Saxby Lighting Nova Manual

• TheLEDmoduleinthisproductisnonreplaceable
Instructionleaflet
Nova Emergency Exit Light
54544
www.saxbylighting.com
Foryoursafety,alwaysswitchoffthesupplybeforecleaning.
Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilities
exist.CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
Recycling advice
Safety information
SaxbyLighting.BH233PE
Werecommendcleaningwithasoftdrycloth.
Donotusesolventsorabrasivecleanersasthesecould
damagethefinish.
Fitting/replacing bulbs
Iss.114072015
• Connectthebattery,ensuringthecorrectpolarityis
observed.
• Refittheproducttothetopcoverremovedearlier.
• Replacefuseorcircuitbreakerandswitchon.Your
lightisnowreadyforuse.
Commissioning
Care and cleaning
• Thebatterytestbuttonislocatedonthewhiteceiling
cover.Pushtotesttheemergencyfunctionofthe
product.
• Testscanbecarriedoutasandwhenrequired.
• WhentheLEDlightnexttothetestbuttonis
illuminated,thisindicatesthattheunitischarging
Product testing

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeand
satisfactoryoperationofthisproduct.Pleaseretaintheseinstructionsforfuturereference.
Warning
This light fitting is Class 2 (Double
Insulated) and must not be connected to an
Earth circuit.
Pleasereadtheseinstructionscarefullybefore
commencinganywork.
Thisunitmustbefittedbyacompetentandqualified
electrician.
InstallinaccordancewithIEEWiringregulationsand
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupply
beforeinstallingormaintainingthisfitting.Ensure
otherpersonscannotrestoretheelectricalsupply
withoutyourknowledge.Ifyouareinanydoubt,
pleaseconsultaqualifiedelectrician.
Thislightfittingshouldbeconnectedtoafusedcircuit.
Ifreplacinganexistingfitting,makeacarefulnoteof
theconnections.
Thissystemcontainsnon-replaceablepartsand
cannotbeserviced.Ifdamageoccursthepartshould
bescrapped.
Wasteelectricalproductsshouldnotbedisposedof
withhouseholdwaste.Pleaserecyclewherefacilities
exist.Checkwithyourlocalauthorityorretailerfor
recyclingadvice.
ThisproductisratedatIP20.
Thisproductisnotsuitablefordimming.
Layout
• Themainssupplycablemusthaveaminimumcross
sectionalareaof1.0mm²
Existingfittingsmustbecompletelyremovedbefore
installationofanewproduct.Beforeremovingthe
existingfitting,carefully note the position of each set
of wires.
• Removethetopcoverbypushingintheretaining
clipswithaflatheadscrewdriver(Fig.1)
• Usingthetopcoverasatemplate,markthelocation
ofthefixingholes.Drillholesandfitsuppliedwall
plugs(suitableformasonryonly-forothersurfaces
useappropriatefixings).Fixproducttothewallusing
thesuppliedscrews.Takecaretoavoiddamaging
anyconcealedwiringandpipes.
• Feedtheincomingsupplycablethroughthecable
entryhole.
• Wireasdetailedbelow.
Installation
Wiring
Thisproductcanbewiredindifferentways,depending
onwhethernonmaintained/maintained/switched
maintainedwiringisrequired.
ToconfiguretheproductasaNon-maintainedfitting,
thesuppliedjumperloopmustberemovedandthelive
supplywiremustbeconnectedtooneofthepermanent
liveterminalsandtheneutralsupplywiretotheterminal
markedN.
1)Toconfiguretheproductasamaintainedfitting,
connectthesuppliedjumperloopbetweentheLandL
terminals.
2)Ifthemaintainedmodeneedstobeswitchablethen
thejumperisnotneededandaswitchedlivesupplywire
willneedtobeconnectedtotheLsterminalinstead.
Check that...
• Youhavecorrectlyidentifiedthewires.
• Theconnectionsaretight.
• Noloosestrandshavebeenleftoutoftheconnection
block.
Specification
Voltage : 240V~50Hz
Lamp : 2WLEDModule(SMD28
  35)CoolWhite-46lm
IPrating : 20
Lumens : 50lminEMmode
Duration : 3hours(180minutes)
OperatingTemperature : 5˚Cto50˚C
MaximumOperatingHumidity: 10%-90%
ChangeoverTime : Approximately1s
BatterySpecification : 4.8V600mAhNi-Cad
BatteryChargeTime : 24hours
Fig. 1
LLNLs
Permanent
Live
Brown
Neutral
Blue
Switched
Live
