Sangean PR-D3 User manual

PR-D3
Version 1
D中文
GB

1
GB
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not fit
into your outlet. Consult an electrician for replacement of the
obsolete outlet.
Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
IMPORTANT SAFETY INSTRUCTIONS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.

2
Only use attachments/accessories specified by the
manufacturer.
Use only with the cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when unused
for long periods of time.
Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged. liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
To Reduce the Risk of Fire or Electric Shock, Do not Expose
This Appliance To Rain or Moisture.
11.
12.
13.
14.
15.

3
GB
The Shock Hazard Marking and Associated Graphical Symbol
is provided on the rear of unit.
Apparatus shall not be exposed to dripping or splashing and no
objects lled with liquids, shall be placed on the apparatus.
Excessive sound pressure on ear- and headphones could
impair the hearing ability. Higher setting that idle on the
equalizer leads to higher signal voltages on the output for ear
and headphones.
The power plug should be close to the radio, and easy to be
approached that during the emergency, to disconnect the power
from the radio, just unplug the power plug from the AC power
slot.
Where the MAINS plug or an appliance coupler is used as the
disconnect device, the disconnected device shall remain readily
operable.
16.
17.
18.
19.
20.

4

5
GB
Controls
Power/Sleep button
Preset button
AM NARR button/FM mono button
Band button
Tuning up/down button
Display button
Clock set button
Buzzer alarm button
Radio alarm button
Treble/Bass button
Tuning control rotary
Lock switch
Volume control rotary
Headphone socket
Telescopic aerial
Mains input socket
External AM antenna
Battery compartment
Reset button
2
1
3
5
7
19
18
17
16
15
14
13
12
11
10
9
4
6
8

6
Display icon
Battery power level indicator and Signal strength meter
Battery symbol
Key lock symbol
Preset indicator
Stereo indicator
Sleep timer/Snooze indicator
Indicates Band in use
Radio alarm indicator
AM/PM indicator
Buzzer alarm
Frequency/Clock display
Clock seconds
H
G
F
E
D
C
B
A
L
K
J
I

7
GB
CHOOSING A POWER SUPPLY
This radio can be operated using: 4 Alkaline UM-1 (D size)
batteries or AC power (230V/50 Hz or 240V/50 Hz)
AC operation
Before you plug the AC cord into the radio be sure the AC voltage
is 230 Volts/50 Hz (European version)/240 Volts/50 Hz (Australian
version). If you have batteries in the radio and you use the AC
power cord, the batteries will automatically be disconnected.
The AC cord should be disconnected from the mains supply when
not in use.
Note:
If you remove the power cord without turning the radio OFF, the
radio will automatically revert to the batteries

8
Power with batteries
● INSTALLING BATTERIES
1. Position the radio face down on a soft surface to protect it.
2. Press the catch and pull out the battery compartment cover.
3. Insert 4 UM-1 (D size) batteries as indicated in the drawing on
the right hand side.
4. Replace the battery cover.
● BATTERY REPLACEMENT
The battery indicator will temporarily display the battery level when
the radio is power off. The battery indicator will show ( ) when
the battery in full power level, whereas ( ) indicates the batteries
are low.
When battery indicator flashes, the batteries should be
replaced. After removing the batteries, you have approximately
3 minutes to replace the batteries after which clock and memory
information will be lost (if the radio is not plugged in).
Note:
When the radio is power on, the bar indicates as the signal strength
meter.

9
GB
Clock time setting
After the batteries are installed or AC power is plugged in, the
screen will display all icons, then the display will show -:--.
1. Clock time can be set while radio is on or off.
2. Press and hold the Clock set button, the hour digits will flash,
press the Tuning Up/Down (or use the Tuning control rotary) to
adjust the required hour time.
3. Press and release the Clock set button again, the minute digits
will flash, press Tuning Up/Down button again to adjust the
required minute time.
4. Press and release the Clock Set button again to complete time
setting. This also sets the seconds to “00.”
Setting the alarm
Setting the type of alarm
There are two different alarm modes in this unit. You can choose to
wake up to the radio ( ) or to a buzzer ( ). You
can set the alarm with the radio on or off.
1. Press and hold the Alarm button until you hear a beep and see
one of these symbol or ashing on the display.
2. Now both the hour digit and alarm symbol will ash. Press the
Tuning up/down button to set the required hour. Then press the
Alarm button again.

10
3. Now the minute digit will ash on the display. Press the Tuning
up/down button to adjust the required minute. Then press the
Alarm button again to complete the alarm setting. Once the alarm
is set, it will automatically go off the next day at the same time.
Note:
● If the radio alarm is selected, tune the radio to your favorite station
and set the volume before turning your radio off for the day. When
the alarm activates, the radio will play the last station listened to.
● The buzzer alarm is called HWS or Humane Wake System. The
alarm tone beep will increase in volume every 15 seconds for one
minute followed by one minute of silence before repeating the
cycle.
Turning off the sounding alarm
Press the Power button to turn off the sounding alarm, otherwise,
the alarm will sound for an hour.
Cancelling the alarm setting
Press and hold the Alarm button until you hear a beep and the
alarm symbol will disappear on the display.

11
GB
Snooze (only available in alarm buzzer)
1. When the alarm buzzer sounds, press any button other than the
Standby button will silence the alarm for 5 minutes. “ “ will
appear on the display.
2. To cancel the snooze timer while the alarm is suspended, press
the Standby button.
Sleep timer
Your radio can be set to turn off automatically after a preset time
has elapsed. The Sleep Timer setting can be adjusted between
15,30, 45, 60, 90 and 120 minutes.
1. Press and hold the Power/Sleep timer button until you hear a beep
and the symbol of shows on the display.
2. Holding the Power/Sleep timer button down will cycle through
the times of 120, 90, 60, 45, 30 and 15 minutes.
3. Release the button when the desired sleep timer option appears
on the display. Now the symbol will appear on the display. The
radio will shut off after a preset time has elapsed.
Note:
To deactivate the sleep timer, simply press and release the Power
button.

12
Radio operation
This radio features 2 bands: AM and FM.
Manual Tuning
1. Press the Power button to turn on the radio.
2. Select the desired band by pressing the Band button.
3. Press the Tuning up/down button to tune the frequency up or down.
Scan Tuning
1. Press the Power button to turn on the radio.
2. Select the desired band by pressing the Band button.
3. Press and hold the Tuning up/down button. Your radio will scan
in an upwards direction (low frequency to high frequency) or
downwards direction (high frequency to low frequency) and stop
automatically when it nds a station of sufcient strength.
Rotary Tuning
Rotate the Tuning knob to tune the frequency up/down or press
and release the knob to scan the stations of sufcient strength.

13
GB
Memory Tuning
Five stations may be stored in memory in each band.
1. Tune to the station you want to memorize.
2. Press and hold the desired Preset Button until you hear a beep.
The station or channel is then memorized. The display will show
the preset number.
To recall the preset station, select the correct band and briefly
press and release the Preset Button. The radio will instantly tune to
the station stored in memory.
Note:
Your radio automatically fine tunes the Twin Coil Ferrite® AM
Antenna for a few seconds after a station is changed in AM mode.
The “signal” icon will ash during this time.
Note:
To see time or frequency on the screen, press the Display button.
Antenna setup for AM reception
The radio comes with built-in AM antenna which should be enough
for normal listening. To improve the AM reception, you may connect
the outdoor AM antenna with AM external antenna terminal.

14
Stereo/Mono switching
If the FM radio station via the headphone has a weak signal, some
hiss may be audible. It is possible to reduce this hiss by forcing the
radio to play the station in mono rather than stereo.
1. Tune to the required FM station as previously described.
2. Press and release the AM NARR/FM MONO button to switch to
mono mode. The red light indicator will illuminate and the
symbol will disappear from the display.
3. Press the same button again to return to stereo operation.
Note:
FM stereo is only available when using headphones.
AM bandwidth narrowing
In order to obtain better reception, your radio has the function to
narrow the AM bandwidth to lter the hiss from the high frequency.
1. Select the AM band by pressing the Band button.
2. Press the AM NARR/FM MONO button to activate the function
and the red light indicator will illuminate.

15
GB
Treble and Bass
The sound on your radio can be adjusted to suit your personal
taste for the material that you are listening to.
Rotate the treble control or bass control to adjust to your liking.
Display Light
Display Light on AC Power
When the radio is plugged into AC power, the display light will
always be on unless you turn it off. The display light has three light
levels. If you want to change the light level or turn off the display
light, press and release the Light button until you reach the desired
level.
Display Light on Batteries
When batteries are used, the display light can be turned on by
pressing the light button. The display light automatically goes off 2
minutes after the last time you press any button.
Key Lock function
The key lock function is used to prevent unintentional operation of
the radio.
1. Key lock switch is located on the panel on the right hand side of
the radio. When the key lock switch is set to LOCK, every button
will be disabled. Display will show the lock symbol
2. To disable the key lock function switch the key lock button to off
position. The key lock function will be disabled.

16
Headphone socket
A 3.5mm stereo Headphone Socket is provided on the right hand
side of your digital receiver for use with headphones. Inserting a
plug automatically mutes the internal loudspeaker.
IMPORTANT:
Excessive sound pressure from earphones and headphones can
cause hearing loss.
Reset the radio
If the radio fails to operate correctly or some digits on the display
are missing or incomplete, you may use a suitable implement (the
end of a paper clip or pen), press the RESET button located at the
bottom of the unit. This will reset the microprocessor, clock time
and clear all the stations stored in the preset memory.
Specications
FREQUENCY COVERAGE:
FM 87.50 - 108 MHz
AM 520 - 1710 kHz
POWER SOURCE:
AC 230V/50 Hz (European version)
AC 240V/50Hz (Australian version)
Battery: UM-1 (D size) X 4

17
GB
POWER CONSUMPTION:
AC Power: 10W
Battery power: 400 mADC
10% T.H.D. OUTPUT POWER:
AC: 2 W typical
Battery: 0.8 W typical
Speaker: 5 inches, 4 ohm, 6W
Earphones impedance: 32 ohm
ANTENNA:
FM: Telescopic aerial
AM: Built-in ferrite bar antenna.
DIMENSION:
W x H x D: 280 x 170 x 92 in mm.
Weight: Approx. 1740g without batteries.
If at any time in the future you should need to dispose of this
product please note that: Waste electrical products should not be
disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
(Waste Electrical and Electronic Equipment Directive)
Specications will change without prior notice.
