Save Phace Gen X User manual

Tactical Mask
TACTICAL-M0_062016
Mask, Lens Care, Lens Replacement and Headgear Assembly Instructions
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
!
© June 2016

2
THIS IS NOT TO BE USED FOR PAINTBALL
• Tactical masks are available, contact your reseller.
SAFETY AND GENERAL INFORMATION
• Failure to comply with the enclosed may result in injury or blindness.
• Materials which come into contact with the wearer’s skin could possibly cause allergic reactions
to susceptible individuals.
• Scratched or damaged oculars (lenses) should be replaced.
!
WARNING
NOTICE:
• PLEASE DON’T THROW AWAY THESE INSTRUCTIONS.
• THESE WARNINGS ARE VERY IMPORTANT TO YOUR SAFETY.
• FOLLOW ALL INSTRUCTION EXACTLY TO PROLONG THE LIFE OF YOUR COOL NEW SAVE
PHACE TACTICAL MASK! FAILURE TO DO SO MAY RESULT IN SERIOUS EYE INJURY OR
BLINDNESS.
• NEVER EVER REMOVE THE MASK WHEN YOU ARE IN OR NEAR AN AREA WHERE PAINT-
BALL MARKERS ARE BEING USED OR WHEN HANDLING A PAINTBALL MARKER (GUN).
• NEVER EVER REMOVE THE MASK WHILE PLAYING OR IN THE PLAYING AREA, EVEN IF
THE LENS FOGS OR GETS DIRTY.
• BEFORE EACH GAME, BREATHE ON THE INSIDE SURFACE OF YOUR LENS. IF IT FOGS
UP, AND BEFORE YOU USE YOUR MASK, REPLACE THE LENS OR USE OUR SAVE PHACE
ANTI FOG SOLUTION.
• USE ONLY THE SAVE PHACE APPROVED LENSES THAT HAVE BEEN DESIGNED FOR YOUR
SAVE PHACE TACTICAL MASK.
• CHECK THE LENS FOR PROPER INSTALLATION EACH TIME BEFORE PLAY.
• CHECK THE LENS BEFORE AND AFTER EACH USE.
• REPLACE THE LENS AFTER ONE YEAR, EVEN IF IT LOOKS OR SEEMS TO BE IN PERFECT
CONDITION.
• IMMEDIATELY REPLACE THE LENS IF IT SHOWS CRACKS.
• REPLACE THE LENS IMMEDIATELY IF IT HAS RECEIVED A DIRECT IMPACT FROM 10 FEET
(3m) OR LESS FROM A PAINTBALL.
• DO NOT MAKE ANY MODIFICATION TO YOUR MASK.
• THE RETENTION STRAP IS NOT AN EAR PROTECTOR AND SHOULD NOT BE USED AS
EAR PROTECTION.
• BEFORE PLAY, CHECK ALL MARKERS WITH A CHRONOGRAPH. ANY MARKER THAT
EXCEEDS 300 F.P.S. (91 M/S) SHOULD NOT BE USED FOR PLAY. HIGHER SPEEDS COULD
EXCEED THE RESISTANCE OF YOUR MASK AND LEAD TO SERIOUS INJURY.
• ALWAYS FOLLOW SAFETY RULES OF THE GAME WHEN PLAYING AND WHEN HANDLING
PAINTBALL MARKERS, (GUNS).
• IN VERY RARE CASES, ANY MASK MAY CAUSE SKIN IRRITATION AND SHOULD NOT BE
WORN BY PERSONS WHO ARE SUBJECTED TO DERMATITIS OR OTHER SKIN CONDI-
TIONS. IN CASE OF IRRITATION, DISCONTINUE THE USE OF THE MASK IMMEDIATELY AND
CONSULT A PHYSICIAN.

3
LENS CARE INSTRUCTIONS
Caution!! Read and follow these instructions EXACTLY for care and cleaning of the lenses.
Your cool new Save Phace Tactical lenses are made from the highest quality poly carbonate known
to man. BUT! IMPORTANT, PLEASE know that lenses will deteriorate, weaken and break if you
don’t clean them correctly every time you clean them. AND anti fog solutions eventually come off.
If you clean the lenses improperly, you’ll increase the rate of deterioration or possibly wipe off the
coatings. So, PLEASE follow these instructions every time you clean the lens.
1. NEVER use Windex®, 409®, Fantastic®, gasoline or anything that has alcohol or ammonia in
it to clean your lens. Most lens cleaners have ammonia or alcohol that will deteriorate the lens
coatings and/or lens material and may cause the lens to break. If your lens comes in contact with
one of these, throw it away and get a new replacement lens from us.
2. ALWAYS clean your lens every time you use it or before each game!
3. Use warm clean water and the Save Phace Micro ber lens cloth/bag or lint free cotton cloth to
clean the lens. NEVER use paper towels, newspaper, sandpaper, etc. to clean the lens.
4. Clean the lens sealing channels on both the lens and mask. Sometimes paint will get into and
build up in these areas and may cause the lens to not seat correctly in the mask.
5. NEVER let paint or paint spray stay on the lenses overnight!
6. Single Lens Care: Take the lens out of the mask and wash with warm clean water and dry with
Save Phace Micro ber Lens Cloth/bag.
7. Thermal Lens Care: NEVER EVER submerge the thermal lens in water. Never scrub the soft
inner lens. Never apply any type of anti fog solution to the inner lens.
8. NEVER store your Save Phace lenses or mask near chemicals or fumes.
9. NEVER store your Save Phace lenses or mask in hot places or near heat sources, for example
in the trunk of your car, in plastic bags, in direct sun light.
Always store in cool dry places. Always store the mask in a cool dry place and away from all
chemicals. Transport the mask in a protective Save Phace mask bag.
LENS INSTALLATION AND REPLACEMENT
• IMPORTANT: If you can pull the Lens Locking Key out of the Lens Anchor, DO NOT USE the
MASK! Replace the Lens Locking Anchor and Lens Locking Keys before you use your mask.
• IMPORTANT: There are 4 Parts to the Lens Locking System; 2-Lens Locking Anchors and 2 Lens
Locking Keys. Each piece is marked with and “R” and “L”.
• IMPORTANT: If you do not install ALL 4 Lens Locking Pieces correctly DO NOT Use the Mask.
1. Remove the Strap.
2. Insert the lens through the lens channels.
3. Press the lens rmly into the mask and install the Lens Locking Anchor that is marked “R” installed
on the Right side. And vice versa. IMPORTANT: Make sure the “R” and “L” markings on the Lens
Locking Anchor are facing toward the mask.
4. After both Anchors are in place, insert the Lens Locking Key marked with and “R” through the hole
on the Lens Anchor “R” and fully press the Lens Key through the Lens Key Channel until it is ush
against the Lens. You should feel the Lens Locking Key lock into place. IMPORTANT: Make sure
the “R” and “L” markings on the Lens Locking Keys are facing towards the inside of the mask.
STRAP REPLACEMENT
Press the strap clips together and press the strap clip toward the back of the mask.

4
MASK FIT AND CARE INSTRUCTIONS
GOGGLES MUST FIT PROPERLY AND CORRECTLY TO PROVIDE
PROTECTION!
1. Tighten the adjustable strap enough to hold the mask rmly in place. If you can shake the mask
off, it’s too loose.
2. Make sure the foam in the inside of the goggle area seals around your face.
3. CLEAN the mask after EACH use. Failure to do so may cause the paint to stick to the mask.
Clean the mask and foam with warm clean water and dry off with lint free towel.
4. After proper cleaning, apply ONLY Save Phace Mask Protectant to help you mask clean easier
after a direct Paintball hit.
FOAM INSTALLATION AND CARE INSTRUCTIONS
If your Save Phace mask comes with R.W.I. (Replaceable, (hand)Washable, Interchangeable) foam
please do not clean the foam with any detergent that could cause skin irritations.
1. To uninstall the foam, starting on one side, grab the foam support, not the foam itself, and starting
from the top edge, gently roll the foam support up and out towards you and work your way to the
other side until the foam support is completely off the tops of the foam base.
2. To install the foam, simply reverse the process and when you hear a SNAP, the foam and sup-
port is secured on the foam base… PLEASE check to ensure all edges of the foam support are
secured around the edges of the foam base.
MASK CLEANING AND STORAGE
• IF you have a Mask that has R.W.I. (Replaceable, (hand)Washable, Interchangeable) Foam,
please remove it before cleaning.
• Remove lens before cleaning.
• Remove the strap before cleaning.
• NEVER EVER leave paint on the mask for more than 4 hours.
• After each cleaning use Save Phace Mask Protectant ONLY to protect your mask.
DO NOT remove the Black Rubber Lens Gasket!
Clean with water only. DO NOT wear or use the
mask if the Black Rubber Lens Gasket has been
removed or is missing!
!
WARNING
This product meets or exceeds ASTM F1776.01 Standards for Paintball.

5
FOREHEAD AND VISOR INSTALLATION AND REMOVAL
Removal:
First remove the lens. Then with a magnetic Phillips screwdriver, unscrew the screws located in
the mask top ventilation piece.
Installation:
Line up the accessory you are trying to install with the screw hold located in the top ventilation piece.
FOREHEAD AND VISOR INSTALLATION AND REMOVAL
Installation:
Starting in the middle, using a magnetic screwdriver, loosely install one screw at a time. When all
screws have been installed, tighten each one until the accessory is rmly in place.
Removal:
Reverse installation order.
Ocular Marking
SP: The manufacturer’s identication mark.
EN 166: Number of this standard.
2: Optical Class markings after the manufacturer’s identication mark.
S: Increased Robustness marking after Optical Class marking.
O: Marking identifying the ocular is an original part.
Frame Marking
SP: The manufacturer’s identication mark.
EN166: Number of this standard.
S: Increased Robustness marking (S)
Complies with European Standard En 166.2001
Notied Body – INSPEC, 56 Leslie Hough Way, Salford, M6 6AJ, UK. NB number 0194

6
REPLACEMENT PARTS
Not all components are replacement items, but are illustrated as a convenient reference of location
and position in the assembly sequence. When ordering parts, please give the Model number and
parts description. Call or write for current pricing:
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A.
E-Mail: [email protected] Tel: [phone] Fax: [phone]
Item
Part Number
Description Qty.
Gen X
1Mask
2Mask Hood or Cap
3Lens
4Clip
5Protective Inside Lens
6ADF
7ADF Holder
8Protective Lens
9Halo (Not Shown)
2
6
7
5
3
4
1

7
NOTES:

8
ONE YEAR LIMITED WARRANTY
SavePhace products undergo a strict quality control inspection for workmanship, function, and
safety before leaving the factory. From the date of purchase, SavePhace will warranty or
repair it's products for: one (1) year on its helmet and two (2) years on its ADF against defects in
parts and workmanship. We have a general warranty claim form along with potential request of
proof of purchase.
In the unlikely event a problem is experienced with any of our products, a return merchandise
authorization (RMA) number must be obtained by contacting us toll-free at 866-783-3223. Each
product to be returned must have the item number, description of the problem and proof of purchase.
All returns must have a RMA number marked clearly on the outside of the shipping box, and printed
RMA form enclosed inside the box. Only SavePhace can determine if product can be repaired or
must be replaced.
Except where such limitations and exclusions are specically prohibited by applicable law, (1) THE
CONSUMER'S SOLE AND EXCLUSIVE REMEDY SHALL BE THE REPAIR OR REPLACEMENT
OF DEFECTIVE PRODUCTS AS DESCRIBED ABOVE. (2) SavePhace. SHALL NOT BE
LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGE OR LOSS WHATSOEVER. (3)
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO
ONE YEAR, OTHERWISE THE REPAIR, REPLACEMENT OR REFUND AS PROVIDED UNDER
THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER,
AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. (4) ANY
MODIFICATION, ALTERATION, ABUSE, UNAUTHORIZED SERVICE OR ORNAMENTAL DESIGN
VOIDS THIS WARRANTY AND IS NOT COVERED BY THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you. This warranty
gives you specic legal rights, and you may also have other rights, which vary from state to state.
