Sandstrom SVDB12E User manual

Instruction Manual
DAB+ / FM Radio
SVDB12E / SVDW12E
GB
NO
SE
FI
DK
SVDB12E SVDW12E
Instruction Manual
DAB+ / FM Radio
Bruksanvisning
DAB+ / FM-radio
Bruksanvisning
DAB+ / FM Radio
Käyttöopas
DAB+ / FM-radio
Brugervejledning
DAB+ / FM Radio
SVDB_W12E_IB_RC_Final121106.indb 1 7/11/12 4:56 PM

SVDB_W12E_IB_RC_Final121106.indb 2 7/11/12 4:56 PM

Contents GB
Unpacking............................................................................. 6
Product Overview................................................................. 7
Front View............................................................................................... 7
Rear View ................................................................................................ 7
Power Source ........................................................................ 8
Mains Power .......................................................................................... 8
Connections .......................................................................... 8
Using Earphones.................................................................................. 8
Basic Operation .................................................................... 9
Powering ON/OFF................................................................................ 9
Selecting Modes................................................................................... 9
Adjusting the Volume......................................................................... 9
Setting the Clock ................................................................................. 9
Setting the Alarm................................................................................. 9
Activating the Alarm Function......................................................10
Automatic Alarm Repeat.................................................................10
Snooze Function ................................................................................10
Sleep Function....................................................................................10
Display Backlight................................................................................11
System Reset .......................................................................................11
Software Version ................................................................................11
DAB Operation.................................................................... 12
DAB Auto Scan....................................................................................12
Secondary Services...........................................................................13
Manual Tuning....................................................................................13
Presetting Stations ............................................................................14
Recalling a Preset Station................................................................14
DAB Display Modes...........................................................................15
FM Operation...................................................................... 16
Switching from DAB to FM Mode.................................................16
Auto Scan..............................................................................................16
Manual Scan ........................................................................................16
Audio Mode.........................................................................................16
Presetting Stations ............................................................................16
Recalling a Preset Station................................................................17
FM Display Modes .............................................................................17
Maintenance ....................................................................... 18
Hints and Tips...................................................................... 18
Specications...................................................................... 18
Safety Warnings.................................................................. 71
Innhold NO
Pakke opp............................................................................ 19
Produktoversikt.................................................................. 20
Sett forfra..............................................................................................20
Sett bakfra ............................................................................................20
Strømkilde........................................................................... 21
Strøm fra stikkontakt........................................................................21
Forbindelser........................................................................ 21
Bruke øretelefoner.............................................................................21
Elementær betjening ......................................................... 22
Slå På/av................................................................................................22
Velge modus........................................................................................22
Justere volumet..................................................................................22
Stille inn klokken ...............................................................................22
Stille inn alarmen...............................................................................22
Slik aktiveres alarmfunksjonen.....................................................23
Automatisk alarmrepetisjon ..........................................................23
Slumrefunksjon ..................................................................................23
Sovnefunksjon....................................................................................23
Bakgrunnsbelysning.........................................................................24
Systemtilbakestilling ........................................................................24
Programvareversjon..........................................................................24
Bruk av DAB ........................................................................ 25
Autosøk i DAB .....................................................................................25
Sekundære tjenester ........................................................................26
Manuell innstilling.............................................................................26
Forhåndsinnstille stasjoner............................................................27
Gjenopprette en forhåndsinnstilt stasjon.................................27
DAB-visningsmoduser .....................................................................28
Bruk av FM........................................................................... 29
Bytte fra DAB til FM...........................................................................29
Autosøk .................................................................................................29
Manuelt søk .........................................................................................29
Lydmodus.............................................................................................29
Forhåndsinnstille stasjoner............................................................29
FM-visningsmoduser........................................................................30
Gjenopprette en forhåndsinnstilt stasjon.................................30
Vedlikehold......................................................................... 31
Råd og tips .......................................................................... 31
Spesikasjoner ................................................................... 31
Sikkerhetsadvarsler ........................................................... 71
SVDB_W12E_IB_RC_Final121106.indb 3 7/11/12 4:56 PM

Innehållsförteckning SE
Packa upp............................................................................ 32
Produktöversikt.................................................................. 33
Vy framifrån..........................................................................................33
Baksida...................................................................................................33
Strömkälla........................................................................... 34
Elnät........................................................................................................34
Anslutningar ....................................................................... 34
Använda hörlurar...............................................................................34
Grundläggande handhavande.......................................... 35
Ström PÅ/AV.........................................................................................35
Välja läge...............................................................................................35
Justera volymen .................................................................................35
Inställning av klockan .....................................................................35
Ställa in larmet....................................................................................35
Aktivering av larmfunktionen. ......................................................36
Automatisk larmrepetition.............................................................36
Slummerfunktion...............................................................................36
Insomningsfunktion .........................................................................36
Displayens bakgrundsbelysning..................................................37
Systemåterställning ..........................................................................37
Programversion..................................................................................37
DAB-drift ............................................................................. 38
DAB automatisk sökning.................................................................38
Sekundära tjänster ............................................................................39
Manuell inställning............................................................................39
Förinställa stationer ..........................................................................40
Hämta en förinställd station..........................................................40
DAB visningslägen.............................................................................41
FM-hantering ...................................................................... 42
Växla från DAB till FM-läge .............................................................42
Auto sök ................................................................................................42
Manuell sökning.................................................................................42
Ljudläge.................................................................................................42
Förinställa stationer ..........................................................................42
Hämta en förinställd station..........................................................43
FM visningslägen...............................................................................43
Underhåll............................................................................. 44
Tips och råd......................................................................... 44
Specikationer.................................................................... 44
Säkerhetsvarningar............................................................ 72
Sisältö FI
Pakkauksesta purkaminen ................................................ 45
Tuotteen yleiskatsaus ........................................................ 46
Näkymä edestä...................................................................................46
Näkymä takaa......................................................................................46
Virtalähde............................................................................ 47
Verkkovirta...........................................................................................47
Liitännät .............................................................................. 47
Korvakuulokkeiden käyttö .............................................................47
Peruskäyttö......................................................................... 48
Virran kytkeminen Päälle/Pois.......................................................48
Tilojen valinta......................................................................................48
Äänenvoimakkuuden säätö...........................................................48
Kellon asettaminen ..........................................................................48
Herätyksen asettaminen.................................................................48
Hälytystoiminnon aktivointi ..........................................................49
Automaattinen hälytyksen toisto................................................49
Torkkutoiminto...................................................................................49
Unitoiminto..........................................................................................49
Näytön taustavalo..............................................................................50
Järjestelmän nollaus.........................................................................50
Ohjelmistoversio................................................................................50
DAB-käyttö.......................................................................... 51
Automaattinen DAB-haku..............................................................51
Toissijaiset palvelut ...........................................................................52
Manuaalinen viritys...........................................................................52
Asemien esiasettaminen.................................................................53
Esiasetusaseman nouto...................................................................53
DAB-näyttötilat...................................................................................54
FM-käyttö............................................................................ 55
Vaihtaminen DAB-tilasta FM-tilaan.............................................55
Automaattinen haku ........................................................................55
Manuaalinen haku.............................................................................55
Audiotila................................................................................................55
Asemien esiasettaminen.................................................................55
FM-näyttötilat......................................................................................56
Esiasetusaseman nouto...................................................................56
Kunnossapito...................................................................... 57
Vihjeitä ja vinkkejä............................................................. 57
Tekniset tiedot.................................................................... 57
Turvallisuusvaroitukset ..................................................... 72
SVDB_W12E_IB_RC_Final121106.indb 4 7/11/12 4:56 PM

Indholdsfortegnelse DK
Udpakning .......................................................................... 58
Produktoversigt.................................................................. 59
Set forfra................................................................................................59
Set bagfra .............................................................................................59
Strømkilde........................................................................... 60
Stikkontakt ...........................................................................................60
Tilslutninger........................................................................ 60
Brug af øretelefoner..........................................................................60
Grundlæggende anvendelse ............................................. 61
Sådan TÆNDES/SLUKKES enheden .............................................61
Valg af funktioner ..............................................................................61
Indstilling af lydstyrken ...................................................................61
Indstilling af uret ...............................................................................61
Indstilling af vækkeuret...................................................................61
Aktivering af vækkeuret..................................................................62
Automatisk gentagelse af alarmen.............................................62
Slumrefunktionen..............................................................................62
Dvalefunktionen ................................................................................62
Baggrundslys på skærm..................................................................63
Nulstilling af systemet......................................................................63
Softwareversion .................................................................................63
DAB betjening..................................................................... 64
DAB autom. søgning.........................................................................64
Sekundære tjenester ........................................................................65
Manuel indstilling..............................................................................65
Kanalindstilling...................................................................................66
Genindhentning af forudindstillede kanaler...........................66
DAB skærmtilstande.........................................................................67
FM betjening....................................................................... 68
Sådan skifter du fra DAB til FM......................................................68
Autosøg.................................................................................................68
Manuel søgning .................................................................................68
Lydtilstand............................................................................................68
Kanalindstilling...................................................................................68
Genindhentning af forudindstillede kanaler...........................69
FM skærmtilstande............................................................................69
Vedligeholdelse.................................................................. 70
Gode råd.............................................................................. 70
Specikationer.................................................................... 70
Sikkerhedsforanstaltninger .............................................. 73
SVDB_W12E_IB_RC_Final121106.indb 5 7/11/12 4:56 PM

6
GB
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
The Unit Instruction Manual x 1
Thank youfor purchasing your new Sandstrøm DAB+ / FM Radio.
We recommend that you spend some time reading this instruction manual in order
that you fully understand all the operational features it oers. You will also nd
some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
Mains Adapter x 1
OK
MODE
MENU
INFO
MEMORY
BACKLIGHT
SLEEP
VOL+
VOL-
SNOOZE
ALARM
R
O
S
C
L
L
SVDB_W12E_IB_RC_Final121106.indb 6 7/11/12 4:56 PM

7
GB
Product Overview
Front View
1. LCD Display
2. Button
3. INFO Button
4. MODE Button
5. MEMORY Button
6. MENU Button
7. SCROLL Dial & OK Dial
8. VOLUME + Button
9. BACKLIGHT Button
10. VOLUME – Button
11. SLEEP Button
12. ALARM/SNOOZE Button
13. Speaker
14. Earphones Socket
15. FM Aerial
16. DC IN Socket
1
3
5
2
4
6
7
8
10
12
9
11
13
14
16
15
Rear View
OK
MODE
MENU
INFO
MEMORY
BACKLIGHT
SLEEP
VOL+
VOL-
SNOOZE
ALARM
R
O
S
C
L
L
DC IN
SVDB_W12E_IB_RC_Final121106.indb 7 7/11/12 4:56 PM

88
Power Source
Mains Power
• This unit is designed to operate with an
DC 12V 1.5A power supply.
• Unwind the cable to its full length.
Connect the other end of the cable to
the DC IN Socket at the rear of the unit
then connect the mains adapter to
the mains socket. Make sure the mains
adapter is rmly inserted into the mains
socket. The unit is now connected and
ready to use.
• To switch the unit o completely,
remove the mains plug from the mains
socket.
DC IN
Ensure all connections are connected before connecting to the mains
power socket.
Connections
Using Earphones
Turn down the volume before connecting the
earphones. Slowly raise the volume with the
earphones on until you reach your desired volume.
When earphones are connected, the speaker is
automatically disabled.
Long-term exposure to loud music may cause hearing
damage. It is best to avoid extreme volume when using
earphones, especially for extended periods of time.
DC IN
SVDB_W12E_IB_RC_Final121106.indb 8 7/11/12 4:56 PM

9
GB
Basic Operation
Powering ON/OFF
When you rst connect the unit to the mains socket, the unit will be in STANDBY mode and
the display will rst show the greeting message and then nally the clock.
• Press the button to switch the unit on.
• Press the button to switch the unit back to standby mode.
• Disconnect the mains plug from the mains socket if you want to switch the unit o
completely.
Selecting Modes
Press the MODE button repeatedly to switch between modes (DAB or FM).
Adjusting the Volume
Press the VOL +/– buttons to adjust the volume.
Setting the Clock
The clock can only set and be updated if you can receive DAB signals in your location. In
order for the clock to synchronise to the current local time you must leave it on one DAB
station for a short period of time. Manual clock setting is not required.
Setting the Alarm
Make sure you have preset FM and DAB stations before setting the Alarm, if you want to
wake up to DAB or FM radio.
1. Press and hold the ALARM/SNOOZE button to set
the alarm. The display will show“Alarm Setting”
and the hour digits will ash.
2. Turn the SCROLL dial to adjust the hour digits and
then press the OK dial to conrm.
3. The minute digits will ash. Turn the SCROLL dial to
adjust the minute digits and then press the OK dial
to conrm.
4. Turn the SCROLL dial to select from one of the 1-10
DAB preset stations. Press the OK dial to conrm.
5. Turn the SCROLL dial to select from one of the 1-10
FM preset stations. Press the OK dial to conrm.
6. Turn the SCROLL dial to select either Buzzer tone 1 or 2. Press the OK dial to conrm.
7. Turn the SCROLL dial to select the radio wake up volume level from 1-20. Press the OK
dial to conrm.
SVDB_W12E_IB_RC_Final121106.indb 9 7/11/12 4:56 PM

10
GB
Activating the Alarm Function
1. To activate the alarm function, repeatedly press the ALARM/SNOOZE button. The
alarm wake-up modes will be displayed and change in the below sequence on every
press:
Alarm Off DAB Preset # FM Preset # Buzzer Tone #
2. When the display shows your desired alarm wake-up mode, stop pressing the ALARM/
SNOOZE button. The alarm function is now activated and an alarm icon will be
displayed.
3. When the alarm time arrives, the selected wake-up mode will be on and the alarm icon
in the display will ash to indicate that the alarm is triggered. To stop the alarm sooner,
press the button.
4. To check the alarm status, press the ALARM/SNOOZE button. The alarm status will
show on the display.
• If you have activated the alarm function and the wake-up mode is DAB or FM, make sure that the
volume is at a sucient level for you to hear.
• If the wake-up mode is DAB and the DAB signal strength is low, the buzzer alarm will be triggered.
Automatic Alarm Repeat
The alarm will automatically repeat each day at the selected time as long as the alarm icon
is displayed. To cancel this function, repeatedly press the ALARM/SNOOZE button until
“Alarm O”shows on the display.
Snooze Function
When the alarm has gone o, press the ALARM/SNOOZE button to temporarily switch o
the alarm for 5 minutes. The display will show“z”to indicate that snooze is on. The snooze
function will continue for 1 hour from the set alarm time.
To cancel snooze mode press standby to turn the unit on then turn radio o. The alarm will
be ready for the following day.
Sleep Function
This function allows you to programme the unit to turn to standby mode by itself after a set
period of time.
1. To activate the sleep function, press the SLEEP button repeatedly. The“Sleep Timer”
will show on the display. The time will change in the below sequence on every press:
90 80 70 60 30 10
2. When your desired sleep time appears in the display, stop pressing the button and the
sleep function will be activated in two seconds.“s”will be displayed on the display.
3. When the sleep time counts to zero, the unit will turn to standby mode. To turn the
sleep function o while the sleep timer is still counting down, press the SLEEP button
once,“s”will disappear from the display.
4. Press the INFO button repeatedly to show the sleep timer status on the display when
it is turned on.
SVDB_W12E_IB_RC_Final121106.indb 10 7/11/12 4:56 PM

11
GB
Display Backlight
There are four backlight levels for you to select from in Standby and On mode individually.
To set the backlight, press the BACKLIGHT button repeatedly and the brightness of the
display will change in the below sequence on every press:
Backlight o > Backlight 01 > Backlight 02 > Backlight 03 > Backlight o >……
During standby mode, the backlight will be set to full brightness for 5 seconds on every key
press.
The display backlight level default is to“Backlight 01” in AC standby and
“Backlight 03” during operation.
System Reset
There may be times when you need to reset your unit back to the factory settings especially
when you have moved house. If you experience reception problems you may want to reset
and try again. If you move to another part of the country and pick up the local and national
DAB stations in that area, your previously tuned channels may no longer be available.
1. Press and hold the MENU button until the“Press SELECT to conrm reset”shows on
the display.
2. Press the OK dial to start the system reset,“Restarting…”will show on the display.
After the reset is complete, the unit will go to standby mode.
3. Press the button again to turn the unit on, the unit will then start scanning for DAB
channels immediately.
After the system reset, all the tuned stations, DAB & FM preset stations and
alarm settings will be erased.
Software Version
1. Press and hold the INFO button for 2 seconds and then release it to view the software
version of this unit.
2. The software version will automatically disappear after 5 seconds.
SVDB_W12E_IB_RC_Final121106.indb 11 7/11/12 4:56 PM

12
GB
1. To activate auto scan, rst press the MENU button
to enter the Tune Select Menu. Then turn the
SCROLL dial to select“Autoscan”, and then press
the OK dial to conrm. The display will show
“Scanning …”and a progressing slide bar. This may
take a few minutes, depending on the number of
stations found.
2. All the stations that have been found will be
stored automatically. To explore the found
stations, turn the SCROLL dial. Press the OK dial
to conrm.
DAB Auto Scan
The auto scan will search for the all DAB Band III channels. After the scan has nished, the
rst alphanumerically found station will be automatically selected.
DAB Operation
If the unit is connected to the mains power and then
switched on from standby for the rst time, the unit
will automatically enter the DAB mode and start
automatically scanning. During the scan the LCD
display will show“Scanning…”together with a slide
bar that indicates the progress of the scan and the
amount of stations that have been found so far.
Once the scan has nished, the unit will select the rst
alphanumerically found station. Explore the found
stations by turning the SCROLL dial. When you nd a
station that you would like to listen to, press the OK
dial.
Full auto scan will not replace the DAB stations in the unit’s memory. If you
want to delete all the previously scanned stations, a system reset is required.
If there are no stations found after auto scan, the radio will enter the
Tune Select Menu, you can now turn the SCROLL dial then press OK
dial to select“Manual tune”or “Autoscan”for stations.
SVDB_W12E_IB_RC_Final121106.indb 12 7/11/12 4:56 PM

13
GB
Secondary Services
You may see a“>”symbol after the name of the primary station whilst exploring the found
stations by turning the SCROLL dial. This indicates that there are secondary services
available to that station. These secondary services contain extra services that are related
to the primary station. e.g. a sports station may want to add extra commentaries. The
secondary services are inserted directly after the primary station in the station list.
To select the secondary station, turn the SCROLL dial continuously until you nd the
secondary service and press the OK dial to conrm. When the secondary service ends, the
unit will automatically switch back to the primary station.
Manual Tuning
As well as using the auto tune function, you can manually tune the receiver. This can help
you when aligning your aerial or when adding stations that were missed while auto tuning.
1. Press the MENU button and then press the OK dial
to select Manual tune, the display will now show
Manual tune.
2. Turn the SCROLL dial to cycle through the DAB
channels, which are numbered from 5A to 13F.
3. After your desired channel number is selected,
press the OK dial to conrm, the top line will now
display the channel number, the frequency and
the multiplex name. The bottom line will display
the signal strength.
4. Press the OK dial to listen to this channel or turn
the SCROLL dial to continue manual tuning.
SVDB_W12E_IB_RC_Final121106.indb 13 7/11/12 4:56 PM

14
GB
Presetting Stations
You can store up to 10 of your favourite 10 DAB stations to the memory. This will enable you
to access your favourite stations quickly and easily.
1. To store a preset, you must rst be listening to
the station that you would like to save, press and
hold the MEMORY button. The display will show
“Empty Preset 1“, and the preset number will
ash.
2. Turn the SCROLL dial to select your desired
station preset number.
3. Press the OK dial to conrm your station, the
display will show“Preset # saved“.
Recalling a Preset Station
1. Once you have saved a station, you can recall it by
pressing the MEMORY button, and then turn the
SCROLL dial to select your desired preset number,
then press the OK dial to conrm.
2. If you choose a preset that hasn’t been allocated a
station,“Preset # empty“ will be displayed.
SVDB_W12E_IB_RC_Final121106.indb 14 7/11/12 4:56 PM

15
GB
Signal Strength
DLS
Programme Type
DAB Display Modes
The station name will be displayed on the top line of the LCD display.
Every time you press the INFO button, the bottom line of the display will cycle through the
following display modes: Time/Date,Frequency, Audio Bit Rate, Signal Strength, DLS,
Programme Type, Ensemble/Multiplex.
Time/Date
The broadcaster (Radio station) provides clock
and date information automatically so there’s
no need to manually set this information. In the
unlikely event that the broadcaster does not
transmit any clock information, the display will
show“<TIME/DATE> ”.
Frequency
The frequency of the present station will be
displayed, such as“11C 220.352MHz”.
Audio Bit Rate
The display will show the radio mode (DAB
or DAB+) and the digital audio bit rate being
received.
Signal Strength
The display will show a slide bar to indicate
the signal strength, the stronger the signal, the
longer the bar will be from left to right.
DLS
Dynamic Label Segment is a scrolling message
that the broadcaster may include with their
transmissions. The message usually includes
information, such as programme details etc.
Programme Type
This describes the“Style”or“Genre”of music
that is being broadcast e.g. “Rock” or “Classical”.
If the information is not available, the display
will show <Programme Type>.
Ensemble/Multiplex (Group name)
A Ensemble/Multiplex is a collection of radio
stations that are bundled and transmitted on
one frequency. There are national and local
multiplexes. Local ones contain stations that are
specic to that area.
Frequency
Time/Date
Audio Bit Rate
Ensemble/Multiplex
(Group name)
SVDB_W12E_IB_RC_Final121106.indb 15 7/11/12 4:56 PM

16
GB
FM Operation
Switching from DAB to FM Mode
To switch the unit from DAB to FM mode, press the MODE button once. The top line of the
display will show FM and the frequency or the station name if a RDS station is tuned in.
Auto Scan
To search for an FM station, press and hold the
OK dial to start the auto scan. The display will
show“Searching ... >.”or“Searching ... <.”. Once
a station has been found, the scanning will stop
automatically.
Manual Scan
To search for FM stations manually, turn the SCROLL dial until your desired frequency is
reached.
Audio Mode
Press the OK dial to toggle between the Auto or Mono audio mode.
• The unit will automatically switch between stereo and mono mode, when auto mode is
selected but you can override this and switch this function manually by changing it to
mono mode. This is helpful when receiving poor signal reception.
• During stereo reception, the received L/R stereo sound will be automatically combined
into one single channel to suit the single speaker design of this radio.
Presetting Stations
You can store up to 10 of your favourite 10 FM stations to the memory. This will enable you
to access your favourite stations quickly and easily.
1. To store a preset, you must rst be listening to
the station that you would like to save, press and
hold the MEMORY button. The display will show
“Empty Preset 1“, and the preset number will
ash.
2. Turn the SCROLL dial to select your desired
station preset number.
3. Press the OK dial to conrm your station, the
display will show“Preset # saved“.
SVDB_W12E_IB_RC_Final121106.indb 16 7/11/12 4:56 PM

17
GB
Radio Text
As with DAB, the broadcaster can include a
scrolling text that displays information about
the current program. If Radio text information is
not available, then the display will show <Radio
Text>.
Frequency
This shows the frequency of the current station.
If the information is not available, the display
will show <Name>.
Programme Type
This describes the“Style”or“Genre”of music
that is being broadcast e.g. “Rock” or “Classical”.
If the information is not available, the display
will show <Programme Type>.
Time/Date
The DAB broadcaster (Radio station) provides
clock and date information automatically so
there’s no need to manually set this information.
In the unlikely event that the broadcaster does
not transmit any clock information, the display
will show the incorrect time and date.
Radio Text
Frequency
Programme Type
Time/Date
FM Display Modes
Every time you press the INFO button, the display will cycle through the following display
modes: Radio Text, Frequency, Programme Type, Time/Date.
Recalling a Preset Station
1. Once you have saved a station, you can recall it by
pressing the MEMORY button, and then turn the
SCROLL dial to select your desired preset number,
then press the OK dial to conrm.
2. If you choose a preset that hasn’t been allocated a
station,“Preset # empty“ will be displayed.
SVDB_W12E_IB_RC_Final121106.indb 17 7/11/12 4:56 PM

18
GB
Maintenance
Hints and Tips
If a problem does occur, it may often be due to something very minor. The following table
contains various tips.
Problem Solution
No Sound Adjust the volume control, it may not be turned up.
Static Sound Signal reception too low. Adjust the aerial or move the unit to
a stronger signal location.
Sound is distorted Volume is too high. Adjust the volume control.
Desired station not found Weak signal. Use the Manual Tune function.
The display shows“DAB”
and“Manual Tune”after
auto scanning
No DAB coverage in your area or poor reception. Adjust the
position of the aerial.
Poor reception. Adjust the position of the aerial.
The display is blank This may occur if the broadcaster changes the label of a
service or removes a label while tuned. The unit will try to
retune or perform a scan.
• To clean the unit, wipe the case with a slightly moist, lint-free cloth.
• Do not use any cleaning uids containing alcohol, ammonia or abrasives.
• Do not spray an aerosol at or near the unit.
Ensure the unit is fully unplugged from the mains socket before cleaning.
If the unit is not working properly disconnect the power source and then reconnect it.
Specifications
Model SVDB12E / SVDW12E
Power Supply AC/DC Adapter
Input: AC 100-240V ~ 50/60Hz
Output: DC 12V 1.5A
Output Power 5.0W
Frequency DAB 174 – 240 MHz
FM 87.5 – 108 MHz
Weight: 1.26kg
Dimensions: 115mm(W) x 128mm(D) x 190mm(H)
Features and specications are subject to change without prior notice.
SVDB_W12E_IB_RC_Final121106.indb 18 7/11/12 4:56 PM

NO
19
Pakke opp
Fjern all emballasje fra enheten. Ta vare på emballasjen. Ta hensyn til lokale forskrifter om
avfallshåndtering hvis du må kaste emballasjen.
Følgende elementer er vedlagt:
Takk for at du kjøpte ny Sandstrøm DAB+ / FM-radio.
Vi anbefaler at du tar deg tid til å lese gjennom hele bruksanvisningen for å bli
fortrolig med alle funksjonene. Veiledningen gir deg også mange tips og råd for å
løse eventuelle problemer.
Les alle sikkerhetsanvisningene nøye før bruk og oppbevar bruksanvisningen for
fremtidig referanse.
Strømadapter x 1
Enheten Bruksanvisning x 1
OK
MODE
MENU
INFO
MEMORY
BACKLIGHT
SLEEP
VOL+
VOL-
SNOOZE
ALARM
R
O
S
C
L
L
SVDB_W12E_IB_RC_Final121106.indb 19 7/11/12 4:56 PM

NO
20
Produktoversikt
Sett forfra
1. LCD-skjerm
2. -knapp
3. INFO-knapp
4. MODUS-knapp
5. MINNE-knapp
6. MENY-knapp
7. Rullehjul og OK-hjul
8. VOLUM +-knapp
9. BAKLYS-knapp
10. VOLUM –-knapp
11. SOVNE-knapp
12. ALARM/SLUMRE-knapp
13. Høyttaler
14. Øretelefonkontakt
15. FM-antenne
16. Likestrøm inn-kontakt
1
3
5
2
4
6
7
8
10
12
9
11
13
14
16
15
Sett bakfra
OK
MODE
MENU
INFO
MEMORY
BACKLIGHT
SLEEP
VOL+
VOL-
SNOOZE
ALARM
R
O
S
C
L
L
DC IN
SVDB_W12E_IB_RC_Final121106.indb 20 7/11/12 4:56 PM
