SATA DY03001 User manual

口袋式数字万用表
Pocket Digital
Multimeter
DY03001
中文
EN

目 录
简介 ��������������������������������� 1
安全须知 ������������������������������� 1
告戒 ���������������������������������
电器符号 �������������������������������
综合规范 �������������������������������
面板介绍 �������������������������������
技术指标 �������������������������������
操作说明 �������������������������������
测量直流电压 ����������������������������
测量交流电压 ����������������������������
测量直流电流 ����������������������������
测量电阻 ������������������������������
通断测试 ������������������������������
二极管测试 �����������������������������
维护保养 �������������������������������
电池和保险丝的更换 ��������������������������
附件 ���������������������������������
3
3
4
4
5
8
8
8
9
9
10
10
10
11
11

简介
本万用表是一款结构紧凑的3 1/2位数字万用表.可用来测量直流和交流电
压、直流电流、电阻、二极管及通断，并具有极性指示及电池低电压指示功能。本
仪表体积小，重量轻，采用盒式结构设计，便于携带，是理想的测量工具。
本仪器的设计符合IEC 61010，污染等级2级，测量种类II（CATII 300V）。
为避免电击和人身伤害，请遵循以下操作要求：
1. 仪器存在破损时，请勿使用。 使用前请检查外壳，尤其应注意连接器
周围的绝缘。
2. 检查表笔的绝缘是否有损坏或暴露的金属。检查表笔是否导通。
如果表笔有损坏，请更换后再使用。
3. 若仪器工作失常，请勿使用。保护设施可能已遭破坏。
若有疑问，应把仪器送去维修。
-1-
安全须知
DY03001 用户手册

-2-
4. 切勿在爆炸性的气体，蒸汽或灰尘附近使用本仪器。
5. 切勿在两只表笔之间或表笔与地之间施加超过仪表上所标示的额定电压。
6. 使用前，通过测量已知电压的方式确认仪器工作正常。
7. 维修时，只使用指定的更换部件。
8. 对于30Vac有效值，42Vac峰值或60Vdc以上的电压，工作时要小心，这
类电压会有电击的危险。
9. 使用表笔时，应把手指置于表笔上的护指装置之后。
10.连接时，先连接黑色表笔，而后才连接红色表笔。拆除接线时，先拆红
色表笔，而后才拆除黑色表笔。
11.打开后盖之前，应先将表笔从被测电路取下。
12.仪器的后盖被拆下或松开时，切勿使用仪器。
13.当屏幕出现电池低电压符号“ ”，应马上更换电池。电池电量不足会
使仪器读数错误，从而导致电击或人身伤害。
14.如果仪表或手很潮湿，请勿使用仪表。
15.为避免电击，使用者不要接触任何裸露的导体。
16.给一个输入端子接上一个危险的电压时, 请注意，在所有其它端子上可
能出现此电压。
17.CATII：通过电源线连接到室内插座的用电设备的一次电气线路。
不要把仪器用在属于CATIII和CATIV的测量范围。
DY03001 用户手册

告戒
电气符号
-3-
为避免对仪器或设备造成损害，请遵守以下几点要求：
1. 在测量电阻，通断和二极管之前，先断开待测电路的电源，并对所有的电
容器充分放电。
2. 使用正确的功能。
3. 测量电流前，确认仪器的保险丝完好。在把仪器连接到待测电路之前，切
断待测电路的电源。
4. 在移动功能开关或转动量程开关之前，先把表笔从被测电路上移开。
DC（直流） 地端子
符合欧盟指令。
有双重绝缘或加强绝缘保护。
警惕！有电击危险。 保险丝
AC（交流）
AC 或 DC
警惕！有危险。使用前请参阅说明书。
DY03001 用户手册

DIGITAL MULTIMETER
MAX
MAX
300V
FUSED 200mA
OFF
300
2000
200
20
2
CAT II
综合规范
面板介绍
-4-
显示屏： 3 1/2液晶显示屏，
最大读数1999
自动负极性显示：屏幕显示“ - ”
采样速率： 2 ~ 3次/秒
IP等级： IP20
工作环境： 0℃ ~ 40℃，
相对湿度 <75%
1. 显示屏
2. 功能开关：用于选择所需的功能。
3. 量程开关：用于选择所需的量程以
及开启和关闭仪表电源。关机时，
应将此开关置于“OFF”档。
4. 表笔
储存环境：-10℃ ~ 50℃，
相对湿度 <85%
电源： 1.5V×2，LR44钮扣电池
电池低电压指示：显示“ ”符号
尺寸： 114×56×23mm
重量： 约101克（含电池）
1
2
3
4
DY03001 用户手册

技术指标
-5-
精度在校正后一年内指定，温度18℃-28℃，相对湿度：<75%.
精度指标采用的形式：±（[读数%]+[最低有效数位]）
输入阻抗：1MΩ
最大允许输入电压：300V dc
备注1：当仪表测量超过300V的信号时，是可以显示实际测量所得的数值，
但可能引起危险。
DY03001 用户手册
量 程功 能
2V 0.001V
0.01V ±（1.0% + 5） 屏幕显示“1”
0.1V
1V 见备注1
20V
200V
300V
分辨率 精 度 过量程指示
直流电压

-6-
输入阻抗：约500kΩ
频率响应：40 ~ 400Hz
最大允许输入电压：300V ac rms
显示：正弦波有效值（平均值响应）
备注1：当仪表测量超过300V的信号时，是可以显示实际测量所得的数值， 但可
能引起危险。
过载保护：250mAH 250V 快速熔断保险丝
DY03001 用户手册
量 程功 能
±（1.2%+10） 屏幕显示“1”
0.1V
1V 见备注1
200V
300V
分辨率 精 度 过量程指示
交流电压
量 程功 能
±（1.2%+5） 屏幕显示“1”
0.1mA
200mA
分辨率 精 度 过量程指示
直流电流

-7-
最大开路电压：0.4V
DY03001 用户手册
量 程功 能
±（1.2% + 5） 屏幕显示“1”
分辨率 精 度 过量程指示
电阻
2kΩ 0.001kΩ
0.01kΩ
0.1kΩ
1kΩ
20kΩ
200kΩ
2000kΩ
二极管测试
量 程功 能 介 绍 备 注
备 注
液晶屏显示二极管的
正向电压降的近似值
开路电压：约2.5V
最大测试电流：1mA
通断测试
量 程功 能 介 绍
当被测电路的电阻小于约30Ω，
内置蜂鸣器响。
当电阻在30Ω到100Ω之间时，
蜂鸣器可能响或不响。
电阻大于100Ω时，蜂鸣器不响。
开路电压：约2.5V

-8-
操作说明
测量直流电压
测量交流电压
1. 将功能开关置于“V ”位置。
2. 将量程开关置于所需的电压档。如果待测电压的大小范围事先不知道，
先将量程开关置于最高档，然后逐渐降低档位直至获得满意的分辨率。
3. 将表笔跨接到待测电源或电路的两端。
4. 读取屏幕读数。红表笔连接端的极性也将一同指示。
注意：为避免受到电击或造成仪表损坏，请勿将大于300V的电压加到输入端。
1. 将功能开关置于“V ”位 置 。
2. 将量程开关置于“300V ”或“200V ”档。如果待测电压的大小范围
事先不知道，先将量程开关置于最高档，然后再降低档位直至获得满意的
分辨率。
3. 将表笔跨接到待测电源或电路的两端。
4. 读取屏幕读数。
注意：为避免受到电击或造成仪表损坏，请勿将大于300V的电压加到输入端。
DY03001 用户手册

1. 将功能开关置于“A ”位置。
2. 将量程开关置于“200mA”档 。
3. 断开待测电路的电源，把表笔串接到待测电路，然后开启电路的电源。
4. 读取读数。红表笔连接端的极性也将同时指示。
-9-
测量直流电流
测量电阻
1. 将功能开关置于“Ω ”位 置 。
2. 将量程开关置于所需的电阻档位。
3. 将表笔跨接到待测电阻的两端。
4. 从屏幕读取测量结果。
注意：
1. 当所测量的电阻值为1MΩ或1MΩ以上时，读数可能需要过几秒钟才能稳
定，这对于高阻的测量是正常的。
2. 当输入端开路时，屏幕显示“1”作为过量程指示。
3. 在测量电路上的电阻之前，断开被测电路的电源，并对所有电容进行充
分放电。
DY03001 用户手册

-10-
通断测试
二极管测试
维护保养
1. 将功能开关置于“Ω ”位置。
2. 将量程开关置于“ ”位置。
3. 将表笔跨接到待测电路的两端。
4. 当电阻小于约30Ω时，内置蜂鸣器将响。
注意：测量前，断开待测电路的电源并对所有电容器充分放电。
1. 将功能开关置于“Ω ”位置。
2. 将量程开关置于“ ”位置。
3. 将红色表笔接到待测二极管的正极，黑色表笔接到待测二极管的负极。
4. 从屏幕上读取二极管的正向压降的近似值。如果表笔接反，则屏幕将显
示“1”。
除更换电池和保险丝外，若非合格的专业技师并且拥有足够的校准、性能测试
和维修仪表的相关说明，切勿尝试修理或保养您的仪表。建议校准周期为12个月。
定期用潮布和少许清洁剂擦拭外壳。请勿使用磨料或溶剂。
DY03001 用户手册

-11-
电池和保险丝的更换
附件
说明
说明书： 1本
保修卡： 1张
1.5V钮扣电池（LR44）： 2个
1. 当屏幕显示“ ”符号，表示电池电量不足，必须立即更换。请用十字
螺丝刀，将其后盖的两个螺丝取下，打开后盖，换上2个新的1.5V LR44
电池，确保电池极性正确（见电池仓底部的极性标识）。盖好后盖，锁
紧螺丝。
2. 更换保险丝：
用上文所述方法打开后盖，用相同规格新的保险丝更换已熔断的保险丝。
盖上后盖，锁紧螺丝。
保险丝规格：250mA / 250V快速熔断保险丝，Ø5×20mm。
1. 本公司保留对说明书内容修改的权利。
2. 本公司不负责任何由于使用时引起的其它损失。
3. 本说明书内容不能作为将产品用做特殊用途的理由。
警 告 打开仪表后盖之前，先将表笔从被测电路取下。
DY03001 用户手册

TABLE OF CONTENT
INTRODUCTION ····································································································································································
WARNING ··············································································································································································
CAUTION ···············································································································································································
ELECTRICAL SYMBOLS ······················································································································································
SCREEN INTRODUCTION ···················································································································································
GENERAL SPECIFICATION ·················································································································································
TECHNICAL SPECIFICATIONS ···········································································································································
OPERATING INSTRUCTION ··············································································································································
DC/AC Voltage ························································································································································
DC Current / Resistance ····································································································································
Diode/ Continuity Test ········································································································································
Maintenance ··························································································································································
Button Cell And Fuse Replacement ·················································································································
UNPACKING INSPECTION ···············································································································································
1
1
3
3
4
5
5
9
9
10
11
12
12
13

The multimeter has been designed according to IEC 61010 concerning electronic measuring
instruments with a measurement category (CAT II 300V) and Pollution degree 2.
Warning
To avoid possible electric shock or personal injury, follow these guidelines:
DY03001 Users Manual
Do not use the meter if it is damaged. Before you use the meter, inspect the case. Pay particular
attention to the insulation surrounding the connectors.
Inspect the test leads for damaged insulation or exposed metal. Check the test leads for
continuity. Replace damaged test leads before you use the meter.
Do not use the meter if it operates abnormally. Protection may be impaired. When in doubt, have
the meter serviced.
Do not operate the meter where explosive gas, vapor, or dust is present.
Do not apply more than the rated voltage, as marked on the meter, between the probes or
between any probe and earth ground.
Before use, verify the meter's operation by measuring a known voltage.
When measuring current, turn off circuit power before connecting the meter in the circuit.
Remember to place the meter in series with the circuit.
When servicing the meter, use only specified replacement parts.
●
●
●
●
●
●
●
-1-
Introduction
This meter is a compact 3 1/2-digit digital multimeter for measuring DC and AC voltage, DC current,
resistance, diode and continuity. It features polarity indication, low battery indication, small size, lightness,
and uses box-type design. It is easy to carry and is an ideal test tool.

DY03001 Users Manual
Use caution when working with voltage above 30V ac rms, 42V peak, or 60V dc. Such voltages
pose a shock hazard.
When using the probes, keep your fingers behind the finger guards on the probes.
When making connections, connect the black test lead before you connect the red test lead.
When you disconnect test leads, disconnect the red test lead first.
Remove the test leads from the circuit under test before you open the back cover.
Do not operate the meter with the back cover removed or loosened.
To avoid false readings, which could lead to possible electric shock or personal injury, replace
the button cells as soon as the low battery indicator ( ) appears.
To avoid electric shock, do not touch any naked conductor with your hand or skin, and do not
ground yourself while using the meter.
Remaining endangerment:
When a probe is connected to dangerous live potential, it is to be noted that this potential can
occur at the other probe!
CAT II - Measurement Category II is for measurements performed on circuits directly
connected to low voltage installation. ( Examples are measurements on household appliances,
portable tools and similar equipments. )
Do not use the meter for measurements within Measurement Categories III and IV.
●
●
●
●
●
●
●
●
●
-2-

DY03001 Users Manual
Caution
To avoid possible damage to the meter or to the equipment under test, follow these guidelines:
Disconnect circuit power and discharge all capacitors before testing resistance,
diode or continuity.
Use the proper function for your measurements.
Before measuring current, check the meter's fuse and turn off power to the circuit before
connecting the meter to the circuit.
Before moving the function switch or rotating the range switch, disconnect the test leads from
the circuit under test.
●
●
●
●
-3-
Electrical Symbols
Direct Current
Alternating Current
Both direct and alternating current
Caution, risk of electric shock.
Caution, risk of danger, refer to the
operating manual before use.
Earth (ground) Terminal
Fuse
Conforms to European Union directives
The equipment is protected throughout by
double insulation or reinforced insulation.

DY03001 Users Manual
1. Display
3 1/2-digit LCD, with a max. reading of 1999
2. Function Switch
Used to select desired function.
3. Range Switch
Used to select desired range as wel as to turn
on or off the meter. Set this range switch to the "
OFF " position when the meter is not in use.
4. Test Probes
-4-
Screen Introduction
DIGITAL MULTIMETER
MAX
MAX
300V
FUSED 200mA
OFF
300
2000
200
20
2
CAT II
1
2
3
4
