SC&T PC2A User manual

Smart Cabling & Transmission Corp. V1.0
Power Converter Series
User Manual
Model : PC2A
AC/DC to DC 12V Regulated Power Converter, 2000mA

1
User Manual
PC2A
Introduction
PC2A is a power converter that allows DC powered camera to be powered by AC.
Features
Converts AC/DC to DC 12V 2A.
Supports AC 18V to 26V or DC 18V to 36V power input.
Built-in 2-pin terminal block at both ends.
Installation View
LED Indication
LED
LED Color
Description
POWER
GREEN ON
Power On
Caution
Please pay attention to the power input and output connection.
The power connection between the positive and negative must be correct to avoid the product
damage.
DC 12V Out
AC 18~26V
DC 18~36V

2
User Manual
PC2A
Specification
ITEM NO.
PC2A
Support
Input Power
AC 18~26V/ DC18~36V
Output Power
DC12V Regulated
Output Current
2000mA (Max)
Ports & Interfaces
Power Input
1 x 2-pin Terminal Block
Power Output
1 x 2-pin Terminal Block
Ambient Temperature
Operation
-40 to 85℃
Storage
-50 to 95℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
102.8 x 25.4 x 25.4mm
Weight
75g
