Sandstrom SF-DABA18 User manual

Portable Bluetooth® DAB
Radio
Instruction Manual
SF-DABA18 / SF-DABG18

Contents
Safety Warnings.............................................................................................. 5
Unpacking....................................................................................................... 8
Product Overview........................................................................................... 9
Front View ...........................................................................................................................9
Rear View...........................................................................................................................10
Top View ............................................................................................................................11
Connections .................................................................................................. 12
Using the AUX Connection.........................................................................................12
Using Earphones ............................................................................................................12
Power Source ................................................................................................ 14
Mains Power.....................................................................................................................14
Battery Power ..................................................................................................................15
Battery Life (Approx. Hours) .......................................................................................15
Knowing when to Replace the Batteries................................................................15
General Operation........................................................................................ 17
Powering ON/OFF ..........................................................................................................17
Selecting Modes .............................................................................................................17
Adjusting the Volume...................................................................................................17
Automatically Setting the Clock...............................................................................18
Adjusting the Brightness.............................................................................................18
System Settings ............................................................................................ 18
Setting a Sleep Timer....................................................................................................18
Equaliser ............................................................................................................................19
Setting Time and Date..................................................................................................19
Backlight............................................................................................................................20
Inactive Standby.............................................................................................................20
Language ..........................................................................................................................20
Factory Reset....................................................................................................................21
Software version.............................................................................................................21
Alarm ..................................................................................................................................22

Activate/Deactivate the Alarm Function...............................................................23
DAB Operation.............................................................................................. 24
Auto Scan..........................................................................................................................24
Manual Tune.....................................................................................................................25
Presetting Stations.........................................................................................................25
Recalling a Preset Station............................................................................................26
DAB Display Modes .......................................................................................................26
FM Operation ................................................................................................ 28
Selecting FM Mode........................................................................................................28
Searching for a Station Automatically....................................................................28
Searching for a Station Manually..............................................................................28
Scan Setting .....................................................................................................................28
Audio Setting...................................................................................................................29
Presetting Stations.........................................................................................................29
Recalling a Preset Station............................................................................................30
FM Display Modes..........................................................................................................30
Bluetooth® Operation .................................................................................. 32
AUX Operation.............................................................................................. 33
Maintenance ................................................................................................. 34
Cleaning the Unit ...........................................................................................................34
Hints and Tips................................................................................................ 34
Specications................................................................................................ 35

Safety Warnings
• Read all the instructions carefully
before using the unit and keep
them for future reference.
• Retain the manual. If you pass the
unit onto a third party make sure
to include this manual.
• Check that the voltage marked
on the rating label matches your
mains voltage.
Damage
• Please inspect the unit for
damage after unpacking.
• Do not continue to operate the
unit if you are in any doubt about
it working normally, or if it is
damaged in any way - switch o,
withdraw the mains plug and
consult your dealer.
Location of Unit
• The unit must be placed on a at
stable surface and should not be
subjected to vibrations.
• Do not place the unit on sloped
or unstable surfaces as the unit
may fall o or tip over.
• The mains socket must be located
near the unit and should be easily
accessible.
• This unit is designed for indoor,
domestic use only.
Temperature
• Avoid extreme degrees of
temperature, either hot or cold.
Place the unit well away from
heat sources such as radiators or
gas/electric res.
• Avoid exposure to direct sunlight
and other sources of heat.
Naked Flames
• Never place any type of candle or
naked ame on the top of or near
the unit.
Moisture
• To reduce the risk of re, electric
shock or product damage, do not
expose this unit to rain, moisture,
dripping or splashing. No objects
lled with liquids, such as vases,
should be placed on the unit. Do
not operate the unit with wet
hands, near water or other liquid.
• If you spill any liquid into the
unit, it can cause serious damage.
Switch it o at the mains
immediately. Withdraw the mains
plug and consult your dealer.
Ventilation
• To prevent the risk of electric
shock or re hazard due to
overheating, ensure that curtains
and other materials do not
obstruct the ventilation vents.
• Do not install or place this unit in
a bookcase, built-in cabinet or in
another conned space. Ensure
the unit is well ventilated.
5

Safety
• Always disconnect the unit
from the mains supply before
connecting/ disconnecting other
devices or moving the unit.
• Unplug the unit from the mains
socket before a lightning storm.
Mains Adapter Cable
• Make sure the unit or unit stand
is not resting on top of the mains
adapter cable, as the weight of
the unit may damage the cable
and create a safety hazard.
Mains Adapter
• The mains adapter will continue
to draw electricity from the mains
supply when plugged in the
mains socket. In the interests of
safety and to avoid unnecessary
energy consumption, never leave
the adapter plugged in the mains
socket while unattended for long
periods of time. Disconnect the
adapter from the power supply.
• The adapter plug is the
disconnecting device. Install this
unit so that the adapter can be
unplugged from the socket outlet
immediately.
Use only power supplies
listed in the user instructions.
The mains adapter is used
as disconnect device, the
disconnect device shall
remain readily operable.
Interference
• Do not place the unit on or near
appliances which may cause
electromagnetic interference. If
you do, it may adversely aect
the operating performance of the
unit, and cause a distorted picture
or sound.
Earphones
• Listening to loud
sounds for prolonged
periods of time may
permanently damage
your hearing.
Supervision
• Children should be supervised to
ensure that they do not play with
the unit.
• Never let anyone especially
children push anything into the
holes, slots or any other openings
in the case - this could result in a
fatal electric shock.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with
arrowhead symbol, within an
equilateral triangle, is
intended to alert the user to
the presence of uninsulated
“dangerous voltage” within
the unit’s enclosure that may
be of sucient magnitude to
constitute a risk of electric
shock.
The exclamation point within
an equilateral triangle is
intended to alert the user to
6

the presence of important operating
and maintenance (servicing)
instructions in the manual
accompanying the unit.
Service
• To reduce the risk of electric
shock, do not remove screws. The
unit does not contain any user-
serviceable parts. Please leave all
maintenance work to qualied
personnel.
• Do not open any xed covers
as this may expose dangerous
voltages.
Batteries
• Batteries used in the unit are
easily swallowed by young
children and this is dangerous.
• Keep loose batteries away from
young children and make sure
that the battery holder tray is
secure in the unit. Seek medical
advice if you believe a cell has
been swallowed.
• Please dispose of batteries
correctly by following the
guidance in this manual.
• Do not expose the battery to
direct sunlight or sources of
excessive heat.
• Attention should be drawn to the
environmental aspects of battery
disposal.
Risk of explosion if the
battery is replaced by an
incorrect type;
Disposal of a battery
into re or a hot oven, or
mechanically crushing or
cutting of a battery, that can
result in an explosion;
Leaving a battery in an
extremely high temperature
surrounding environment
that can result in an
explosion or the leakage of
ammable liquid or gas
A battery subjected to
extremely low air pressure
that may result in an
explosion or the leakage of
ammable liquid or gas
Maintenance
• Ensure the unit is fully unplugged
from the power supply before
cleaning.
• Do not use any type of abrasive
pad or abrasive cleaning solutions
as these may damage the unit’s
surface.
• Do not use liquids to clean the
unit.
• This equipment is a Class
II or double insulated
electrical appliance. It has
been designed in such a
way that it does not require
a safety connection to
electrical earth.
~ AC voltage: This symbol indicates
that the rated voltage marked with
the symbol is AC voltage.
DC voltage: This symbol indicates
that the rated voltage marked with
the symbol is DC voltage.
7

Main Unit Mains Adapter
Instruction Manual 3.5 mm to 3.5 mm stereo
audio cable
Instruction
Manual
If items are missing, or damaged please contact Partmaster (UK
only).
Tel: [phone] for assistance.
Thank you for purchasing your new product.
We recommend that you spend some time reading this instruction
manual in order that you fully understand all the operational
features it oers. You will also nd some hints and tips to help you
resolve any issues.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose
of it please do so according to local regulations.
The following items are included:
8

Product Overview
Front View
1. Speakers
2. Adjustable Handle
3. Display
3
2
1
9

1. Battery Compartment
2. DAB / FM Aerial
3. 12V 1A Socket
4. AUX IN Socket
5. Earphones Socket
6. RESET Button
3 4 5 621
Rear View
RESETAUX IN
12V 1A
10

1. STANDBY/MUTE Button
• Press to switch between On and Standby mode.
• In On mode, press and hold to mute/resume playback.
2. ALARM Button
Press to enter Alarm 1/2 Setup menu.
3. MODE Button
Press to switch between FM, DAB, Auxiliary Input and Bluetooth
mode.
4. DIMMER Button
Press repeatedly to select the brightness level.
5. PRESETS 1/2/3 Button
• Press and hold to directly save preset station 1-3.
• Press to directly recall preset station 1-3.
6. –VOLUME+/SELECT/SNOOZE Dial
• Turn to increase/decrease volume.
• Press to conrm a selection in the menu.
• Press to activate the snooze function when the alarm sounds.
• Press to pause/resume playback in Bluetooth mode.
• Press and hold to disconnect the paired device in Bluetooth mode.
• Press and hold to reconnect the last paired device in Bluetooth mode.
Top View
2
3 4 5 6
1
11

7. INFO/MENU Button
• Press repeatedly to show the information.
• Press and hold to enter the menu page.
8. Button
• Press to skip backwards to the beginning of the track or to the
previous track in Bluetooth mode.
• Press to skip forwards to the next track in Bluetooth mode.
• Press to tune FM station.
• Press and hold to search for a radio station going forwards/
backwards through accessible radio frequencies in FM mode.
• Press to select DAB station.
87
12

Connections
Using the AUX Connection
Use a 3.5 mm to 3.5 mm stereo audio cable (included) to connect a mobile
device to the main unit’s AUX IN socket.
RESETAUXIN
12V 1A
RESETAUXIN
12V 1A
Using Earphones
Turn down the volume before connecting the earphones (not included).
Slowly raise the volume with the earphones on until you reach your desired
volume. When earphones are connected, the speakers automatically mute.
Long-term exposure to loud music may cause hearing damage. It
is best to avoid extreme volume when using earphones, especially
for extended periods.
13

RESETAUX IN
12V 1A
To the mains socket
Power Source
Your unit can be mains powered or battery powered. We recommend for
prolonged use to use the mains power.
Mains Power
Connecting the unit to any other power source may damage the unit.
Unwind the mains adapter cable to its full length. Connect the end of the
cable to the DC IN Socket at the rear of the unit and then connect
the mains adapter to the mains socket. Make sure the mains adapter is
rmly inserted into the mains socket. The unit is now connected and ready
to use.
Ensure all connections are connected before connecting to the
mains power socket.
Extend the aerial before switching to DAB mode for the rst time.
This will ensure that the initial scan captures all stations in your
area.
14

RESETAUX IN
12V 1A
Battery Power
Insert 4 x 1.5V AA battery (not included) into the battery compartment
located at the rear of the unit.
Battery Life (Approx. Hours)
Battery Type
Alkaline (Size AA)
DAB FM
5 5
Using your radio at high volume will reduce your battery life.
Knowing when to Replace the Batteries
When the batteries become weak, the sound becomes weak and distorted.
The display backlight becomes unstable when a button is pressed. The
display will show“Battery Low“.
When the batteries are completely exhausted, the power is turned o.
15

Handling the Batteries
• Improper or incorrect use of batteries may cause corrosion or
battery leakage, which could cause personal injury or damage
to property.
• Install the batteries correctly by following the polarity (+ and –)
indications in the battery compartment.
• Use only the types of the batteries which are indicated in this
manual.
• Do not install new batteries with used ones and do not mix
dierent types of batteries.
• Do not dispose of the used batteries as domestic waste.
Dispose of them in accordance with local regulations.
• If you are not going to use the unit for a long time, remove the
batteries to avoid damage from battery leakage and corrosion.
Due to the short battery life span of some alkaline batteries, it
is recommended to use rechargeable batteries. You will need to
purchase a charger to charge the rechargeable batteries. This
saves money and is more environmentally friendly.
16

General Operation
Powering ON/OFF
After connecting the mains adapter to the unit and the mains socket, the
unit will enter Standby mode.
• Press the STANDBY/MUTE button to switch on the unit.
• Press the STANDBY/MUTE button again to switch the unit back to
Standby mode.
• Disconnect the power cable of the mains adapter from the mains socket
if you want to switch the unit o completely.
The unit will automatically Standby mode after 15 minutes if
there is no audio input signal in Auxiliary Input or Bluetooth
mode. Press the STANDBY/MUTE button to resume.
While using battery power,
• Press the STANDBY/MUTE button to switch on the unit.
• Press the STANDBY/MUTE button again to switch o the unit.
Selecting Modes
Press MODE button repeatedly on the unit to switch between DAB, FM,
Bluetooth and Auxiliary Input mode.
Adjusting the Volume
• Turn –VOLUME+/SELECT/SNOOZE dial to increase/decrease the
volume.
• Press and hold the STANDBY/MUTE button to mute/resume playback.
17

Automatically Setting the Clock
The clock will be updated automatically if you can receive DAB/FM signal in
your location.
In order to synchronise to the current local time, you must leave it on the
DAB/FM station for a period of time. It may take about 1-2 minutes to
receive the time signal.
If there is no DAB broadcast in your area, switch the unit into
FM mode to receive the time signal, or you may set the clock
manually (Refer to“Setting the Time and Date” section below).
Adjusting the Brightness
In Standby mode, press the DIMMER dial repeatedly to select the
brightness level.
System Settings
Setting a Sleep Timer
You can set a sleep timer so if you are listening to your radio and fall asleep,
it will automatically switch o at the preset time. The sleep timer can be
activated for up to a maximum of 90 minutes.
1. In ON mode, press and hold the INFO/MENU button, and then turn the
–VOLUME+/SELECT/SNOOZE dial or press the button to select
<System>. Press the –VOLUME+/SELECT/SNOOZE dial to conrm.
2. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select <Sleep>. Press the –VOLUME+/SELECT/SNOOZE dial to
conrm.
3. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select between <Sleep o>, <15 minutes>, <30 minutes>, <45
minutes>, <60 minutes> or <90 minutes>, and then press the –
VOLUME+/SELECT/SNOOZE dial to conrm.
4. When a sleep timer has been set, the “ ” symbol will be displayed.
18

Equaliser
Your radio has preset equaliser setting. This feature enables you to set a
sound equalization prole. The equalization setting will change the tone of
the sound from your radio.
1. In ON mode, press and hold the INFO/MENU button, and then turn the
–VOLUME+/SELECT/SNOOZE dial or press the button to select
<System>. Press the –VOLUME+/SELECT/SNOOZE dial to conrm.
2. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select <Equaliser>. Press the –VOLUME+/SELECT/SNOOZE dial to
conrm.
3. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select a prole through <Normal>, <Classic>, <Jazz>, <Pop>,
<Rock>, and <Speech>, and then press the –VOLUME+/SELECT/
SNOOZE dial to conrm.
Setting Time and Date
1. Press and hold the INFO/MENU button, and then turn the –VOLUME+/
SELECT/SNOOZE dial or press the button to select <System>.
Press the –VOLUME+/SELECT/SNOOZE dial to conrm.
2. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select <Time>. Press the –VOLUME+/SELECT/SNOOZE dial to
conrm.
3. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select options, and then press the –VOLUME+/SELECT/SNOOZE dial
to conrm.
Set Time/Date Here you can manually set the time and date.
Auto update Choose how you want the time to be
automatically updated: Update from Any /
Update from FM / Update from DAB / No
update
Set 12/24 hour Set 12 hour or Set 24 hour display.
4. Press the INFO/MENU button to exit the menu.
19

Backlight
You can set the brightness for the power on screens and the Standby
screen.
1. In ON mode, press and hold the INFO/MENU button, and then turn the
–VOLUME+/SELECT/SNOOZE dial or press the button to select
<System>. Press the –VOLUME+/SELECT/SNOOZE dial to conrm.
2. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select <Backlight>. Press the –VOLUME+/SELECT/SNOOZE dial to
conrm.
3. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select between <High>, <Medium> or <Low>, and then press the
–VOLUME+/SELECT/SNOOZE dial to conrm.
Inactive Standby
1. In ON mode, press and hold the INFO/MENU button, and then turn the
–VOLUME+/SELECT/SNOOZE dial or press the button to select
<System>. Press the –VOLUME+/SELECT/SNOOZE dial to conrm.
2. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select <Inactive Standby>. Press the –VOLUME+/SELECT/SNOOZE
dial to conrm.
3. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select between <O>, <2 hour>, <4 hour>, <5 hour> or <6 hour>,
and then press the –VOLUME+/SELECT/SNOOZE dial to conrm.
Language
This feature enables you to change menu language.
1. In ON mode, press and hold INFO/MENU button, and then turn the
–VOLUME+/SELECT/SNOOZE dial or press the button to select
<System>. Press the –VOLUME+/SELECT/SNOOZE dial to conrm.
2. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select <Language>. Press the –VOLUME+/SELECT/SNOOZE dial to
conrm.
3. Turn the –VOLUME+/SELECT/SNOOZE dial or press the button
to select a language, and then press –VOLUME+/SELECT/SNOOZE dial
to conrm.
20
