SC&T CD1664HD User manual

Smart Cabling & Transmission Corp. V1.0
HD-TVI/ AHD/ HD-CVI/ CVBS Distributor Series
User Manual
Model : CD1664HD
16 x 64 HD-TVI/AHD/HDCVI/CVBS Video Distributor in 2U Rack

1
User Manual
CD1664HD
Introduction
CD1664HD is a video distributor that can split 16 HD-TVI/ AHD/ HDCVI/ CVBS signals into 64 ones with up to
4K (8MP) resolution.
Features
Extends and splits 16 video signals into 64 ones.
Supports HD-TVI, AHD, HDCVI, 960H, NTSC, PAL video signal.
Resolution up to 8MP(4K).
Support UTP (Up the Coax)
Built in TVS protection.
Installation View
Slide switch at video

2
User Manual
CD1664HD
Slide switch at VIDEO+DATA
Dip Switch Mode Function
VIDEO Output 1 support video only.
VIDEO + DATA Output 1 support HD camera video with data control signal
Panel View
Cable & Transmission Distance

3
User Manual
CD1664HD
Link cable recommend use high quality 75ohm coaxial RG59/RG6U cable. The transmission distance will
be affected by different quality of Camera, DVR and BNC connector, cable, installation…etc.
LED Indication
Orange Power ON/OFF
Caution
Output 1 under Video+Data mode, the output must connect with HD-DVR. Not allow to connect with CVBS
Camera/DVR.

4
User Manual
CD1664HD
Specifications
ITEM NO.
CD1664HD
Support
Video Format
HD-TVI, AHD, HDCVI, 960H, NTSC, PAL
Max. Video Resolution
4K
Video Bandwidth
100MHz 0.1dB Gain Flatness
Ports & Interfaces
Video Input
16 x BNC (1V p-p, 75Ω)
Video Output
64 x BNC (1V p-p, 75Ω)
Power
Power Supply
DC 12V 1200mA
Power Consumption
960mA (Typical), 1150mA (Max)
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
483 x 91.5 x 88.4mm
Weight
2700g
