SC&T UE03 User manual

Smart Cabling & Transmission Corp. V2.1
USB/Keyboard Mouse Extender
User Manual
Model : UE03
USB 2.0 CAT5e Extender with 4 Port Hub 50M

1
User Manual
UE03
Introduction
UE03 is a peripheral device designed for extending 4 of USB 2.0 signals, such as USB cameras, touch
screen, touchpad, HDD(External Hard Drive),USB flash drives, keyboards, mouses...etc.
Features
Extends 4 USB signals over an Ethernet cable.
Signal extension up to 50M (USB2.0), 90M (USB1.0/ 1.1) over a CAT5e cable.
Supports USB 2.0 high-speed and USB 1.1 low-speed, full speed devices.
Built-in 4 USB ports at TX unit for remote control.
Plug & play.
Installation View
Transmission Chart
USB Standard
Data Rate
Distance
Cable
USB2.0
480Mbps
50M
CAT5e/CAT6
USB1.1/ USB1.0
12/1.5Mbps
90M
CAT5e/CAT6
*The transmission test is conducted by the application of COMMSCOPE (57535-2) CAT5e cables.
Link Cable
1. It’s recommended to use high-quality Ethernet cables, such as CAT5e, CAT6. The thicker the cable
and the wider the diameter is, the better transmission performance.
2. It’s recommended to use solid conductors rather than copper-clad steel or stranded conductor
cables which might decrease the transmission performance.
3. Please note that STP/FTP cables might decrease the transmission distance.

2
User Manual
UE03
Panel View
UE03T Client Unit
UE03R Local Unit
LED Status
LED Status
Blinking
Breathing
Dark
Function
Data Transferring
Stand-by*
No Power to UE03T
*Stand-by Description
1. UE03T is not connected to UE03R.
2. UE03T is connected to UE03R, but no USB Host connected to UE03R.
3. UE03R is connected to UE03T and a USB Host, but the USB Host is power-off.
RJ45 Pin Define
PIN
Signal
1
Orange-white
DATA +
2
Orange
DATA -
3
Green-white
4
Blue
5
Blue-white
6
Green
7
Brown-white
8
Brown

3
User Manual
UE03
Caution
1. UE03 is not an Ethernet device, which CAN NOT connect to any Ethernet or PoE device.
2. The cabling must be away from any equipment with electromagnetic wave, i.e.: microwave,
radio equipment, high voltage.
3. UE03 is not applicable for USB hosts that remain powered after PC/Laptop are shut down.
*If the given situation is encountered as showed in Fig 1, devices connected to UE03T will not be
recognized. Try to un-plug and re-plug the USB port of UE03R or plug to another USB host port
(not powered after shut down) to solve the issue.
Fig 1
Package Includes:
No.
Item
Amount
1
UE03T
1
2
UE03R
1
3
Screw
4
4
Screw Plug
4
5
DC5V 2A Power Adapter
1

4
User Manual
UE03
Specification
ITEM NO.
UE03T
UE03R
Support
Compliance
USB 2.0, USB 1.1, USB1.0
Data Bandwidth
480Mbps (High-speed), 12Mbps (Full-speed), 1.5Mbps (Low-speed)
Max. Transmission
Distance
50M (USB2.0)/ 90M (USB1.0/ 1.1)
Ports & Interfaces
Data Input
4 x USB Type A (Female)
1 x RJ45
Data Output
1 x RJ45
1 x USB Type A (Male)
Power
Power Supply
DC 5V 2A Regulated
No Power Required
Power Output
500mA / each USB device connected
Power Consumption
1.5W
1W
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
60 x 70 x 27mm
25.4 x 25.4 x 240mm & 190mm cable
Weight
115g
55g
