Sauder 415700 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Nice wheels.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-9
Français pg 10-11
Español pg 12-13
Lot # 356870 11/15/13
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Utility Cart
415700

Table of Contents Assembly Tools Required
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
2
3
4-9
10-11
12-13
14
15
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Part Identification
A END(2)
B TOP (1)
C BOTTOM (1)
D SHELF (1)
E SKIRT (2)
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A
A
B
C
D
E
E
415700 www.sauder.com/servicesPage 2

åScrews are shown actual size. You may receive extra hardware with your unit.
Hardware Identification
ANGLE BRACKET - 2
5G
BROWN 7/16" LARGE HEAD SCREW - 18
6S BROWN 1-1/2" FLAT HEAD SCREW - 12 14S
SCREW COVER - 8
20P
HIDDEN CAM - 4
1F
CAM DOWEL - 4
2F
415700www.sauder.com/services Page 3
SWIVEL CASTER - 2
8CS NONSWIVEL CASTER - 2 8CN

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push four HIDDEN CAMS (1F) into the ENDS (A). Then,
insert the metal end of a CAM DOWEL (2F) into each
HIDDEN CAM.
415700 www.sauder.com/servicesPage 4
Arrow
1F
2F
Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
A
A
(4 used)
(4 used)

å Fasten the ENDS (A) to the SHELF (D). Use four BROWN
1-1/2" FLAT HEAD SCREWS (14S).
Step 2
415700www.sauder.com/services Page 5
A
A
BROWN 1-1/2" FLAT HEAD SCREW
(4 used in this step)
14S
14S
D
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Unfinished surface

å Carefully stand your unit upside down. Fasten the
ENDS (A) to the TOP (B). Tighten four HIDDEN CAMS.
Step 3
415700 www.sauder.com/servicesPage 6
A
A
B
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Surface with holes

Step 4
415700www.sauder.com/services Page 7
A
A
B
å Fasten two ANGLE BRACKETS (5G) to the SKIRTS (E). Use
two BROWN 7/16" LARGE HEAD SCREWS (6S).
å NOTE: Be sure the edges of the ANGLE BRACKETS are
even with the edges of the SKIRTS.
å Fasten the SKIRTS (E) to the ENDS (A). Use four
BROWN 1-1/2" FLAT HEAD SCREWS (14S).
å Fasten the SKIRTS (E) to the TOP (B). Use two
BROWN 7/16" LARGE HEAD SCREWS (6S).
5G
E
E
E
E
The ANGLE BRACKETS
should be facing each other
and laying against the TOP (B).
BROWN 1-1/2" FLAT HEAD SCREW
(4 used in this step)
14S
14S
BROWN 7/16" LARGE HEAD SCREW
(4 used for the ANGLE BRACKETS)
6S

å Fasten two NON-SWIVEL CASTERS (8CN) to the front
corners of the BOTTOM (C). Use eight BROWN 7/16"
LARGE HEAD SCREWS (6S).
å Fasten two SWIVEL CASTERS (8CS) to the back
corners of the bottom. Use six BROWN 7/16" LARGE
HEAD SCREWS (6S).
å Fasten the BOTTOM (C) to the ENDS (A). Use four
BROWN 1-1/2" FLAT HEAD SCREWS (14S).
å NOTE: Two BROWN 1-1/2" FLAT HEAD SCREWS (14S)
will go through the SWIVEL CASTERS (8CS), through the
BOTTOM (C), and into the ENDS (A).
Step 5
415700 www.sauder.com/servicesPage 8
BROWN 7/16" LARGE HEAD SCREW
(14 used for the CASTERS)
6S
BROWN 1-1/2" FLAT HEAD SCREW
(4 used in this step)
14S
These edges
must be even.
8CN
8CN
8CS
8CS
C
C
A
A
Surface with
more holes
The tabs on the NON-SWIVEL
CASTERS must insert into these holes.
The wheel must be closer
to the long front edge.

Step 6
415700www.sauder.com/services Page 9
å Center a SCREW COVER (20P) over the head of each
SCREW and press firmly.
å NOTE: Please read the back pages of the instruction
booklet for important safety information.
å This completes assembly. Clean with your favorite furniture
polish or a damp cloth. Wipe dry.
And to celebrate, why not share your success story?
(8 used)
To cover screws
20P
20 lbs.
30 lbs.
40 lbs.

A l’usage exclusif du
Canada Noter la date
d’achat de cet élément
et conserver le livret
pour future référence.
Pour contacter Sauder
en ce qui concerne cet
élément, faire référence
au numéro de lot et
numéro de modèle en
appelant notre numéro
sans frais.
Lot nº : ____________
Date de
l’achat: ____________
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
NOUS SOMMES LA POUR VOUS AIDER!
Nous faisons de notre mieux pour nous assurer que votre meuble
arrive dans d’excellentes conditions. Nos représentants du service
Clientèle sont aimables et prêts à vous aider au cas où une pièce
aurait été endommagée ou manquerait (ou si vous aviez besoin
d’aide pour l’assemblage). NE RAMENEZ PAS LE MEUBLE AU
MAGASIN. Au Canada, composez ce numéro d’appel gratuit:
1-800-523-3987
Du lundi au vendredi, de 9 heures du matin à
5:30 heures du soir (horaire Côte Est)
(sauf jours fériés)
Si une pièce a besoin d’être remplacée, la pièce de remplacement
sera envoyée dans les 48 heures. (Sauf week-ends et jours fériés)
Utilisez les instructions d’assemblage en français avec les
schémas étape par étape du manuel d’instruction en anglais.
Chaque étape en français correspond à la même étape
en anglais. La pièce devant être attachée à l’élément est
représentée en gris sur les schémas de chaque étape pour plus
de précision. Comparer la “Liste de pièces” ci-dessous avec
la “PART IDENTIFICATION” du manuel en anglais pour vous
familiariser avec les pièces avant l’assemblage.
REMARQUE : CE MANUEL D’INSTRUCTIONS CONTIENT
D’IMPORTANTES INFORMATIONS RELATIVES À LA SÉCURITÉ.
À LIRE ET CONSERVER POUR TOUTE RÉFÉRENCE FUTURE.
8CS ROULETTE PIVOTANTE........................................2
8CN ROULETTE NON-PIVOTANTE..........................2
1F EXCENTRIQUE ESCAMOTABLE.....................4
2F CHEVILLE D'EXCENTRIQUE ..............................4
5G CONSOLE À ÉQUERRE.........................................2
20P CACHE-VIS ......................................................................8
6S VIS TÊTE LARGE 11 mm MARRON........... 18
14S VIS TÊTE PLATE 38 mm MARRON...........12
A EXTRÉMITÉ......................................................................2
B DESSUS...............................................................................1
C DESSOUS...........................................................................1
D TABLETTE..........................................................................1
E PLINTHE.............................................................................2
Desserte d'appoint415700
415700 www.sauder.com/servicesPage 10
