Satco Products Fluorescent Ballasts Manual

Fluorescent
Ballasts

Ballasts
135
ballasts
Have a special requirement? Visit our website at www.satco.com
Electronic Ballasts
T2 Subminiature, Programmed Start, < 15% THD, Universal Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
FM13 1 / 2 120/277 S5246 SQT-FM 50 Wiretap Connectors
Listed for 1 or 2 FM6, FM8, FM11, FM13 Lamp(s)
T5 Programmed Start, < 10% THD, Universal Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
FP28T5
1 120/277 S5221 SQTP1X28T5/UNIV/PSN/NL 20 Wiretap Connectors
2 120/277 S5222 SQTP2X28T5/UNIV/PSN/NL 20 Wiretap Connectors
Listed for FP14, FP21, FP28, FP35
T5HO Programmed Start, < 10% THD, Universal Voltage Ballasts
Primary
Lamp
TypePrp
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
FP24T5
1 120/277 S5214 SQTP1X39/24T5HO/UNV/PSN/NL 20 Wiretap Connectors
2 120/277 S5215 SQTP2X39/24T5HO/UNV/PSN/NL 20 Wiretap Connectors
Listed for FPC22T5, FP24T5HO, FT24DL, CF24DF, FT36DL, CF36DL, FP39T5HO, FPC40T5
FP54T5
1 120/277
S5218
SQTP1X54T5HO/UNV/PSN/NL 20 Wiretap Connectors
2 120/277
S5219
SQTP2X54T5HO/UNV/PSN/NL 20 Wiretap Connectors
Listed for FP54T5/HO, FT55DL, FPC55
FP80T5
1 120/277 S5220 SQTP1X80T5HO/UNV/PSN/NL 20 Wiretap Connectors
Listed for FP80T5/HO, FT80DL

Ballasts
ballasts
136
Customer Service 1-800-43-SATCO
Electronic Ballasts
T8 Instant Start, Standard <20% THD, Dedicated Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
F32T8 1 120v S6623 SQT1X32T8/120/ISN/SC 10 Leads
277v S6633 SQT1X32T8/277/ISN/SC 10 Leads
2 120v S6624 SQT2X32T8/120/ISN/SC 10 Leads
277v S6634 SQT2X32T8/277/ISN/SC 10 Leads
3 120v S6625 SQT3X32T8/120/ISN/SC 10 Leads
277v S6635 SQT3X32T8/277/ISN/SC 10 Leads
4 120v S6626 SQT4X32T8/120/ISN/SC 10 Leads
277v S6636 SQT4X32T8/277/ISN/SC 10 Leads
Listed for FBO16, FO17, FBO24, FO25, FBO31, FO32, FBO32, FO40 & SS Equivalents
Can operate 1 lamp on 2 lamp ballast, 2 lamps on 3 lamp ballast, 3 lamps on 4 lamp ballast
For F40T8 operation use 1 lamp on a 2 lamp ballast, 2 lamps on a 3 lamp ballast,
or 3 lamps on a 4 lamp ballast
T8 Instant Start, Professional <10% THD, Universal Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
F32T8 1 120/277 S5207 SQTP1X32T8/UNIV/ISN/SC 10 Leads
2 120/277 S5208 SQTP2X32T8/UNIV/ISN/SC 10 Leads
3 120/277 S5209 SQTP3X32T8/UNIV/ISN/SC 10 Leads
4 120/277 S5210 SQTP4X32T8/UNIV/ISN/SC 10 Leads
Listed for FBO16, FO17, FBO24, FO25, FBO31, FO32, FBO32, FO40 & SS Equivalents
Can operate 1 lamp on 2 lamp ballast, 2 lamps on 3 lamp ballast, 3 lamps on 4 lamp ballast
For F40T8 operation use 1 lamp on a 2 lamp ballast, 2 lamps on a 3 lamp ballast, or 3 lamps
on a 4 lamp ballast
T8 Programmed (Rapid) Start, Professional <10% THD, Universal Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
F32T8 1 120/277 S5286 SQTP1X32T8/UNIV/PSN/TC 10 Leads
2 120/277 S5287 SQTP2X32T8/UNIV/PSN/TC 10 Leads
3 120/277 S5288 SQTP3X32T8/UNIV/PSN/SC 10 Leads
4 120/277 S5289 SQTP4X32T8/UNIV/PSN/SC 10 Leads
Listed for FBO16, FO17, FBO24, FO25, FBO31, FO32, FBO32 & SS Equivalents
Can operate 1 lamp on 2 lamp ballast, 2 lamps on 3 lamp ballast, 3 lamps on 4 lamp ballast

Ballasts
137
ballasts
Have a special requirement? Visit our website at www.satco.com
Electronic Ballasts
T8 Instant Start, Standard <20% THD, Dedicated Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
F96T8 2 120v S5211 SQT2X59/120/IS 10 Leads
2 277v S5212 SQT2X59/277/IS 10 Leads
Listed for FO96T8 and SS equivalents
Can operate 1 lamp on 2 lamp ballast
T8 Instant Start, Professional <10% THD, Universal Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
F96T8 2 120/277 S5213 SQT2X59T8/UNIV/ISN/SC 10 Leads
Listed for FO96T8 and SS equivalents
Can operate 1 lamp on 2 lamp ballast
T12 Rapid Start, < 10% THD, Dedicated Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
F40T12
1 120 S5258 SQTP1X40T12/120/RSN B 20 Leads
277 S5259 SQTP1X40T12/277/RSN B 20 Leads
2 120 S5260 SQTP2X40T12/120/RSN B 20 Leads
277 S5261 SQTP2X40T12/277/RSN B 20 Leads
3 120 S5262 SQTP3X40T12/120/RSN B 20 Leads
277 S5263 SQTP3X40T12/277/RSN B 20 Leads
Listed for F34T12, FB34T12, F40T12, FB40T12, F40T10
FT40DL Instant Start, <20%THD, Dedicated Voltage Ballasts
Primary
Lamp
Type
No of
Lamps Input Voltage
Satco
Product
Number Ballast Code Pkg Qty Wiring Method
FT40DL
1 120 S5240 SQT1X40/120/DL 10 Leads
2 277 S5241 SQT1X40/277/DL 10 Leads
1 120 S5242 SQT2X40/120/DL 10 Leads
2 277 S5243 SQT2X40/277/DL 10 Leads
1 120 S5244 SQT3X40/120/DL 10 Leads
2 277 S5245 SQT3X40/277/DL 10 Leads

Ballasts
ballasts
138
Customer Service 1-800-43-SATCO
Electronic Ballasts
Compact Fluorescent Programmed Start, <10%THD, Universal Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
CF13 1 / 2 120/277 S5223 SQTP1/2X13CF/UNV/BS 20 Wiretap Connectors
S5225 SQTP1/2X13CF/UNV/TS 20 Wiretap Connectors
Listed for 1 or 2 CF13DD/E or CF13DT/E lamp(s)
CF18 1 / 2 120/277 S5226 SQTP1/2X18CF/UNV/BS 20 Wiretap Connectors
S5228 SQTP1/2X18CF/UNV/TS 20 Wiretap Connectors
Listed for 1 or 2 CF18DD/E or CF18DT/E Lamp(s)
CF26 1 / 2 120/277 S5229 SQTP1/2X26CF/UNV/BS 20 Wiretap Connectors
S5231 SQTP1/2X26CF/UNV/TS 20 Wiretap Connectors
Listed for 1 or 2 CF26DD/E, CF26DT/E, FPC22T5, FT24DL, CF24DF Lamp(s)
Also Listed for 1 ea CF32DT/E, CF42DT/E, F28/2D, F38/2D, FPC40T5, FT40DL Lamp
Also Listed for 2 ea CF13DS/E, FT18DL/RS, CF18DF, F21/2D Lamps
CF26 1 / 2 120/277 S5232 SQTP1/2CF/UNV/BM 20 Wiretap Connectors
S5233 SQTP1/2CF/UNV/PM 18 Wiretap Connectors
S5234 SQTP1/2CF/UNV/TM 18 Wiretap Connectors
Listed for 1 or 2 CF26DD/E or CF26DT/E Lamp(s)
Also Listed for 1 ea CF32DT/E or CF42DT/E
CF26 2 120/277 S5235 SQTP2X26/32/42CF/UNV/BM 20 Wiretap Connectors
S5236 SQTP2X26/32/42CF/UNV/PM 18 Wiretap Connectors
S5237 SQTP2X26/32/42CF/UNV/TM 18 Wiretap Connectors
Listed for 2 ea CF26DT/E, CF32DT/E, CF42DT/E, FT36DL, FT40DL, FPC40T5 Lamps
Also Listed for 1 ea FPC22T5 plus FPC40T5 Lamps (must use both lamps together)
CF57 1 120/277 S5238 SQTP1X57CF/UNV/BM 20 Wiretap Connectors
S5239 SQTP1X57CF/UNV/PM 18 Wiretap Connectors
Listed for 1 ea CF57DT/E or CF70DT/E Lamp
Plastic Enclosure Styles (S)
BS = Bottom Mount for
recessed downlight
fixtures
TS = Top Mount for
ceiling and wall
sconce installation
Metal Enclosure Styles (S)
BM = Bottom Mount for
recessed downlight
fixtures
PM = Bottom Mount with
PEM studs for recessed
downlight fixtures
TM = Top Mount with PEM
studs for ceiling and
wall sconce installation

Ballasts
139
ballasts
Have a special requirement? Visit our website at www.satco.com
Electronic Ballasts
T4 4-Pin CF-L Socket and Electronic Ballast Combination
Featuring New TwistLock Protection
Lamp
Wattage(s)
Satco
Product
Number MOL MOD Finish
Master /
Inner Pack
Mounting
Method
Wire
Spec
Lead
Length
13 80/1384
Short 13 Watt Socket 2.12” 2.00” x 2.37” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1325
Standard 13 Watt Socket 3.00” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1405
Standard 13 Watt Socket 2.37” 1.75” Ivory 200/25 Rt Angle Snap In UL1015 24”
80/1335
13 Watt Socket With Uno Ring 1.88” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
C-UL Listed for Indoor/Outdoor applications Minimum Starting Temp -20 C / -4 F
18 80/1385
Short 18 Watt Socket 2.12” 2.00” x 2.37” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1324
Standard 18 Watt Socket 3.00” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1406
Standard 18 Watt Socket 2.37” 1.75” Ivory 200/25 Rt Angle Snap In UL1015 24”
80/1336
18 Watt Socket With Uno Ring 1.88” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
C-UL Listed for Indoor/Outdoor applications Minimum Starting Temp -20 C / -4 F
26 80/1386
Short 26 Watt Socket 2.12” 2.00” x 2.37” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1383
Standard 26 Watt Socket 3.00” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1382
26 Watt Socket With Uno Ring 1.88” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
C-UL Listed for Indoor/Outdoor applications Minimum Starting Temp -20 C / -4 F
26-32-42 80/1323
26/32/42 Watt Socket 3.12” 2.50” Ivory 200/25 1/8” IPS Hickey UL1015 24”
C-UL Listed for Indoor/Outdoor applications Minimum Starting Temp -20 C / -4 F
26 - 32 80/1331
26W/32W Dimmer Socket 3.25” 3.75” Ivory 50/25 1/8” IPS Hickey UL1015 36”
C-UL Listed for indoor applicatons
Dimmer sockets are for Table and Floor Lamp Applications Only
Dimmer Control, and Harp Saddle are integral to the socket
120v 60Hz operation
3 Year Warranty
(Replacement only)

Ballasts
ballasts
140
Customer Service 1-800-43-SATCO
Magnetic Ballasts
T8 and T12 Preheat / Trigger Start Ballasts
Primary
Lamp Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Starting
Method Potted
F15T12
1 120 S5268 SMB1X15/120PH/TP 16 Trigger Start Yes
F20T12
1 120 S5269 SMB1X20/120PH/TP 40 Preheat Yes
S5270 SMB1X20/120PH/TP 40 Preheat No
2 120 S5271 SMB2X20/120PH/TP 16 Trigger Start Yes
Listed for F14T8, F14T12, F15T8, F15T12, F20T12 Lamps
Preheat ballasts require the use of a starter
Trigger start ballasts eliminate the need for a starter
T9 Circline Rapid Start Ballasts
Primary
Lamp Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Sound
Rating
Power
Factor
FC8T9
1 120 S5273 SMB1X22/120CIRC 16 Class A NPF
FC12T9
1 120 S5272 SMB1X32/120CIRC 16 Class A NPF
Listed for FC12T9 and FC16T9 Lamps
T12 Rapid Start Ballasts
Primary
Lamp Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Sound
Rating
Power
Factor
F30T12
2 120 need # SMB2X30/120RS/SRNK 10 Class A HPF
277 need # SMB2X30/277RS/SRNK 10 Class A HPF
Listed for F25T12/SS and F30T12 Lamps

Ballasts
141
ballasts
Have a special requirement? Visit our website at www.satco.com
Magnetic Ballasts
T12 Rapid Start Ballasts (cont.)
Primary
Lamp Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Sound
Rating
Power
Factor
F34T12
1 120 S5274 SMB1X40/120RS/SRNK 10 Class A HPF
277 S5275 SMB1X40/277RS/SRNK 10 Class A HPF
Listed for F25T12/SS, F30T12, F34T12, FB34T12, F40T10, F40T12, FB40T12 Lamps
F34T12
2 120 S6620 SMB2X40/120RS/SRNK 10 Class A HPF
277 S6622 SMB2X40/277RS/SRNK 10 Class A HPF
Listed for F34T12, FB34T12, F40T10, F40T12, FB40T12 Lamps
F40T12
1 120 S5276 SMB1X40/120RES/SRNK 16 Class A NPF
Listed for F40T12 FULL WATTAGE ONLY - Residential Application
T12 Instant Start Slimline Ballasts
Primary
Lamp Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Sound
Rating
Power
Factor
F48T12 2 120 S5277 SMB2X48/120IS-SRNK 6 Class B HPF
277 S5278 SMB2X48/277IS-SRNK 6 Class B HPF
Listed for F48T12/SS and F48T12 Lamps
F96T12 1 120 S5279 SMB1X96/120IS-SRNK 6 Class B HPF
277 S5280 SMB1X96/277IR-SRNK 6 Class B HPF
2 120 S6621 SMB2X96/120IS-SRNK 6 Class B HPF
277 S5281 SMB2X96/277IS-SRNK 6 Class B HPF
Listed for F60T12, F64T12, F72T12, F84T12, F96T12/SS, and F96T12 Lamps

Ballasts
ballasts
142
Customer Service 1-800-43-SATCO
Magnetic Ballasts
T12 HO (800mA) Rapid Start Ballasts
Primary
Lamp Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Sound
Rating
Power
Factor
F96T12/HO
1 120 S5282 SMB1X96HO/120RS-SRNK 4 Class C HPF
277 S5283 SMB1X96HO/277RS-SRNK 4 Class C HPF
2 120 S5284 SMB2X96HO/120RS-SRNK 4 Class C HPF
277 S5285 SMB2X96HO/277RS-SRNK 4 Class C HPF
Listed for all T12 HO Lamps 18” through 96”
F18T12, F24T12, F30T12, F42T12, F48T12/SS, F48T12, F60T12, F64T12, F72T12, F84T12,
F96T12/SS, F96T12/CT, F96T12
T12 HO (800mA) Rapid Start Sign Ballasts
Primary
Lamp Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty Total Lamp Length
T12/RS/HO
1-2 120 S5290 SMSB-12-0412-TP 1 4ft to 12ft
2-4 120 S5291 SMSB-24-0620-TP 1 6ft to 20ft
S5292 SMSB-24-1224-TP 1 12ft to 24ft
S5293 SMSB-24-2040-TP 1 20ft to 40ft
4-6 120 S5294 SMSB-46-1240-TP 1 12ft to 40ft
S5295 SMSB-46-2448-TP 1 24ft to 48ft
Listed for all T12 HO Lamps 18” through 120”, as long as they fall within the quantity of lamps
and lamp length requirements listed
T12 VHO (1500mA) Rapid Start Ballasts
Primary
Lamp Type
No of
Lamps
Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Sound
Rating
Power
Factor
F96T12/VHO
1 120V S5264 SMB1X96VHO/120RS-SRNK 4 Class D HPF
277V S5265 SMB1X96VHO/277RS-SRNK 4 Class D HPF
120V S5266 SMB2X96VHO/120RS-SRNK 4 Class D HPF
277V S5267 SMB2X96VHO/277RS-SRNK 4 Class D HPF
Listed for F48T12/VHO, F60T12/VHO, F72T12/VHO, F96T12/VHO/SS, F96T12/VHO
