Scanstrut SPH-8-W User manual

IMPORTANT
Helm Pods are only compatible with marine electronics devices as stated in the latest Scanstrut Product Guide – subject to change
without prior notice.
Use with unapproved products,or overloading,invalidates any warranty.
No liability is accepted for damage caused by incorrect installation.
The installation and assembly must be regularly inspected for evidence of damage or loose parts.
This product has been designed specifically for the mounting of approved marine electronics devices under normal boating
conditions.
This product is designed to be fitted to pedestal guards manufactured from stainless steel tubing,Ø25-33.7mm [1”- 1.33”] with wall
thicknesses of 1.5mm[1/16”] minimum.
For installations that differ from those stated here, please consult Scanstrut head office.
Scanstrut Scanpod Installation Instructions
®
INSTALLATION SOLUTIONS FOR MARINE ELECTRONICS
HELM POD

x1
x1
Parts List
Pod Front
Pod Back
x8
60541
x8
Hole Saw
ø25mm (1")
Tools Required
Power drill
Jigsaw/Spiral
Saw
Posidriv No. 3
Screwdriver
6
8 x 60541
8 x 60545
60545
3
x2
2
4
5
910
8
1
Short Saddle Pack Long Saddle Pack
SPH-8 SPH-12,15,SYSTEM
x2 x2
Drill Bit
ø9.5mm (3/8")
13mm Socket
Socket Wrench
+ Extension
ø9.5mm (3/8”)
ø25mm (1”)
SPH-8 used in all illustrations
7
For ø25mm (1“) tube: ø20mm (25/32”) hole saw
For ø32mm (1 1/4”) tube: ø25mm (1”) hole saw
60042 60043
1x 190SPH3
1x 10SPSADDLE - S
1x 190SPH4
2x 60453
4x 60452 4x 60547
2x 190SPH3
1x 10SPSADDLE - L
6x 60452 6x 60547
3x 60453
2x 190SPH4
190SPH4
10SPSADDLE - S
8x 60452
8x 60547
2x 190SPH3
4x 60453
01-02-11 Issue 1
x8
60452
