Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
Content [Original Version: German]
1. Symbols..................................75
2. Technical Data........................75
3. Scope of Delivery ...................76
4. Technical Design ....................76
5. Intended Use..........................76
6. Safety Instructions..................77
7. Use.........................................79
8. Cleaning of the Pressure
Measuring Devices.................80
9. Battery Replacement..............81
10. Troubleshooting......................82
11. Disposal..................................83
12. After Sale Service...................83
13. Warranty / Liability..................83
14. Spare Parts ............................83
15. Declaration of Conformity.......84
1. Symbols
Warning! Risk which could cause heavy injuries or death.
Warning! Risk which could cause damage.
Explosion risk! Warning against risk which could cause
heavy injuries or death.
Notice! Useful tips and recommendations
2. Technical Data
Max. operating pressure 10.0 bar
Max. operating temperature 60 °C
Energy supply Battery RENATA CR2032
(Art. No. 160739)
Display accuracy +/- 0.05 bar
Approval for use in explosive
areas
II 2G Ex ia IIC T4
(KEMA 05ATEX1090X)
EU directive 94/9 EG
[EN] Operating Instructions | english
163881-BAL-SATA adam 2.indb 75 12.02.2016 15:10:47

76
EN
Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
3. Scope of Delivery
Component
Product
SATA
adam 2
display
SATA
adam 2
dock
SATA
adam 2
mini dock
SATA
adam 2 U
dock
SATA adam 2 X X - -
SATA adam 2 mini X - X -
SATA adam 2 display - X - -
SATA adam 2 U X - - X
One RENATA CR2032 battery is included in the delivery.
4. Technical Design [1]
[1-1] SATA adam 2 dock connec-
tion module for SATA spray
guns except for
SATAjet 5000 B
[1-2] SATA adam 2 dock con-
nection module for SATAjet
5000 B
[1-3] SATA adam 2 mini dock
connection module for SATA
minijet spray guns
[1-4] SATA adam 2 U dock
[1-5] Regulation wing
[1-6] Ball valve
[1-7] SATA adam 2 display
[1-8] O-ring | Please regularly
lubricate with high per-
formance grease (Art. No.
48173)
[1-9] Locking clip
[1-10] Digital display
5. Intended Use
The SATA adam 2 devices are designed for adjustment and control of the
inlet pressure of a SATA spray gun.
Warning!
• The user is responsible for any damage and accidents caused by im-
proper use!
163881-BAL-SATA adam 2.indb 76 12.02.2016 15:10:47

77
EN
Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
6. Safety Instructions
6.1. General Safety Instructions
Warning! Attention!
• Before using the device, please read all safety instructions as well as
the operating instructions of the paint spray gun carefully. Safety instruc-
tions and indicated safety measures are mandatory.
• Please keep all enclosed documents and make sure that the device is
handed over only together with these documents.
• Reading the operating instructions of the respective SATA paint spray
gun is mandatory!
6.2. Specific Safety Advice
Warning!
• Local safety, accident prevention, work safety and environment protection
regulations are mandatory!
• Use, cleaning and maintenance by skilled personnel only!
• People whose ability to react is impaired by drugs, alcohol, medication or
for other reasons are not allowed to use the device!
• Never use the device when it is damaged or when parts are
missing! Especially, only use when locking screw (see chapter
7.) is firmly tightened!
• Before use, always check and, if necessary, repair the device!
• Put device out of operation when damaged, disconnect from compressed
air supply!
• Never manipulate or technically modify the device!
• Use original SATA spare parts and accessories only!
• Never apply spray media containing acid, alkaline or benzine!
• Alwayskeepthedeviceawayfromignitionsources,suchasopenre,
burning cigarettes or non-explosion-proof electronic devices!
163881-BAL-SATA adam 2.indb 77 12.02.2016 15:10:48

78
EN
Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
6.3. Personal Protection Equipment
Warning!
• Always wear approved breathing and eye protection as well as
suitable protective gloves, overall and shoes when using the device
as well as during cleaning and maintenance!
6.4. Use In Explosive Areas
Thedeviceisapprovedfortheuse/storageinexplosiveareasclassied
as Ex-Zone 1 and 2.
Warning! Risk of explosion!
The following applications and operations lead to the loss of
the explosion protection and are, therefore, prohibited:
• The SATA adam 2 must not be brought along with or used on a spray
guninexplosiveareasclassiedasEx-Zone0!
• Do not use solvents and cleaning agents based on halogenised
hydrocarbons! Chemical reaction which may occur when using these
substances may be explosive!
The electronic pressure measuring device has been submitted to a design
examination and is developed, constructed and manufactured in accord-
ancewiththeEUdirective94/9EU.ItwasclassiedtoII2GExiaIICT4
FM Global IS CL I, ZN 1, AEx ia IIC T4 IS CL I, DIV 1, GP A, B, C&D, T4
and may be used and stored in the explosive zones 1 and 2 up to 60°C
ambient temperature. Inspection authority: KEMA 05 ATEX 1090 X.
Ex-sign
Equipment category Gas category Type of ignition protection Temperature
classi󰘰cation
Device category Equipment category
II 2 G Ex ia IIC T4
II 2 G Ex ia IIC T4
IECEx label: IECEx KEM 09.0075
163881-BAL-SATA adam 2.indb 78 12.02.2016 15:10:48

79
EN
Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
Warning! Risk of explosion!
The following applications and operations lead to the loss of
the explosion protection and are, therefore, prohibited:
• Battery replacement in explosive areas!
• Installation of a battery other than CR 2032, RENATA (SATA Art. No.
160739)!
7. Use [2]
Warning! Attention!
• Please disconnect spray gun from the air supply prior to the installation of
the SATA adam 2 to the spray gun.
• Pleaseensurethatallscrewsarermlytightened.
Steps 1. - 4. only apply to the SATA adam 2 (mini)
25. Loosen and remove the locking screw [2-1].
26. Removeairmicrometer(airowcontrolknob)[2-2]
27. Insert SATA adam 2 [2-3] in the spray gun.
28. Tightenlockingscrewrmly[2-4].
Warning!
• Checkiflockingscrewhasbeenrmlytightened!SATAadam2(mini)
could otherwise shoot out from the spray gun in an uncontrolled way!
7.1. Disassembly and Assembly of the Display [3]
Disassembly:
• Place the regulation wing [3-1] in the horizontal centre position.
• Press down the locking clip [3-2] and slide display [3-3] upwards out of
the groove.
Assembly:
• Place the regulation wing [3-4] in the horizontal centre position.
• Place display [3-5] correctly in the groove and slide in until it snaps
home.
163881-BAL-SATA adam 2.indb 79 12.02.2016 15:10:48

80
EN
Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
7.2. Adjust Spray Gun Inlet Pressure [4]
Note!
• Fully pull the trigger [4-1] and adjust the spray gun inlet pressure with
the regulation wing [4-2], then release the trigger.
• With SATA adam 2 U fully pull the trigger [4-1] – air micrometer on
spray gun must be fully opened –and adjust the spray gun inlet pressure
according to [4-1], the release the trigger.
• If the required spray gun inlet pressure is not reached, please increase
pressure at the air supply; high pressure leads to increased trigger
forces.
8. Cleaning of the Pressure Measuring Devices
Warning! Attention!
• Please make sure to remove the SATA adam 2 display before clean-
ing the spray gun in a gun washing machine (see chapter 7.1). Never
clean SATA adam 2 display in the washing machine! SATA
adam 2 dock can remain on the spray gun while cleaning the spray
gun in the gun washing machine.
• Please also observe the cleaning instructions for your SATA spray gun.
• Blow dry spray gun and material passage, air cap incl. thread and
gravityowcupaswellasthedock connection module with clean
compressed air after cleaning!
• Never soak the SATA adam 2 display or a spray gun in cleaning
agent!
• The SATA adam 2 display is exclusively to be cleaned with a
cloth soaked in cleaning agent. Afterwards, lubricate O-ring
[1-6] with high performance grease (Art. No. 48173).
• Use neutral cleaning solution (pH value 6 to 8)!
• Do not use acids, lyes, pickling agents, unsuitable reclaimed
materials or other aggresive cleaning media, such as Toluol,
for example!
• Do not clean the glass plate of the SATA adam 2 display with pointed,
sharp or abrasive objects!
• Please open the display in case of battery exchange only!
163881-BAL-SATA adam 2.indb 80 12.02.2016 15:10:48

81
EN
Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
Note!
• Further cleaning tips can be found at www.sata.com/TV.
9. Battery Replacement [5]
Warning! Risk of explosion!
• Replace the battery outside of explosive areas only!
• Please observe safety instructions in chapter 6.4!
Only RENATA batteries (CR2032) must be used. Use the battery kit (Art.
No. 160739) consisting of battery, O-rings, locking clip, elastic rubber
strap and special tool. According to the intensity of use, the battery will
last between 1 to 3 years. The battery capacity is electronically controlled.
Toexcludemeasurementerrors,thedisplayswitchesoffwithinsufcient
battery power. In this case, the battery has to be replaced.
Depending on display and use, the battery must be replaced within the
following time frames:
Display:
Battery symbol 4-5 weeks
Exclamationmarks(ashing) 2-3weeks
Display "Lob" upon switching-on <1 week
1. Disassembly of the display [5-1] (also see chapter 7.1).
2. Open display using the special tool and the elastic rubber strap
[5-2], [5-3].
3. Remove the battery with special tool [5-4].
4. Insert a new RENATA CR 2032 (observe polarity of battery!).
5. Remove the sealing with the special tool [5-5] and insert the new
sealing.
6. Screw the housing back onto the display. To prevent penetration of
cleaning agent, please ensure to tighten the housing hermetically
(completely) [5-3].
7. If required, replace the locking clip and the small O-ring. Flat side of
locking clip must be visible [no illustration].
163881-BAL-SATA adam 2.indb 81 12.02.2016 15:10:48

82
EN
Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
10. Troubleshooting
Malfunction Cause Corrective action
No pressure is
displayed.
• Display has not prop-
erly snapped into the
dock
• Battery is empty
• Slide in the display
until it snaps home,
chapter 7.1
• Replace the battery
Display cannot
be removed at
all or only with
difculty.
• Regulation wing is not
in horizontal centre
position
• Slide-in groove is
clogged.
• Locking clip has not
snapped in.
• Special O-ring [1-6] is
swollen due to soaking
in solvent.
• Place regulation wing
in horizontal centre
position, chapter 7.1
• Clean the slide-in
groove.
• Press in the locking
clip, chapter 7.1
• Avoid soaking in sol-
vent, chapter 8
Air leaks be-
tween display
and connection
module dock
O-Ring beneath the
locking clip is missing or
damaged.
Replace the O-ring,
chapter 9
Air leaks from
the ball valve [1-
8] (when using
without display)
Ball valve is clogged Clean ball valve, chap-
ter 8
Display does not
snap-in
• Locking clip is dam-
aged.
• Slide-in groove of the
connection module is
clogged or damaged
• Replace locking clip,
chapter 9
• Clean the groove
or replace the dock,
respectively
Digital display is
either black or
blurred.
Display has been exces-
sively exposed to clean-
ing solution.
Cleaning, chapter 8,
replacement of the dig-
ital unit
163881-BAL-SATA adam 2.indb 82 12.02.2016 15:10:48

83
EN
Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
11. Disposal
To protect the environment, batteries as well as SATA adam 2 have to be
disposed of appropriately. Please observe local regulations!
12. After Sale Service
Please contact your SATA dealer for accessories, spare parts and techni-
cal support.
13. Warranty / Liability
The SATA General Conditions of Sale and Delivery and further contractual
agreements, if applicable, as well as the valid legislation at the time apply.
SATA cannot be held responsible especially in the following
cases:
• In case when the cleaning instructions are not observed (please see
chapter 8)
• In case when liquids have penetrated the SATA adam 2 display be-
cause it has not been hermetically (completely) tightened (please see
chapter 9)
• In case of any other form in which the operating instructions are not
observed.
• When the product is used in other than the intended ways of usage.
• When untrained staff is employed.
• When no personal protection equipment is worn.
• When no original accessories and spare parts are used.
• When the product is manipulated, tampered with or technically modi-
ed.
• In case of normal wear and tear.
• In case when the product has been exposed to untypical shockloads
and impacts during usage.
• Assembly and disassembly
14. Spare Parts
Art.
No.
Description
160739 Battery kit for SATA adam 2 and SATA adam 2 mini
160788 SATA adam 2 dock (außer SATAjet 5000 B)
163881-BAL-SATA adam 2.indb 83 12.02.2016 15:10:48

84
EN
Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
Art.
No.
Description
160796 2 pieces SATA adam 2 dock (except for SATAjet 5000 B)
211565 SATA adam 2 dock for SATAjet 5000 B
211573 2 pieces SATA adam 2 dock for SATAjet 5000 B
160861 SATA adam 2 mini dock
160689 SATA adam 2 display (bar)
160697 SATA adam 2 display (psi)
162164 5x locking clip
162172 2x O-ring
162081 5x dock protect
195214 SATA adam 2 U (air micrometer G 1/4 with adam 2 display
>bar<)
195222 SATA adam 2 U (air micrometer G 1/4 with adam 2 display
>psi<)
195230 SATA adam 2 U dock (without display)
195925 SATA dock with G 1/8 Male thread
15. Declaration of Conformity
Manufacturer:
SATA GmbH & Co. KG
Domertalstrasse 20
D-70806 Kornwestheim
We hereby declare that the product named in the following, on the basis
of its conception, construction and type of construction in the model we
have brought on the market, corresponds to the fundamental safety re-
quirements of the 94/9/EC guideline, EC Directive 2014/34/EC including
the changes applicable at the time of this declaration and can be used
according to EC-Directive 94/9/EC, EC Directive 2014/34/EC in explosion
hazard areas (ATEX), appendix X, B.
Product description: ..............digital pressure measuring device
163881-BAL-SATA adam 2.indb 84 12.02.2016 15:10:48

85
EN
Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U Operating instructions pressure measuring devices SATA adam 2, SATA adam 2 U
Product type:..............................................SATA adam 2 (mini),
......................................... SATA adam 2 display, SATA adam 2 U
ATEX classification: ...................................... II 2 G Ex ia IIC T4
Inspection Autority: 0344
KEMA 05 ATEX 1090
IECEx KEM 09.0075X
DEKRACerticationB.V.
Meander 1051
6825 MJ Arnhem
Corresponding EC directive
• EN 60079-0:2013, EN 60079-11:2012, EN 60079-26:2007
• EU machinery directive 2006/42/EU
• EC Directive 94/9/EC Devices and protection systems for intended use
in explosion hazard areas, valid until 19.04.2016
• EC Directive 2014/34/EC Devices and protection systems for intended
use in explosion hazard areas, valid from 20.04.2016
Applied harmonised norms:
• DIN EN 1127-1:2011 "Explosion control part 1: Basics and methodology"
• DIN EN 13463-1:2009 "Non-electronic devices for the use in explosive
areas - Part 1: Basics and Requirements"
• DIN EN ISO 12100:2011; "Machine safety, general requirements"
• DIN EN 1953:2013 "Spray and application devices for coating materials
- safety requirements"
Applied national norms:
DIN 31000:2011 "General guidelines for the safety-compliant design of
technical products"
The documents required according to guideline 2014/34/EC appendix VIII
areledfor10yearsinthenamedlocationnumber0123withthedocu-
ment number 70023722.
70806 Kornwestheim, 18.01.2016
Albrecht Kruse
President
SATA GmbH & Co. KG
163881-BAL-SATA adam 2.indb 85 12.02.2016 15:10:48
