Sanremo CAPRI SAP User manual

1
mod. CAPRI SAP - SED
Libretto Istruzioni mod. Capri SAP - SED
Instruction Booklet
Bedienungsanleitung
Livret D’Instructions
Libro De Instrucciones

19
This instruction booklet contains all the necessary information and advice for best possible use and
storage of your coffee machine.
This booklet refers to the following models:
Model – CAPRI SAP
Semiautomatic with continuous dispensing and solenoid valve controlled by rocker switch located on the
control panel. Available in 1, 2 group versions.
Model – CAPRI SED
Microprocessor-controlled electronic model with programmable dosing through a keypad with indicator
lights. Available in 1, 2 group versions.
SPECIFICATIONS
GROUPS 12
Width mm 430 600
Depth mm 485 485
Height mm 505 505
Capacity litres 4,5 8,6
Voltage V 120/230/400 120/230/400
Heating element input kW 1,95/2,4 2,7/4,5
Electric pump input kW 0,3 0,3
Solenoid valve input kW 0,0135 0,0225
Automatic level controller input kW 0,01 0,01
Boiler design pressure (2 Bar) MPa 0,2 0,2
Boiler working pressure (0,8-1 Bar) MPa 0,08:0,1 0,08:0,1
Safety valve calibration pressure (1,8 Bar) MPa 0,18 0,18
Exchanger design pressure (20 Bar) MPa 2 2
Exchanger safety valve calibration pressure (12 Bar) MPa 1,2 1,2
Mains water pressure (max) (6 Bar) MPa 0,6 0,6
Coffee dispensing pressure (8-9 Bar) MPa 0,8/0,9 0,8/0,9
The weighted sound pressure level A of the coffee machine is less than 70dB.
For correct appliance operation and trouble-free maintenance, please read this booklet carefully and
comply with the instructions and rules, also referring to the diagrams given in it.
INSTALLATION
Before installing the appliance ensure that the mains voltage and power correspond to the data given in
the specifications table. Take the appliance out of the packaging and put it in its final place of installation
ensuring that it is stable and safe and that there is the necessary space for using it.
Electrical connection
Connect the power cable to the mains supply through a circuit breaker with suitable capacity. The
appliance must also be efficiently earthed.
N.B. CHECK THAT THE DATA ON THE RATING PLATE CORRESPOND TO YOUR MAINS ELECTRICITY
SUPPLY.
Water connection
1) Only cold water must be supplied to the appliances.
2) If the mains water pressure exceeds 6 bar, a pressure reducer must be installed to regulate the outlet
pressure to a maximum of 6 bar.
ENGLISH

20
3) Connect the drain hose to the tray, avoiding sharp bends and keeping a sufficient slope for regular
flow of the drain water.
4) Connect the 3/8” hose to the mains outlet and then to the water softener and to the appliance.
N.B. A water softener is indispensable for correct appliance operation, best coffee in the cup and long
life of the components, since it removes scale and residues from the water that would otherwise shorten
their life.
The company is relieved of all and any liability in the event of failure to comply with the
above instructions.
USE
Preliminary check
Before using the appliance, check that:
- the plug is inserted properly into the mains power outlet;
- the water filling hose is correctly connected to the mains water outlet, check for leaks and that the water
tap is open;
- the drain pipe is positioned in accordance with the preceding instructions.
With a steam tap (B) open, put the on/off switch (D) to position 1 and wait for the water in the boiler to
reach the maximum level set by the electronic control. If the boiler does not fill within the set time-out
(90 sec.), the pump stops and the indicator lights on the keypad start to blink. In this case put the on/off
switch (D) to position 0 and then to position 1 to finish filling the boiler.
Now put the on/off switch (D) to position 2 so that the heating elements are powered and therefore start
to heat the water.
Wait for steam to come out the steam nozzle (B), then close the tap and, using the Boiler pressure
gauge, check that the pressure has reached and maintains a value of 0.8:1 bar. If it is not on this value,
turn the adjusting screw on the pressure switch (+increase, - decrease, see figure below).
Pressure switch parts:
1 - Ring
2 – Membrane unit
3 – Teflon membrane
4 - Nut
5 – Disk with pipe tap
6 - Grommet
7 - Screw
Hot water
Ensure that the boiler pressure gauge indicates a pressure of 0.5:1 bar. Turn the tap knob (C) counter-
clockwise.
Pay the utmost attention in order to prevent scald burns.
Steam
Except for the 1-group machine that has just one steam nozzle, all the other models have 2 located
at the sides. These steam nozzles are recessed but can swivel out thanks to an articulated joint. To
dispense steam, just turn the knobs (B) counter-clockwise.
Pay the utmost attention in order to prevent scald burns.
Coffee with Mod. CAPRI SAP
Insert the filter holder (E) into the group head (F) turning the filter holder counter-clockwise. Press button
(I), wait for the required quantity of coffee to be dispensed and then put it back to its original position.
ENGLISH

21
Coffee with Mod. CAPRI SED
Insert the filter holder (E) into the group head (F) turning the filter holder counter-clockwise. Select the type
of dispensing required on the keypad (M):
M1=One strong/normal coffee.
M2=One normal/weak coffee.
M3=Two strong/normal coffees.
M4=Two normal/weak coffees.
M5=Electronic programming key or continuous manual dispensing.
CLEANING
Filter: after having dispensed the last cup of coffee, the filter and filter holder must be washed with
water. If they are damaged, worn or clogged, they should be replaced.
Drip tray and grid: the drip tray and grid should be removed frequently and coffee residues cleaned away.
Water softener: the softener should be periodically regenerated according to the manufacturer’s
directions given in the instruction booklet.
External housing: the external housing and the steel parts should be cleaned with sponges and soft
cloths to avoid scratching. Only use detergents that do not contain abrasive powders or solvents and do
not use steel wool.
WARNINGS: when using the appliance it is recommended that the various instruments be kept under
control, checking that they are in the previously indicated normal working conditions.
APPLIANCE FAILURE
The user must check that this is not due to:
- power failure or blackout.
- lack of mains water supply or no water inside the boiler.
For any other causes, contact a qualified SANREMO After-Sales Service Centre.
BEFORE CARRYING OUT ANY WORK INSIDE THE APPLIANCE OR REMOVING ANY PART OF
THE HOUSING, ALWAYS DISCONNECT FROM THE ELECTRICITY SUPPLY.
WARRANTY
Every purchased appliance (keep the receipt, invoice and delivery note) is covered by a statutory guarantee.
This warranty envisages the replacement free of charge of parts that are shown to the service centre or
manufacturer’s satisfaction to be defective due to faulty materials or workmanship and providing that the
appliance has not been misused or tampered with by unauthorised persons or persons using incorrect
components or techniques.
Any defective part shall be returned to the manufacturer.
WARNINGS
The appliance must not be cleaned using a water jet.
Do not put the appliance in water.
The appliance must not be positioned near to any source of heat.
The appliance is unsuitable for outdoor installation.
To ensure safe use the appliance must be in a level position.
If the power cable is damaged, have it replaced by a SANREMO After-Sales Service
Centre, since a special tool is required for this purpose.
The appliance must be used in rooms with a temperature between 5°C and 35°C.
ENGLISH

22
IN THE EVENT OF FAILURE OR MALFUNCTION, REQUEST SERVICE ONLY FROM QUALIFIED
PERSONNEL AT THE AFTER-SALES SERVICE CENTRE.
The data and features indicated in this booklet are not binding on the manufacturer, which reserves the
right to make changes to its models at any time.
The manufacturer shall not be under any liability for injury to persons or damage to property arising from
failure to comply with the instructions given in this booklet.
MICROPROCESSOR DISPENSING
The volumetric dispensing by microprocessor is a technologically highly sophisticated system that allows
many programmable functions and extreme reliability to be obtained while keeping dimensions to a
minimum.
A single control unit controls both the water level in the boiler and the various coffee quantities. The
electronic system comprises:
- power pack with high insulation transformer resistant to short circuit in compliance with the standards
UL940VO, VDE 0551 and EEC 15;
- boiler water level control through maximum level sensor;
- data transmission;
- programmable pushbutton panel with four coffee quantities, a button for programming or continual
dispensing and a programmable button for the dispensing of hot water;
- relays in compliance with the standard VDE 0551, UL940VO and with 4kW insulation;
- printed circuits in FR4 to UL940VO.
DIRECTIONS FOR USE
Dispenser programming
a) To access this phase keep the button M5 on the first pushbutton panel on the left pressed for over 5
seconds. The indicator lights of the buttons M5 start to blink continuously. Select the caption corresponding
to the amount required and press to dispense. The indicator light of button M5 and that of the selected
caption remain lit. When the required amount has been dispensed, press the selected dispensing button
again so that the control unit stores the data. Repeat the above procedure for all 4 dispensing buttons on
the pushbutton panel. A dispensed quantity may also be set for the hot water button (M6) by repeating
the above procedure. Upon completion of the procedure, the remaining groups will automatically use
the stored quantity. The other groups may, however, be programmed independently by repeating the
same procedure as above after having programmed the first group on the left.
b) There are 2 safety systems inside the control unit designed to protect the electronic system and the
various parts of the appliance. If, upon pressing a dispensing button, the corresponding indicator
light starts blinking, this indicates a malfunction in the electronic system or lack of water. For safety
reasons, the dispensing of water stops after 4 minutes and in any case after 4 litres of water.
c) The CAPRI SED electronics also offers the possibility of reproducing the pre-brewing effect by wetting
the coffee for 0.6 seconds and then stopping the subsequent brewing from starting for 1.2 seconds.
This option is only applicable for single shots of coffee.
To enable pre-brewing
With the appliance switched off, put the on/off switch (D) to position 1 and at the same time keep the
button (M1) on the left-hand group pressed until the indicator light corresponding to the button (M5)
remains lit; then release the button (M1). Now put the on/off switch (D) to position 0 and then to position
2 in order to store the operation.
To disable pre-brewing
With the appliance switched off, put the on/off switch (D) to position 1 and at the same time keep the
button (M2) on the left-hand group pressed until the indicator light corresponding to the button (M5)
remains lit; then release the button (M2). Now switch the appliance off and then on again using the on/off
switch (D) in order to store the operation.
ENGLISH

23
ENGLISH

24
ENGLISH

25
PARTS OF EXPLODED VIEW CAPRI UPDATE 09-05
POS. CODE DESCRIPTION
1A 10019011C FRAME CA 1GR BLACK
1B 10022825C FRAME CA 2GR BLACK
2A 10022765 R.H. SIDE PANEL CA BLUE
2B 10022766 R.H. SIDE PANEL CA BLACK
2C 10022802 R.H. SIDE PANEL CA RED
3A 10022768 L.H. SIDE PANEL CA BLUE
3B 10022769 L.H. SIDE PANEL CA BLACK
3C 10022803 L.H. SIDE PANEL CA RED
4 10352031 R.H./L.H. CUP GUARD CA
5A 10022760 SS REAR PANEL CA 2GR
5B 10022786 SS REAR PANEL CA 1GR
6A 10022778 REAR CUP GUARD BLACK CA 2GR
6B 10022779 REAR CUP GUARD BLUE CA 2GR
6C 10022795 REAR CUP GUARD. BLUE CA 1GR
6D 10022807 REAR CUP GUARD RED CA 2GR
6E 10022809 REAR CUP GUARD BLACK CA 1GR
6F 10022811 REAR CUP GUARD RED CA 1GR
7A 10022772 UPPER FRONT PANEL CA 2GR SED
7B 10022774 UPPER FRONT PANEL CA 2GR SAP
7C 10022791 UPPER FRONT PANEL CA 1GR SED
7D 10029773 UPPER FRONT PANEL CA 1GR SAP
8A 10022763 UPPER GRID CA 2GR
8B 10022789 UPPER GRID CA 1GR
9A 10022785 UPPER DRIP TRAY CA 2GR
9B 10022799 UPPER DRIP TRAY CA 1GR
10A 10022758A LOW GROUP HEAD PROTECTION CA 1GR
10B 10022759B LOW GROUP HEAD PROTECTION CA 2GR
11A 10015311 DRAIN GRID CA 1GR FILINOX
11B 10015312 DRAIN GRID CA 2GR FILINOX
12A 10022761 DRAIN PLATE CA 2GR
12B 10022787 DRAIN PLATE CA 1GR
13A 10022875 LOWER FRONT PANEL CA 2GR SCREEN-PRINTED
13B 10022892 LOWER FRONT PANEL CA 1GR SCREEN-PRINTED
14A 10022764 FRONT PROTECTION CA 2GR
14B 10022821 FRONT PROTECTION CA 1GR
15 10352050 FOOT 40X40 10MA
17A 10022428A DRAIN TRAY CA 1GR
17B 10022459 DRAIN TRAY CA 2GR
18 10806099 SS HOSE CLAMP
19A 10455050 HEAT. ELEM 1950W 230V 1GR
19B 10455051 HEAT. ELEM 1950W 120V 1GR
19C 10455052 HEAT. ELEM 2700W 230V 2GR
19D 10455053 HEAT. ELEM 2700W 120V 2GR
19E 10455060 HEAT. ELEM 2400W 230V 2GR
19F 10455065 HEAT. ELEM 2400W 120V 2GR
19G 10455080 HEAT. ELEM 4500W 230V 2GR
20 10502020 PTFE WASHER D56X41X2mm
21A 10002635 COPPER BOILER 1GR D.180
21B 10002636 COPPER BOILER 2GR D.180
22A 10252079A EL. MOTOR150W 120V W/CONNECTOR
22B 10252080A EL. MOTOR 150W 230V W/CONNECTOR
23 10255022 VIBRATION DAMPING BUFFER
24 10252070 ROTARY PUMP 150L/H W/CLAMP
25 10602010 PRESSURE SWITCH
26A 10112010 LEVEL CONTROLLER 230V
26B 10112011 LEVEL CONTROLLER 120V
26C 10112074A CONTROL UNIT ET-30CT SED 120V
26D 10112091A CONTROL UNIT ET-30CT SED 230V
27A 10303088 2-WAY SOL. V. 230V 0-10B
27B 10303090 2-WAY SOL. V.120V 0-10B
28 10112130 VOLUMETRIC METER
29A 10122016 SINGLE-PHASE JUMPER SWITCH
29B 10122018 THREE-PHASE JUMPER SWITCH
30 10052012 RING GROUP HEAD ASSY.
31A 10302066 LOW 3-WAY SOL. V. 32X32 230V
31B 10305555 LOW 3-WAY SOL. V. 32X32 120V
32A 10553021 ORANGE IND. LIGHT D6 230V WIRED
32B 10553024 ORANGE IND. LIGHT D6 120V WIRED
33A 10102155 WIRING CA 2GR SAP
33B 10109103 WIRING CA 1GR SED
33C 10109104 WIRING CA 2GR SED
33D 10109110 WIRING CA 1GR SAP
34 10552021A PRESSURE GAUGE
35 10552022A FLANGE FOR SELECT. SWITCH
36 10805069 SCREW (HEX.CONV.SO) M3X10 A2
37 10402056 O RING 2062 VITON
38 10402043 ARTIC. JOINT SPRING
39 10402054 ARTIC. JOINT CAP
40 10402063 O RING 115 EPDM
41 10402022B ARTIC. JOINT NUT
42 10858589 ARTICULATED JOINT
43 10422136 STEAM NOZZLE CAPRI
44 10753050 ANTI-SCALD RUBBER PROTECTION
45 10402195 UPPER NOZZLE JET
46A 10402196 LOWER NOZZLE JET 4 HOLES
46B 10402198 LOWER NOZZLE JET 2 HOLES
47 10022140 WATER DISPENSING TUBE
48 10502041 O RING 2025 EPDM
49 10402140 DISPENSING HEAD
50 10402145 COMPLETE WATER NOZZLE CA
51 10402010 COMPLETE WATER TAP CA
52 10402120A TAP BODY
53 10505561 TAP COPPER BUSHING
54 10505121 O RING NBR TAP ROD
55 10402015 TAP ROD BUSHING
56 10402014 TAP ROD SPRING
57 10402061 CENTRAL TAP ROD
58 10505558 TAP ROD SEAL
59 10803547 PLAIN WASHER D20 ZN
60 10402070 KNOB RING NUT
61 10402074 TAP KNOB
62 10806370A TAP SPLIT PIN
63 10351105 WATER TAP KNOB CAP
64 10402040 TAP BRASS WASHER
65 10402028 CHROMED RAISED HALF NUT 1/2”
66 10351104 STEAM TAP KNOB CAP
67 10402260 COMPLETE STEAM NOZZLE CA
68 10402230 COMPLETE STEAM TAP CA
69 10402121A 1-CUP FILTER HOLDER ASSY
70 10402122A 2-CUP FILTER HOLDER ASSY
71A 10052088 SMALL 2-WAY SPOUT, OPEN
71B 10052090 2-WAY SPOUT
72 10052040 FILTER-HOLDER HANDLE
73 10052030 FILTER-HOLDER BODY
74 10052050 FILTER RETAINING SPRING
75 10052100 1-CUP FILTER
76 10052110 2-CUP FILTER
77 10052220 SOLID FILTER
78A 10052078 SMALL 1-WAY SPOUT, OPEN
78B 10052080 1-WAY SPOUT, OPEN
79A 10052126 RING GROUP HEAD ASSY CA 230V
79B 10052128 RING GROUP HEAD ASSY CA 120V
80 10255028A SWIVEL ELBOW F1/8
ENGLISH

26
81 10852030A 1020 6-1/8”M ELBOW
82 10853085 HEX NUT 1/8”
83 10852080A 1050 6-1/8”M STRAIGHT COUPLER
84 10052144 FILLING BLOCK JET HOLE D.1.5
85 10402063 O RING 115 EPDM
86 10502028 O RING 3037 VITON
87 10052139 SS MESH FILTER
88 10852672 STRAIGHT REDUCER NI CH22X23 3/8F-1/4M
89 10852682 CONNECTOR NI CH.22X38 1/8”MFM
90 10852901 2520 1/8”F-1/4”M STRAIGHT REDUCER
91 10652020 CHECK VALVE
92A 10056061 FILLING BLOCK ASSY CA 230V
92B 10056062 FILLING BLOCK ASSY CA 120V
93 10102250 CABLE GLAND PG 21
94 10102249 CHECK NUT PG.21
95 10805071 SCREW (HEX.CH.SOCK.) M4X10 A2
96 10502038 UNDER-CUP SEAL W/SLITS
97 10502070 O RING 3187 EPDM
98 10052230 RING GROUP HEAD MAZZOCCO
99 10052170 PROFESS. FILTER HEAD D.53
100 10801032 SCREW (HEX FLAT SOCK) M5X12 ZN
101 10052142 RING GROUP HEAD JET CLOSING CAP
102 10052143 RING GROUP UPPER CAP GASKET
103 10052135 GROUP HEAD JET HOLE D.0.8
104 10852033 EXTENSION NI CA RING GROUP HEAD
105 10052136 GROUP HEAD FILTER E-61/RING
106 10805078 SCREW (HEX CH SOCK) M6X8 A2
107 10111015 THERMOSTAT W/ MANUAL RESET
108 10805872 CHEESEHEAD SCREW + M4X6 ZN
109 50302018 SELECTOR SWITCH LABEL SER.012
110 10122011 SWITCH KNOB SCREW
111 10122012 SWITCH KNOB
112 10105190 2-WAY BLOCK F.
113 10803010 CHEESEHEAD SCREW - M4X40 ZN
114 10402059 DRAIN TAP W/KNOB
115 10852050A 1050 8-1/8”M STRAIGHT COUPLING
117 10402060 BOILER DRAIN TAP KNOB
118 10853058 1510 STRAIGHT OUTLET CONNECTOR 6-1/8”M
119 10905010 TRANSP. SILICONE TUBE
120A 10102190 POWER CABLE 3X2.5 M3 N5 SINGLE-PHASE
120B 10102191 POWER CABLE 5X2.5 M3 N4 THREE-PHASE
120C 10102193 POWER CABLE 3X4 M3 N7
120D 10102196 POWER CABLE 3x12AWG SJOOW 3MT
120E 10102197 POWER CABLE 3x14AWG SJOOW
121 10803519 SERRATED WASHER D4.2.ZN
122 10805512 MEDIUM-HEIGHT NUT 4MA ZN
123 10852450 STAY PIPE L=2000
124 10852470 STAY PIPE L=450
125 10852530A 1020 10-3/8”M ELBOW
126 10852280A 1020 8-3/8”M ELBOW
127 10112066 PUSHBUTTON STRIP FOR DISP. 3D5
128A 10112078 PIN TO PIN CABLE 600mm
128B 10112079 PIN TO PIN CABLE 800mm
129 10555060A COFFEE SWITCH W/SCREEN PRINT
130 10852460 HELICALLY WOUND DRAIN PIPE L.2 M
131 10805028 TRUSS HEAD SCREW - M6X10 A2
132 10855556 1310 NOSE FITTING D4
133 10855557 1303 NUT 4-1/8”F
134 10852580A 1050 6-1/4”M STRAIGHT COUPLING
135 10855031 2003 TEE F/F/F 1/4”
136 10852250A 1020 6-1/4”M ELBOW
137 10112064 LEVEL SENSOR 120mm
138 10652040 BOILER RELIEF VALVE
139 10852180 COPPER WASHER 1/4”
140 10853053 STRAIGHT SUCTION PIPE 1/4”M
141 10106060 BRASS RESISTOR CONNECTION JUMPER
142 10652010 SAFETY VALVE
143A 10052156 JET HOLE D2.5
143B 10052157 JET HOLE D3
143C 10052158 JET HOLE D3.5
143D 10052159 JET WITHOUT HOLE
144 10806324 COPPER WASHER 3/8”
145 10852540 2611 1/4”M PLUG
146 10852060A 1020 8-1/4”M ELBOW
147 10855030 2070 TEE M/F/F 3/8” +
148 10852290A 1050 10-3/8”M STRAIGHT COUPLING
149 10852092 2530 STRAIGHT REDUCER 3/8M-1/4F
150 10402124 EXCHANGER FITTINGS ASSEMBLY
151 10852240A 1170 6-1/4” JOINT CONNECTION
152 10042017 UNIVERSAL INJECTOR
153 10853215 TEE 1/8 M/F/F
154 10655555 EXPANSION VALVE
155 10852028A 1010 6-6-1/8”M TEE
156 10852520 2530 STRAIGHT REDUCER 1/4M-1/8F
157 10805074 HEX-HEAD SCREW M4X8 ZN
158 10805027 TRUSS HEAD SCREW - M4x10 A2
159 10803546 PLAIN WASHER D4 A2
160 10805584 CAP NUT 4MA A2
161 10805018 TRUSS HEAD SCREW - M4X12 A2
162 10803538 SERRATED WASHER D8.2 ZN
163 10802500 MEDIUM-HEIGHT NUT M8 ZN CL8PG
164A 10952051A AL RATING PLATE SAN REMO 230V
164B 10952052A AL RATING PLATE SAN REMO 400V
164C 10952053A AL RATING PLATE SAN REMO 120V
165 10805950 TEAR-OFF RIVET D3x6
166A 10955018 SAN REMO LABEL 70X11.3
166B 10955020 SAN REMO LABEL 101X16.5
167 10955013 HOT SURFACE TRIANG. LABEL
168 10955025 EARTH TRIANG. LABEL
169 10955015 VOLTAGE TRIANG. LABEL
170 10809019 BURNISHED SCREW (HEX CONV SOCK) M3X8
171 10805105 HEX-HEAD SCREW M6X12 ZN
172 10803536 SERRATED WASHER D6.2 ZN
173 10805075 HEX-HEAD SCREW M5X8 ZN
174 10803520 SERRATED WASHER D5.3 ZN
175 10252038 MOTOR CAPACITOR 150W
ENGLISH

27
ENGLISH

28
ENGLISH

29
ENGLISH

30
ENGLISH

31
ENGLISH

32
ENGLISH

80
80
AGG. 09/05 - COD. 80011110A
SANREMO s.r.l.
Via Bortolan, 52
Zona Industriale Treviso Nord
31050 Vascon di Carbonera (TV)
tel. [phone]
fax [phone]
www.sanremomachines.com
SANREMO PASSION / PERFORMANCE / STYLE
