Saxby Lighting SightEco 72640 Manual

Instruction leaflet
SightEco Emergency Wall Light
72640
www.saxbylighting.com
Live Voltages may be present in this unit even when turned of or when completely disconnected.
For your safety, always switch off the supply before changing lightbulbs, or cleaning.
This system contains non-replaceable parts and cannot be serviced. If damage occurs the part should be scrapped.
Safety information
Cleaning Information
Saxby Lighting. BH23 3PE
• Werecommendcleaningwithasoftdryclothorwash
with warm water or just use a damp cloth.
• Donotuseabrasivematerialsasthesewilldamagethe
finish.
Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilitiesexist.
Check with your Local Authority or retailer for recycling advice.
Recycling advice
This bulb is protected by a shade. This part must be replaced immediately should the shade become
cracked or damaged. This fitting must not be used without the shade in place.
Iss 1 20102017

Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and satisfactory
operation of this product. Please retain these instructions for future reference.
Warning
This product is Double Insulated and does
not require connection to an Earth circuit.
Please read these instructions carefully before
commencing any work.
This unit must be fitted by a competent and qualified
electrician.
InstallinaccordancewithIEEWiringregulationsand
current Building Regulations.
To prevent electrocution switch off at mains supply
before installing or maintaining this fitting. Ensure other
persons cannot restore the electrical supply without your
knowledge.
This light fitting should be connected to a fused circuit.
If replacing an existing fitting, make a careful note of the
connections.
This product is not suitable for dimming.
Wasteelectricalproductsshouldnotbedisposedofwith
household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling
advice.
These products should not be fitted to PIR circuits or short
duration timed switches.
Specification
Layout
• Themainssupplycablemusthaveaminimumcrosssectionalareaof1.0mm²
• Thisproductissuitableforwallmountingonly.
• ThisproducthasspecialprotectionagainsttheingressofmoistureandisIP65rated.
Existing fittings must be completely removed before
installation of a new product. Before removing the existing
fitting, carefully note the position of each set of wires.
• Undothetwoscrewsateachendofthediffuser.
Remove the screws and diffuser and set aside.
• Thisunitissuitableforwallmountingonly.
• Unclipthegeartraybypushingthequickreleasetabs
to expose back casing.
• Drilloutselectedknockoutsandcableentryholeon
the back casing of the product.
• Usingtheunitasatemplate,markthepositionof
the fixing holes. Take care to avoid damaging any
concealed wiring and pipes. The correct fixings should
be used, depending upon the surface to be mounted.
• Pullthecablethroughthecableentryholeandsealto
maintain the IP rating, and wire as detailed below.
Installation
Wiring
Check that...
• You have correctly identified the wires
• The connections are tight
• No loose strands have been left out of the connection
block.
Voltage:240V~50Hz
Lamp:3WLEDModule(SmD2835)-6500K/100lm
IPrating:65
Duration:3hours(180minutes)
Change over Time: Approximately 1s
Battery Specification: 3.6V 600mAh Ni-Cad
Battery Charge Time: 24 hours
Having correctly identified the wiring from your existing light fitting, pull the wire through the hole and connect to the
connection block inside the product in the following way:
PERMANENT LIVE
NEUTRAL
SWITCHED LIVE
NEUTRAL TERMINAL
LIVE TERMINAL
SUPPLYLIGHT FITTING

• Reclipthegeartrayinplaceandresecurethediffuserusingthescrews.Ensurethatthesealiscorrectlyfitted.
• Replacefuseorcircuitbreakerandswitchon.Yourlightisnowreadyforuse.
• TheLEDshouldlighttoindicatethatthebatteryischarging.Ifthe"SW/L"linkhasbeenleftinplace,theLED
shouldalsolight.Ifyouhaveconnectedaswitchacrosstheterminal"SW",testtheoperationoftheswitch.
Commissioning
• Thelightwillremainlitallthetimeandintheevent
of a power failure will remain on. The unit will charge
automatically.
• Ensurethelinkfrombetweentheterminalsmarked
"SW/L"and"L"isconnectedandwireasdetailed
overleaf.
• Replacefuseorcircuitbreakerandswitchon.Ensure
that the source is mains(240V~50Hz).
• VerifythattheLEDisilluminated;thisconfirmsthatthe
batteries are charging.
• Chargethebatteryforatleast24hoursbeforefirstuse.
• IftheLEDisnotilluminatedthentheremaybenoa.c.
supply, the battery has not been connected properly or
the internal circuit may have failed.
• Thebatteryshouldbere-chargedandcheckedevery
three months.
• Thebatteryshouldbedischargedandthedurationofthe
lamp in emergency mode checked every six months.
• Thelightwillnormallybeoffandcharging.Intheeventof
a power failure, the light will switch on automatically.
• Removethelinkfromtheterminals"SW/L"and"L"for
light to be off and wire as detailed overleaf.
• Replacefuseorcircuitbreakerandswitchon.Ensure
that the source is mains(240V~50Hz).
• VerifythattheLEDisilluminated;thisconfirmsthatthe
batteries are charging.
• Chargethebatteryforatleast24hoursbeforefirstuse.
• IftheLEDisnotilluminatedthentheremaybenoa.c.
supply, the battery has not been connected properly or
the internal circuit may have failed.
• Thebatteryshouldbere-chargedandcheckedevery
three months.
• Thebatteryshouldbedischargedandthedurationofthe
lamp in emergency mode checked every six months.
Operation in Maintained mode
Operation in Non-maintained mode
• Ifafterroutineoperationcheck,thelampdoesnotremain
lit for the three hour period, a new battery pack may be
required.
• Switchofftheelectricityatthemains,allowbatteriesto
fully discharge then reconnect to supply and allow to
charge for 24 hours.
• Testagainfortwohours,iflightdoesnotremainlit
change the battery pack as follows:
• Undothetwoscrewsholdingthefrontdiffuserinplace.
Remove the diffuser and set aside.
• Undotheclipsholdingthegeartrayandfolddown.
• UnplugthebatteryleadfromthePCB.
• Removethebatterypack.Wasteelectricalproducts
should not be disposed of with household waste. Please
recycle where facilities exist. Check with your local
authority or retailer for recycling advice.
• Replace the battery with a 3.6V 600mAh Ni-Cd
ONLY.Useofadifferenttypeofbatterywilldamagethe
product.
• Writecurrentdateonthenewbatterypack.
• Fitthenewbatterypackinpositionandresecure.Plug
battery pack into the PCB.
• Reclipthegeartraybackinposition,takingcarenotto
trap any wires.
• Performfulloperationcheckandupdatetestrecord.
• Refit the diffuser. Ensure that the seal is correctly
located. Tighten the screws carefully to avoid damaging
the threads.
• Restore power and allow to charge for 24 hours.
Battery Replacement
•TheLEDModuleinthisproductisnon-replaceable.
Fitting/replacing bulbs
