Saswell SAS6000UTK-7-WIFI User guide

TEL：[phone]/4/5
FAX：[phone]
Mail：[email protected]
Factory:3/4/6 F Building A,East 8th Region,
shangxueIndustry&Science Park,Buji town,
ShenzhenCity,Guangdong,China
SAS6000UTK-7-WIFI
SAS6000UTK-7-WIFI
Installation and Operation
Instruction Installation
Operation
Instruction for
and

Content
Installation Instruction Operation Instruction
Pre-installation checklist 02
Remove old thermostat 03
Lable wires and remove old wallplate 04
New thermostat installation 07
The wiring diagram 08
Alternate wiring-conventional system 09
Alternate wiring-for heat pumps only 11
Batteries installation 12
Program setting 20
Permanent hold override 24
Vacation hold override 25
Specifications/Feature 15
Time setting 17
System setting 18
Fan setting 19
Temporary hold override 26
Screen cleaning 27
Configurtion menu 29

for SAS6000UTK-7-WIFI
Installation Instruction Pre-installation Checklist
Check to make sure your package includes the following items:
SAS6000UTK-7-WIFI thermostat
(wallplate attached to back)
Wire labels
Wall anchors and
mounting screws (2 each)
Instruction for Installation
and Operation
01 02
SAS6000UTK-7-WIFI
Installation
Operation
Instruction for
and
www.saswell.com
Printed in China
This thermostat only work for 2.4Ghz.Before install ,adjust your router to 2.4Ghz

Lable Wires and Remove Old WallplateRemove Old Thermostat
1. Turn off power at heating/cooling system (or fuse/circuit-breaker panel).
2. Remove cover and thermostat.
Is there a sealed tube containing mercury?
If so, see inside front cover of this manual
for proper disposal instructions.
Old thermostat
Cover
Leave wallplate in place
Please leave wallplate with
wires attached when you
remove cover and thermostat.
1. Use a screwdriver to disconnect wires one by one. As you disconnect each wire ,
wrap it with the label matching the letter on your old thermostat.
(Adhesive labels are supplied in your thermostat package.)
2. Remove the old wallplate only after all wires are labeled. Be careful not to let
loose wires fall into the wall opening.
Wrap supplied labels securely around each wire.
Do not let wires fall into wall opening!
Do not use wire color as a guide.
Use only letter on the labels to
identify wire types.
03 04

3. Grasp top and bottom of wallplate and pull to remove from thermostat.
+
++
Wallplate
Pull wires through
wallplate.
Level wallplate if desired. Mark positions of
both screw holes.
4. Mark wallplate mounting position
12 3
05 06

New Thermostat Installation
1. Drill holes at pencil-marked locations:
2. Use hammer to tap
anchors into holes until
flush with wall.
3. Place wallplate over
anchors and insert screws.
Check level if desired,
then tighten screws.
4. Connect wires to terminal block
on base using appropriate wiring
schematic.
5. Carefully line the thermostat up
with the base and snap into place.
The Wiring Diagram
Insert wires, then
tighten screws.
L
RH
RC
G
AUX
E
S2
S1
Y
C
O/B
Y2
L
RH
RC
G
W
W2
S2
S1
Y
C
Y2
1. Match each labeled wire with
same letter on terminal.
(Use HEAT PUMP letters if
you have a heat pump system.)
2. Use a screwdriver to loosen
screw terminals, insert wires,
then tighten screws.
3. Push any excess wire back
into the wall opening.
Remove jumper wire between
RC and (R)RH terminals
before using on a DUAL
TRANSFORMER system
C
O/B
Y2
If labels do not match letters
on thermostat, see pages 09-11.
Y2
Y2
07 08

The Wiring Diagram
Alternate Wiring-Conventional System
RC
RH
W
Y
G
C
S1
S2
RC
RH
W
Y
G
C
S1
S2
2
3
2
If labels do not match terminals, connect
wires as shown here (see notes, below).
Remove metal jumper connecting
RH and RC only if you must connect
both RH and RC wires.
If your old thermostat had both R
and RH wires, remove metal jumper.
Connect the R wire to the Rc terminal,
and the RH wire to the R terminal.
If your old thermostat had only 1 C or
C1 wire, connect it to the C terminal.
If your old thermostat had 2 C or C1
wires, wrap each separately with
electrical tape and do not connect them.
1H/1C System
RC
RH
W
Y
G
C
W2
Y2
Rc
R
W
Y
G
C
W2
Y2
2
3
2
Remove metal jumper connecting
RH and RC only if you must connect
both RH and RC wires.
If your old thermostat had both R
and RH wires, remove metal jumper.
Connect the R wire to the Rc terminal,
and the RH wire to the R terminal.
If your old thermostat had only 1 C or
C1 wire, connect it to the C terminal.
If your old thermostat had 2 C or C1
wires, wrap each separately with
electrical tape and do not connect them.
2H/2C System
S1
S2
S1
S2
Remote Sensor
Remote Sensor
Heat Relay
Compressor
contactor
Fan relay
24v common
Remote Sensor
Heat Relay 1
Compressor
contactor 1
Fan relay
24v common
Heat Relay 2
Compressor
contactor 2
Remote Sensor
09 10

Front Panel 2 AA Batteries
Base
Batteries Installation
Battery Location:
Batteries are optional (to provide backup power) if your thermostat was wired
to run on AC power when installed.
Battery replacement:
Install fresh batteries immediately when the “ ” warning begins flashing. Low Batt
The warning flashes about 60 days before batteries are depleted. Even if the
warning does not appear, you should replace batteries once a year, or before
leaving home for more than 1 month.
To replace batteries, set system to OFF, remove thermostat from wall and
install the batteries in the rear along thetop of the thermostat.
Alternate Wiring-For Heat Pumps Only
If labels do not match letters on the thermostat,
check the chart at right and connect to terminal
as shown here (see notes, below).
2
3
3
5
5
46
6
RH
S1
S2
S1
S2
Remote Sensor
Remote Sensor
Compressor
contactor
Fan relay
24v common
Changeover
valve
Equipment
monitor
Emergency
heat relay
Auxiliary heat
relay(Heat 2)
Leave metal jumper in place, connecting
R & RC terminals.
If your old thermostat had both V and VR
wires, stop now and contact a qualified
contractor for help.
If your old thermostat had separate O
and B wires, attach the B wire to the
C terminal. If another wire is attached
to the C terminal,stop now and contact
a qualified contractor for help.
If your old thermostat had Y1, W1 and
W2 wires, stop now and contact a
qualified contractor for help.
5If L terminal is used, C terminal wire
must be connected (contact a
contractor if there is no C wire).
6If E and Aux terminals do not each have
a wire connected, use a small piece of
wire to connect them to each other.
11 12

for SAS6000UTK-7-WIFI
Operation Instruction
Important safety information
Always turn off power at the main power source by unscrewing fuse or switching
circuit breaker to the off position before installing, removing, cleaning, or servicing
this thermostat.
Read all of the information in this manual before installing this thermostat.
Only a professional contractor should install this thermostat.
All wiring must conform to local and national building and electrical codes and
ordinances.
Use this thermostat only as described in this manual.
13 14

Features
Specifications
SAS6000UTK-7-WIFI
Power Supply : Dual Power 24VAC (18-30VAC,50/60Hz)
or Battery Powered
Terminal Load : 1.0 A per terminal, 2.0A maximum total load
Set point Temperature Range : 41℉ to 95℉(5℃ to 35℃)
Operating Ambient : 32℉ to 122℉ (0℃ to 50℃)
Operating Humidity : 90% non-condensing max
Shipping Temperature Range : 14℉ to +140℉
(-10℃ to 60℃)
Dimensions : 5.9 inch×4.5 inch×1.2inch
(150mm×115mm ×32mm)
Color : White
Apply with various kind of heating and cooling system. Including Single stage,
Multi-stage And Heat Pump
(Up to 3-stage heat, 2-stage cool, with Aux. Or Emergency heat)
Large LCD display with backlight, continuous backlight option
Menu driven programming
Fan switch with on and auto
Permanent user setting retention during power loss, no batteries are required
Optional temperature display of Celsius or Fahrenheit scale
Auto change over
Optional 7 day programming and non-programmable
The screen displays the set temperature, the room temperature and current
time simultaneously
Air filter change indicator
Both vacation mold and hold duration mode available for comfort and energy
saving
UV light change indicator
15 16

System Setting
Time Setting
1.Press“ ” to display MENU
the first function menu .
MENU
2.Press“ ” to set current time and week. SET TIME
3.Press“ ”“ ” to set current time，press “+ - NEXT
STEP” to shift between setting minutes and
hours.
Press day to set current day of the week.
4.Press“ ” to save & exit (or press DONE
“ ”to exit without changing theCANCEL
time).
DONE
CANCEL
NEXT STEP
DONE
1.Press the “ ” to select the system:SYSTEM
AUTO: Auto Changeover is used in areas where both heating and
cooling may be required on the same day. When SYSTEM
button set to AUTO, the thermostat automatically select
heating or cooling depending on the indoor temperature.
2.Press the “ ” to save and exit .DONE
17 18
COOL: Thermostat controls only the cooling system
displays when first stage cooling activate
displays when both first stage cooling and second
stage cooling activate
HEAT: Thermostat controls only the heating system
displays when first stage heating activate
displays when both first stage heating and second
heating activate
EMER: Thermostat controls Emergency and Auxiliary Heat.
Compressor is locked out.
(only for heat pumps with auxiliary heat):
displays when Auxiliary heating or Emergency heating
activate

Program SettingFan Setting
DONE
FAN
1.Press the “ ” to select fan opertion :FAN
2.Press the “ ” to save and exit .DONE
AUTO: Fan Auto is the most commonly selected setting and
runs the fan only when the heating or cooling system
is on.
ON: Fan On selection runs the fan continuously for increased
air circulation or to allow additional air cleaning.
2.Press “ ” to enter set programSET SCHED
mode.
MENU
1.Press “ ” button to MENU
display main menu button.
SET SCHED
3.Select “ ”or “ ”for program HEAT COOL
setting system button.
19 20
displays when circulating fan activate

4.Press day buttons(Mon-Sun) to select
days to set program schedule.
It can be a single day the week
or a roup of days of the week
5.Select 4 different time period for setting
program schedule.
7.Press “ ”or “ ” to adjust + -
the temperature for the
time period.
Wake Up
(Morning 6:00)
Go To Bed
(Night 22:00)
Leave For Work
(Day 8:00)
Return Home
(Evening 17:00)
WAKE
SLEEP
LEAVE
RETURN
6.Press “ ”or “ to adjust the+ -
time for program period
start.
WAKE
SLEEP
LEAVE
RETURN
9.After you have complete the settings,
press “ ” to confirm and exit.DONE
8.Press “ ”for setting the NEXT STEP
program for the rest day(s) of the
week.
NEXT STEP
DONE
VIEW SCHED
CANCEL
RESET
1.VIEW SCHED: if you want to view the
preset setting schedule, please press
“ ” VIEW SCHED
2.RESET: press “ ” to resumeRESET
factory default program setting.
3.CANCEL: press “ ” to cancelCANCEL
the setting and exit.
21 22

Default setting
(Morning) (Day) (Evening) (Night)
Heating Program
6:00
70℉
8:00
62℉
17:00
70℉
22:00
62℉
Cooling Program 75℉ 82℉ 75℉ 78℉
SLEEP
LEAVE
RETURN
WAKE
Periods
Heat/Cool
system
The thermostat is programmed with the energy saving settings shown in the
table below for all days of the week. If this program suits your needs, simply set
the thermostat clock and press the RUN button. The table below shows the factory
set heating and cooling schedule for all days of the week
1.In Heating, lower temperatures will save energy
2.In Cooling, higher temperatures will save energy
3.If you plan on using Auto Changeover, set the heating temperature below
the cooling set temperature for more than the value of pre-set dead ban
(See configuration menu item 5).
Permanent Hold Override
2. Press “ ” to permanently adjust HOLD
the temperature.
3. Press “ ”or “ ” to adjust the temperature. + -
1.Press “ ” button to display main menu button.MENU
RUN SCHED
1.The function will turn off the program
schedule
2.Whatever temperature you set will
be maintained 24h a day, until you
manually change it, or press “RUN
SCHED” to cancel “HOLD”and
resume the program schedule.
23 24
HOLD

Temporary Hold OverrideVacation Hold Override
2. Press “ ” for to enter vacationHOLD 5s
hold setting.
3. Set temperature and days.
Press “ ”or “ ” to adjust+ -
the temperature.
1.Press “ ” button to display main menu button.MENU
RUN SCHED
Days
Days
Press “ ”or “ ” to set time+ -
of day.
The function will turn off the program
schedule ,until the vacation hold
program is completed .
if you want to resume the schedule
earlier ,please press “ ”RUN SCHED
This feature can suspend the program schedule for extended period of days.
RUN SCHED
This function can be set in the main interface directly.
1.Set the temperature
Press “ ”or “ ” to adjust+ -
the temperature.
2.Set the time
Press “ ”or “ ” to set the+ -
time for temporary hold.
if you want to cancel the temporary setting
and resume the schedule earlier , please
press “ ”RUN SCHED
25 26
HOLD
Sun
SETTING
Temporary Hold
ROOM TEMP

Screen Cleaning
2.Press “ ” to display the hidden OTHER
menu button.
1.Press “ ” button to MENU
display main menu button.
3.Press “ ” to lock the CLEAN DISPLAY
screen for cleaning.
The screen will remain locked for 30
seconds so you can clean the screen
without changing any setting.
4.After 30 seconds, press “ ” to DONE
resume normal operation, or press
“ ” again if you CLEAN DISPLAY
require more time for cleaning.
CLERN
CLEANDISPLAY
Do not spray any liquid directly on the thermostat. Spray liquids onto a cloth,
then use the damp cloth to clean the screen. Use water or household glass
cleaner. Avoid abrasive cleansers.
27 28
MENU
HOLD
CLEANDISPLAY

Configurtion Menu
The configuration menu allows you to set certain thermostat operating
characteristics to your system or personal requirements.
DONE
1.Press the “ ” SYSTEM
until “ ”blick.OFF
2.Press the “ ” to DONE
save changes .
MENU
3.Press the “ ”forMENU
display main menu.
4.Press the “ ”for display other menu. OTHER
5.Press the “ ” for entering CONFIG
configuration menu.
6.Press “ ” “ ” to select configuration
parameter setting.
7.Press “ ” for changing toNEXT STEP
the next menu item setting.
8.After all configuration parameters are set
up, press “ ” to confirm and exit. DONE
If you want to go back to the previous
item setting , press “ ” . PREVIOUS STEP
29 30
TECHNICIAN SETUP: USE UP AND DOWN FOR CURRENT SELECTION
AND NEXT STEP PREVIOUS STEP KEY TO THE NEXT PREVIOUS STEP

1.System type option
Parameter options:(1H,2H,HP1,HP2)
1H: 1 heat/1 cool conventional 2H: 2 heat/2 cool conventional
HP1: 1 compressor heat pump HP2: 2 compressors or 2 speed compressor
heat pump
Factory default:2H
2.Fan control option
Parameter options:(HA,HE)
HA: Gas heating. Furnace controls blower
HE: Electric heating. Thermostat controls blower
Factory default:HA
3.Auxiliary heat type option
Parameter options:(HA,HE)
HA: Fossil fuel backup heat HE: Electric backup heat
Factory default:2H
This option apply only to HP1 or HP2 setting in system type option
4.Manual/Autochangeover option
Parameter options:(0,1)
0: Manual changeover 1: Auto changeover
Factory default:0
5.Auto changeover dead band option
Parameter options:(2~9℉)
Factory default:3℉
6.Intelligent recovery option
Parameter options:(OF,ON)
OF: Deactivate the intelligent recovery function
ON: Activate the intelligent recovery function
Factory default:OF
1.Intelligent recovery function doesn't activate when program setting to
non-programmable.
2.Intelligent recovery function: it means bringing your room temperature to the set
temperature at exactly the pre-set time by turning on the heating earlier.
31 32

7.First heating cycle rate
Parameter options:(FA,SL)
FA: Fast rate, heating will activate 0.6℉below set point
SL: Slow rate, heating will activate 1.2℉below set point
Factory default:FA
8.First cooling cycle rate
Parameter options:(FA,SL)
FA: Fast rate, cooling will activate 1.2℉abvoe set point
SL: Slow rate, cooling will activate 1.7℉above set point
Factory default:FA
9.Emergency heat cycle rate
Parameter options:(FA,SL)
FA: Fast rate, Emergency will activate 1.2 ℉below set point
SL: Slow rate, Emergency heat will activate 1.7℉below set point
Factory default:FA
This option apply only to HP1 or HP2 setting in system type option
10.Compressor lockout delay option
Parameter options:(0,5)
To protect the compressor from short cycling, you can select compressor off-time cycle
between 0 or 5 minutes
Factory default:5
When the thermostat compressor time delay occurs, “Comp Dly” display during compressor
lockout.
11.Display backlight option
Parameter options:(1,2,3)
1:No backlight display
2:The backlight come on for approximately 30s when any button is touched
3:The backlight remain on continuously
Factory default:2
When operated from batteries (No “C” terminal connection, or if AC power goes off), the
LCD continuously display of backlight will be disabled.)
33 34

12.Temperature recalibration option
Parameter options:(-4~+4)
Factory default:0
13.℉ or ℃ readout option
Parameter options:(℉ , ℃)
Factory default:℉
14.Program option
Parameter options:(7,0)
7: 7-day program function for the thermostat 0: non-program function for the thermostat
Factory default:7
This option apply only to HP2 or 2H setting in system type option
15.Sceond stage heating rate option
Parameter options:(FA,SL)
FA: Fast second stage heating rate. Second stage heating will activate 1.5℉below first stage heating
SL:Slow second stage heating rate. Second stage heating will activate 2.5℉below first stage heating
Factory default:7
16.Sceond stage cooling rate option
Parameter options:(FA,SL)
FA: Fast second stage cooling rate. Second stage cooling will activate 1.5℉above first stage
cooling
SL: Slow second stage cooling rate. Second stage heating will activate 2.5℉above first stage
cooling
Factory default:FA
17.Filter replacement run time option
Parameter options:(00-12)
This is a reminder to change or clean your air filter. This time can be set from 0 to 12 months in
1 month increments.
Factory default:00
1.The thermostat will display the “Chg Filter” after a set time of operation.
2.Selection of 00 will cancel the function.
This option apply only to HP2 or 2H setting in system type option
35 36
