Santec KARLIE 1870EP User manual

Installation Instruction
Bidet Fitting
KARLIE COLLECTIONS
Please read the instructions completely before beginning the installation.
Karlie Collection
Model Number: 1870EP
Flush both supply lines before installation, then shut off both supply lines.
Minimum hole size for the spout and handle trim is 1-1/4” and maximum of 1-1/2”
- Remove complete trim from vacuum breaker valve.
- Install bidet elbow into threaded outlet.
- Insert gasket into bidet wye and thread onto bottom of vacuum
breaker valve.
- Remove black plastic lock nut, nylon slip washer and one
black self-seating china seal.
- Insert diverter valve body up from below and reinstall black
self-seating china seal, nylon slip washer and black plastic lock
nut being sure to tighten firmly by hand.
- Thread trim cylinder onto vacuum breaker valve and tighten
firmly. Place handle on top and secure with brass screw. Insert
handle cap with arrow facing towards front of bidet.
Rev 06/2016
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
VACUUM BREAKER INSTALLATION
1/5
1
2
3
4
5
6
Black plastic lock nut
Trim Cylinder
Handle
Screw
Handle Cap
Black Soft Seating China Seals
Black Soft Seating China Seals
White Nylon Slip Washer
Karlie Crystal Collection
Model Number: 1870RC

HANDLE TRIM INSTALLATION
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
POP-UP INSTALLATION
DO NOT DISASSEMBLE HANDLE ASSEMBLY - DROP-IN VALVES
2/5
- Remove the valve body mounting hardware from valve body.
Hot valve assembly “Red” to be mounted on left. Cold valve
assembly “Blue” to be mounted on right.
- Apply a ring of silicone caulking around the handle hole on
bidet top. DO NOT USE PLUMBERS' PUTTY, WHICH CAN
DAMAGE FINISH.
- Slip valve through appropriate hole on top of bidet. Reinstall
valve body mounting hardware, fiber washer and valve body
locknut. Align handles with respect to the bidet, and tighten valve
body locknut until secure.
- Aim outlet hoses towards bidet wye and attach securely to
avoid leakage.
1
2
3
4
- Remove decorative drain flange and drain plug from pop-up
assembly.
- Apply a ring of silicone caulking to underside of decorative
drain flange. DO NOT USE PLUMBERS' PUTTY, WHICH CAN
DAMAGE FINISH.
- Insert threaded end of the assembly up from below bidet.
Completely thread drain body into decorative drain flange and
align with ball rod hole facing back and tighten lock nut from below.
- Insert drain plug into decorative drain flange with adjustable
eye-screw facing back. Attach ball rod washers and ball rod nut
to horizontal ball rod and install into drain body. Do not over tighten,
ball rod must operate freely.
- Drop lift knob flange through appropriate hole in bidet and
attach mounting hardware. Insert lift rod and knob through lift
knob flange, lift rod strap and tighten thumbscrew.
- Gently push the horizontal ball rod down to place the drain
plug in the up position.
- Slip one leg of ball rod clip off horizontal ball rod and insert lift
rod strap, reattach leg of ball rod clip.
- Test pop-up for smooth operation and adjust if necessary.
1
2
3
4
5
6
7
8
Lift Knob
Lift Knob Flange
Lift Knob
Lift Rod Strap
Side Hole
Ball Rod
Ball Rod Clip
Ball Rod Nut
Drain Tube
Drain Fla
Gasket
Washer
Lock Nut
Thumb Screw
Flange Shank
Rubber Washer
Metal Washer
Lock Nut

COMPLETE ASSEMBLY
SPECIFICATION SHEETS
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
3/5
INLET HOSE
INLET HOSE
258 " 158 "
2"
5"
218 "
178 "
3"
3
1
4
"

We recommend that all faucets, drains, etc., be gently wiped dry with a soft cloth after use to avoid water
spotting and water deposit build-up. A mild liquid hand soap may be used occasionally if desired. Use of a
non-abrasive carnauba wax will add protection to the finish and should be used if the faucets will not be dried
after use. For clear coated finishes, it is recommended to clean your product weekly with a soft moist cloth.
WARNING: Do not clean your SANTEC product with ammonia (Window cleaner), bleach, soap, acids,
abrasives, harsh polish, harsh cleaners, a coarse surfaced cloth, coarse sponge, or any type of scouring pad.
Doing so may ruin your faucet finish and/or void the warranty.
Thank you for making SANTEC a part of your lifestyle and luxury spa experience. Our products have been
created as works of enduring quality and sophisticated design.
Luxurious finishes need proper care and attention, so in order to understand how to properly clean your
distinctive luxury finish, please refer to the finish care information below:
Your SANTEC product can be identified in one of two categories: clear coated finishes or non-clear coated
finishes. Clear coated finishes are more scratch-sensitive and are more reactant to harsh cleaning chemicals
than non-clear coated finishes. Once you have identified the specific luxury finish of your SANTEC product,
please follow the important corresponding care instructions.
We recommend that all faucets, drains, etc., be gently wiped dry with a soft cloth after use to avoid water
spotting and water deposit build-up. A mild liquid hand soap may be used occasionally if desired. Use of a
non-abrasive carnauba wax is occasionally required and will add protection to the finish if the faucets will not
be dried after use.
FINISH CARE INFORMATION
CLEAR COATED FINISHES
NON-CLEAR COATED FINISHES
TO OBTAIN WARRANTY SERVICE
Please read ‘WHAT IS COVERED BY OUR WARRANTY’ and ‘EXCLUSIONS AND LIMITATIONS OF
WARRANTY’ sections to understand what is and what is not covered. Please have ready the proof of
purchase (original sales receipt), description of the problem, and carefully package the product or defective
part with postage prepaid. Then, please contact your local SANTEC Showroom or write to SANTEC Technical
Services.
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
4/5

LIFETIME LIMITED WARRANTY
SANTEC is committed to enhancing your bathroom experience by creating luxury products that will provide
enduring satisfaction. Every effort has been made to satisfy the highest standards of design and production,
to create lasting peace of mind for our customers. We provide the following limited warranties on our products:
LENGH OF WARRANTY & WHO IS COVERED BY OUR WARRANTY
This warranty extends to the original consumer purchaser only and extends for as long as the original
purchaser owns the product and the home in which the product is installed.
WHAT IS COVERED BY OUR WARRANTY
FINISHES: SANTEC Polished Chrome, Polished Nickel and Satin Nickel finishes carry a Lifetime Limited
warranty against manufacturing defects and tarnish to the original purchaser. All other finishes carry a ten
(10) year limited warranty against manufacturing defects and tarnish to the original puchaser only.
CARTRIDGES: Santec cartridges carry a lifetime limited warranty, with the exception of thermostatic and
pressure balanced cartridges, which carry a three (3) year limited warranty against manufacturing defects
to the original purchaser.
PARTS: Santec parts carry a 10-year limited warranty against manufacturing defects, to the original
purchaser.
EXCLUSIONS & LIMITATIONS OF WARRANTY
Damage due to negligence, accident, abuse, improper installation, or improper maintenance such as, but
not limited to: heat from soldering during installation, the use of plumber’s putty, damage from tools used
during installation, the use or exposure to chemicals or cleaning products either abrasive or non-abrasive,
or the use of any cleaning tool or product other than a soft, clean cloth. Reverse osmosis may also shorten
the life of the finish.
Changes in the finish or in the product due to normal wear or aging does not cover any products or parts
which have been altered or used in a manner not typical for the product.
Loss, damages, or expense, incidental or consequential whatsoever, originating from the purchase,
installation, use, repair, failure, or replacement of any SANTEC product or part, allowed by law.
This warranty does not cover:
Commercial and/or Industrial installations and use of the product.
This warranty does not include labor, travel charges, or any costs incurred for repair, removal, installation,
servicing, diagnosing, or handling of either defective or replacement parts.
SANTEC reserves the product components of the covered product will be repaired, refinished, or replaced
at the sole discretion of SANTEC. SANTEC reserves the right to examine any product claimed defective prior
to any warranty claim being accepted or processed, at its sole discretion. This warranty gives you specific
legal rights and you may have other rights which may vary from state to state.
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
Damage or deterioration caused by environmental impacts.
5/5
