Schumacher Electric SpeedCharge SEM-1562A User manual

0099001192WB-00
Model / Modelo: SEM-1562A
OWNER’S MANUAL
MANUAL DEL USUARIO
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.
FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY OR DEATH.
LEA EL MANUAL COMPLETO ANTES DE UTILIZAR ESTE
PRODUCTO. CUALQUIER FALLA PODRÍA RESULTAR EN SERIAS LESIONES O
PODRÍA SER MORTAL.
DO NOT RETURN THIS PRODUCT TO THE STORE!
Call Customer Service for Assistance: 800-621-5485
¡NO LO DEVUELVA ESTE PRODUCTO A LA TIENDA!
Llame a Servicios al Cliente para Asistencia: 800-621-5485
Automatic Battery Charger
Cargador de batería automático
Voltage / Tensión: 6, 12
Amperage / Amperaje: 1.5

• 1 •
IMPORTANT:
READ AND SAVE THIS SAFETY AND INSTRUCTION MANUAL.
SAVE THESE INSTRUCTIONS – This manual will show you
how to use your charger safely and effectively. Please read,
understand and follow these instructions and precautions
carefully, as this manual contains important safety and operating
instructions. The safety messages used throughout this manual
contain a signal word, a message and an icon.
The signal word indicates the level of the hazard in a situation.
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury to the
operator or bystanders.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury to the
operator or bystanders.
Indicates a potentially hazardous situation which, if not
avoided, could result in moderate or minor injury to the
operator or bystanders.
Indicates a potentially hazardous situation which, if not
avoided, could result in damage to the equipment or
vehicle or property damage.
Pursuant to California Proposition 65, this product contains
chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm.
IMPORTANT SAFETY INSTRUCTIONS –1.
SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions
RISK OF ELECTRIC SHOCK OR FIRE.
Keep out of reach of children.1.1
Do not expose the charger to rain or snow.1.2
Use only recommended attachments.1.3
Use of an attachment not recommended
or sold by Schumacher®Electric Corporation may result in a risk
of re, electric shock or injury to persons or damage to property.

• 2 •
To reduce the risk of damage to the electric plug or cord, pull by1.4 the plug rather than the cord when disconnecting the charger.
An extension cord should not be used unless absolutely necessary.1.5
Use of an improper extension cord could result in a risk of re and
electric shock. If an extension cord must be used, make sure:
That the pins on the plug of the extension cord are the same• number, size and shape as those of the plug on the charger.
That the extension cord is properly wired and in good• electrical condition.
That the wire size is large enough for the AC ampere rating of•
the charger as specied in section 8.
To reduce the risk of electric shock, unplug the charger from the1.6 outlet before attempting any maintenance or cleaning. Simply
turning off the controls will not reduce this risk.
Do not operate the charger with a damaged cord or plug; have1.7
the cord or plug replaced immediately by a qualied service
person. (Call customer service at: 1-800-621-5485.)
Do not operate the charger if it has received a sharp blow, been1.8
dropped or otherwise damaged in any way; take it to a qualied
service person. (Call customer service at: 1-800-621-5485.)
Do not disassemble the charger; take it to a qualied service 1.9 person when service or repair is required. Incorrect reassembly
may result in a risk of re or electric shock. (Call customer
service at: 1-800-621-5485.)
RISK OF EXPLOSIVE GASES.
WORKING IN THE VICINITY OF A LEAD-ACID1.10
BATTERY IS DANGEROUS. BATTERIES GENERATE
EXPLOSIVE GASES DURING NORMAL BATTERY
OPERATION. FOR THIS REASON, IT IS OF UTMOST
IMPORTANCE THAT YOU FOLLOW THE INSTRUCTIONS
EACH TIME YOU USE THE CHARGER.
To reduce the risk of a battery explosion, follow these1.11 instructions and those published by the battery manufacturer
and the manufacturer of any equipment you intend to use in the
vicinity of the battery. Review the cautionary markings on these
products and on the engine.

• 3 •
This charger employs parts, such as switches and circuit breakers,1.12 that tend to produce arcs and sparks. If used in a garage, locate
this charger 18 inches (46 cm) or more above oor level.
PERSONAL PRECAUTIONS2.
RISK OF EXPLOSIVE GASES.
NEVER smoke or allow a spark or ame in the 2.1
vicinity of a battery or engine.
Remove personal metal items such as rings, bracelets,2.2
necklaces and watches when working with a lead-acid battery.
A lead-acid battery can produce a short-circuit current high enough
to weld a ring or the like to metal, causing a severe burn.
Be extra cautious to reduce the risk of dropping a metal tool2.3 onto the battery. It might spark or short-circuit the battery or
other electrical part that may cause an explosion.
Use this charger for charging LEAD-ACID batteries only. It is2.4 not intended to supply power to a low voltage electrical system
other than in a starter-motor application. Do not use this battery
charger for charging dry-cell batteries that are commonly used
with home appliances. These batteries may burst and cause
injury to persons and damage to property.
NEVER charge a frozen battery.2.5
NEVER overcharge a battery.2.6
Consider having someone close enough by to come to your aid2.7 when you work near a lead-acid battery.
Have plenty of fresh water and soap nearby in case battery acid2.8 contacts your skin, clothing or eyes.
Wear complete eye and body protection, including safety2.9 goggles and protective clothing. Avoid touching your eyes while
working near the battery.
If battery acid contacts your skin or clothing, immediately2.10 wash the area with soap and water. If acid enters your eye,
immediately ood the eye with cold running water for at least 10
minutes and get medical attention right away.
If battery acid is accidentally swallowed, drink milk, the whites of2.11 eggs or water. DO NOT induce vomiting. Seek medical attention
immediately.

• 4 •
PREPARING TO CHARGE3.
RISK OF CONTACT WITH BATTERY ACID.
BATTERY ACID IS A HIGHLY CORROSIVE
SULFURIC ACID.
If it is necessary to remove the battery3.1
from the vehicle to charge it, always remove the
grounded terminal rst. Make sure all of the accessories in the
vehicle are off to prevent arcing.
Be sure the area around the battery is well ventilated while the3.2 battery is being charged.
Clean the battery terminals before charging the battery. During3.3 cleaning, keep airborne corrosion from coming into contact
with your eyes, nose and mouth. Use baking soda and water to
neutralize the battery acid and help eliminate airborne corrosion.
Do not touch your eyes, nose or mouth.
Add distilled water to each cell until the battery acid reaches the3.4
level specied by the battery manufacturer. Do not overll. For
a battery without removable cell caps, such as valve regulated
lead acid batteries (VRLA), carefully follow the manufacturer’s
recharging instructions.
Read, understand and follow all instructions for the charger,3.5 battery, vehicle and any equipment used near the battery
and charger. Study all of the battery manufacturer’s specic
precautions while charging and recommended rates of charge.
Determine the voltage of the battery by referring to the vehicle3.6 owner’s manual and make sure that the output voltage selector
switch is set to the correct voltage. If the charger has an
adjustable charge rate, charge the battery in the lowest rate rst.
Make sure that the charger cable clips make tight connections.3.7
CHARGER LOCATION4.
RISK OF EXPLOSION AND
CONTACT WITH BATTERY ACID.
Locate the charger as far away4.1
from the battery as the DC cables permit.
Never place the charger4.2
directly above the battery being charged; gases from the battery
will corrode and damage the charger.

• 5 •
Do not set the battery on top of the charger.4.3
Never allow battery acid to drip onto the charger when reading4.4
the electrolyte specic gravity or lling the battery.
Do not operate the charger in a closed-in area or restrict the4.5 ventilation in any way.
DC CONNECTION PRECAUTIONS5.
Connect and disconnect the DC output clips only after setting5.1 all of the charger switches to the “off” position (if applicable) and
removing the AC plug from the electrical outlet. Never allow the
clips to touch each other.
Attach the clips to the battery and chassis, as indicated in5.2 sections 6 and 7.
FOLLOW THESE STEPS WHEN BATTERY IS INSTALLED6.
IN VEHICLE
A SPARK NEAR THE BATTERY MAY
CAUSE A BATTERY EXPLOSION.
TO REDUCE THE RISK OF A SPARK
NEAR THE BATTERY:
Position the AC and DC cables6.1
to reduce the risk of damage by the hood, door and moving or hot
engine parts. NOTE: If it is necessary to close the hood during the
charging process, ensure that the hood does not touch the metal
part of the battery clips or cut the insulation of the cables.
Stay clear of fan blades, belts, pulleys and other parts that can6.2 cause injury.
Check the polarity of the battery posts. The POSITIVE (POS,6.3 P, +) battery post usually has a larger diameter then the
NEGATIVE (NEG, N, -) post.
Determine which post of the battery is grounded (connected) to6.4 the chassis. If the negative post is grounded to the chassis (as
in most vehicles), see step 6.5. If the positive post is grounded
to the chassis, see step 6.6.
For a negative-grounded vehicle, connect the POSITIVE6.5 (RED) clip from the battery charger to the POSITIVE (POS,
P, +) ungrounded post of the battery. Connect the NEGATIVE
(BLACK) clip to the vehicle chassis or engine block away from
the battery. Do not connect the clip to the carburetor, fuel lines

• 6 •
or sheet-metal body parts. Connect to a heavy gauge metal part
of the frame or engine block.
For a positive-grounded vehicle, connect the NEGATIVE6.6 (BLACK) clip from the battery charger to the NEGATIVE (NEG,
N, -) ungrounded post of the battery. Connect the POSITIVE
(RED) clip to the vehicle chassis or engine block away from the
battery. Do not connect the clip to the carburetor, fuel lines or
sheet-metal body parts. Connect to a heavy gauge metal part of
the frame or engine block.
Connect charger AC supply cord to electrical outlet.6.7
When disconnecting the charger, turn all switches to off,6.8 disconnect the AC cord, remove the clip from the vehicle chassis
and then remove the clip from the battery terminal.
See CALCULATING CHARGE TIME for length of charge6.9 information.
FOLLOW THESE STEPS WHEN BATTERY IS OUTSIDE7.
VEHICLE
A SPARK NEAR THE BATTERY MAY
CAUSE A BATTERY EXPLOSION.
TO REDUCE THE RISK OF A SPARK
NEAR THE BATTERY:
Check the polarity of the7.1
battery posts. The POSITIVE (POS, P, +) battery post usually
has a larger diameter than the NEGATIVE (NEG, N, -) post.
Attach at least a 24-inch (61 cm) long 6-gauge (AWG) insulated7.2 battery cable to the NEGATIVE (NEG, N, -) battery post.
Connect the POSITIVE (RED) charger clip to the POSITIVE7.3 (POS, P, +) post of the battery.
Position yourself and the free end of the cable you previously7.4 attached to the NEGATIVE (NEG, N, -) battery post as far away
from the battery as possible – then connect the NEGATIVE
(BLACK) charger clip to the free end of the cable.
Do not face the battery when making the nal connection.7.5
Connect charger AC supply cord to electrical outlet.7.6
When disconnecting the charger, always do so in the reverse7.7
order of the connecting procedure and break the rst connection
while as far away from the battery as practical.

• 7 •
A marine (boat) battery must be removed and charged on shore.7.8 To charge it onboard requires equipment specially designed for
marine use.
GROUNDING AND AC POWER CORD CONNECTIONS8.
RISK OF ELECTRIC SHOCK OR FIRE.
This battery charger is for use on a8.1
nominal 120-volt circuit. The plug must be
plugged into an outlet that is properly installed
and grounded in accordance with all local codes
and ordinances. The plug pins must t the receptacle (outlet).
Do not use with an ungrounded system.
8.2 Never alter the AC cord or plug provided – if it
does not t the outlet, have a proper grounded outlet installed by
a qualied electrician. An improper connection can result in a
risk of an electric shock or electrocution.
NOTE: Pursuant to Canadian Regulations, use of an adapter
plug is not allowed in Canada. Use of an adapter plug in the
United States is not recommended and should not be used.
Recommended minimum AWG size for extension cord:8.3
100 feet (30.5 meters) long or less–use an 18 gauge • (0.82 mm2) extension cord.
Over 100 feet (30.5 meters) long–use a 16 gauge •
(1.31 mm2) extension cord.

• 8 •
FEATURES9.
1
2
3
CONNECTED1. (red) LED
CHARGING2. (yellow) LED
CHARGED3. (green) LED
Battery Clip Cable Assembly4.
Ring Terminal Cable Assembly5.
Quick-Connect Connector6.
4
5
6
ASSEMBLY INSTRUCTIONS10.
Remove all cord wraps and uncoil the cables prior to using the
battery charger.
CONTROL PANEL11.
LED Indicators
CONNECTED (red) LED lit: Indicates that there is AC power
supplied to the battery charger.
CHARGING (yellow) LED lit: Indicates the charger is
charging the battery.
CHARGING (yellow) LED ashing: Indicates the charger is
in abort mode.
CHARGED (green) LED lit: Indicates the battery is fully
charged and the charger is in maintain mode.

• 9 •
NOTE: See the Operating Instructions section for a complete
description of the charger modes.
OPERATING INSTRUCTIONS12.
This battery charger must be properly assembled in
accordance with the assembly instructions before it is used.
Charging
Ensure that all of the charger components are in place and in1. good working condition, for example, the plastic boots on the
battery clips.
Connect the battery following the connection instructions2. described in Using the Quick-Connect Cable Connectors section.
Connect the AC power following the precautions listed3. in Section 8. Make sure to place the charger on a dry,
non-ammable surface, such as metal or concrete.
If you’ve connected everything correctly, the CHARGING4.
(yellow) LED should be lit, indicating that the charger is
charging. If the CHARGING (yellow) LED does not light,
check the connections or have the battery checked/replaced.
To disconnect, reverse the procedure.5.
NOTE: This charger is equipped with an auto-start feature. It will not
supply current to the battery clips until a battery is properly connected.
Unlike traditional chargers, the clips will not spark if touched together.
USING THE QUICK-CONNECT CABLE CONNECTORS
NOTE: Never connect the clamp and ring terminal connectors
together for use in other applications, such as external battery or
other power source charging, or to extend the output cable length,
as reverse polarity and/or overcharge conditions will occur.
50 Amp Battery Clips:
Connect the end of the charger output cable to the end of the1. 50 amp battery clips cable.
Follow the steps in sections 6 and 7 to connect the output2. clips to the battery.
After a good electrical connection is made to the battery, plug3. the power cord into a grounded 120V AC electrical wall outlet.

• 10 •
Make sure to place the charger on a dry, non-ammable
surface, such as metal or concrete.
Permanent Ring Connectors:
To permanently attach it to a battery, loosen and remove1. each nut from the bolts at the battery terminals.
Connect the red positive ring connector ring to the positive2. (POS, P, +) battery terminal.
Connect the negative ring connector ring to the negative3. (NEG, N, -) battery terminal.
Replace and tighten the nuts to secure them.4.
Connect the ring connector cable assembly to the charger.5. Take care to keep both wires and plug away from hot and
moving parts.
Plug the charger power cord into a grounded 120V AC6. electrical wall outlet. Make sure to place the charger on a
dry, non-ammable surface, such as metal or concrete.
Automatic Charging Mode
When an Automatic Charge is performed, the charger switches to
the Maintain Mode (see below) automatically after the battery is
charged. For a battery with a starting voltage under 0.2 volts, use
a manual charger to pre-charge the battery for ve minutes, to get
additional voltage into the battery.
Aborted Charge
If charging can not be completed normally, charging will abort.
When charging aborts, the charger’s output is shut off, and
the CHARGING (yellow) LED will blink. To reset after an
aborted charge, unplug the charger from the AC outlet, wait a few
moments, and plug it back in.
Desulfation Mode
Desulfation could take 8 to 10 hours. If desulfation fails, charging
will abort and the CHARGING (yellow) LED will blink.
Completion of Charge
Charge completion is indicated by the CHARGED (green)
LED. When lit, the charger has stopped charging and switched to
the Maintain Mode of operation.

• 11 •
Maintain Mode (Float-Mode Monitoring)
When the CHARGED LED is lit, the charger has started
Maintain Mode. In this mode, the charger keeps the battery
fully charged by delivering a small current when necessary. If
the charger has to provide its maximum maintain current for a
continuous 12 hour period, it will go into Abort Mode (see Aborted
Charge section). This is usually caused by a drain on the battery,
or the battery could be bad. Make sure there are no loads on the
battery. If there are, remove them. If there are none, have the
battery checked or replaced.
Maintaining a Battery
The Schumacher SEM-1562A is a battery maintainer, and
maintains both 6 and 12 volt batteries, keeping them at full charge.
It can charge small batteries and maintain both small and large
batteries. If you are maintaining a fully charged large battery, you
will be properly utilizing the battery charger. However, if you use
the battery charger to charge a large battery, such as a marine
deep cycle battery, that was not fully charged, you may lose some
of the battery’s capacity. This would cause the large battery to be
unable to hold a charge and become useless. Therefore, we do not
recommend charging a large battery with this unit.
NOTE: The maintain mode technology utilized in Schumacher’s
maintainers allows you to safely charge and maintain a healthy
battery for extended periods of time. However, problems with your
battery, electrical problems in your vehicle, improper connections
or other unanticipated conditions could cause excessive current
draws, as such, occasionally monitoring your battery and the
charging process is recommended.
CALCULATING CHARGE TIME13.
Find your battery’s rating on the chart below, and note the charge
time given. The times given are for batteries with a 50% charge prior
to recharging. Add more time for severely discharged batteries.
CCA = Cold Cranking Amps
AH = Amp Hour
RC = Reserve Capacity
MAINTAIN ONLY = See Maintaining a Battery in the “Operating
Instructions” section.

• 12 •
BATTERY SIZE/RATING CHARGING TIME
SMALL
BATTERIES Motorcycle, garden tractor,
etc.
6 - 12 AH 2 ½ - 4 hrs
12 - 32 AH 5 - 13 ½ hrs
CARS/
TRUCKS 200 - 315 CCA 40 - 60 RC MAINTAIN ONLY
315 - 550
CCA 60 - 85 RC MAINTAIN ONLY
550 - 1000
CCA 80 - 190 RC MAINTAIN ONLY
MARINE/DEEP CYCLE 80 RC MAINTAIN ONLY
140 RC MAINTAIN ONLY
160 RC MAINTAIN ONLY
180 RC MAINTAIN ONLY
MAINTENANCE INSTRUCTIONS14.
Before performing maintenance, unplug and disconnect the14.1 battery charger (see Sections 6, 7 and 8).
After use, unplug the charger and use a dry cloth to wipe all14.2 battery corrosion and other dirt or oil from the terminals, cords,
and the charger case.
Ensure that all of the charger components are in place, securely14.3 attached and in good working condition, for example, the plastic
boots on the battery clips.
Servicing does not require opening the unit, as there are no14.4 user-serviceable parts.
All other servicing should be performed by qualied service 14.5 personnel.
STORAGE INSTRUCTIONS15.
Store charger unplugged, in an upright position. The cord will15.1 still conduct electricity until it is unplugged from the outlet.
Store inside, in a cool, dry place.15.2
Do not store the clips clipped together, on or around metal, or15.3 clipped to the cables.

• 13 •
If the charger is moved around the shop or transported to15.4 another location, take care to avoid/prevent damage to the
cords, clips and charger. Failure to do so could result in personal
injury or property damage.
TROUBLESHOOTING16.
PROBLEM POSSIBLE CAUSE REASON/SOLUTION
Charger
will not turn
on when
properly
connected.
AC outlet is dead
Poor electrical
connection.
Severely discharged,
but otherwise good,
battery.
Clips are not making a
good connection to the
battery.
Battery is defective.
Reverse connections
at battery.
Check for an open fuse or
circuit breaker supplying the
AC outlet.
Check the power cord and
extension cord for as loose
tting plug.
The battery may not want
to accept a charge due to
a run-down state. Allow the
charging to continue until the
battery has had a chance to
recover sufciently enough to
take a charge. If more than 20
minutes, stop charging and
have the battery checked.
Check for poor connection to
battery and frame. Make sure
connection points are clean.
Rock clips back and forth for a
better connection.
Check the battery.
Unplug the charger and
correct the lead connections.
Charger
makes a
loud buzz
or hum.
Transformer
laminations vibrate
(buzz).
Shorted Diode
Assembly or Output
Rectier Assembly (hum).
No problem, this is a normal
condition.
Have charger checked by a
qualied technician.

• 14 •
PROBLEM POSSIBLE CAUSE REASON/SOLUTION
Charging
(yellow)
LED is
ashing
Indicates the charger
is in abort mode.See “Aborted Charge” in the OPERATING INSTRUCTIONS
Section.
Battery
clips do not
spark when
touched
together.
The charger is
equipped with an
auto-start feature. It
will not supply current
to the battery clips until
a battery is properly
connected. Unlike
traditional chargers,
the clips will not spark
if touched together.
No problem, this is a normal
condition.
BEFORE RETURNING FOR REPAIRS17.
When a charging problem arises, make certain that the battery17.1 is capable of accepting a normal charge. Double check all
connections, the AC outlet for a full 120-volts, the charger clips
for correct polarity and the quality of the connections from the
cables to the clips and from the clips to the battery system. The
clips must be clean.
When a battery is very cold, partially charged or sulfated, it17.2 will not draw the full rated amperes from the charger. It is both
dangerous and damaging to a battery to force higher amperage
into it than it can effectively use in recharging.
When an UNKNOWN OPERATING PROBLEM arises, please17.3 read the complete manual and call the customer service number
for information that will usually eliminate the need for return.
If the above solutions do not eliminate the problem or for information
about troubleshooting, call toll-free from anywhere in the U.S.A
1-800-621-5485, 7:00 am to 5:00 pm Central Time
Monday through Friday

• 15 •
SPECIFICATIONS18.
Input Voltage...................................................................... 120V AC
Output Current Rating.....................................................12V – 1.5A
6V – 1.5A
Maximum Charge Voltage.............................................12V – 14.8V
6V – 7.4V
Maintain Voltage ...........................................................12V – 13.3V
6V – 6.6V
Size.................................................................. 2⅝" H x 6" W x 3" D
Weight....................................................................................2½ lbs
REPLACEMENT PARTS19.
Battery Clip Cable Assembly........................................ 3899001235
Ring Terminal Cable Assembly .................................... 2299001950
LIMITED WARRANTY20.
SCHUMACHER ELECTRIC CORPORATION, 801 BUSINESS
CENTER DRIVE, MOUNT PROSPECT, IL 60056-2179, MAKES
THIS LIMITED WARRANTY TO THE ORIGINAL RETAIL
PURCHASER OF THIS PRODUCT. THIS LIMITED WARRANTY
IS NOT TRANSFERABLE OR ASSIGNABLE.
Schumacher Electric Corporation (the “Manufacturer”) warrants
this battery charger for 2 years from the date of purchase at retail
against defective material or workmanship that may occur under
normal use and care. If your unit is not free from defective material
or workmanship, Manufacturer’s obligation under this warranty is
solely to repair or replace your product with a new or reconditioned
unit at the option of the Manufacturer. It is the obligation of the
purchaser to forward the unit, along with mailing charges prepaid
to the Manufacturer or its authorized representatives in order for
repair or replacement to occur.
Manufacturer does not provide any warranty for any accessories
used with this product that are not manufactured by Schumacher
Electric Corporation and approved for use with this product. This
Limited Warranty is void if the product is misused, subjected to
careless handling, repaired, or modied by anyone other than
Manufacturer or if this unit is resold through an unauthorized retailer.
Manufacturer makes no other warranties, including, but not limited
to, express, implied or statutory warranties, including without

• 16 •
limitation, any implied warranty of merchantability or implied
warranty of tness for a particular purpose. Further, Manufacturer
shall not be liable for any incidental, special or consequential
damage claims incurred by purchasers, users or others associated
with this product, including, but not limited to, lost prots,
revenues, anticipated sales, business opportunities, goodwill,
business interruption and any other injury or damage. Any and all
such warranties, other than the limited warranty included herein,
are hereby expressly disclaimed and excluded. Some states do
not allow the exclusion or limitation of incidental or consequential
damages or length of implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you specic
legal rights and it is possible you may have other rights which vary
from this warranty.
THIS LIMITED WARRANTY IS THE ONLY EXPRESS LIMITED
WARRANTY AND THE MANUFACTURER NEITHER ASSUMES
OR AUTHORIZES ANYONE TO ASSUME OR MAKE ANY
OTHER OBLIGATION TOWARDS THE PRODUCT OTHER
THAN THIS WARRANTY.
Schumacher Electric Corporation Customer Service
1-800-621-5485, Monday – Friday 7:00 a.m. to 5:00 p.m. CST
Schumacher and the Schumacher Logo are registered trademarks of
Schumacher Electric Corporation
To activate the warranty, please ll in the warranty registration card on
page 18 and mail it in, OR go to www.batterychargers.com to register
your product online.
DO NOT RETURN THIS PRODUCT
TO THE STORE!
Call Customer Service for Assistance:
800-621-5485

• 17 •
2 YEAR LIMITED
WARRANTY PROGRAM
REGISTRATION
MODEL:___________________
DESCRIPTION:___________________________
This is the only express limited warranty, and the manufacturer neither assumes nor authorizes
anyone to assume or make any other obligation. There is no other warranty, other than what is
described in the product owner’s manual.
The warranty card should be submitted within 30 days of purchase. The customer must
keep the ORIGINAL receipt because it will be required for any warranty claims.
This warranty is not transferable.
Mail To: Schumacher Electric Corporation 801 Business Center Drive Mount Prospect, IL 60056-2179 Name_______________________________________________________________ Street Address________________________________________________________ City_________________________________State__________Zip Code__________ Phone______________________Email____________________________________ Store Name Where Purchased____________________Date of Purchase__________ Store Location_____________________UPC Number_________________________ Serial Number________________________(SEE PRODUCT)

• 18 •
PROGRAMA DE REGISTRO
DE 2-AÑOS DE GARANTÍA
LIMITADA
MODELO:___________________ DESCRIPCIÓN:___________________________
Esta es la única garantía limitada expresa, y el productor no autoriza ni otorga a alguien a realizar
alguna otra obligación. No existe ninguna otra garantía más que la descrita en el manual del dueño.
La tarjeta de garantía debe enviarse durante los primeros 30 días después de la compra.
El cliente debe mantener el recibo de compra ORIGINAL como comprobante,
el cual le otorga todo derecho a cualquier reclamo de garantía.
Esta garantía no es tranferible.
Dirigase a: Schumacher Electric Corporation 801 Business Center Drive Mount Prospect, IL 60056-2179 Nombre______________________________________________________________ Dirección_____________________________________________________________ Ciudad_______________________________Estado_____________C.P.__________ Tel:_______________________Correo electrónico____________________________ Nombre de la Tienda donde se Compró_________________Fecha de compra _____ Localización de la Tienda___________________Numero de Serie _______________ Código de barras ________________________(CONSULTE EL PRODUCTO)

• 19 •
IMPORTANTE: LEA Y GUARDE ESTE MANUAL DE
INSTRUCCIONES Y SEGURIDAD.
GUARDE ESTAS INSTRUCCIONES: Este manual le mostrará
cómo utilizar su cargador en forma segura y efectiva. Por favor,
lea, comprenda y siga estas instrucciones y precauciones
cuidadosamente, ya que este manual contiene instrucciones
operativas y de seguridad de importancia. Los mensajes de
seguridad representados en este manual contienen palabras
guía, un mensaje y una gura.
La palabra guía indica el nivel de peligro en determinada
situación.
Indica una inminente situación de riesgo que, si no
se evita, resultaría mortal o de serios perjuicios al
operador o personas alrededor.
Indica una situación potencialmente riesgoso que, si
no se evita, podría resultar o de serios perjuicios al
operador o personas alrededor.
Indica una situación potencialmente peligrosa que, de
no evitarse, podría resultar en menores o serio daños
al usuario y terceras personas.
Indica una situación potencialmente peligrosa que, de
no evitarse, podría causar daño al equipo, al vehículo
y propiedades alrededor.
Conforme a la propuesta 65 de California, este producto
contiene químicos de los cuales en el Estado de
California se tiene conocimiento que provocan cáncer y
malformaciones congénitas u otras lesiones reproductivas.
INSTRUCCIONES IMPORTANTES DE SEGURIDAD–1.
GUARDE ESTAS INSTRUCCIONES – Este manual contiene
instrucciones operativas y de seguridad de importancia
EL RIESGO DE DESCARGA ELÉCTRICA O
INCENDIO
Manténgase alejado de los niños.1.1
No exponga el cargador a la lluvia o a1.2
la nieve.
