Sanyo DTA-2680 User manual

SANYO Canada Inc.
www.sanyo.ca

SAFETY INFORMATION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
The lighting flash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
!
!
SAFETY CERTIFICATION
This unit is made and tested to meet exacting safety standards. It meets CSA and FCC requirements and complies with
safety performance standards of the U.S. Department of Health and Human Services.
CAUTION - USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
THIS UNIT SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT QUALIFIED SERVICE
PERSONNEL.
WARNING: TO AVOID THE HAZARDS OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR OTHER MOISTURE.
CAUTION: TO PREVENT ELECTRICAL SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Thank-you for choosing SANYO. This audio system includes a built-in CD player, AM/FM stereo tuner,
iPod dock, alarm clock, timer, motorized CD door, removable speakers and remote control. The unit can
be wall mounted in order to save desk or counter space.
INVISIBLE LASER RADIATION
DO NOT STARE INTO BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS
CLASS 3A LASER PRODUCT
CLASS 1 LASER PRODUCT
PRODUIT DE LASER DE CLASSE 1.
1

2
WARNING: Handling the cord on this product or cords associated with accessories sold with this product, will expose
you to lead, a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm.
Wash hands after handling.
FCC information
For CD player section: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between equipment and receiver.
- Connect the equipment into an outlet on a different circuit from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV tech.
FOR SAFE AND EFFICIENT OPERATION
- Do not damage the power cord.
- When not in use, disconnect the power cord from the outlet. Grasp the plug, not the cord, when disconnecting the unit.
- If water should enter the unit, electrical shock or malfunction may result. Use in an area where there is low humidity
and little dust.
- Do not disassemble or alter the unit in any way.
- Do not use the unit in areas where extremes in temperature occur (below 40 F or exceeding 95 F), or where it may
be exposed to direct sunlight.
- Because of the CD player’s extremely low noise and wide dynamic range, there is a tendency to turn the volume on
the amplifier higher than necessary. Doing so may produce an excessively high output from the amplifier, which can
cause damage to your speakers. Please be careful in this regard.
- Sudden changes in the surrounding temperature can cause dew to form on the optical pickup lens inside unit. Under
this condition, the unit may be unable to operate properly. If this should occur, remove the disc and allow the player to
adjust to the surrounding temperature.

3
Read Instructions - All the safety and operating instructions should be read before the
product is operated.
Retain Instructions - The safety and operating instruction should be retained for future
reference.
Heed Warnings - All warnings on the product and in the operating instructions should be
adhered to.
1.
2.
3.
Follow Instructions - All operating and use instructions should be followed.
Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Attachments - Do not use attachments not recommended by the product manufacturer as
they may cause hazards.
4.
5.
6.
Water and Moisture - Do not use this product near water - for example, near a bath tub,
wash bowl, kitchen sink, or laundry tub, in a wet basement, or near swimming pool, and the
like.
7.
Accessories - Do not place this product on an unstable cart, stand tripod, bracket, or
table. The product may fall, causing serious injury to a child or adult, and serious damage
to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any mounting of the product should follow the
manufacturer’s instructions and should use a mounting accessory recommended by the
manufacturer.
A product and cart combination should be moved with care. Quick stops, excessive force,
and uneven surfaces may cause the product and cart combination to overturn.
8.
9.
Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating, and these openings must not be blocked
or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or
other similar surface. This product should not be placed in a built-in installation such as a bookcase
or rack unless proper ventilation is provided or the manufacturer’s instruction have been adhered
to.
Power Sources - This product should be operated only from the type of power source indicated on
the marking label. If you are not sure of the type of power supply to your home, consult your
product dealer or local power company. For products intended to operate from battery power, or
other sources, refer to the operating instructions.
10.
11.
S3125A
PORTABLE CART WARNING
(symbol provided by RETAC)

4
Grounding or Polarization - This product may be equipped with a polarized alternating current line
plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug.
12.
14.
15.
Lightning - For added protection for this product during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the
product due to lightning and power-line surges.
16.
Overloading - Do not overload wall outlet, extension cords, or integral convenience receptacles as
this can result in a risk of fire or electric shock.
Object and Liquid Entry - Never push objects of any kind into this product through openings as they
may touch dangerous voltage points or short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
Servicing - Do not attempt to service this product yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Damage requiring Service - Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an importer
adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way.
f) When the product exhibits a distinct change in performance - this indicates a need for
service.
17.
18.
Power-Cord Protection - Power supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they exit from the product.
13.

Replacement Parts - When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
Safety Check - Upon completion of any service or repairs to this product, ask the service technician
to perform safety checks to determine that the product is in proper operating condition.
Wall or Ceiling Mounting - The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
Heat - The product should be situated away from heat sources such as radiators, heat registers ,
stoves, or other objects (including amplifiers) that produce heat.
Nonuse Periods - Unplug the product’s power cord when you will not be using it for an extended
period.
19.
20.
21.
22.
23.
5

LOCATION OF CONTROLS - UNIT
112 2 34 5678 9
14 15 16 17 18 19 20
23 24 25 26 27 28
22
6
10 11
21
13
29
30
31 36
38
37
39
35
41
32 33 34
40

LOCATION OF CONTROLS - UNIT (cont.)
Detachable Speaker (L)
Insert
CD Door OPEN/CLOSE Button
Open or close the CD door
iPod/CD-SKIP/TUNING/CLOCK Time
Backward Button ( )
-iPod/CD-Skip/search backward
-TUNER-Backward tuning or station
search
-Clock or Timer-Select the time
-SUREWAKE vol level setting
CD Door
Volume UP Button (+)
To increase volume level
LCD Display
Shows the operating status in all modes
iPod/CD-SKIP/TUNING/CLOCK Time
Forward Button ( )
-iPod/CD-Skip/search forward
-TUNER-Forward tuning or station search
-Clock or Timer-Select the time
-SUREWAKE vol level setting
POWER ON/STANDBY Button
To power ON, standby light should be
switched off
Remote Control Sensor
Insert
1.
2.
3.
4.
5.
6.
7.
8.
9.
Detachable Speaker (R)
Surround Indicator
SURROUND ON/OFF Button
Press to turn the surround sound ON or
OFF. The indicator lights while surround
is ON
iPod PLAY/PAUSE Button
To start iPod playback/short PAUSE of
iPod playback
AUX Button
To activate AUX mode
MP3 MODE/ST/MO/ENTER Button
-To display ID3 TAG information, if
available during MP3 playback
-To select Stereo or Mono in TUNER FM
mode
-To confirm iPod menu selected
10.
11.
12.
PRESET/FOLDER/SELECT Button
-Press to retrieve preset radio station up
-Press to retrieve MP3 folder up
-Press to select iPod menu up
iPod DOCK
Volume DOWN Button (-)
To decrease volume level
Pedestal
14.
15.
16.
17.
19.
20.
21.
22.
13.
7
PRESET/FOLDER/SELECT Button
-Press to retrieve preset radio station
down
-Press to retrieve MP3 folder down
-Press to select iPod menu down
18.

33.
AUDIO OUT for iPod (R)
AUDIO OUT for iPod (L)
VIDEO OUT for iPod
HEADPHONE Jack (3.5mm)
Connect a pair of stereo headphones
(not supplied) for private listening
Speaker Terminal
Connect the speaker wires to left and
right speakers
Subwoofer Jack
To connect powered subwoofer (not
supplied)
AC Input Socket
To connect to AC power cord
Note: The cord was fixed on main unit
Battery Cover/Compartment
For tuner and clock memory back-up, to
install 1.5V x 2 “AAA” Batteries
WALL MOUNTING SLOT
AM Antenna Socket
AM antenna connection socket (for the
frame antenna included in the
accessories)
34.
35.
36.
CD/iPod STOP Button ( )
Interrupting the CD/iPod playback/clearing
the CD program iPod charging mode
CD PLAY/PAUSE Button
To play or pause CD playback
PROG/MENU/CLOCK SETTING Button
-Tuner/CD program/Clock setting button
(in off mode)
-iPod menu selection
TUNER/BAND Button
Sets to tuner (radio) mode and selects the
AM or FM band
DISPLAY ON/OFF Button
To select display backlight on/off
AUX IN Jack (3.5mm)
AUX input for stereo line level input
23.
24.
25.
26.
27.
28.
32.
29.
LOCATION OF CONTROLS - UNIT (cont.)
AUX Socket (L) (LINE OUT)
AUX Socket (R) (LINE OUT)
FM Antenna Bracket
Note - Do not connect to external antenna
8
37.
38.
39.
40.
41.
30.
31.

9
INSTALLATION (Speakers and Decorative Insert)
DISASSEMBLE AND FIX THE DECORATIVE INSERT
To fix the insert, place it with two holes
into main unit speaker holder (2), then fix
it by 3 pcs screws (3).
To remove the insert, release 3 pcs
screws (1), then pull out the insert from
the main unit.
PLACE AND FIX THE SPEAKER
Insert the speaker stud into the hole of the
main unit (1).
Push the speaker backward to the end until it
clicks (2).
DISASSEMBLE THE SPEAKER
Push the speaker forward from the back side
(1).
Release the speaker from the main unit
speaker holder (2).
1
2
3
2
2
1
1
2
1
2

10
ANGLE ADJUSTMENT (Speakers)
B
B
A
A
TILT ANGLE
Insert the bracket with (B) side and push upward to adjust for desired angle.
VERTICAL ANGLE
Insert the bracket with (A) side and push upward to adjust for vertical angle.
Used to connect the bracket (included) to set the speaker box on an angle.
1
2
1
2

INSTALLATION (Wall Mounting)
Installation options:
Wall mount
To mount the center section on the wall:
Position the bracket (supplied) on the wall (as show below) where you want to hang the whole unit. Drill 2 holes
slightly undersized for a firm fit.
Secure the bracket on the wall using 2 dowels and 2 screws (supplied).
The mounting screws should be anchored into solid wall support, such as wood frame or concrete wall.
Mount the center unit onto the wall bracket.
Make sure the mounting tab on the center unit fits securely into the mounting slot on the wall bracket.
Screws and plastic dowels are also provided for speakers if they are to be wall-mounted away from the center
section.
11
Note: speakers can be wall mounted separately as on below drawing.

REMOTE CONTROL
1a
1b
2
3
Remove the battery tray by pressing point
(1a) inside, then sliding point (1b) area at
the same time.
Pull out the battery tray.
Install or replace the button-type battery
“CR2032” (supplied).
Close the battery tray.
4
1.
2.
3
4
LOCATION OF CONTROLS - REMOTE CONTROL
Battery Installation
Note: Pull out insulation tag from the
button battery tray before operating the
remote control.
12
4243 44 46 47
48
49 50
51 52
53 54
55
56
58 59
60 61
62 63
64
65
45
57

LOCATION OF CONTROLS - REMOTE CONTROL (Cont.)
MUTE Button
To mute the sound
CD Door OPEN/CLOSE Button
Press to open or close the CD door at CD
mode
SUREWAKE/TIMER Button
To activate surewake/deactivate the timer
Remote Control Transmitter
POWER ON/STANDBY Button
Switches the system on or off
0 - 9 NUMERIC Buttons
Tuner: To recall preset stations
CD: To recall tracks
REPEAT Button
Repeat 1/ALL function for CD/iPod mode
INTRO Button
Plays 10 seconds of each CD track
RANDOM Button
CD play in random sequence
Volume UP Button ( + )
To increase volume level
BASSXPANDER Button
Press for a rich bass sound
PLAY/PAUSE Button
To start CD/iPod playback/short PAUSE
of CD playback
EQ Button
To select “ PASS, CLASSIC, ROCK, POP
and JAZZ” for desired sound effect
42.
43.
44.
45.
46.
47.
48.
49.
50.
51.
52.
53.
54.
56.
57.
61.
Volume DOWN Button ( - )
To decrease volume level
iPod/CD-SKIP/TUNING/CLOCK time
Backward Button ( )
-iPod/CD-Skip/search backward
-TUNER-Backward tuning or station
search
-Clock or Timer-Select the time
-SUREWAKE vol level setting
PRESET/FOLDER/SELECT Button
-Press to retrieve preset radio station
down
-Press to retrieve MP3 folder down
-Press to select iPod menu down
CD/iPod STOP Button ( )
Interrupting the CD/iPod playback/clearing
the CD program iPod charging mode
PRESET/FOLDER/SELECT Button
-Press to retrieve preset radio station up
-Press to retrieve MP3 folder up
-Press to select iPod menu up
PROG/MENU/CLOCK SETTING Button
-Tuner/CD program/Clock setting (in off
mode)
-iPod menu for selection
MP3 MODE / ST/MO/ENTER Button
-To display ID3 TAG information if
available during MP3 playback
-To select Stereo or Mono in TUNER FM
mode
-To confirm iPod menu selected
SLEEP Button
Press for sleep to music function
TUNER/BAND Button
Sets to tuner (radio) mode and selects the
AM or FM band
SOURCE Button
To select “CD, iPod, AUX, TUNER” mode
58.
59.
60.
62.
63.
64.
65.
iPod/CD-SKIP/TUNING/CLOCK time
Forward Button ( )
-iPod/CD-Skip/search forward
-TUNER-Forward tuning or station search
-Clock or Timer-Select the time
-SUREWAKE vol level setting adjustable
55.
13

14
POWER SUPPLY
BATTERY SUPPLY (For Tuner/Clock Memory Back-up)
+
-+
-
NOTE:
This unit is equipped with a polarized plug. If you
have difficulty inserting the plug, turn it over and
reinsert it.
CAUTION:
TO PREVENT ELECTRICAL SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
Install batteries (not supplied).
Observe + and - signs.
Remember to replace the battery
compartment lid
2 “AAA” size batteries
CAUTION:
WHEN INSTALLING BATTERIES
To prevent leakage from the batteries, which are
corrosive and can cause personal injury and
damage to the unit, observe the following
precautions:
The batteries must be installed correctly. Match
the polarities (+ and - signs) on the batteries, to
the polarities shown on the battery
compartment of the unit (see above).
Do not mix new batteries with old or used
batteries.
Only use batteries of the same type and brand.
If the unit will not be used for an extended
period of time, remove the batteries and store
them in a cool place.
Carefully follow the battery manufacturer’s
instructions for proper use and disposal.
DO NOT ALLOW YOUNG CHILDREN TO
HANDLE BATTERIES.
1.
2.
3.
4.
5.
6.
IMPORTANT NOTE:
SPENT OR DISCHARGED BATTERIES MUST BE
RECYCLED OR DISPOSED OF PROPERLY IN
COMPLIANCE WITH ALL APPLICABLE LAWS.
FOR DETAILED INFORMATION, CONTACT
YOUR LOCAL COUNTRY SOLID WASTE
AUTHORITY.
AC power operation
The cord is fixed on main unit.
120V AC, 60 Hz

15
When the AC power is connected, “-- -- : -- --“ shows on the LCD display.
Press the POWER/STANDBY button to turn the unit 'ON'.
To switch to POWER OFF, press the POWER/STANDBY
button to turn the unit 'OFF'. “GOOD BYE” appears on
display. The STANDBY LED lights.
POWER ON/OFF
SETTING THE TIME
When the unit is first connected to an AC power outlet, the display
shows "-- -- : -- --". To set the clock to the current time proceed as
follows:
OPERATING INSTRUCTIONS
In power off mode, press and hold the PROG button for 2
seconds, the “12” hour digits begin to flash.
Press the PROG button once more, the display
stops flashing and the clock begins to run.
1.
2.
3.
1.
7.
Example : FM mode
NOTE: Please turn off the unit to standby mode before disconnecting main power supply from the unit.
Press the / to adjust the hour time while it is
flashing. Be sure to set the hour correctly for AM or PM.
Press the / to adjust the minute time while it is
flashing.
4.
6.
Note: The LCD display lights up and “HELLO” greeting
shows on display, the STANDBY LED light goes off.
Volume at 13 (max 30).
You can now select your desired music source by
pressing one of the function buttons: TUNER/BAND or
CD PLAY/PAUSE or AUX or iPod on main console.
Display back light ON/OFF won’t be affected by power
ON/OFF.
4.
Press the / to select your desire either 12 or 24
hour clock time format.
2.
Press the PROG button to hour mode until the hour flashes.3.
Press PROG button once to minute mode and the minutes will flash.5.
/ON
/ON

16
TIMER ON/OFF SETTING
NOTE: The clock should be adjusted before the Timer On/Off setting.
Press the / to adjust the hour time up or
down. Be sure to set the hour correctly for AM or PM.
Press the / to adjust the hour time up or
down. Be sure to set the hour for correctly for AM or
PM.
Press the SUREWAKE TIMER button on remote control
again, the TIMER OFF indicator and hour digit begin to
flash.
Press the TIMER button on remote control once more, then the Timer On and Off adjustment is finished with the
" " display remaining ON (The SUREWAKE TIMER setting will show you once on display).
4.
5.
6.
8.
2.
11.
Press the SUREWAKE TIMER button on remote control
once, the TIMER ON indicator and hour digit begin to
flash.
To cancel the Timer On setting, press SUREWAKE TIMER button on remote control until " " display goes off.
1.
Note : To turn off the set while timer is on, press POWER button.
Note: Timer function with SUREWAKE starts the music quietly and then increases the volume to room level or your
selected volume level to make sure you are awake.
Press the / to adjust the minute time up or
down.
Press / button to adjust the minute time up or
down.
SETTING THE SLEEP
Pressing SLEEP button on remote control permits
settings from 10 to 90 minutes. When the desired time
appears, releasing your finger will set the time.
(Pressing "SLEEP" after the 10 minute showed, sleep
timer position will cancel the sleep timer.)
Change of SLEEP Setting
90 80 70 60 50 40
9. Press the SUREWAKE TIMER button once;
setting to: TUNER or CD or iPod are selected
by pressing the / button.
10. Press the SUREWAKE TIMER button, then press
the / to select the volume level.
30 20 10
Press the SUREWAKE TIMER button once, the minute
digits begin to flash.
3.
Press the SUREWAKE TIMER button once, the minute
digits begin to flash.
7.

17
BASIC OPERATION
Electronic volume control
Electronic volume control display
Press VOL-DOWN (-) button to adjust
sound level down, the volume level (00 - 30)
will be shown in the LCD display.
Holding down the button will result in
continuous decrease of the sound level.
Similarly, press VOL-UP (+) button to adjust
sound level up.
1.
2.
3.
Muting Function
If the MUTE button is pressed, the audio output will
be muted, and the current display begins to
flashing.
Pressed the MUTE button again to resume.
PRESET EQUALIZATION
Press the EQ button on remote control repeatedly
to cycle through the preset EQ showing on the LCD
display -- PASS, CLASSIC, ROCK, POP and JAZZ.
BASSXPANDER Control
Press the BASSXPANDER button to get the rich
bass sound.
BASSXPANDER shows on display
To switch off the BASSXPANDER function, press
the button once more.
BASSXPANDER shows on display

18
4.
Auto tuning - Press the TUNING forward or
backward buttons momentarily and release. The
tuner will move forward or backward to the next
available station.
Manual Tuning - Press and hold the SKIP forward/
backward buttons until the display approaches your
desired station. Then tap the buttons repeatedly
until the display shows the exact frequency.
Press the POWER/STANDBY button to turn the
system 'ON'.
1.
2. Press the TUNER/BAND button to select the
radio function.
3. Press the TUNER/BAND button repeatedly to
select AM or FM band.
1.
STORING PRESET STATIONS
The unit enables you to program 30 stations of FM
and 10 stations of AM band.
LISTENING TO THE RADIO
Example : FM mode 5. When finished listening, press the POWER button
to shut the system OFF.
Press the SKIP Forward or Backward buttons to
tune to the desired station.
2. Press the PROG button once, and the preset
station number will be flashing.
4. Press the PROG button again. The station is
stored.
Tune to the station you wish to store.
3. Press the PRESET button repeatedly to set the
desired preset station number.
5. To store other stations, repeat above steps.
RECALLING PRESET STATION
Press the PRESET buttons to select the
desired station.
FM
TUNER/
BAND
or
Note: For AM reception, plug the supplied frame
antenna into the AM ANT jack. Then adjust the frame
antenna until it is in position with the best reception.
Note: When setting or recalling the preset station by
directly pressing the number, on remote control unit
to press key number 0, 1 to preset station 01; press
0, 9 to preset station 09; press 1, 5 to preset station
15.

19
Switch on the power and press the CD PLAY/
PAUSE button to select the CD mode.
IN PLAY MODE
PRESS ONCE PRESS TWICE IN STOP MODE PRESS ONCE
BACK TO THE
BEGINNING OF THE
CURRENT TRACK PREVIOUS
TRACK PREVIOUS TRACK
NEXT TRACK NEXT TRACK
Press and hold the SKIP button during playback:
: FAST BACKWARD : FAST FORWARD
PLAYING COMPACT DISCS
If there is no CD inside, a "NO DISC" display
will appear.
When there is no disc
1.
2.
Loading a disc
Press the CD DOOR OPEN/CLOSE button to
open the CD door.
To load a disc, simply put the disc onto the
center spindle of the player and then press the
CD DOOR OPEN/CLOSE button again to close
the CD door. After that, reading TOC will start.
Playing the disc ( )
Press PLAY/PAUSE button to play the CD.
Playing track 1
Pause the playing ( )
Press PLAY/PAUSE button while the disc is
playing, the playing time will flash.
While paused
Stopping the disc
Press STOP ( )
Stop condition (TOC display)
Skip and Search Function
Press the SKIP Forward or Backward buttons momentarily during play mode or stop mode.
Ensure that the disc is correctly mounted on the
spindle and locked in place.
1.
2.
The display will show the total number of tracks and
the playing time of the disc.
Press PLAY/PAUSE button again to resume.
To operate by remote control
After reading TOC
Select desired track by pressing 0-9, then press
PLAY/PAUSE button to start playback.
Example: 03=Track 3, 11=Track 11.
