Satco Products R20 Soft Square Manual

track
Heads
track heads
274
R30 Step Cylinder
TH206 White
TH207 Black
TH304 Brushed Nickel
(1) R30/PAR30 75W max.
(Long Neck)
Dimensions: Height 61⁄2”,
Width 41⁄2”,Extension 81⁄2”
R20 Step Cylinder
TH204 White
TH205 Black
TH303 Brushed Nickel
(1) R20/PAR20 50W max.
Dimensions: Height 51⁄4”,
Width 31⁄2”,Extension 71⁄2”
R30 Soft Square
TH214 White
TH215 Black
(1) R30/PAR30 75W max.
(Long Neck)
Dimensions: Height 7”,
Width 41⁄2”,Extension 91⁄2”
R20 Soft Square
TH212 White
TH213 Black
(1) R20/PAR20 50W max.
Dimensions: Height 6”,
Width 31⁄2”,Extension 8”
track
Heads

track
Heads
track heads
275
R20 Straight Cylinder
TH200 White
TH201 Black
TH307 Brushed Nickel
(1) R20/PAR20 50W max.
Dimensions: Height 61⁄2”,
Width 41⁄4”,Extension 91⁄2”
R30 Straight Cylinder
TH202 White
TH203 Black
TH308 Brushed Nickel
(1) R30/PAR30 75W max.
(Long Neck)
Dimensions: Height 7”,
Width 41⁄2”,Extension 91⁄2”
R20 Bullet Cylinder
TH208 White
TH209 Black
TH305 Brushed Nickel
(1) R20/PAR20 50W max.
Dimensions: Height 7”,
Width 41⁄2”,Extension 91⁄2”
R30 Bullet Cylinder
TH210 White
TH211 Black
TH306 Brushed Nickel
(1) R30/PAR30 75W max.
(Long Neck)
Dimensions: Height 7”,
Width 41⁄2”,Extension 91⁄2”
track
Heads

track
Heads
track heads
276
PAR38 Gimbal Ring
TH224 White
TH225 Black
TH302 Brushed Nickel
(1) PAR38 150W max.
Dimensions : Height 61⁄4”,
Width 5”,Extension 101⁄2”
PAR30 Gimbal Ring
TH222 White
TH223 Black
TH301 Brushed Nickel
(1) PAR30 75W max.(Short Neck)
Dimensions: Height 43⁄4”,
Width 4”,Extension 101⁄2”
PAR30 Short Bullet
Cylinder
TH218 White
TH219 Black
(1) PAR30 75W max.(Short Neck)
Dimensions: Height 51⁄4”,
Width 41⁄2”,Extension 8”
PAR20 Short Bullet
Cylinder
TH216 White
TH217 Black
(1) PAR20 50W max.
Dimensions: Height 41⁄2”,
Width 31⁄2”,Extension 7”
PAR20 Gimbal Ring
TH220 White
TH221 Black
TH300 Brushed Nickel
(1) PAR20 50W max.
Dimensions: Height 41⁄2”,
Width 23⁄4”,Extension 63⁄4”
track
Heads

MR16 Round
TH234 White
TH235 Black
TH309 Brushed Nickel
(1) 50W MR16 12V max.
Dimensions: Height 31⁄4”,
Width 21⁄4”,Extension 61⁄2”
12V track
Heads
12V track heads
277
MR16 Roundback
TH236 White
TH237 Black
TH327 Brushed Nickel
(1) 50W MR16 12V max.
Dimensions: Height 31⁄4”,
Width 21⁄4”,Extension 61⁄2”
MR11 Mini Square
TH269 White
TH270 Black
(1) 35W MR11 12V max.
Dimensions: Height 21⁄4”,
Width 11⁄2”,Extension 51⁄2”
MR11 Mini Round
TH267 White
TH268 Black
(1) 35W MR11 12V max.
Dimensions: Height 31⁄4”,
Width 21⁄4”,Extension 61⁄2”
MR16 Cast Ring
TH259 White
TH260 Black
TH328 Brushed Nickel
(1) MR16 50W max.
Dimensions: Height 4”,
Width 21⁄4”,Extension 61⁄2”
MR16 Square
TH232 White
TH233 Black
TH310 Brushed Nickel
(1) 50W MR16 12V max.
Dimensions: Height 31⁄4”,
Width 21⁄4”,Extension 61⁄2”
MR16 Gimbal Ring
TH238 White
TH239 Black
TH311 Brushed Nickel
(1) MR16 50W 12V max.
Dimensions: Height 21⁄4”,
Width 2”,Extension 41⁄2”
PAR36 Gimbal Ring
TH271 White
TH272 Black
(1) 50W PAR36 12V max.
Dimensions: Height 3”,
Width 41⁄4”,Extension 7”
12V track
Heads

120V
Track Heads
120V track heads
278
MR16 Square
TH312 White
(1) 50W MR16 / GU10 base 120V max.
Dimensions: Height 31⁄4”,
Width 21⁄4”,Extension 61⁄2”
MR16 Roundback
TH315 White
(1) 50W MR16 / GU10 base 120V max.
Dimensions: Height 31⁄4”,
Width 21⁄4”,Extension 61⁄2”
MR16 Gimbal Ring
TH321 White
(1) 50W MR16 / GU10 base 120V max.
Dimensions: Height 21⁄4”,
Width 2”,Extension 41⁄2”
MR16 Square
TH313 Black
(1) 50W MR16 / GU10 base 120V max.
Dimensions: Height 31⁄4”,
Width 21⁄4”,Extension 61⁄2”
MR16 Roundback
TH316 Black
(1) 50W MR16 / GU10 base 120V max.
Dimensions: Height 31⁄4”,
Width 21⁄4”,Extension 61⁄2”
MR16 Gimbal Ring
TH322 Black
(1) 50W MR16 / GU10 base 120V max.
Dimensions: Height 21⁄4”,
Width 2”,Extension 41⁄2”
MR16 Square
TH314 Brushed Nickel
(1) 50W MR16 / GU10 base 120V max.
Dimensions: Height 31⁄4”,
Width 21⁄4”,Extension 61⁄2”
MR16 Roundback
TH317 Brushed Nickel
(1) 50W MR16 / GU10 base 120V max.
Dimensions: Height 31⁄4”,
Width 21⁄4”,Extension 61⁄2”
MR16 Gimbal Ring
TH323 Brushed Nickel
(1) 50W MR16 / GU10 base 120V max.
Dimensions: Height 21⁄4”,
Width 2”,Extension 41⁄2”
120V
Track Heads

track
Heads
track heads
279
Power Flood
with Barndoor
TH228 White
TH229 Black
(1) 150W J Type 78MM
(Short) max.
Dimensions: Height 23⁄4”,
Width 5X23⁄4”, Extension 41⁄2”
R40 Step Cylinder
TH281 White
TH282 Black
(1) 150W BR40/
PAR38/BR38 max.
Dimensions: Height 8”,
Width 51⁄2”,Extension 11”
Snake–Flexible
Gooseneck
TH273 White
TH274 Black
(1) 50W MR16 12V. max.
Dimensions: Height 22”,
Width 21⁄4”
R40 Straight Cylinder
TH283 White
TH284 Black
(1) 150W BR40/
PAR38/BR38 max.
Dimensions: Height 8”,
Width 51⁄2”,Extension 12”
track
Heads

universal
Holders
universal holders
280
Universal Holder Lamping Suggestions
R20
PAR20 PAR30 PAR38
BR30 BR40
Mini Universal
Holder
TH279 White
TH280 Black
(1) R20/BR30/BR40/PAR20
/PAR30/PAR38 150W.max.
Dimensions: Height 23⁄4”Width 2”,
Extension 6”(without lamp)
Universal Holder
TH226 White
TH227 Black
TH324 Brushed Nickel
(1) R20/BR30/BR40/PAR20
/PAR30/PAR38 150W.max.
Dimensions: Height 43⁄4”Width 2”,
Extension 7”(without lamp)
universal
Holders

track lighting
Accessories
track lighting accessories
281
POWER FEEDS
CONNECTORS
Mini Straight Connector
TP144 White
TP145 Black
Connects tracks in a straight run.
“L” Connector
TP146 White
TP147 Black
Connects tracks at a 90˚ angle.
“X”Connector
TP150 White
TP151 Black
Connects four tracks together
in an“X” shape pattern.
Flexible Connector
TP167 White
TP168 Black
Variable angle connector.
“T”Connector
TP148 White
TP149 Black
Connects three tracks together in
a“T” shape pattern.
Inline Feed
TP171 White
TP172 Black
Live End Cord Kit
TP156 White
TP157 Black
Electrifies the track from the end of the
run supplied with 15’ of two conductor
wire and line switch.
Live End Cord Kit
TP154 White
TP155 Black
Electrifies the track anywhere along
the length of the run.
Conduit Live End
TP169 White
TP170 Black
Electrifies the track from the end
of the run to a conduit pipe.
Live End & Canopy
TP152 White
TP153 Black
Electrifies the track from the end
of the run.
track lighting
Accessories
Self
Grounding
3 Conductor
System

track Lighting
Accessories
track lighting accessories
282
White Baffle
TP180 R20 Size
TP181 R30 Size
Pendant
Suspension Kit
24" TP178 White
TP179 Black
Kit Includes:
Canopy,Stem,
Support & Power
Feed Acsessories
Monopoint Adapter
Offset Monopoint
Adapter
TP176 White
TP177 Black
Offset monopoint
for low voltage track heads.
Monopoint Adapter
TP142 White
TP143 Black
Individually mounts a single
track head to a junction box.
Note: Not for use with low voltage
track heads.
Extensions
18” TP159 White
TP163 Black
24” TP160 White
TP164 Black
36” TP161 White
TP165 Black
48” TP162 White
TP166 Black
Lowers track heads
to desired length.
Tracks
2’ TR118 White
TR119 Black
TR126 Brushed Nickel
4’ TR120 White
TR121 Black
TR127 Brushed Nickel
6’ TR124 White
TR125 Black
TR128 Brushed Nickel
8’ TR122 White
TR123 Black
TR129 Brushed Nickel
All tracks include two
dead end caps and
mounting hardware.
15⁄16”•
•
•
5⁄8”
•
track Lighting
Accessories

track lighting
Kits
track lighting kits
283
All track
kits supplied
with floating
canopy kit
•(1) Four foot track
•(3) Track lighting heads
•(1) Floating power feed canopy
•All necessary mounting hardware
•Four color display carton
ALL TRACK KITS INCLUDE:
PAR30 Gimbal Ring
TK316 White
(3) PAR30 (shortneck) 75W max.
PAR30 Gimbal Ring
TK317 Black
(3) PAR30 (shortneck) 75W max.
PAR30 Gimbal Ring
TK343 Brushed Nickel
(3) PAR30 (shortneck) 75W max.
R30 Straight Cylinder
TK318 White
(3) R30/PAR30 (longneck) 75W max.
R30 Straight Cylinder
TK319 Black
(3) R30/PAR30 (longneck) 75W max.
R30 Straight Cylinder
TK341 Brushed Nickel
(3) R30/PAR30 (longneck) 75W max.
R30 Step Cylinder
TK320 White
(3) R30/PAR30 (longneck) 75W max.
R30 Step Cylinder
TK321 Black
(3) R30/PAR30 (longneck) 75W max.
R30 Step Cylinder
TK340 Brushed Nickel
(3) R30/PAR30 (longneck) 75W max.
R30 Bullet Cylinder
TK322 White
(3) R30/PAR30 (longneck) 75W max.
R30 Bullet Cylinder
TK323 Black
(3) R30/PAR30 (longneck) 75W max.
R30 Bullet Cylinder
TK342 Brushed Nickel
(3) R30/PAR30 (longneck) 75W max.
track lighting
Kits
