installer must make sure that the ceiling structure and the securing elements can bear the
weight of the unit, taking into account that it is a dynamic load.
Model Weight (kg)
40 597
54 730
For all configurations
Once secured the device in correct position, the installer have to realise the connection with air duct,
connection to the electric supply, and in the case of versions with water coil, the connection with closed
circuit of hot water coil.
Inside of the unit are supplied the following accessories:
Drain*
a)
b) c)
x2 x2 x2 x1
Cable ManualRemote terminal
x1 x1
* In the models 40 and 54 the drain is installed by default in the unit.
The drain is composed by 3 pieces:
a) Drainpipe
b) Female screw
c) Joint ring Install the two drains as indicated in the following drawing:

10
ENGLISH
a) Horizontal versions of CADB/T HE 04 to 33
b) Horizontal versions of CADB/T HE 40 to 54
c) Vertical versions of CADB/T HE 04 to 33

11
ENGLISH
d) Vertical versions of CADB/T HE 40 to 54
In these versions, the drainpipe and the siphon are supplied mounted in the unit.
6.1.1. Outdoor installation
The CADB/T-HE PRO-REG range is designed to be mounted indoors. When it is installed
outdoors, it is necessary to place the equipment under a cover which offers enough protection
to prevent rain falling directly to the unit, or install the corresponding roof mounting.
In horizontal version, models 04 to 33, ensure the sufficient space below the unit, to install a
siphons in the drain pipe.
Drain pipe connexion
Rain protection canopy available, according to the heat recovery unit model:
Heat recovery unit model Rain protection cowl model
Horizontal (LH / RH) Vertical (LV / RV)
CADB-HE D/DI/DC 04 TPP-HE-H 04 TPP-HE-V 04
CADB-HE D/DI/DC 08 TPP-HE-H 08 TPP-HE-V 08
CADB-HE D/DI/DC 12 TPP-HE-H 12 TPP-HE-V 12
CADB-HE D/DI/DC 16 TPP-HE-H 16 TPP-HE-V 16
CADB/T-HE D/DI/DC 21 TPP-HE-H 21/33 TPP-HE-V 21
CADT-HE D/DI/DC 33 TPP-HE-H 21/33 TPP-HE-V 33
CADB/T-HE D/DI/DC 40 TPP-HE-H 40 TPP-HE-V 40
CADB/T-HE D/DI/DC 54 TPP-HE-H 54 TPP-HE-V 54

12
ENGLISH
Avoid condensations in electrical cabinet
In units located in outdoor installation where the heat recovery units stop during the night or
during long intervals of time, it is necessary to:
a) Install isolation dampers in air inlet and air outlet.
b) Add anticondensation devices in the electrical cabinet as: cabinet heating elements that pre-
vent condensation formation on cabinet surfaces and electronic components.
6.2. DIMENSIONS AND FREE SPACE FOR MAINTENANCE
a) Horizontal versions of CADB/T HE 04 to 21 (False ceiling installation)
Distances for maintenance in installations with access from the lateral panels
Conf. LH
Conf. RH
Access to filters and heat exchanger
Access to control panel, fans and coils/battery
connections (DI/DC versions)
Distances for maintenance in installations with access from the inferior panels
L
Conf. LH
Conf. RH
Access to filters and heat exchanger Access to filters and fan
Access to control panel, fans and coils/battery
connections (DI/DC versions) Access to heat exchanger
Model W H L A B C D Ø E F Weight
(kg)
04 760 375 1520 400 400 700 350 200 350 920 147
08 910 425 1750 450 400 860 400 250 400 950 183
12 1050 425 1700 500 400 1000 400 315 400 900 190
16 1240 450 1950 600 500 1190 425 315 400 1150 235
21 1640 550 2300 800 700 1590 525 400 500 1300 333
33 1640 650 2300 800 700 1590 625 400 500 1300 420

13
ENGLISH
b) Horizontal versions of CADB/T HE 40 and 54 (Ground installation)
  

  


R/STUVA;0MW1XY=ZN[\CI2E>] !"HJ3#$^_KO`<4aLb%:P.&F'?@PG5(6c)de*Q7+%fg,BhD89-i 
./0!'17
%234#567
# -+,$*7$$7
"&(-)7
Conf. LH
Conf. RH
Access to filters and heat exchanger
Access to control panel, motors and coils/
battery connections (DI/DC versions)
Ground installation
Model W H L A B Ø Weight
(kg)
40 1500 1200 2100 400 600 450 597
54 1550 1580 2250 400 750 500 730
c) Vertical versions of CADB/T HE

Conf. LV
Conf. RV
-4
444%.4


4
 

  

""

4
%.4
%/404444
&4
 

 
14
'4

"424
4
%4









 
 
"
!"
"



 
"



  



4(4
44
%%)44
 

 
34
Access to filters and heat exchanger
(On-site cleaning)
Access to control panel, motors and coils/
battery connections (DI/DC versions)
Model W H L A B Ø Weight
(kg)
4540 920 1125 400 400 200 149
8610 1020 1275 400 400 250 185
12 770 1020 1325 400 400 315 192
16 770 1070 1475 400 400 315 237
21 970 1270 1750 400 500 400 335
33 1170 1270 1750 400 500 400 412
40 1120 1580 2100 400 600 450 597
54 1500 1630 2250 400 800 500 730

14
ENGLISH
6.3. MOUNTING PROCESS OF AN ADDITIONAL SUPPLY FILTER
The heat recovery unit is supplied with the filters already installed.
F7 in exhaust air and M5 in supply air. In addition, it is possible to mount a second filter in the unit
(accessory). (For more information see section “Replacing filters”).
6.4. RANGE SPECIFICATIONS
D Models: without heater battery
Model Complete unit Fan Weight
(kg)
Air
connections
diameter
(mm)
Nominal
airflow
(m3/h)
Efficiency*
(%) Electrical supply Max. abs.
power
(kW)
Maximum
current
(A)
Speed
(r.p.m.) Maximum current
(A)
CADB-HE D 04 PRO-REG 200 450 87 1/230V, 50Hz 0,2 2,2 3700 0,95 147
CADB-HE D 08 PRO-REG 250 800 86,4 1/230V, 50Hz 0,4 2,9 2650 1,3 183
CADB-HE D 12 PRO-REG 315 1.200 85,3 1/230V, 50Hz 0,95 3,5 2550 1,6 190
CADB-HE D 16 PRO-REG 315 1.600 85,5 1/230V, 50Hz 0,95 4,3 2845 2,0 235
CADB-HE D 21 PRO-REG 400 2.100 86,7 1/230V, 50Hz 0,9 4,7 1580 2,2 333
CADT-HE D 33 PRO-REG 400 3.300 85,9 3+N/400V, 50Hz 2,2 4,3 2600 2,0 420
CADB-HE D 40 PRO-REG 450 4.000 86,8 1/230V, 50Hz 2,5 15,1 2340 7,4 597
CADB-HE D 54 PRO-REG 500 5.400 87,1 1/230V, 50Hz 3,4 20,3 2110 10 730
* Humid efficiency referring to nominal airflow, outdoor conditions (-5ºC / 80% RH) and indoor (20ºC / 50% RH)
DC Models: with built-in hot water coil
Model Complete unit Fan Hot water coil Weight
(kg)
Air
connections
diameter
(mm)
Nominal
airflow
(m
3
/h)
Efficiency*
(%) Electrical supply Max. abs.
power
(kW)
Maximum
current
(A)
Speed
(r.p.m.) Maximum current
(A)
Heat
power
T.water
80/60ºC
(kW)
Heat
power
T.water
50/45ºC
(kW)
CADB-HE DC 04 PRO-REG 200 450 87,0 1/230V, 50Hz 0,2 2,2 3700 0,95 2,7 1,6 149
CADB-HE DC 08 PRO-REG 250 800 86,4 1/230V, 50Hz 0,4 2,9 2650 1,3 5,1 3,1 186
CADB-HE DC 12 PRO-REG 315 1.200 85,3 1/230V, 50Hz 0,95 3,5 2550 1,6 7,1 4,3 193
CADB-HE DC 16 PRO-REG 315 1.600 85,5 1/230V, 50Hz 0,95 4,3 2845 2,0 8,6 5,3 239
CADB-HE DC 21 PRO-REG 400 2.100 86,7 1/230V, 50Hz 0,9 4,7 1580 2,2 12,6 7,8 338
CADT-HE DC 33 PRO-REG 400 3.300 85,9 3+N/400V, 50Hz 2,2 4,3 2600 2,0 18,2 11,1 427
CADB-HE DC 40 PRO-REG 450 4.000 86,8 1/230V, 50Hz 2,5 15,1 2340 7,4 23,9 14,4 606
CADB-HE DC 54 PRO-REG 500 5.400 87,1 1/230V, 50Hz 3,4 20,3 2110 10 32,1 19,5 742
* Humid efficiency referring to nominal airflow, outdoor conditions (-5ºC / 80% RH) and indoor (20ºC / 50% RH)
DI Models: with built-in electric heater battery
Model Complete unit Fan Electrical heater
battery
Weight
(kg)
Air
connections
diameter
(mm)
Nominal
airflow
(m
3
/h)
Efficiency*
(%) Electrical supply Max. abs.
power
(kW)
Maximum
current
(A)
Speed
(r.p.m.) Maximum current
(A)
Power
(kW)
Maximum
current
(A)
CADB-HE DI 04 PRO-REG 200 450 87,0 1/230V, 50Hz 1,2 6,7 3700 0,95 1 4,5 148
CADB-HE DI 08 PRO-REG 250 800 86,4 1/230V, 50Hz 2,4 12,0 2650 1,3 2 9,1 185
CADB-HE DI 12 PRO-REG 315 1.200 85,3 1/230V, 50Hz 4,0 14,9 2550 1,6 3 11,4 192
CADB-HE DI 16 PRO-REG 315 1.600 85,5 1/230V, 50Hz 4,5 20,2 2845 2,0 3,5 15,9 237
CADB-HE DI 21 PRO-REG 400 2.100 86,7 3+N/400V, 50Hz 6,9 13,8 1580 2,2 6 9,11 336
CADT-HE DI 33 PRO-REG 400 3.300 85,9 3+N/400V, 50Hz 9,7 15,7 2600 2,0 7,5 11,4 424
CADB-HE DI 40 PRO-REG 450 4.000 86,8 3+N/400V, 50Hz 11,5 28,8 2340 7,4 9 13,7 602
CADB-HE DI 54 PRO-REG 500 5.400 87,1 3+N/400V, 50Hz 15,4 38,5 2110 10 12 18,2 737
* Humid efficiency referring to nominal airflow, outdoor conditions (-5ºC / 80% RH) and indoor (20ºC / 50% RH)

15
ENGLISH
6.5. CONNECTIONS
6.5.1. Piping and duct connections
6.5.1.1. Connection with air duct
The fans are always blowing out with regard to the machine. Before making the connection of air
lines, verify existing identification labels in each mouth of the heat recovery units.
Outdoor air
Aire exterior
Aria di rinnovo
Air neur
Aussenluft
Extract air
Aire de extracción
Estrazione dal locale
Air repris
Abluft
Exhaust air
Aire de expulsión
Espulsione all esterno
Air rejeté
Fortluft
Supply air
Aire de impulsión
Inmissione
Air Soufflé
Zuluft
6.5.1.2. Connecting the water coil piping. DC Versions
Connecting the unit to the water network
- Maximum pressure: 10 bar
- Maximum temperature: 100°C
• Minimum temperature: -20ºC (with the addition of
the corresponding antifreeze).
• Water coils of DC versions have threaded connec-
tions. Secure the coil manifold with the appropiate
tool when tightening the threads. This will prevent
the force from being transmitted to the manifold,
which can damage it.
• The following table indicate the size and type o thread used on water coils for DC versions:
CADB/T-HE MODEL THREAD
04, 08, 16, 21 and 33 1/2”
40 and 54 1”
• To ensure the installation on a hand, it is essential that the installation includes the following
elements:
- Unit intake pre-filter that traps suspended particulate matter.
- Bleed valves should be fitted at each of the high points in the installation.
- Auto-filter valve to keep water in the hydraulic system at all times.
- Pressure to detect the lack of water pressure.
- Shut-off valves must be installed at each connection on the water line to allow the unit to be
isolated if necessary (to clean filters, make repairs, replace parts, etc) and avoid the need to
completely drain the water circuit.
- Anti-vibration bellows should be installed at the inlet and outlet from the unit to prevent
the transmission of vibrations that could result in damage to the heat exchanger coil due to
excess stress on the circuits.
Once the installation is performed check that the heating water flow is adequate.

16
ENGLISH
6.5.1.3. Condensate drainage
The units are supplied with 2 drains (one for each circuit). For added security it has to connect
two drains to the condensate discharge pipe. This connection must be made through a pipe of
22 mm of inner diameter and a flange for secure fixation.
Drainage system
• To ensure the removal of draining condensate from the tray a siphon must be installed with
pressure head difference in mmWG greater than the pressure provided by the fan.
• The horizontal sections should have a minimum slope of 2%.
Condensation connection
6.5.2. Electrical connection
In the recovery unit PRO-REG range, all components integrated into the device, are supplied into
the electrical panel (motors, pressure filters, motor pressure switches, temperature sensors,
batteries and by-pass damper).
The electrical connection is limited to the connection of control terminal (10 m. of supplied ca-
ble) and possible electrical accessories as such as CO2sensors or control valves for water coils,
and finally the connection of the power supply line.
Make electrical connection in accordance with the described in the corresponding wiring dia-
gram, found at the end of this manual.
6.5.2.1. External Touch Display (ETD) control connection
The ETD control must be connected to the controller with a 4 wires shielded twisted-wire pair
cable of 100 m max length. 4P4C connector is reserved for ETD.

17
ENGLISH
The ETD control has an electrical protection IP-20 degree, so it is valid; it is reserved exclusively
for an indoor usage sheltered from moisture.
It is equipped with an internal temperature probe.
In case of an outdoor mounting of the CADB/T-HE unit OI, you can also leave it inside the hou-
sing of the electrical box. Once the parameter setting is done, the remote control can be dis-
connected.
Placement of the support and the remote control:
ETD remote control Fixation support
6.6. CONFIGURATIONS
CADB/T-HE D/DI/DC PRO-REG standard configuration
From these configurations there are multiple variables that can be performed by the professional
installer quickly and easily.
Panel replacement process
The CADB-HE heat recovery units are available in two configurations LH and RH in the horizontal mo-
dels and LV, RV in vertical models.

18
ENGLISH
Vertical
Horizontal
Factory configuration
LH
RH
Examples of some of the configurations that is possible to obtain from
factory configuration
Factory configuration
LV
Examples of some of the configurations that is possible to obtain from
factory configuration
RV
EXHAUST AIR
FRESH AIR

19
ENGLISH
7. CONTROL FUNCTIONS
MAIN ELEMENTS
Control panel includes:
General switch
Electric box including control and wiring components, with access from side panel.
FUNCTIONS
Airflow adjustments
Manual airflow adjustment, adjustable at any point of the fan curve.
Automatic airflow adjustment, according to time band (Through a timer, included in the controller))
Automatic airflow adjustment in VAV mode, according to external signal 0-10V (CO2accessory)
Automatic speed adjustment of the fans in Constant Arflow mode (Increase of fan speed on the basis of pollution
of filters)
Automatic speed adjustment of the fans in Constant Pressure mode (Increase of fan speed when pressure in the
duct system decreases)
BOOST function (Forced speed preset via external power free contact)
ON/OFF function (Remote ON/OFF via external power free contact)
Temperature regulation
Temperature probes integrated within the unit (supply, extract, inlet and outlet)
Anti-frost probe water coil (DC-Versions)
Thermal power regulation of hot water coil
Modulating 3 points control of water valve (accessory)
Regulation of water coil thermal power. 0-10V control of the water valve (accessory).
Regulation of electric heater battery thermal power in DI versions. Proportional control via SSR.
Bypass adjustments
Manual actuation of bypass
Automatic actuation of bypass function free-cooling/ free-heating and heat exchanger anti-freezing protection
Night free-cooling mode (Cooling of the building at night)
SECURITY FUNCTIONS
Control of polluted filters via pressure switches (included)
Alarm display in remote control
Detailed information of alarms
Failure in temperature probes
Failure in fan via pressure switches (included)
Fire alarm indication, via activation by external contact coming from fire switchboard.
Anti-frost protection of heat exchanger via bypass activation.
COMMUNICATION
Remote wiring control
ON/OFF remote digital input via external power free contact.
Alarm digital output via power free contact.
Modbus RTU (RS-485)
Bacnet TCP/IP

20
ENGLISH
8. CONTROL SCHEME
D version
SF
EF
S1
S2
S3
S4
FCD
FFD
HE
RT
F7
M5
M
FC
SCO2
TDP
ID
SM
Supply fan
Extract fan
Supply temperature probe
Extract temperature probe
Inlet temperature probe
Outlet temperature probe
Polluted filters detector (pressure switch)
Failure motor detector (pressure switch)
High-efficiency heat exchanger
Remote control panel
Supply filter
Extract filter
Bypass actuator
Frequency inverter (models 40 and 54)
CO2sensor (accessory)
Pressure sensor TDP-S (accessory)
Isolation damper (accessory)
Actuator damper (accessory)
DI version
SF
EF
S1
S2
S3
S4
FCD
FFD
HE
RT
F7
M5
M
Pr1/Pr2
SSR
FC
SCO2
TDP
ID
SM
Supply fan
Extract fan
Supply temperature probe
Extract temperature probe
Inlet temperature probe
Outlet temperature probe
Polluted filters detector (pressure switch)
Failure motor detector (pressure switch)
High-efficiency heat exchanger
Remote control panel
Supply filter
Extract filter
Bypass actuator
Security protectors (Manual/Auto)
Electric heater battery proportional regulator
Frequency inverter (models 40 and 54)
CO2sensor (accessory)
Pressure sensor TDP-S (accessory)
Isolation damper (accessory)
Actuator damper (accessory)
