SC&T SDI01A-12G User manual

Smart Cabling & Transmission Corp. V1.0
SDI Converter
User Manual
Model : SDI01A-12G
12G-SDI to HDMI 2.0 Converter with Audio
Embedded/Extractor

1
User Manual
SDI01A-12G
Introduction
SDI01A-12G is a 12G-SDI to HDMI 2.0 converter that can allows you to monitor 12G SDI video using a
cost-effective HDMI display. The new converter has a built-in SDI loop-out port to send the input SDI
signal to an extra SDI device.
Furthermore, SDI01-12G also features diverse audio interfaces for audio embed or extract to integrate
with your professional audio equipment.
Features
Resolution up to 4K@60Hz 4:4:4 HDMI and 12G-SDI.
Built-in fiber module for long distance transmission.
Built-in SDI loop out.
Built-in XLR (AES/ EBU), 6.3mm phone jack, and RCA audio interfaces
Supports HDMI audio embedder and SDI audio extractor.
Support HDMI video up/down scaler.
Diagram

2
User Manual
SDI01A-12G
Step by step installation
1. Connect 12G-SDI source to SDI01A-12G by 12G RG6U cable (BELDEN 4694 or higher).
2. Connect 4K 6G HDMI monitor to SDI01A-12G by HDMI 2.0 premium cable.
3. Connect 12G-SDI monitor to SDI01A-12G by 12G RG6U cable (BELDEN 4694 or higher).
4. Connect AUDIO INPUT/OUTPUT between SDI01A-12G and audio equipment by XLR cable.
5. Connect DC 12V power adaptor to SDI01A-12G and turn on POWER switch.
Panel View
Front View
Back View
SDI Input
-Coax/Optical
SDI Loop out
-Coax/Optical
Audio Input
-SDI 8 Channel by Group selection
-2 CH XLR / RCA / 6.5mm phone jack/ AES
Audio Output (simultaneously)
-HDMI
-2 Channel XLR / 6.5 mm phone jack/ AES
Micro USB
-Firmware update

3
User Manual
SDI01A-12G
-System setting
-HDMI audio mapping
Mechanical Dip Switch
-Select audio interface
-Select HDMI resolution
-HDCP On / off
LED Indication
Front Panel LED
Function
ON
Blink
Green ON
Power
Power Good
Green SIGNAL
SDI Signal Indicator
Signal Locked
Green HDMI
HDMI Output Indicator
HDMI Outputted
Resolution not supported
Blue 12G/6G
12G/6G Indicator
12G-SDI
6G-SDI
Blue 3G/1.5G
3G/1.5G Indicator
3G-SDI
1.5G-SDI
Blue 270M
270M Indicator
270M-SDI
Green XLR
XLR Input Indicator
XLR Input
Blue AES
AES Input Indicator
AES Input
Red MIC
Mic Input Indicator
Mic Input
Rear Panel LED
Function
ON
Green READY
System Ready Indicator
System Ready
Blue SDI
Coaxial Indicator
Coaxial Input
Blue Optical
Optical Indicator
Optical Input
Green XLR
XLR Output Indicator
XLR Output
Blue AES
AES Output Indicator
AES Output

4
User Manual
SDI01A-12G
Dip Switch Settings
※Please adjust the DIP switch when power off then turn on to take effect.
Phantom Power Voltage Setting
Supported Format
No.
Function
↑OFF
↓ON
1
Video Input Select
Coaxial Input
Optical Input
2
Audio Mode
Audio Extractor
Audio Embedder
3
Audio Select
4↑3↑= XLR
4↑3↓= RCA
4
4↓3↑= MIC
4↓3↓= AES
5
Scaler Setting
6↑5↑= Pass Through
6↑5↓= 1080p@60Hz
6
6↓5↑= 3840x2160@60Hz
6↓5↓= User Define
Default 4096x2160p@60Hz
7
Reserve
8
HDCP Setting
Without HDCP
With HDCP
Jumper No.
Phantom Voltage
JP5 Short
48V
JP6 Short
24V
JP7 Short
18V (OEM Version)
JP5, JP6, JP7 All open
12V
SDI Standard
SMPTE 2082-10 Mode 1
12G-SDI
SMPTE 2081-10 Mode 2
6G-SDI
SMPTE 425-1 3GA & 3GB
3G-SDI
SMPTE 425-1 3GB-DS
3G-SDI
SMPTE 292
1.5G-SDI

5
User Manual
SDI01A-12G
SDI Resolution and Frame Rate
HDMI Resolution and Frame Rate
Scaler Resolution and Frame Rate
※The scaler doesn’t process the format of interlace and progressive segmented frame, it will directly
pass-through original format from the input source.
SDI Resolution
SDI Frame Rate
SDI Sampling
SDI Audio
4096x2160
60p, 59.94p, 50p, 48p, 47.95p,
30p, 29.97p, 25p, 24p, 23.98p
4:4:4/4:2:2
32-CH 48KHz 24-Bit
3840x2160
60p, 59.94p, 50p, 48p, 47.95p,
30p, 29.97p, 25p, 24p, 23.98p
2048x1080
60p, 60i, 59.94p, 59.94i, 50p, 50i,
48p, 48i, 47.95p, 47.95i, 30p, 30psf,
29.97p, 29.97psf, 25p, 25psf, 24p,
24psf, 23.98p, 23.98psf
1920x1080
60p, 60i, 59.94p, 59.94i, 50p, 50i,
48p, 48i, 47.95p, 47.95i, 30p, 30psf,
29.97p, 29.97psf, 25p, 25psf, 24p,
24psf, 23.98p, 23.98psf
1280x720
60p, 59.94p, 50p, 48p, 47.95p,
30p, 29.97p, 25p, 24p, 23.98p
HDMI Resolution
HDMI Frame Rate
HDMI Sampling
HDMI Audio
4096x2160
60p, 59.94p, 50p, 48p, 47.95p,
30p, 29.97p, 25p, 24p, 23.98p
4:4:4/4:2:2
8-CH 48KHz 24-Bit
3840x2160
60p, 59.94p, 50p, 48p, 47.95p,
30p, 29.97p, 25p, 24p, 23.98p
2048x1080
60p, 60i, 59.94p, 59.94i, 50p, 50i,
48p, 48i, 47.95p, 47.95i, 30p,
29.97p, 25p, 24p, 23.98p
1920x1080
60p, 60i, 59.94p, 59.94i, 50p, 50i,
48p, 48i, 47.95p, 47.95i, 30p,
29.97p, 25p, 24p, 23.98p
1280x720
60p, 59.94p, 50p, 48p, 47.95p,
30p, 29.97p, 25p, 24p, 23.98p
HDMI Resolutions
HDMI Frame Rates
4096x2160
60, 50Hz
3840x2160
60, 50Hz
1920x1080
60, 50Hz
1280x720
60, 50Hz
720x576p
50Hz
640x480p
60Hz

6
User Manual
SDI01A-12G
Trouble Shooting
1. We strongly recommend using high quality 75Ωcoaxial cables, bad quality of cable may affect the
connection stability and transmission distance.
2. SD-SDI (480i & 576i) in the SMPTE 292 standard 270M is not supported.
3. Any change of HDCP settings must reboot to take effect.

7
User Manual
SDI01A-12G
Specification
ITEM NO.
SDI01A-12G
Support
Compliance
SMPTE 2082-10 Mode 1 (12G-SDI)
SMPTE 2081-10 Mode 2 (6G-SDI)
SMPTE 425-1 3GA & 3GB (3G-SDI)
SMPTE 425-1 3GB-DS (3G-SDI)
SMPTE 292 (1.5G-SDI)
HDMI 2.0
HDCP 2.2
Max. Video Resolution
12G-SDI, 4096x2160@60Hz HDMI
Transmission Distance
10KM over Single Mode Fiber Optic Cable, 100M over Coaxial Cable
Ports & Interfaces
Video Input
1 x 75ΩBNC, 1 x Video SMPTE SFP+
Video Output
1 x HDMI Type A
Video Loop-out
1 x 75ΩBNC, 1 x Video SMPTE SFP+
Audio Interface
2 x XLR Male Jack
2 x XLR Female Combo 6.4 Jack
2 x 10KΩRCA
Power Interface
1 x (5.5 x 2.1mm) DC Jack
Firmware Update
1 x Micro USB
Power
Power Supply
DC 12V Regulated
Power Consumption
1.0A (Typical), 1.2A (Maximum)
Ambient Temperature
Operation
0 to 50℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
253 x 162.5 x 40mm
Weight
1030g
