Schumacher SL184U Series User manual

SL184U
SERIES
Lithium Ion 360°
Slim Rechargeable Work Light
MANUAL

• 2 •
PATENT/PATENT PENDING INFORMATION
Patent Numbers Countries
WO2013/171471 PCT Number
2013261606 AUS
9851082 B2 USA
2850357 European
2502180 GB
104302963 China
2912813 Canada
1205782 HK

• 3 •
ENGLISH Original instructions
SL184U Series
Lithium Ion 360° Slim Rechargeable Work Light
OWNERS MANUAL
1. IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS.
1.1 SAVE THESE INSTRUCTIONS – This manual contains important safety and
operating instructions.
1.2 Read, understand and follow all instructions, cautions and warnings listed in this
manual. Failure to follow all instructions and abide by all cautions and warnings
could result in personal injury, injury to others and property damage.
1.3 IMPORTANT! CHARGE WORK LIGHT IMMEDIATELY AFTER PURCHASE,
AFTER EACH USE, AND AT LEAST EVERY 6 MONTHS.
1.4 DO NOT turn on the work light while it is being charged.
1.5 DO NOT handle or move the work light while it is being charged.
1.6 DO NOT look directly into the light or shine the light directly into the eyes of any
person or animal.
1.7 DO NOT allow children to use the work light.
1.8 DO NOT operate the work light if it has received a sharp blow, been dropped, or
otherwise damaged in any way; take it to a qualied service person.
1.9 DO NOT leave the battery in a discharged state.
1.10 DO NOT use the work light with a charger which has a damaged cord or plug,
replace the cord or plug immediately.
1.11 IMPORTANT! Make sure to use a USB charging port rated for 1A @ 5V DC or higher.
2. PERSONAL SAFETY PRECAUTIONS
WARNING! TO REDUCE THE RISK OF BURNS OR FIRE, FOLLOW THESE
SAFETY PRECAUTIONS:
2.1 DO NOT disassemble the work light; take it to a qualied service person when
service or repair is required. Incorrect reassembly may result in a risk of re.
2.2 DO NOT crush, puncture, short external contacts or dispose of in re or water.

• 4 •
2.3 DO NOT expose to temperatures above 140°F (60°C).
2.4 Recycle or dispose of the used battery as required by local regulations.
2.5 If the electrolyte in the cells gets on your skin, wash thoroughly with soap
and water. If it gets into your eyes, rinse thoroughly with cool water and seek
immediate medical attention.
2.6 This product contains a lithium ion battery. In case of re, you may use
water, a foam extinguisher, Halon, CO2, ABC dry chemical, powdered graphite,
copper powder or soda (sodium carbonate) to extinguish the re. Once the re
is extinguished, douse the product with water, an aqueous-based extinguishing
agent, or other nonalcoholic liquids to cool the product and prevent the battery
from re-igniting. NEVER attempt to pick up or move a hot, smoking, or burning
product, as you may be injured.
3. SET UP INSTRUCTIONS
3.1 Remove any cord wraps and uncoil the charging cable.
4. FEATURES
1. 1W end LED
2. 16 SMD LEDs
3. Rotating ball joint
4. Magnetic base
5. Pull-out hook
6. USB/Micro USB charging cable
7. Micro USB charging port (under the cover)
8. Charging status LEDs
9. Power button for end LED
10. ON/OFF rotating switch for SMD LEDs
1 2
3
4
5
6
910
78

• 5 •
5. CHARGING
IMPORTANT! CHARGE THE WORK LIGHT IMMEDIATELY AFTER PURCHASE,
AFTER EACH USE, AND AT LEAST EVERY 6 MONTHS. Failure to do this will
reduce the battery’s capacity and may void the warranty.
5.1 Connect the micro USB end of the charging cable to the micro USB port on the back
of the work light. Insert the USB end of the cable into the USB port on your charger.
5.2 Plug your charger into a live power source.
5.3 The charge level LEDs will ash green and show the level of charge.
5.4 When the battery is fully charged, all ve LEDs will be solid green.
5.5 Recharge the work light after use, and at least every 6 months.
6. OPERATING INSTRUCTIONS
6.1 Hang the work light, using the hook on the end. Pull out the base from the main
body of the work light to rotate 360°, for more precise positioning.
6.2 The magnet may be used instead. Attach the magnetic end of the work light to
any ferrous metal surface.
6.3 Direct the lens away from your eyes before turning on the work light.
6.4 To turn on the side SMD LEDs, turn the switch clockwise. Continue turning, to
increase the brightness. To shut off, turn the switch in the opposite direction.
6.5 Press the power button to turn the end LED on and off.
6.6 Recharge the work light after use, and at least every 6 months. VOTING
7. MAINTENANCE INSTRUCTIONS
7.1 After use and before performing maintenance, unplug and disconnect the work light.
7.2 Use a dry cloth to wipe any dirt or oil from the charging cable and case.
7.3 Ensure that all of the work light’s components are in place and in good working
condition.
7.4 Servicing does not require opening the unit, as there are no user-serviceable parts.
7.5 Any servicing should be performed by qualied service personnel.

• 6 •
8. STORAGE INSTRUCTIONS
8.1 Store inside, in a cool, dry place.
8.2 Take care to avoid/prevent damage to the charging cable and unit. Failure to do
so could result in personal injury or property damage.
8.3 Charge the work light’s internal battery immediately after purchase, after every
use and every 6 months.
8.4 All batteries are affected by temperature. The ideal storage temperature is at
70°F (21 ˚C). The internal battery will gradually self-discharge (lose power) over
time, especially in warm environments. Leaving the battery in a discharged state
may result in permanent battery damage. To ensure satisfactory performance and
avoid permanent damage, charge the internal battery every 6 months.
9. TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
The work light does
not operate. The battery is not charged. Recharge the battery to full charge.
10. BEFORE RETURNING FOR REPAIRS (U.S./CANADA)
DO NOT SHIP UNIT until you receive a RETURN MERCHANDISE
AUTHORIZATION (RMA) number from Customer Service at Schumacher
Electric Corporation.
When returning an item, place the original package into a shipping carton. If you
received an emailed label from Schumacher, please print the label and tape it
to the carton. Only ship via insured ground service with a tracking
number. Return shipping charges are the responsibility of the customer. We
cannot accept C.O.D. deliveries and are not responsible for lost or damaged
packages. Please do not place stickers or shipping labels on the original
manufacturer’s package. Please allow 2-3 days from date we received the
package for us to process your return. All return shipping charges must be
prepaid.

11. DISPOSAL INFORMATION
Do not dispose of this product with other household waste. To prevent
possible harm to the environment or human health from uncontrolled
waste disposal, and to promote the sustainable reuse of material
resources, recycle it responsibly. To discard your used device, please
use the return and collection systems or contact the retailer where the
product was purchased, for environmentally-safe recycling.
12. SPECIFICATIONS
Battery type................................................................... Lithium Ion, 3.7V, 2.6Ah
Light .................................................................. 16 SMD (side) + 1W LED (end)
Lumen output .................................................... Side: 600 lm (high); 50 lm (low)
End: 120 lm
Operating time.......................................... Side: 1.5 hours (high); 16 hours (low)
End: 10 hours
Charging time.......................................................................................... 4 hours
Ingress protection rating...............................................................................IP54
Impact protection rating................................................................................IK07
13. REPLACEMENT PARTS
USB to Micro USB charging cable.....................................................3899003983Z
