Sanyo LNS-S02 Use and care manual

PARTS LIST
Following parts are contained in the packing.
· LENS
· LENS MOUNTING SCREWS
· DRIVER
· LIGHT-BLOCK SHEET
NOTES ON LENS INSTALLATION
LENS REPLACEMENT AND
INSTALLATION PROCEDURE
LCD PROJECTOR LENS
MODEL NO. LNS-S02
Lens installation should be performed by the qualified service personnel.
It should be followed by this procedure precisely.
Before attempt to install the lens, confirm the model number (both the LCD
projector and the lens) and use the proper lens.
If you have any questions, contact to the dealers.
Following checks and confirmations should be taken for safety.
Check the following things by the time of the cabinet assembly after the
lens installation.
1. Confirm the lens is securely fixed by 4 screws.
2.Wiring must not be tangled in the gear of the lens motor or the other
mechanical part.
3.There is no missing part, or no loosing mounting part.
1AA6P1P1981-- (ICPE)
1 piece
6 screws (2 for spare)
1 piece
1 sheet

LENS REPLACEMENT AND INSTALLATION PROCEDURE
Remove screws A (2 screws).
Pull down the lower lens cover while pushing
the part D, then remove it.
Remove screws B (2 screws).
Remove screws C (2 screws) and remove
upper lens cover.
15
Perform the steps to for lens replacement and installation.
1
1.
2.
A
Fig-1
Fig-2
Remove 2 screws and pull down the plate.
2
3.
4.
UPPER LENS COVER
LOWER LENS COVER
C
B
D
D
COVER PLATE
REMOVE THE LENS COVER. (See figure-1)
(At the step , insert the light-block sheet in
the same position as the removed cover plate
has been placed.Two screws are not used.)
4
REMOVE THE COVER PLATE OF THE LENS COVER. (See figure-2)
INSTALL THE LENS. (See figure-3)
Remove protective caps(front and
back) on the lens.
Mount the lens on mounting brack-
et of the main cabinet with 4
screws.Use the screws included
with the lens.
Use the driver included with the
lens to fasten the screws.
(After using, save it for latter use.)
Connect the lead connector of the
lens motor to the “K16B” on the
circuit board as shown in figure-4.
Fasten the lens motor lead at the
A, B points with wire holder as
shown in figure-4.
3
1.
2.
LENS MOUNTING BRACKET
ATTACHED DRIVER Fig-3
3.
4.
LENS MOTOR

MOUNT THE LENS COVER. (See figure-6)
A
INSTALL THE LIGHT-BLOCK SHEET. (See figure-5)
Install the light-block sheet around the lens as
shown in the illustration.
(Use the sheet included with the lens.)
Set the light-block sheet, so that the large rounder
side is set over the lens.
4
Insert the upper part lens cover and
fix them with screws A (4 screws).
Insert the lower part lens cover and
fix them with screws B. (2 screws).
5
1.
2.
UPPER LENS COVER
LOWER LENS COVER
A
B
Fig-5
Fig-6
When in install the both upper and lower lens
covers, install the light-block sheet so that it
should be placed in the guide slot of the lens
cover. If the installation of the light-block
sheet is incorrect, there will be the space
between lens and the lens cover, so that it will
be the cause of leakage of light or the dust
entering at the main cabinet.
LIGHT-BLOCK SHEET
Set the light-block sheet, so that the
largeroundersideissetoverthelens.
LENS MOTOR LEAD
CONNECTOR “ K16B”
(D)
(D)(D)
(D)
B
LENS MOTOR
Fig-4
❋Figure shown inside of the cabinet.
A
WIRE HOLDER
