Schuchmann BASTI User manual

Instructions for use.
basti. The versatile bathing and shower cradle.
basti.

Many thanks.
Dear Customer
At this point we would like to thank you for placing your trust in our company and
for purchasing our product. We ask you to read through the Instructions for use carefully
prior to initial commissioning of the product, and to observe them. Please note that
guidelines and representations in these Instructions for use may deviate from your product
due to diering equipment. We reserve the right to make technical modifications.
Important information!
Ensure that these Instructions for use remain with the product.
Your schuchmann Team

03 Contents.
1. Preparation. ................................................................................ 05
1.1 Delivery............................................................................................................................05
1.2 Safety measures prior to use ..............................................................................05
1.3 Safe disposal...............................................................................................................05
1.3.1 Packaging...........................................................................................................05
1.3.2 Product................................................................................................................05
1.4 Where to store the Instructions for use..........................................................05
2. Product description. .................................................................... 06
2.1 Material information ................................................................................................06
2.2 Transport / handling ..............................................................................................06
2.3 Application areas, use according to the intended purpose .............06
2.3.1 Indication ...........................................................................................................06
2.3.2 Contraindications .........................................................................................06
2.4 Use not in accordance with the intended purpose / warning gui-
delines...................................................................................................................................07
2.5 Equipment for basic model.................................................................................08
2.6 List of accessories....................................................................................................08
2.7 Product overview......................................................................................................08
3. Settings. ..................................................................................... 09
3.1 Backrest .........................................................................................................................09
3.2 Headrest .......................................................................................................................09
3.3 Calf support................................................................................................................09
3.4 Chest and leg strap.................................................................................................10
4. Accessories. ................................................................................ 10
4.1 Head guide pad.........................................................................................................10
4.2 Additional cover ........................................................................................................10
4.3 Additional retaining strap...................................................................................... 11
4.4 Shower cradle sub-frame ..................................................................................... 11
4.5 Sub-frame settings.................................................................................................. 12
5. Cleaning and maintaining. .......................................................... 14
5.1 Cleaning and disinfecting .....................................................................................14
5.1.1 Cleaning ...............................................................................................................14
5.1.2 Disinfection.........................................................................................................14
5.2 Servicing ........................................................................................................................14
5.3 Maintenance ...............................................................................................................14
5.4 Spare parts .................................................................................................................. 15
5.5 Duration of use and re-use.................................................................................. 15
6. Technical data. ............................................................................ 16
6.1 Dimensions bathing and shower cradle ........................................................ 16
6.2 Dimensions sub-frame ........................................................................................... 17

04 Contents.
7. Guarantee. .................................................................................. 17
8. Identication. ............................................................................. 18
8.1 EU Declaration of Conformity..............................................................................18
8.2 Serial number / date of manufacture............................................................ 19
8.3 Product version .......................................................................................................... 19
8.4 Issue of the document ........................................................................................... 19
8.5 Name and address of the manufacturer, specialist dealer sup-
plying the product ........................................................................................................... 19

05 1. Preparation.
1.1 Delivery
On receiving the product, please check it for completeness, lack of faults
and any transport damage. Inspect the goods in the presence of your
forwarder. Should transport damage have occurred, please arrange for
an inventory (determination of the faults) to be made in the presence of
the forwarder. Please send a complaint in writing to the specialist dealer
responsible.
1.2 Safety measures prior to use
The correct use of the product requires a detailed and careful instruction
of the user or the accompanying person. We ask you to read through the
instructions for use carefully prior to initial commissioning of the product,
and to observe them. It is possible that product parts that get in contact
with the skin may heat up in the sun. Cover these areas or protect the de-
vice from direct sunlight.
1.3 Safe disposal
In order to preserve and protect the environment, to prevent environmental
pollution and to improve the recycling of raw materials, please note the
disposal instructions in points 1.3.1 and 1.3.2.
1.3.1 Packaging
The packaging of the product should be kept for any future transport that
might be required. Should you have to return the product for repairs or in
case of a guarantee claim, please if possible use the original box so that
the product is optimally packaged. Otherwise, separate the packaging
materials for recycling according to their classification.
Do not leave packaging materials unattended, as they are a possible source of
danger.
1.3.2 Product
At the end of the product life cycle, recycle the raw materials used in the
product according to their nature (see material information under point 2.1).
1.4 Where to store the Instructions for use
Please store these Instructions for use carefully and ensure that these
Instructions for use remain with the product in case of re-use. Should you
lose the instructions, you can always download an updated version at
www.schuchmann.de .

06 2. Product description.
2.1 Material information
The stainless steel main frame is powder-coated and free from corrosion.
The frames of the backrest and headrest as well as the calf support is
made of aluminium, are black powder-coated and free from corrosion. The
internal structure of the ratchet joints and the bowden cables are made
from stainless steel and are free from corrosion. The removable and was-
hable net cover is made from 100% polyester.
2.2 Transport / handling
basti. can be handled without any problems due to its low dead weight.
You can lift the bathing cradle at any point. To transport the bathing crad-
le, adjust the settings to the most compact dimensions.
2.3 Application areas, use according to the intended purpose
The basti. bathing and shower cradle is a medical product of risk class 1
and is suited exclusively for use in bathtubs, showers, in the sandbox and
on the beach. It supports users who cannot sit unaided and oers addi-
tional hold thanks to retaining straps. Any other use or use over and abo-
ve this purpose shall be considered not in accordance with the intended
purpose.
2.3.1 Indication
The basti. bathing and shower cradle is suited for:
• Users who are unable to sit or lie down in the bathtub due to dysfuncti-
on of the lower limb with significantly reduced
or complete failed joint mobility
• Users with limitation to the muscular strength of the lower extremities
• Users with damage to the nervous system, damage to
neuromusculoskeletal functions
• Users with damage to the movement-related function and/or muscle
function and/or with damage to the neurological function
• Users with movement patterns with significantly reduced or failed trunk
control or reduced or failed body control
2.3.2 Contraindications
In general, the indication should be accompanied by a doctor/orthopae-
dist. It should therefore be clarified prior to procurement whether cont-
raindications exist for the patient. In general, any type of pain represents
a contraindication.

07
2.4 Use not in accordance with the intended purpose / warning guide-
lines
• Ensure that the bathing and shower cradle is used by one user only.
• Never leave the user seated on the bathing and shower cradle without
supervision.
• Correct use of the bathing and shower cradle requires precise and ca-
reful training of the accompanying person.
• The max. load (see Point 6.1) must not be exceeded.
• Do not use the bathing and shower cradle if it has defective, worn or
missing parts.
• For reasons of fire safety, the bathing and shower cradle may not
be placed close to an open fire or any other strong source of heat such
as electric or gas heaters.
• Use only accessories and spare parts made by Schuchmann, otherwise
you will compromise the safety of the user.
• Only use the bathing and shower cradle if all components have been
correctly mounted and adjusted.
• The bathing and shower cradle may not be used to transport people.
• Users who have diculty reading must have someone read these
instructions for use aloud to that they understand how to use the
bathing cradle.
2. Product description.

08 2. Product description.
Headrest
Backrest
Head angle adjustment
Cover with pelvic mould de-
pression and adjustable seat
support for ischiatic bone
Frame, black
powder-coated
Chest strap
Head guide pad
adjustable with hook and loop
closure
Knee angle adjustment
Lower leg support
Back rest angle
adjustment
Leg strap
2.5 Equipment for basic model
• Frame, black powder coated
• removable and washable cover
• Backrest, knee area and head guide pad angle adjustment
• Chest strap
2.6 List of accessories
• Head guide pad, adjustable with hook and loop closure
• additional retaining strap, adjustable with hook and loop closure for
the chest and pelvic area
• Sub-frame shower cradle, movable with 4 braked castors
• Cover with pelvic mould depression and adjustable seat support for
ischiatic bone
2.7 Product overview
The Fig. below is intended to show you the designation of the most im-
portant components as well as the terms which you will find in these Inst-
ructions for use.

09 3. Settings.
basti. transforms any shower and bathing situation into child's play.
Thanks to the backrest and knee angle adjustment, it can be put
optimally to a desired position that is comfortable for the user. Thanks to
the folding head part, washing the hair becomes eortless and due to the
low seat height only a small quantity of water is needed when bathing.
3.1 Backrest
The backrest can be adjusted from 90° to 180°.
For basti. size 1 to 3, pull on the loop (A) on the
rear of the backrest and bring the backrest
to the desired position. Release the loop after
positioning and ensure that the ratchet joints
have engaged.
For size 4 release the two stainless steel ratchet
joints (B), to adjust the backrest.
3.2 Headrest
The headrest (C) can be set from 0° to 90°. Press
the pushbuttons (D) on both sides and bring the
headrest to the desired position. After positio-
ning release the pushbuttons and ensure that
the ratchet joints have engaged.
3.3 Calf support
The calf support (E) can be adjusted between
0° and 90°. Press the pushbuttons (F) on both
sides and bring the calf support to the desired
position. After positioning release the pushbut-
tons and ensure that the ratchet joints have
engaged.
The ratchet joints must engage after each adjust-
ment!
A
B
D
F
E
C

10
3.4 Chest and leg strap
To attach the chest and leg strap (A), loop
it around the bathing cradle at the desired
position and fix it from the rear using the
hook and loop closure. The width of the strap
can be adjusted using additional hook and
loop closures on the sides.
3. Settings.
A
4. Accessories.
Settings and adjustments to the product or accessories may only be made
by people who have been given the necessary instructions by a medical
product advisor. Please ensure that none of the user's extremities are in
the respective area when making adjustments of any kind to minimise the
risk of injury.
4.1 Head guide pad
• adjustable
• with hook and loop closure
Attachment
To attach the head guide pad (B), loop the
strap around the headrest at the desired
position and fix it from the rear using the
hook and loop closures. The two head guide
pads can be adjusted horizontally.
4.2 Additional cover
• with pelvic mould depression
• with adjustable seat support for ischiatic
bone
• with hook and loop closure
B

11
The pelvic mould depression (A) also stabili-
ses the seating position of smaller users and
forms the basis for upright seating. Moreo-
ver, the adjustable seat support for ischiatic
bone (B) defines the seating surface.
Attachment
Bring the backrest in a position almost
parallel to the seat surface and pull the
cover over the frame. Fix it using the hook
and loop closure below the seat surface.
Make sure that the hook and loop
closures are closed!
4.3 Additional retaining strap
• adjustable
• with hook and loop closure
• for the chest or pelvic area
Attachment
To attach the additional retaining strap (A),
loop it around the frame at the desired po-
sition and fix it using the hook and loop clo-
sure.
4.4 Shower cradle sub-frame
• movable
• with 4 braked castors
• Total width: 57 cm
• Lying height: 61* - 66 cm
• Total length: 92 cm
* In combination with the cover with pelvic mould depression
4. Accessories.
C
A
B

12 4. Accessories.
Attachment on the sub-frame
Insert the rear crossbar (A) on the bathing
cradle first into the rear mounts (B) and then
into the latch-in mounts of the sub-frame (C).
Move the bathing cradle and make sure that
it has correctly engaged in the sub-frame.
The width of the mounts (B+C) can be adjus-
ted and can thus be adjusted to the indivi-
dual size (see Point 4.5).
To take out the basti. bathing cradle, simply
pull on the pull strap (D) and lift o the ba-
thing cradle with the other hand.
Make sure that the hook and loop
closures are closed!
4.5 Sub-frame settings
The rear mounts (E) and the latch-in mounts (F) must be fixed at dierent
positions for the respective sizes of basti.
basti. bathing and shower cradle settings Size 1
For size 1, put the mounts (E) and the latch-in mounts (F) inthe following
positions:
B
C
A
D
E
F

13 4. Accessories.
basti. bathing and shower cradle settings Size 2 + 3
For sizes 2+3 put the mounts (A) and the latch-in mounts (B) in the following
positions:
basti. bathing and shower cradle settings Size 4
For size 4, put the mounts (C) and the latch-in mounts (D) in the following
positions:
A
B
C
D

14 5. Cleaning and maintaining.
5.1 Cleaning and disinfecting
5.1.1 Cleaning
Please clean all frame elements regularly with a sponge
or damp cloth; making sure that water droplets are re-
moved. Please clean with a mild household detergent
for severer dirt. Thorough drying of the cleaned areas
is important.
All fabrics that cannot be removed can be wiped with
a moist cloth. For all removable fabrics please pay at-
tention to the sewn-in care labels (such as A+ B) on the
respective element.
Please also pay attention to our general clea-
ning and hygiene advice. This can be found at
www.schuchmann.de/mediathek.
5.1.2 Disinfection
Various products can be used for surface disinfection of metal and plastic
parts.
Liquid disinfectants are available as ready-to-use solutions that are spray-
ed on and evenly applied with a soft cloth. Alternatively, wipes pre-soaked
with disinfectant can be used to wipe the products over the entire surface.
In both cases, care must be taken to ensure complete wetting. Disinfection
in fully automatic disinfection systems is also possible and recommended.
The exposure times may vary and can be found in the manufacturer's ins-
tructions for the products used.
5.2 Servicing
Please carry out a visual inspection on a daily basis and regularly check
the product for cracks, breaks, missing parts and malfunctions. In case of a
defect or malfunction, please contact the specialist dealer who supplied
you with the product (see Point 8.5).
5.3 Maintenance
The product does not require maintenance.
7190045
A
Obermaterial/
top cloth/dessus:
100% Polyester
B

15 5. Cleaning and maintaining.
5.4 Spare parts
Use only original accessories and original spare parts from Schuchmann,
as otherwise the safety of the user is endangered and the warranty expires.
To order spare parts, please contact the supplying specialist dealer (see
point 8.5) stating the serial number of the product. Necessary spare parts
and accessories must only be installed by trained personnel.
5.5 Duration of use and re-use
The expected duration of use of our product, dependent on the usage in-
tensity and amount of re-use, totals up to "8" years if the usage takes place
in accordance with the information in these Instructions for use. It may be
possible to use the product over and above this time period if it is in a
safe condition. The expected duration of use does not refer to wear parts,
such as for example wheels, gas pressure springs,... . The maintenance and
evaluation of the condition, and if applicable the potential for re-use, must
be decided by the specialist dealer.
The product is suited for re-use. Prior to forwarding, please follow the clea-
ning and disinfection instructions stated in Point 5.1. Accompanying docu-
ments such as these Instructions for use are part of the product and must
be passed on to the new user. No disassembly is required prior to re-use. In
the case of storage, it is recommended to fold the product to the smallest
dimension to save space.
Should a serious incident occur during the service life of the product despite
being used as intended
, this must be reported immediately to the manufactu-
rer and the competent authority.

16 6. Technical data.
6.1 Dimensions bathing and shower cradle
Size 1 Size 2 Size 3 Size 4
ASeat width 30cm 35 cm 35cm 40cm
B Seat depth 30cm 34 cm 38cm 44 cm
C Back height 45cm 61cm 71cm 82 cm
D Standing space length 69cm 74cm 88 cm 93 cm
ELower leg length 19cm 20 cm 28 cm 28 cm
Back angle 90° - 180 ° 90° - 180 ° 90° - 180 ° 90° - 180 °
Knee angle 0° - 90 ° 0° - 90 ° 0° - 90 ° 0° - 90 °
Headrest angle 0° - 90 ° 0° - 90 ° 0° - 90 ° 0° - 90 °
Seat height 0* / 5 cm 0* / 5 cm 0* / 5 cm 0* / 5 cm
max. load 35 kg 45kg 55 kg 75 kg
Weight 4 kg 4.1kg 4.3kg 4.8 kg
* In combination with the cover with pelvic mould depression

17 6. Technical data
ALength 92cm
BWidth 57cm
CSeat height with sub-frame 61* / 66 cm
* In combination with the cover with pelvic mould
depression
6.2 Dimensions sub-frame
7. Guarantee.
The two-year statutory guarantee period shall apply for all products. It
starts with the delivery or handover of the goods. Should a verifiable
material or manufacturing fault occur within this time period, we shall, after
carriage paid return to us, view the indicated damage and, if applicable,
either repair or deliver a new product at our discretion.

18 8. Identication.
8.1 EU Declaration of Conformity
EU Konformitätserklärung
EU Declaration of Conformity
Firma / Company Schuchmann GmbH & Co. KG
Rudolf-Runge-Str. 3 · 49143 Bissendorf · Deutschland / Germany
Tel. [phone] / 40 71 00 · Fax [phone]
erklärt in alleiniger Verantwortung, dass das nachfolgend genannte Produkt der Risikoklasse 1
declares under our sole responsibility that the following product(s) of Class 1 Medical Devices
Datei: Konformitätserklärung basti Stand: Rev. 2.0 Seite: 1
„basti.“Bade- und Duschliege / bathing and shower bench
Art.-Nr. / Item-No.: 56 01 000, 56 02 000, 56 03 000, 56 04 000
Basis UDI-DI /
Basic UDI-DI: 4251040200004000560XXXXBV
den einschlägigen Bestimmungen der im folgenden aufgeführten Richtlinien und Standards entspricht:
is / are in conformity with the requirements of the below listed directives and standards:
Verordnung (EU) 2017/745 über Medizinprodukte vom 05. April 2017
Regulation (EU) 2017/745 on medical devices of 5 April 2017
DIN EN 12182:2012 Technische Hilfen für behinderte Menschen
T
echnical aids for disabled persons
DIN EN ISO 14971:2013 Medizinprodukte - Anwendung des Risikomanagements auf Medizinprodukte
Medical devices - Application of risk management to medical devices
Diese Konformitätserklärung gilt nur für Produkte mit den oben genannten Artikelnummern und
ist gültig bis zum 31.12.2023.
This declaration of conformity applies only for products with above-named Item-numbers
and is valid until 31.12.2023.
Datum / Date: 01.04.2020
Unterschrift /
Sign:
Name /
Name: Torsten Schuchmann
Funktion /
Function: Sicherheitsbeauftragter für Medizinprodukte / Safety officer for medical devices

19 8. Identication.
8.2 Serial number / date of manufacture
The serial number, the manufacturer date as well as other details can
be found on the type plate that can be found on each of our products
(A= bathing cradle, B= sub-frame).
8.3 Product version
The basti. bathing and shower cradle is available in four sizes and can be
complemented with various accessories (see Point 4).
8.4 Issue of the document
Instructions for use basti. - Change status I; issue 09.2020
8.5 Name and address of the manufacturer, specialist dealer supplying
the product
This product was manufactured by:
This product has been delivered by the following specialist dealer:
Schuchmann GmbH & Co. KG
Rudolf-Runge-Str. 3 · 49143 Bissendorf · Germany
Phone [phone] / 40 71 00 · Fax [phone]
[e-mail] · www.schuchmann.de
A
B
Product name
Item number
Serial number
schuchmann.de • [e-mail] • Fon +49 (0) 5402 / 40 71 00
Rudolf-Runge-Str. 3 • 49143 Bissendorf • Germany
Barcode UDI-DI Barcode UDI-PI
UDI-DI
SN / UDI-PI
Type
Product
Max. load
Size
MD
Size
max. load
Date of manufacture
Product labelling in accordance with MDR

schuchmann.de GA 56 - EN_1.0
