Scaleo medical Horizon S5 User manual

DOMA119_v4_20200619_Manuel utilisateur Ho2rizon® S5 1
Oxygen concentrator
Ho2rizon®S5
t
USER MANUAL

2 DOMA119_v5_20200629_ Ho2rizon® S5

DOMA119_v5_20200629_ Ho2rizon® S5 3
Content
Warning and safety instructions.........................................................................................................................................................................................................4
Safety notes....................................................................................................................................................................................................................................................4
Warnings...........................................................................................................................................................................................................................................................5
Symbols and pictograms......................................................................................................................................................................................................................... 9
General information about the Ho2rizon®S5.......................................................................................................................................................................10
About the Ho2rizon®S5 ...................................................................................................................................................................................................................10
Intended use...............................................................................................................................................................................................................................................10
Contraindications....................................................................................................................................................................................................................................10
Parts of the Ho2rizon®S5 oxygen concentrator.......................................................................................................................................................... 11
Accessories and spare parts.........................................................................................................................................................................................................12
Unpacking the Ho2rizon®S5 oxygen concentrator ................................................................................................................................................12
Instructions for use........................................................................................................................................................................................................................................13
Operating instructions ........................................................................................................................................................................................................................13
Alerts and troubleshooting...................................................................................................................................................................................................................16
Alerts..................................................................................................................................................................................................................................................................16
Troubleshooting...................................................................................................................................................................................................................................... 17
Cleaning and maintenance ..................................................................................................................................................................................................................18
Technical specifications...........................................................................................................................................................................................................................21
Specifications..............................................................................................................................................................................................................................................21
Classification................................................................................................................................................................................................................................................22
Operating environment.....................................................................................................................................................................................................................22
Storage and transportation environment.........................................................................................................................................................................23
Circuit diagram..........................................................................................................................................................................................................................................23
Electromagnetic compatibility...........................................................................................................................................................................................................24
Guidance and manufacturer's declaration - electromagnetic emissions ..........................................................................................25
Guidance and manufacturer's declaration - electromagnetic immunity............................................................................................25
Terms of warranty & liabilities........................................................................................................................................................................................................... 28
Lifespan and recycling............................................................................................................................................................................................................................ 29
Lifespan.......................................................................................................................................................................................................................................................... 29
Waste disposal........................................................................................................................................................................................................................................ 29
Applicable standards................................................................................................................................................................................................................................30
How to contact us..........................................................................................................................................................................................................................................31
English

4 DOMA119_v5_20200629_ Ho2rizon® S5
Warnings and safety instructions
Safety notes
Please read this manual carefully before using this product and save it for future reference. Do not use this
product without fully reading and understanding these instructions. Injury or damage may result.
If you cannot understand this user manual, please contact your service provider or after-sales service center.
SCALEO Medical provides consulting and training services. Make sure that the user understands this user
manual and uses this product accordingly.
Users of home oxygen therapy should strictly follow the doctor's prescription. Oxygen therapy is performed
according to the doctor's daily oxygen flow and oxygen inhalation at rest, sleep and during exercise. It is
strictly forbidden to adjust the oxygen flow rate and adjust the time by yourself, in order to avoid insufficient
oxygen supply or oxygen poisoning.
Patients who are in urgent need of oxygen, critically ill patients and patients under continuous oxygen
inhalation, shall have other oxygen supply devices (such as compressed oxygen cylinders or liquid oxygen
systems) as a backup product when using the Ho2rizon® S5 oxygen concentrator.
If an adverse reaction appears when inhaling oxygen, stop using it and contact your service provider or your
doctor immediately.
If there is an eventual device failure, contact your service provider or the manufacturer's after-sales service
center immediately and do not disassemble it or repair it.
This device is not intended to be life sustaining or life supporting. Additional monitoring or attention may be
required for pediatric patients, elderly patients or patients using this device who are unable to hear or see
alarms or communicate discomfort. This product is not suitable for babies.
Severe carbon monoxide poisoned patients are banned from using this device.
The nasal cannula is dedicated to one person and should be cleaned and replaced regularly. Be careful not to
adjust the flow meter float (middle part) beyond the red line position. Long-term use will reduce the
efficiency of the oxygen concentrator.
If the product has been stored for 6 months by the dealer, the product must be returned to the factory for
inspection.

DOMA119_v5_20200629_ Ho2rizon® S5 5
Warning
Please read the following information carefully before operating the oxygen concentrator.
Special attention should be given to reducing the risk of fire when using oxygen therapy. When the oxygen
concentration is high, any material becomes extremely flammable and burns quickly, regardless of whether it
is flammable or not. For safety reasons, all ignitions should be kept away from the oxygen concentrator and
preferably shall not be in the same room as the oxygen concentrator.
Oil, grease or petroleum-based products are prone to strong spontaneous combustion when exposed to
oxygen under pressure. These materials must be kept away from oxygen concentrators, piping, connections
and other oxygen concentrator components. Do not use any lubricant.
Oxygen concentrators are strictly prohibited from being inverted or positioned horizontally during use and
displacement, and should avoid an environment of pollution and smoke. The oxygen concentrator requires an
ambient temperature of 10 to 37°C. When the temperature is lower than 10°C, the compressor may have
difficulties starting. Above 37°C will cause the compressor to overheat and shorten the life of the machine.
It is strictly forbidden to use oxygen concentration in an environment above 3000 meters. Such an
environment will reduce the quality of patient treatment.
Please do not move the oxygen concentration while it is in use.Do not turn on the oxygen concentrator with
the flow meter turned off.During use, the oxygen concentrator produces a regular exhaust sound when
oxygen is produced, which is a normal phenomenon.It is normal for the exhaust vent at the bottom of the
oxygen concentrator to discharge hot air.
Please do not block the exhaust vent during use.In order to achieve the best performance of the oxygen
concentrator, SCALEO Medical recommends to use the oxygen concentrator for more than 30 minutes each
time. Frequent use of the oxygen concentrator for a short period of time may reduce the lifespan of the
machine.
If the oxygen compressor power cord or plug is damaged, if the machine is working abnormally or if it falls
into water, please contact your authorized service provider for inspection.Keep the power cord away from
heat or high temperature surfaces. Do not use extension cords.

Do not move the oxygen concentrator by dragging the power cord. Do not drop or insert foreign objects into
any openings. It is strictly forbidden to block the air inlet and exhaust port of the device or place the machine
on a soft surface, such as a sofa or a bed, which can cause the exhaust port to be blocked. Keep the air intake
away from plush, hair or similar.
English

6 DOMA119_v5_20200629_ Ho2rizon® S5
When adding water into the humidifier, do so according to the amount calibrated by the
humidifier. Do not add excessive water.
Oxygen concentrator must be at least 40 cm away from walls, tapestries, furniture and similar objects.
The Ho2rizon® S5 medical oxygen concentrator is equipped with a set of oxygen nasal cannula. Patients can
also choose other anti-extrusion registered oxygen cannula to be purchased as needed. However, the length
of the nasal cannula should not exceed 14 meters. Oxygen nasal cannula should be placed correctly to avoid
the risk of wringing the head or neck.
Do not use parts, accessories, or equipments that are not approved by the manufacturer. The use of
unspecified humidifiers or other accessories may reduce the performance of this concentrator.
Do not connect the concentrator in parallel or series with other oxygen concentrators or oxygen therapy
devices.
Do not use any power cord other than the original. Non recommended power cords can cause increased
electromagnetic radiation or reduce electromagnetic immunity, resulting in operational failure.
Oxygen therapy is harmful under certain conditions. SCALEO Medical recommends the use of the Ho2rizon®
S5 oxygen concentrator under medical prescription only. Oxygen therapy should be performed according to
the prescription of the doctor. Unauthorized adjustment of oxygen flow is strictly prohibited as it may cause
oxygen poisoning or carbon dioxide retention. This medical device is designed to supplement oxygen, not for
first aid or sustain life.
Avoid creating sparks near medical oxygen equipment, including static sparks generated by friction.
If the oxygen concentrator is used under abnormal conditions for a long time (in terms of humidity,
temperature, dust... outside of its normal range) this will reduce its efficiency. Please contact your service
provider or the after-sales service of the manufacturer.
Regularly evaluate your treatment and contact your doctor if you have uncomfortable symptoms when using
this device.
Maintenance
The Ho2rizon® S5 oxygen concentrator is designed to minimize the number of maintenance routine. The
maintenance period is approximately once a year. Only an authorized after sales service can disassemble,
repair or commission the equipment.

DOMA119_v5_20200629_ Ho2rizon® S5 7
Radiofrequency interference
Most appliances are susceptible to interference with radio frequencies. Therefore, the use of portable communication
equipment near the oxygen concentrator will cause interference to the machine.
This product cannot be used in environments such as electrocautery, electro surgery, defibrillation, X-ray,
gamma ray, infrared radiation, transient electromagnetic fields, including magnetic resonance (MRI) and radio
interference.
Portable RF communications equipment (including peripherals such as antenna cables and external antennas)
should be more than 40 cm away from any part of the equipment. Otherwise, the performance of the device
will decrease.
This oxygen concentrator should be avoided from being adjacent to or stacked with other equipment. This
may result in improper operation. If you must be near or stacked, observe and verify the equipment and other
equipment to ensure that it is working properly.
To reduce the burning, electric shock, fire hazard and personal injury, please do the
following:
Do not use this device while bathing. If you need to use it continuously, the oxygen concentrator must be
placed at least 3 meters away from the bathroom.
Do not touch the oxygen concentrator while your body is wet.
Do not use or store this oxygen concentrator near liquids or other electrically conductive materials.
Do not touch the oxygen concentrator that falls into the water or other easily conductive liquid. If it falls into
it, unplug the power cord immediately.
The power plug must be unplugged when not using this oxygen concentrator.
If you find the supply of oxygen insufficient, contact your service provider or your doctor immediately. Do not
adjust the oxygen flow unless directed by a healthcare professional.
Be careful not to place the device in an environment where it can easily collide or where other people can
easily trip over the power cord. Small parts that fall off the device can cause suffocation if eaten or inhaled.
Keep out of reach of children.
Do not perform maintenance while the device is running.
English

8 DOMA119_v5_20200629_ Ho2rizon® S5
Warning
Oxygen is a combustion-supporting gas. Oxygen compressors should be kept away from any source
of ignition and flammable materials. Smoking and open flames near people who absorb oxygen
are strictly prohibited.
Smoking is strictly prohibited during oxygen inhalation. Patients under oxygen therapy must quit
smoking. 
The power cord should be kept away from heat or fire sources. 
The power switch must be turned off when no oxygen therapy is performed. 
Do not place the nasal cannula under the covers or upholstery. 
Before cleaning the oxygen concentrator housing or replacing the fuse, the power plug must be
unplugged to avoid electric shock. 

DOMA119_v5_20200629_ Ho2rizon® S5 9
Symbols and pictograms
Symbols used in this manual
This symbol indicates instructions and safety information, when injuries may occur if warnings are
ignored or partially followed. It is important to carefully follow the advice and warnings.
This symbol indicates important information regarding the use of the equipment. Failure to follow
this information may result in damage or malfunction of the device or other equipment.
This symbol indicates important and useful information. This information will help the user and
optimize the use of the material. It will simplify routine operations and provide solutions to complex
operations.
Pictograms on product and labels
Mark
Definition
I
Power ON
○
Power OFF
Follow instruction for use
No smoking
Caution, consult
accompanying documents.
Class II (double Insulated)
Type BF applied part
CE certification mark
AC power
Mark
Definition
This way up
Fragile, handle with care
Keep dry
Temperature limit
No open flames
IP21
Drip proof equipment
Consult instructions for use
Stand-by
Warning, electricity
Stacking limit by number
English
English

10 DOMA119_v5_20200629_ Ho2rizon® S5
General information about the Ho2rizon®S5
Your health care professional has determined that supplemental oxygen is beneficial to your health and has
prescribed an oxygen concentrator set at a specific flow setting to meet your needs. DO NOT change the flow
settings unless your health care professional tells you to do so. Please read and understand this entire manual
before using the device.
About the Ho2rizon®S5
The device produces concentrated
oxygen from ambient air to patients
requiring low flow oxygen therapy.
The oxygen from the air is
concentrated using molecular sieves
and a pressure swing adsorption
process. Your home care provider will
show you how to operate the
concentrator and will be available to
answer any questions.
Intended use
The Ho2rizon® S5 oxygen
concentrator is intended for the
administration of supplemental oxygen. This device is not intended for life supporting and does not allow any
type of patient monitoring. The system is intended to be operated at home, in community health care centers
and medical institutions.
The Ho2rizon® S5 oxygen concentrator is suitable for adults and children.
Contraindications
This product is not suitable for patients with severe carbon monoxide poisoning.
Workflow chart

DOMA119_v5_20200629_ Ho2rizon® S5 11
Parts of the Ho2rizon®S5 oxygen concentrator
Front panel
1. Oxygen flow meter
2. Flow rate setting knob
3. USB port
4. LCD display
5. Oxygen outlet
6. Power indicator
7. Warning light
8. Power switch
Rear panel
9. Power cable
10. Circuit-breaker
11. Air inlet grid
12. Humidifier bottle
13. Humidifier loop fastener
14. Compressor filter cover
15. Product label
Description of the main parts
Flow meter: the floating ball level indicates the magnitude of the output oxygen flow.
Oxygen outlet: output oxygen.
Alarm indicator: code appears on the display.
Power switch: " I" ON; "○" OFF. A green light is on when the machine starts running.
Humidifier bottle: it is used to prevent the dry oxygen to irritate the throat or the nasal mucosa. Also
prevents phlegm from drying.
Humidifier loop fastener: the loop fastener is used to fit the humidifier bottle.
Air intake grid and filter:filters dust from the air.
Compressor filter cover: contains the compressor filter.
English
English

12 DOMA119_v5_20200629_ Ho2rizon® S5
Accessories and spare parts
If you have questions or concerns about this device, please contact your home care provider. Please use only
the following manufacturer's accessories and spare parts:
Compressor filter
Humidifier connection tube
Unpacking the Ho2rizon®S5 oxygen concentrator
1. Check for any obvious damage to the box or its contents. If damage is evident, notify the carrier, or your
local distributor.
2. Remove the foam block from the packaging and the box.
3. Carefully take out all the parts and the machine from the carton. Inspect/examine the exterior of the
oxygen concentrator for nicks, dents, scratches or other damages.
If there are parts or quality issues, please contact your local distributor. Keep the box and packaging
materials for future storage and transportation.

DOMA119_v5_20200629_ Ho2rizon® S5 13
Instructions for use
Operating instructions
Do not use extension cords or electrical adapters.
1. Select a location that allows the concentrator to draw in room air without being restricted. Make sure the
device is at least 40 cm away from walls, furniture and especially curtains that could impede adequate
airflow to the device. Do not place the device near any heat source.
2. After reading this entire manual, plug the power cord into an electrical outlet.
3. Do either step A or step B below.
A. If you are NOT using a humidifier, follow these steps:
A. 1. Connect the fire damper to the oxygen outlet according to the “1-
A1” diagram.
A. 2. Connect your nasal cannula to the fire damper according to the “1-
A2”diagram.
B. If you are using a humidifier, follow the steps below:
B. 1. Take out the humidifier bottle from the plastic package.
B. 2. Unscrew the brown lid in a counterclockwise direction. Inject a proper amount of
distilled water on the transparent humidification cup and then tighten the brown lid
clockwise.
Use distilled water, purified water or previously boiled (and then cooled) water for the
Diagram: 1-A1
Diagram: 1-A2
Fire damper
Nasal cannula
English

14 DOMA119_v5_20200629_ Ho2rizon® S5
humidifier water. Replace the water once a day. Fill the water up to half of the maximum and minimum tick
marks, or slightly lower to cover the bubble outlet in the humidifier.
When disassembling, rotate the cup counterclockwise to remove the cup. When installing, align the
humidification cup with the cup cover, rotate the cup clockwise and tighten the cup to avoid air
leakage.
B. 3. Install the humidifier with water in the place dedicated to this purpose on the
top of the Ho2rizon® S5, according to the “2-B1”diagram.
B. 4. Use the loop fastener to tighten the bottle and secure it.
B. 5. Connect the PVC hose to the oxygen concentrator outlet and the
humidifier inlet according to the “2-B2” diagram.
B. 6. Connect the fire damper to the outlet end of the humidifier
according to the “2-B3” diagram.
B. 7. Please connect the nasal cannula to the fire damper according to the “2-B4”
diagram.
B. 8. The air path connection is in the removable parts connection diagram below:
This product must be connected to the fire damper according to the above instructions, otherwise
the manufacturer does not assume responsibility of the potential consequences.
Diagram: 2-B1
Diagram: 2-B2
Diagram: 2-B3
Diagram: 2-B4
Fire damper
PVC hose
Nasal cannula

DOMA119_v5_20200629_ Ho2rizon® S5 15
4. Turn on the power switch.
The power cord plug must be securely inserted into a safe and qualified socket.
5. Block the vent of the brown tip of the humidified bottle with your finger for about 20
seconds. Observe whether the float in the flow meter drops, or if the humidification
cup issues a "qiu" sound. If yes, there is no air leakage.
6. Adjust the oxygen output flow by taking the eye line of sight, the midline of the ball
and the scale of the flow meter on the same horizontal line.
The flow meter adjustment knob increases the flow rate counterclockwise and decreases the flow
rate clockwise. For health care, it is recommended to set the flow rate at 1- 2L/min for a period of 45
to 60 minutes per day. For long term oxygen therapy (LTOT), it is very important to strictly follow the
advice of your physician. Take oxygen treatment according to the flow rate and time prescribed by your
doctor. Never adjust the flow rate or time at will.
7. Insert the nasal cannula into the nostrils to start the oxygen therapy.
8. When the oxygen therapy is finished, turn off the power switch.
When not in use, unplug the power cord.
English

16 DOMA119_v5_20200629_ Ho2rizon® S5
Alerts and troubleshooting
Alerts
LDC indication
Area
Indicators
Possible
cause
Status prompt
Test method
Alarm
delay
time
Priority
①
000000
Accumulate
working hours.
It will show working interface in 10
seconds.
Visualization.
----
②
High
High oxygen
purity.
----
Visualization.
----
Low
Low oxygen
purity: 82%.
Solid red LED and the audible alarm
is sounding hurriedly.
Adjust the oxygen flow-
meter to the maximum
level until alarm.
Less
than 1
minute.
High.
③
H01
Output flow is
too low.
Flashing yellow LED and the
audible alarm is sounding
intermittently.
Adjust the oxygen flow-
meter to the minimum level
until alarm.
Less
than 1
minute.
Medium.
H02
Abnormal
temperature
rise.
Solid red LED and the audible alarm
is sounding hurriedly. The device is
not working.
Unplug the blower
connector.
Less
than 2
minutes.
High.
③
H08
Abnormal
working
pressure.
Solid red LED and the audible alarm
is sounding hurriedly. The device is
not working.
Use the variable frequency
power supply to adjust the
supply voltage to less than
85% of the rated voltage.
Less
than 1
minute.
High.
③
E01
Temperature
sensor failure.
Flashing yellow LED and the
audible alarm is sounding
intermittently.
Unplug the temperature
sensor connector.
Less
than 1
minute.
Medium.
④
“00:00”
Current working
time.
----
Visualization.
---
PWR
Power failure
alarm.
Audible alarm is sounding
continuously and the sound is ≥
60dB.
Unplug the power plug
while in operation.
----

DOMA119_v5_20200629_ Ho2rizon® S5 17
When multiple troubleshooting alarms, they will show alternately. Alarms and indicators
depend on the highest priority.
The above alarms are technical alarms.
Within 3 minutes after power is on, the oxygen concentration of less than 82% will not alarm.
When a troubleshooting alarm occurs, identify the type of failure that is displayed on the LCD
and contact your service provider immediately.
The recommended test interval of the alarm system is 18 months.
The alarm sound pressure level is of 60~80 decibels
Troubleshooting
Problem
Why it happened
What to do
Power on, the
equipment is not
working.
The start capacity of the
compressor is broken or the
compressor is not working.
Call your service provider or dealer.
Power on, the
equipment is not
working, or works
un-continuously.
The power cord may not be
plugged correctly or there may be
a bad contact.
* Check if the power cord is damaged.
* Check if the power cord is plugged correctly.
Call your service provider, if you still cannot solve
the problem.
No oxygen outlet or
the outlet flow is
too low.
* Oxygen cannula kinked or
blocked.
* The humidifier bottle is not
tighten.
* Unknit the cannula.
* Re-install the humidifier lid.
Call your service provider, if you still cannot solve
the problem.
The ball in flow
meter is
uncontrolled by the
knob.
* The flow knob is not tighten.
* The knob was turned abruptly
or too fast.
* To tight the knob, turn the knob slowly and
softly.
Call service provider, if still cannot solve the
trouble.
Water goes back to
the cannula.
* There is a temperature
difference caused by the
weather.
* The device is too close to the
wall, curtains or furniture.
* The location of the equipment
and cannula is different.
* Dry the inside of humidifier lid.
* Do NOT use hot water.
* Do NOT over-fill the humidifier.
* Keep the equipment and cannula in the same
room to maintain the same temperature.
English
English

18 DOMA119_v5_20200629_ Ho2rizon® S5
Cleaning and maintenance
It is important to unplug the device before performing any cleaning.
Excess moisture may impair the proper operation of the device.
1. The sponge mesh filter:
The sponge mesh filter should be cleaned weekly to keep the oxygen concentrator running smoothly, or more
frequently if the environmental conditions requires it.
In order to clean the sponge mesh filter, please follow the following instructions :
a. Open the air intake grid located on the back part of the
concentrator. Remove the sponge mesh filter and shake it to let
the dust fall.
b. Rinse the sponge mesh filter thoroughly using clean water, remove
excess water, then allow to air dry completely.
c. The dry mesh filter may be replaced and the air intake grid
reinstalled.
Having a second sponge mesh filter allows a quick
replacement while the other filter is drying. Always use
original spare parts. If the sponge filter needs to be replaced,
please contact your local distributor.
2. Compressor filter replacement:
The compressor filter is used to filter dust entering the compressor. It needs to be replaced regularly. It is
recommended to replace the filter every 4000 hours. The compressor filter needs to be purchased from a
SCALEO Medical distributor.
In order to replace the compressor filter, please follow the following instructions :
a) The compressor filter cover is in the back of the device (see figure 4-1 below). Open the compressor
filter cover (see figure 4-2 below) and unscrew the filter body clockwise (see figure 4-3 below) to remove the
Air intake grid
Sponge mesh
filter

DOMA119_v5_20200629_ Ho2rizon® S5 19
compressor filter (see figure 4-4 below).
b) Replace the new compressor filter, install the filter body counterclockwise and install the filter cover.
3. Cleaning the nasal cannula:
Cleaning the cannula should be done every day with a detergent and then rinsing thoroughly with clean
water, then allowing it to air dry.
It is recommended to replace the cannula once a month.
4. Cleaning the outside case :
With your oxygen concentrator turned off, clean the outer case once or twice per month. Use a damp towel
and a small amount of detergent and then wipe it up with a dry towel.
Filter body
Figure 4-1
Figure 4-2
Figure 4-3
Figure 4-4
Compressor
filter cover
Compressor filter
English

20 DOMA119_v5_20200629_ Ho2rizon® S5
5. Humidifier bottle disinfection :
The humidifier water should be refreshed every day with cool water that is distilled or previously boiled (and
then cooled).
Cleaning and disinfection should be done at least every 3 weeks by cleaning with a mild detergent (such as
Dawn™) then rinsing with warm or hot water followed by soaking in a household disinfectant for 20-30
minutes, then rising thoroughly with warm or hot water and allowing it to air dry.
Keep the humidifier in a clean plastic bag if not using for extended periods of time.
Different disinfectant can be used :
vinegar and distilled water in a ratio of 1 : 1,
bleach and distilled water in a ratio of 1 : 10,
or commercially available household disinfectant.
It is recommended to replace the humidifier bottle once a year.
