Sangean DT-800 User manual

Version 1
中文
GB
DT-800

001
Read and understand all safety and operating instructions before the
radio is operated.
Retain instructions: The safety and operating instructions should be
retained for further reference.
Heed warnings. All warnings on your radio and operating instructions
should be followed.
Follow all operations and use instructions.
Water and moisture: Your radio should not be used near water. Do
not use near a bathtub, washbowl, laundry tub, kitchen sink, wet
basement, swimming pool, etc.
Unplug the radio from the AC power outlet before cleaning. Use only
a damp cloth for cleaning the exterior of the radio.
Do not place the radio on an unstable cart, stand, bracket or table.
The radio may fall, causing serious personal injury and damage to
the radio.
Ventilation: This radio should be situated so that its location or
position does not interfere with its proper ventilation. For example,
the radio should not be used on a bed, sofa, rug or other soft
surfaces that may block the ventilation openings. It should not be
placed in a built-in situation like a cabinet that may reduce air ow
through the ventilation openings.
Power sources: The radio should be operated only from the type of
power source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your radio dealer or
power company.
1.
2.
3.
4.
5.
6.
7.
8.
9.
Important safety instructions

002
Important safety instructions
AC adaptor: The AC adaptor should be positioned so it is not
walked on, pinched, or items placed on top of it. Pay particular
attention to wires at the plug end, receptacles, Wall Outlet and
the point where they exit from the unit. Unplug the AC adaptor by
gripping the adaptor, not the wire. Operate the radio using only the
current type of power source indicated. If you are not sure of the
type of power supply to your home, consult your dealer or local
power company.
Do not overload wall outlets or extension cords. This can result in a
risk of re or electrical shock. Never insert objects of any kind into
the radio. The objects may touch dangerous voltage points or short
out parts. This could cause a re or electrical shock.
If the radio is left unattended or unused for long periods of time,
unplug it from the wall outlet. This will prevent damage caused by
lightning or power line surges.
If the radio is left unattended and not used for a long period of time,
remove the batteries. The batteries may leak and damage your
radio.
Do not attempt to service the radio yourself. Removing the cover
may expose you to dangerous voltage, and will void the warranty.
Refer all servicing to authorized service personnel.
Never push objects of any kind into this radio through openings as
they may touch dangerous voltage points or short-out parts that
could result in a re or electric shock. Never spill liquid of any kind
into the product.
10.
11.
12.
13.
14.
15.

003
Important safety instructions
The radio should be serviced by qualied service personnel when:
The power supply cord or the plug has been damaged.
Objects have fallen or liquid had been spilled into the radio.
The radio has been exposed to rain or water.
The radio does not appear to operate normally or exhibits a marked
change in performance.
The radio has been dropped, or the enclosure damaged.
16.
17.
Recharge the batteries at least every 2 months to help extend
battery life.
Make sure the Battery Select switch inside the battery compartment
is set to the “NiMH” position.
Put the batteries in the compartment while paying attention to the
correct polarity of the batteries (+ and -) as described inside the
battery compartment.
1.
2.
3.
Important information on charging
and using rechargeable batteries
To prevent possible hearing damage, do not listen at high
volume levels for long periods.

004
First use: Charge new batteries in one continuous, uninterrupted,
charge until they are full. This first charge may take longer than
normal. For longer battery life it is advised to always recharge in
one continuous, uninterrupted charge until batteries are full, do not
recharge again while the batteries are still full.
New batteries will only reach their full capacity after some time of
use (several charge and discharge cycles).
Leave the complete group of batteries in place inside the radio and do
not use these batteries or a few of them for other purposes. This will
result in a mix of (fully) charged and (partly) empty batteries. This can
seriously damage the batteries and radio when recharged.
It is advised to only charge batteries at room temperature between
5 degrees C – 35 degrees C. In lower or higher temperatures full
charge may not be achieved.
Depending on the capacity of the batteries, charging from “empty”
to “full” can take several hours, even up to 7 hours or more.
Do not charge batteries when the radio is hot or exposed to heat or
heat sources.
It is advised to clean the metal contacts of the batteries and of the
charger inside the radio e.g. with a contact-spray from time to time.
Do not use a mix of old and new rechargeable batteries.
4.
5.
6.
7.
8.
9.
10.
11.
Important information on charging
and using rechargeable batteries

005
Do not use a mix of rechargeable and non-rechargeable batteries.
Do not use a mix of full and empty rechargeable batteries.
Do not use batteries that have a different mAh capacity.
Do not use damaged, deformed or leaking batteries.
Battery level indication is an approximate indication only and can
vary with battery type that is used.
Batteries can become hot during charging.
In cold conditions the capacity of batteries will be much lower than
when used at normal room temperature
Batteries (if supplied with the radio), as being consumables, do not
fall under the warranty conditions of the radio.
Batteries should not be disposed of by incineration or with
household waste.
Disposable batteries should be taken to a suitable recycling center
if possible.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
“Risk of explosion if the battery is replaced by an incorrect type.”
CAUTION
Important information on charging
and using rechargeable batteries

006
Controls
1
Earphone / FM Antenna jack
The earphones also act as the FM antenna when plugged into
the earphone jack. While listening via speaker, you may plug the
supplied FM wire antenna into the earphones jack and set the ST
/ MO / SP switch to SP position.
2Band / WX Alert set button – to switch radio bands and set
weather alert time period (USA version only).
3
Power switch and auto timer button – When the Power is switched
on, the auto off symbol will appear on the display, the radio will
turn off at selected auto off time period (see MENU TIME 90 for
auto off settings). When the radio is switched off, hold the Power
button for more than 2 seconds until the symbol is removed from
the display and a beep is heard to cancel auto timer off.
4Volume Control
5
Stereo / Mono / Speaker selection – while listening to FM via
speaker, you may plug the supplied FM wire antenna into the
earphones jack and set ST / MO / SP switch to SP position
Top view Left view
4
5
1 2 3

007
Controls
6Preset 1 / Information button
7Display
8Preset 2 / Tuning step button
9Preset 3 / soft mute on / off button
10 Preset 4 / Band Width narrow / wide selection
11 Preset 5 / Alarm on / off selection
12 Preset PAGE / MENU button
13 TUNING / SELECT button – by pressing the TUNING button in it
becomes the SELECT button.
14
Lock Switch – The Lock switch prevents accidental changing of
any of the radio setting. Slide the lock switch to the up 'locked'
position the symbol will appear in the display.The power
and all other buttons will be disabled.
15 USB charging socket
Front view Right view
13
14
15
7
6
9
8
11
10
12

008
16 Belt clip
17 DBB on / off – enable or disable Deep Bass Booster (for
earphones use only)
18 Battery cover
19 Battery cover opening
20 Battery type switch – located inside the battery compartment
Controls
19
18
16
17
20
Back view Back view

009
Display
LCD display
B C D EA IF G H
PJ
KLMNO
AWeather alert indicator
BStereo tuning indicator
CAuto shut off timer indicator
DNarrow / Wide band width
indicator
EAlarm indicator
FRDS station
GCT (auto clock set time)
HStation signal strength
indicator
IBattery power indicator
JTime and radio frequency
KLock button activated
LSoft mute indicator
MMENU indicator
NMemory preset
OMemory preset page
PBand indicator
