2000 & 1400 ANSI LUMENS lTRUE XGA lMULTIMEDIA PROJECTOR
Issued 11/01
PLC-XU35/XU30
XGA Ultraportable Multimedia Projector
DIGITAL PROGRESSIVE SCANNING
Proprietary SANYO digital progressive scanning doubles the
video information being sent to the projector, substantially
increasing video-image detail and resolution. Each pixel is
monitored using SANYO’s original motion detection algorithm
to ensure increased vertical resolution and crisper moving
images.
DIGITAL REALIZED VIDEO SCALING
SANYO’s advanced digital signal processing circuit and
automatic color correction circuit together ensure the highest
color accuracy possible and dramatically enhance image-edge
detail.
COMPONENT VIDEO INPUTS
The PLC-XU35/XU30 comes with component video inputs and
a newly developed Digital RGB Matrix IC that makes projection
of DVD (Y/Cb/Cr) and HDTV (Y/Pb/Pr) possible.
HDTV COMPATIBLE
The SANYO PLC-XU35/XU30 is High Definition Television
Compatible, accepting the 1080i, 1035i, 720p, 575p, 575i, 480p
and 480i HDTV resolution standards.
DIGITAL KEYSTONE CORRECTION
SANYO’s digital keystone correction feature compensates for
angled projector placement by digitally altering the pixels to
produce undistorted images.
WHISPER QUIET FAN
The PLC-XU35/XU30 employs a new Whisper Quiet fan which
produces an amazingly low noise level of only 37 dBA.
OPTIONAL MEDIA CARD IMAGER KIT
An optional Media Card Imager kit with a detachable
Presentation Viewer allows for the storage and playback of a
JPEG file slideshow without the need for a PC to be attached.
The Media Card Imager Kit also includes a 16MB Compact
Flash card, a Type II PC-Card Adapter, and MCI software
CD-ROM.
PRESENTATION TECHNOLOGIES
21605 Plummer Street
Chatsworth, CA 91311
Ph: 818.998.7322 ext. 288
Fax [phone]
www.sanyolcd.com
Specifications
Resolution XGA (1024 x 768)
Brightness (typical) PLC-XU35 -2000 ANSI Lumens
PLC-XU30 –1400 ANSI Lumens
Uniformity 85%
LCD Panel System 0.9” TFT Poly x 3
Number of Pixels 2,359,296 (786,432 x 3)
Contrast Ratio 350:1
Projection Image (diagonal) 31”-300”
Aspect Ratio 4:3
Throw Distance 5.2’-40.1’
Zoom/Focus Powered (1:1.3 zoom)
Up/Down Ratio 9:1
Digital Keystone Correction +/-20°
Projection System Polarized Beam Splitter optical system
Projection Lens F1.7-2.0 / f1.5”-1.9”
Lens Throw Ratio 2.0-2.65:1
Projection Lamp 200W UHP
Scanning Frequency H 15-100kHz; V 50-100Hz
Dot Clock 140 MHz
Color System PAL/PAL-M/PAL-N/SECAM/NTSC/NNTSC4.43
Computer Compatibility SXGA, XGA, SVGA, VGA
Sound Output One-piece, 1-watt Mono
Voltage 100-240V AC; 50/60/Hz (auto sense/select)
BTU Rating 1024 BTU
dB Rating 37.0
Power Consumption 300W
Dimensions (WxHxD) 13.1” x3.5”x9.1”
Net Weight 8.6 lbs.
User Maintenance Clean air filters, replace lamp assembly
PC Input Terminals D-Sub15 lDVI lAudio Mini-jack (stereo)
Video Input Terminal Component RCA x 3 (Y/Video, Pb/Cb, Pr/Cr)
S-Video (mini-DIN 4-pin)
Audio RCA x 2 (R, L-mono)
Output Terminal Audio RCA x 2 (R, L)
Control Port Terminal Mini DIN 8-pin lUSB type B
Included Accessories Wireless remote control with laser pointer and
mouse pad l2 AA batteries lOwner’s manual
lVGA computer cablelPS/2 control cablel
Lens cap lSoft carry bag lAC power supply cord
Optional Accessories lMedia Card Imager Kit (includes Detachable
Presentation Viewer, MCI CD-ROM software,
16MB Compact Flash Card, PC-Card adapter
for Compact Flash, Owner’s Manual)
lSerial Control Cable (POA-MCSRL)
lADB Control Cable (POA-MCMAC)
lMAC/VGA adapter (POA-MACAP)
Warranty Three years parts and labor; 90 days lamp;
Quick Repair Program under warranty
PLC-XU35/XU30 with optional Detachable Presentation Viewer
(Media Card Imager Kit -POA-MD07MCI)
Because its products are subject to continuous improvement, SANYO reserves the right to
modify product design and specifications without notice and without incurring any obligations.
