Chandeliers
chandeliers
208
Five Light
Chandelier
With frosted ribbed shades
76-693 Textured White
(5) 60W A19 max.
Dimensions: Width 22”,
Height18”,Chain 36”
Five Light
Chandelier
With frosted ribbed shades
76-694 Old Bronze
(5) 60W A19 max.
Dimensions: Width 22”,
Height18”,Chain 36”
Five Light
Chandelier
With frosted ribbed shades
76-695 Brushed Nickel
(5) 60W A19 max.
Dimensions: Width 22”,
Height18”,Chain 36”
Five Light
Chandelier
With clear ribbed shades
76-449 Textured White
(5) 60W A19 max.
Dimensions: Width 22”,
Height18”,Chain 36”
Five Light
Chandelier
With clear ribbed shades
76-445 Old Bronze
(5) 60W A19 max.
Dimensions: Width 22”,
Height18”,Chain 36”
Five Light
Chandelier
With clear ribbed shades
76-444 Brushed Nickel
(5) 60W A19 max.
Dimensions: Width 22”,
Height18”,Chain 36”
Five Light
Chandelier
With clear ribbed shades
76-281 Polished Brass
(5) 60W A19 max.
Dimensions: Width 22”,
Height18”,Chain 36”
Five Light
Chandelier
76-280 Polished Brass
(5) 60W Type B ,Cand Base max.
Dimensions: Width 18”,Height 14”,
Chain 36”
decorative
Chandeliers

prismatic
Pendants
pendants
209
Prismatic Dome
With clear ribbed glass
76-282 Polished Brass
(1) 100W A19 max.
Dimensions: Width 15”,
Height 101⁄2”,Chain 36”
Prismatic Dome
With frosted ribbed glass
76-690 Old Bronze
(1) 100W A19 max.
Dimensions: Width 15”,
Height 101⁄2”,Chain 36”
Prismatic Dome
With frosted ribbed glass
76-691 Brushed Nickel
(1) 100W A19 max.
Dimensions: Width 15”,
Height 101⁄2”,Chain 36”
Prismatic Dome
With clear ribbed glass
76-447 Old Bronze
(1) 100W A19 max.
Dimensions: Width 15”,
Height 101⁄2”,Chain 36”
Prismatic Dome
With clear ribbed glass
76-448 Textured White
(1) 100W A19 max.
Dimensions: Width 15”,
Height 101⁄2”,Chain 36”
Prismatic Dome
With clear ribbed glass
76-446 Brushed Nickel
(1) 100W A19 max.
Dimensions: Width 15”,
Height 101⁄2”,Chain 36”
Prismatic Railroad
Shade
76-262 8”Polished Brass
Dimensions: 8”,Height 71⁄2”,Chain 36”
76-263 12”Polished Brass
Dimensions: 12”,Height 8”,Chain 36”
76-264 15”Polished Brass
Dimensions: 15”,Height 91⁄2”,Chain 36”
(1) 100W A19 max.
Prismatic Dome
With frosted ribbed glass
76-692 Textured White
(1) 100W A19 max.
Dimensions: Width 15”,
Height 101⁄2”,Chain 36”
prismatic
Pendants

glass
Pendants
pendants
210
Alabaster Glass Hanging Dome
60-390 Brushed Nickel
(1) 100W A19 max.
Dimensions: Width 16”,Height 111⁄2”,Chain 48”
Alabaster Glass Hanging Dome
60-391 Old Bronze
(1) 100W A19 max.
Dimensions: Width 16”,Height 111⁄2”,Chain 48”
Alabaster Glass Hanging Dome
60-392 Polished Brass
(1) 100W A19 max.
Dimensions: Width 16”,Height 111⁄2”,Chain 48”
10”Prismatic Cone Shade
76-254 Polished Brass
(1) 100W A19 max.
Dimensions: Width 10”,Height 73⁄4”,Chain 36”
12”Prismatic Cone Shade
76-255 Polished Brass
(1) 100W A19 max.
Dimensions: Width 12”,Height 9”,Chain 36”
Alabaster Glass Hanging Dome
60-393 Textured White
(1) 100W A19 max.
Dimensions: Width 16”,Height 111⁄2”,Chain 48”
glass
Pendants

warehouse
shade
Pendants
pendants
211
Black Warehouse Shade
76-284
(1) 100W A19 max.
Dimensions: Width 16”,Height 81⁄8”,Cord 12”
White Warehouse Shade
76-283
(1) 100W A19 max.
Dimensions: Width 16”,Height 81⁄8”,Cord 12”
Green Warehouse Shade
76-660
(1) 100W A19 max.
Dimensions: Width 16”,Height 81⁄8”,Cord 12”
Old Bronze Warehouse Shade
76-662
(1) 100W A19 max.
Dimensions: Width 16”,Height 81⁄8”,Cord 12”
Red Warehouse Shade
76-663
(1) 100W A19 max.
Dimensions: Width 16”,Height 81⁄8”,Cord 12”
Brushed Nickel Warehouse Shade
76-661
(1) 100W A19 max.
Dimensions: Width 16”,Height 81⁄8”,Cord 12”
warehouse
shade Pendants

foyer
Hall/Bedroom
foyer/hall/bedroom
212
11”Semi–flush
60-200 Brushed Nickel
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 12”
11”Flush
60-197 Brushed Nickel
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 47⁄8”
13”Semi–flush
60-201 Brushed Nickel
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 131⁄4”,
Height 14”
15”Semi–flush
60-202 Brushed Nickel
with Alabaster Glass
(3) 60W A19 max.
Dimensions: Width 151⁄4”,
Height 151⁄2”
15”Flush
60-199 Brushed Nickel
with Alabaster Glass
(3) 60W A19 max.
Dimensions:
Width 151⁄4”,
Height 6”
13”Flush
60-198 Brushed Nickel
with Alabaster Glass
(2) 60W A19 max.
Dimensions:
Width 131⁄8”,
Height 53⁄8”
foyer
Hall/Bedroom

foyer
Hall/Bedroom
foyer/hall/bedroom
213
11”Semi–flush
60-216 Polished Brass
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 12”
11”Flush
60-213 Polished Brass
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 47⁄8”
13”Semi–flush
60-217 Polished Brass
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 131⁄4”,
Height 14”
15”Semi–flush
60-218 Polished Brass
with Alabaster Glass
(3) 60W A19 max.
Dimensions: Width 151⁄4”,
Height 151⁄2”
15”Flush
60-215 Polished Brass
with Alabaster Glass
(3) 60W A19 max.
Dimensions:
Width 151⁄4”,
Height 6”
13”Flush
60-214 Polished Brass
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 131⁄8”,
Height 53⁄8”
foyer
Hall/Bedroom

foyer
Hall/Bedroom
foyer/hall/bedroom
214
11”Semi–flush
60-208 Old Bronze
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 12”
11”Flush
60-205 Old Bronze
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 47⁄8”
13”Semi–flush
60-209 Old Bronze
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 131⁄4”,
Height 14”
15”Semi–flush
60-210 Old Bronze
with Alabaster Glass
(3) 60W A19 max.
Dimensions: Width 151⁄4”,
Height 151⁄2”
15”Flush
60-207 Old Bronze
with Alabaster Glass
(3) 60W A19 max.
Dimensions: Width 151⁄4”,
Height 6”
13”Flush
60-206 Old Bronze
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 131⁄8”,
Height 53⁄8”
foyer
Hall/Bedroom

foyer
Hall/Bedroom
foyer/hall/bedroom
215
11”Semi–flush
60-224 Textured White
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 12”
11”Flush
60-221 Textured White
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 47⁄8”
13”Semi–flush
60-225 Textured White
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 131⁄4”,
Height 14”
15”Semi–flush
60-226 Textured White
with Alabaster Glass
(3) 60W A19 max.
Dimensions: Width 151⁄4”,
Height 151⁄2”
15”Flush
60-223 Textured White
with Alabaster Glass
(3) 60W A19 max.
Dimensions: Width 151⁄4”,
Height 6”
13”Flush
60-222 Textured White
with Alabaster Glass
(2) 60W A19 max.
Dimensions: Width 131⁄8”,
Height 53⁄8”
foyer
Hall/Bedroom

foyer
Hall/Bedroom
foyer/hall/bedroom
216
11”Semi–flush
60-232 Antique Brass
with Clear Swirl Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 12”
11”Flush
60-229 Antique Brass
with Clear Swirl Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 47⁄8”
13”Semi–flush
60-233 Antique Brass
with Clear Swirl Glass
(2) 60W A19 max.
Dimensions: Width 131⁄4”,
Height 14”
15”Semi–flush
60-234 Antique Brass
with Clear Swirl Glass
(3) 60W A19 max.
Dimensions: Width 151⁄4”,
Height 151⁄2”
15”Flush
60-231 Antique Brass
with Clear Swirl Glass
(3) 60W A19 max.
Dimensions: Width 151⁄4”,
Height 53⁄4”
13”Flush
60-230 Antique Brass
with Clear Swirl Glass
(2) 60W A19 max.
Dimensions: Width 131⁄8”,
Height 53⁄8”
See Pages 222 and 223
for More Swirl Glass
Flush Dome Fixtures
foyer
Hall/Bedroom

foyer
Hall/Bedroom
foyer/hall/bedroom
217
11”Semi–flush
60-240 Antique Brass
with Frosted Swirl Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 12”
11”Flush
60-237 Antique Brass
with Frosted Swirl Glass
(2) 60W A19 max.
Dimensions: Width 113⁄8”,
Height 47⁄8”
13”Semi–flush
60-241 Antique Brass
with Frosted Swirl Glass
(2) 60W A19 max.
Dimensions: Width 131⁄4”,
Height 14”
15”Semi–flush
60-242 Antique Brass
with Frosted Swirl Glass
(3) 60W A19 max.
Dimensions: Width 151⁄4”,
Height 151⁄2”
15”Flush
60-239 Antique Brass
with Frosted Swirl Glass
(3) 60W A19 max.
Dimensions: Width 151⁄4”,
Height 53⁄4”
13”Flush
60-238 Antique Brass
with Frosted Swirl Glass
(2) 60W A19 max.
Dimensions: Width 131⁄8”,
Height 53⁄8”
