SCHUNK JGP-P 40 User instructions

Assembly and Operating Manual
JGP-P
2-finger parallel gripper
Translation of Original Operating
Manual

Imprint
2 05.00 | JGP-P | Assembly and Operating Manual | en | 1469637
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK SE & Co. KG.
All rights reserved.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 1469637
Version: 05.00|24/08/2023|en
Dear Customer,
Thank you for trusting our products and our family-owned company, the leading technology
supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions. Ask
us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
Customer Management
Tel. [phone]
Fax [phone]
[e-mail]
Please read the operating manual in full and keep it close to the product.

Table of Contents
05.00 | JGP-P | Assembly and Operating Manual | en | 1469637 3
Table of Contents
1 General ............................................................................................. 5
1.1 About this manual............................................................................... 5
1.1.1 Presentation of Warning Labels ..................................................... 5
1.1.2 Applicable documents ................................................................. 6
1.1.3 Sizes........................................................................................ 6
1.1.4 Variants ................................................................................... 6
1.2 Warranty ........................................................................................... 7
1.3 Scope of delivery................................................................................. 8
1.4 Accessories ........................................................................................ 9
1.4.1 Spare parts packages .................................................................. 9
2 Basic safety notes ................................................................................ 10
2.1 Intended use...................................................................................... 10
2.2 Constructional changes......................................................................... 10
2.3 Spare parts ........................................................................................ 10
2.4 Gripper fingers .................................................................................. 10
2.5 Ambient conditions and operating conditions ........................................... 11
2.6 Personnel qualification ........................................................................ 11
2.7 Personal protective equipment .............................................................. 12
2.8 Notes on safe operation........................................................................ 12
2.9 Transport........................................................................................... 13
2.10 Malfunctions ...................................................................................... 13
2.11 Disposal ............................................................................................ 13
2.12 Fundamental dangers .......................................................................... 13
2.12.1 Protection during handling and assembly ....................................... 14
2.12.2 Protection during commissioning and operation ............................... 14
2.12.3 Protection against dangerous movements ....................................... 14
2.12.4 Protection against electric shock.................................................... 15
2.13 Notes on particular risks ....................................................................... 16
3 Technical data ..................................................................................... 18
4 Design and description .......................................................................... 19
4.1 Design .............................................................................................. 19
4.2 Description ........................................................................................ 19
5 Assembly and settings ........................................................................... 20
5.1 Installing and connecting ..................................................................... 20

Table of Contents
4 05.00 | JGP-P | Assembly and Operating Manual | en | 1469637
5.2 Connections ....................................................................................... 21
5.2.1 Mechanical connection................................................................ 21
5.2.2 Pneumatic connection................................................................. 24
5.3 Attaching additional structure................................................................ 26
5.4 Mounting the sensor............................................................................ 28
5.4.1 Overview of sensors .................................................................... 28
5.4.2 Setting dimensions for magnetic switches ....................................... 29
5.4.3 Switch-off hysteresis for magnetic switches ..................................... 30
5.4.4 Mounting inductive proximity switch IN .......................................... 31
5.4.5 Mounting MMS 22 magnetic switch................................................. 33
5.4.6 Mounting programmable MMS 22-PI2 magnetic switch ....................... 34
5.4.7 Mounting programmable MMS 22-P 22 magnetic switch ...................... 35
5.4.8 Mounting MMS 22-PI1 programmable magnetic switch........................ 36
5.4.9 Mounting the magnetic switch MMS 22-IOL ...................................... 38
5.4.10 Mounting analog MMS 22-A magnetic switch.................................... 40
5.4.11 Mounting analog position sensor APS-Z80 ....................................... 43
5.4.12 Mount the flexible position sensor FPS............................................ 45
5.4.13 Mounting analog position sensor APS-M1......................................... 47
6 Troubleshooting................................................................................... 49
6.1 Product does not move......................................................................... 49
6.2 Product is not executing the complete stroke ............................................ 49
6.3 Product opens or closes abruptly ............................................................ 49
6.4 Product does not achieve the opening and closing times ............................. 50
6.5 Gripping force is dropping..................................................................... 50
7 Maintenance ....................................................................................... 51
7.1 Notes................................................................................................ 51
7.2 Maintenance intervals.......................................................................... 51
7.3 Lubricants/Lubrication points (basic lubrication) ....................................... 52
7.4 Lubricate product................................................................................ 53
7.5 Replace seal. (variant without gripping force maintenance) ......................... 54
7.6 Replace seal. (variant with gripping force maintenance "O.D. gripping")......... 55
7.7 Replace seal. (variant with gripping force maintenance "I.D. gripping") ......... 57
7.8 Installation position of the magnets in the piston ...................................... 59
7.9 Tightening torques .............................................................................. 60
7.10 Assembly drawing ............................................................................... 61
8 Translation of the original declaration of incorporation ................................. 65
9 UKCA declaration of incorporation ............................................................ 66
10 Information on the RoHS Directive, REACH Regulation and Substances of Very High
Concern (SVHC) ..................................................................................... 67

General
05.00 | JGP-P | Assembly and Operating Manual | en | 1469637 5
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working
is the observance of all safety instructions in this manual.
In addition to these instructions, the documents listed
under }1.1.2 [/6] are applicable.
NOTE: The illustrations in this manual are intended to provide a
basic understanding and may deviate from the actual version.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Dangers for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
CAUTION
Material damage!
Information about avoiding material damage.

General
6 05.00 | JGP-P | Assembly and Operating Manual | en | 1469637
1.1.2 Applicable documents
lGeneral terms of business *
lCatalog data sheet of the purchased product *
lAssembly and operating manuals of the accessories *
The documents labeled with an asterisk (*) can be downloaded
from schunk.com.
1.1.3 Sizes
This operating manual applies to the following sizes:
lJGP-P 40
lJGP-P 50
lJGP-P 64
lJGP-P 80
lJGP-P 100
lJGP-P 125
lJGP-P 160
lJGP-P 200
lJGP-P 240
lJGP-P 300
1.1.4 Variants
This operating manual applies to the following variations:
lJGP-P stroke 1
lJGP-P stroke 2
lJGP-P with gripping force maintenance "O.D. gripping" (AS)
lJGP-P with gripping force maintenance "I.D. gripping" (IS)

General
05.00 | JGP-P | Assembly and Operating Manual | en | 1469637 7
1.2 Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
l
Observe the ambient conditions and operating
conditions, }2.5 [/11]
l
Observe the specified maintenance intervals, }7 [/51]
Parts touching the workpiece and wear parts are not included in
the warranty.
JGP-P Warranty duration
[months]
or maximum cycles
[mil.]*
40 24 20
50 24 15
64 24 15
80 24 15
100 24 15
125 24 15
160 24 15
200 24 10
240 24 10
300 24 5
* A cycle consists of a complete gripping process: "Open gripper"
and "Close gripper".

General
8 05.00 | JGP-P | Assembly and Operating Manual | en | 1469637
1.3 Scope of delivery
The scope of delivery includes
l2-finger parallel gripper JGP-P in the version ordered
lAccessory pack
Content of the accessory pack:
l2x centering sleeve for gripper fastening
l4x centering sleeve for finger fastening
l2 x O-ring for hose-free direct connection
ID.-No. of the accessory pack
JGP-P ID number
40 5518410
50 5512043
64 5512044
80 5512045
100 5512046
125 5512047
160 5512048
200 5512049
240 5513858
300 5512050

General
05.00 | JGP-P | Assembly and Operating Manual | en | 1469637 9
1.4 Accessories
A wide range of accessories are available for this product
For information regarding which accessory articles can be used
with the corresponding product variants, see catalog data sheet.
1.4.1 Spare parts packages
Spare parts packages allow for the maintenance and repair of
individual components. For information on the range of the
spare parts packages, see www.schunk.com > Service.
The following spare parts packages are available for this product:
lSpare part package "Sealing kit"
JGP-P ID number
40 1325991
50 1326003
64 1326011
80 1326019
100 1326027
125 1326031
160 1326040
200 1326045
200-AS 1477531
200-IS 1489746
240 1326048
240-AS 1489780
240-IS 1489781
300 1479146
Tab.: ID. No. spare part kit "Sealing kit"

Basic safety notes
10 05.00 | JGP-P | Assembly and Operating Manual | en | 1469637
2 Basic safety notes
2.1 Intended use
The product is designed exclusively for gripping and temporarily
holding workpieces or objects.
lThe product may only be used within the scope of its technical
data, }3 [/18].
lThe product is intended for installation in a machine/
automated system. The applicable guidelines for the machine/
automated system must be observed and complied with.
lThe product is intended for industrial and industry-oriented
use. Its use outside enclosed spaces is only permitted if
suitable protective measures are taken against outdoor
exposure. The product is not suitable for use in salty air.
lThe product can be used within the permissible load limits
and technical data for holding workpieces during simple
machining operations, but is not a clamping device according
to EN 1550:1997+A1:2008.
lAppropriate use of the product includes compliance with all
instructions in this manual.
lAny utilization that exceeds or differs from the appropriate
use is regarded as misuse.
2.2 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of
the product or damage it.
lStructural changes should only be made with the written
approval of SCHUNK.
2.3 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
lUse only original spare parts or spares authorized by SCHUNK.
2.4 Gripper fingers
Requirements of gripper fingers
Accumulated energy can make the product unsafe and risk the
danger of serious injuries and considerable material damage.

Basic safety notes
05.00 | JGP-P | Assembly and Operating Manual | en | 1469637 11
lExecute the gripper fingers in such a way that the product
reaches either the "open" or "closed" position in a de-
energized state.
lOnly change gripper fingers if no residual energy can be
released.
lMake sure that the product and the top jaws are a sufficient
size for the application.
2.5 Ambient conditions and operating conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the
product unsafe, leading to the risk of serious injuries,
considerable material damage and/or a significant reduction to
the product's life span.
lMake sure that the product is used only in the context of its
defined application parameters, }3 [/18].
2.6 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
lAll work may only be performed by qualified personnel.
lBefore working with the product, the personnel must have
read and understood the complete assembly and operating
manual.
lObserve the national safety regulations and rules and general
safety instructions.
The following personal qualifications are necessary for the
various activities related to the product:
Trained electrician Due to their technical training, knowledge and experience,
trained electricians are able to work on electrical systems,
recognize and avoid possible dangers and know the relevant
standards and regulations.
Qualified personnel Due to its technical training, knowledge and experience,
qualified personnel is able to perform the delegated tasks,
recognize and avoid possible dangers and knows the relevant
standards and regulations.
Instructed person Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.

Basic safety notes
12 05.00 | JGP-P | Assembly and Operating Manual | en | 1469637
Service personnel of
the manufacturer
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.
2.7 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
lWhen working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
lObserve the valid safety and accident prevention regulations.
lWear protective gloves to guard against sharp edges and
corners or rough surfaces.
lWear heat-resistant protective gloves when handling hot
surfaces.
lWear protective gloves and safety goggles when handling
hazardous substances.
lWear close-fitting protective clothing and also wear long hair
in a hairnet when dealing with moving components.
2.8 Notes on safe operation
Incorrect handling of the personnel
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
lAvoid any manner of working that may interfere with the
function and operational safety of the product.
lUse the product as intended.
lObserve the safety notes and assembly instructions.
lDo not expose the product to any corrosive media. This does
not apply to products that are designed for special
environments.
lEliminate any malfunction immediately.
lObserve the care and maintenance instructions.
lObserve the current safety, accident prevention and
environmental protection regulations regarding the product's
application field.

Basic safety notes
05.00 | JGP-P | Assembly and Operating Manual | en | 1469637 13
2.9 Transport
Handling during transport
Incorrect handling during transport may impair the product's safety
and cause serious injuries and considerable material damage.
lWhen handling heavy weights, use lifting equipment to lift
the product and transport it by appropriate means.
lSecure the product against falling during transportation and
handling.
lStand clear of suspended loads.
2.10 Malfunctions
Behavior in case of malfunctions
lImmediately remove the product from operation and report
the malfunction to the responsible departments/persons.
lOrder appropriately trained personnel to rectify the
malfunction.
lDo not recommission the product until the malfunction has
been rectified.
lTest the product after a malfunction to establish whether it
still functions properly and no increased risks have arisen.
2.11 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's
safety and cause serious injuries as well as considerable material
and environmental harm.
lFollow local regulations on dispatching product components
for recycling or proper disposal.
2.12 Fundamental dangers
General
lObserve safety distances.
lNever deactivate safety devices.
lBefore commissioning the product, take appropriate
protective measures to secure the danger zone.
lDisconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
lIf the energy supply is connected, do not move any parts by
hand.
lDo not reach into the open mechanism or movement area of
the product during operation.

Basic safety notes
14 05.00 | JGP-P | Assembly and Operating Manual | en | 1469637
2.12.1 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
lHave all work carried out by appropriately qualified
personnel.
lFor all work, secure the product against accidental operation.
lObserve the relevant accident prevention rules.
lUse suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.
Incorrect lifting of loads
Falling loads may cause serious injuries and even death.
lStand clear of suspended loads and do not step into their
swiveling range.
lNever move loads without supervision.
lDo not leave suspended loads unattended.
2.12.2 Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious
injuries and even death.
lTake appropriate protective measures to secure the danger
zone.
lNever step into the danger zone during operation.
2.12.3 Protection against dangerous movements
Unexpected movements
Residual energy in the system may cause serious injuries while
working with the product.
lSwitch off the energy supply, ensure that no residual energy
remains and secure against inadvertent reactivation.
lNever rely solely on the response of the monitoring function
to avert danger. Until the installed monitors become effective,
it must be assumed that the drive movement is faulty, with its
action being dependent on the control unit and the current
operating condition of the drive. Perform maintenance work,
modifications, and attachments outside the danger zone
defined by the movement range.
lTo avoid accidents and/or material damage, human access to
the movement range of the machine must be restricted. Limit/
prevent accidental access for people in this area due through
technical safety measures. The protective cover and protective

Basic safety notes
05.00 | JGP-P | Assembly and Operating Manual | en | 1469637 15
fence must be rigid enough to withstand the maximum
possible movement energy. EMERGENCY STOP switches must be
easily and quickly accessible. Before starting up the machine
or automated system, check that the EMERGENCY STOP system
is working. Prevent operation of the machine if this protective
equipment does not function correctly.
2.12.4 Protection against electric shock
Possible electrostatic energy
Components or assembly groups may become electrostatically
charged. When the electrostatic charge is touched, the discharge
may trigger a shock reaction leading to injuries.
lThe operator must ensure that all components and assembly
groups are included in the local potential equalisation in
accordance with the applicable regulations.
lWhile paying attention to the actual conditions of the working
environment, the potential equalisation must be
implemented by a specialist electrician according to the
applicable regulations.
lThe effectiveness of the potential equalisation must be
verified by executing regular safety measurements.

Basic safety notes
16 05.00 | JGP-P | Assembly and Operating Manual | en | 1469637
2.13 Notes on particular risks
DANGER
Risk of fatal injury from suspended loads!
Falling loads can cause serious injuries and even death.
lStand clear of suspended loads and do not step within their
swiveling range.
lNever move loads without supervision.
lDo not leave suspended loads unattended.
lWear suitable protective equipment.
WARNING
Risk of injury from objects falling and being ejected!
Falling and ejected objects during operation can lead to serious
injury or death.
lTake appropriate protective measures to secure the danger
zone.
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
lBefore starting any work on the product: Switch off the power
supply and secure against restarting.
lMake sure, that no residual energy remains in the system.
WARNING
Risk of injury from crushing and impacts!
Serious injury could occur during movement of the base jaw, due
to breakage or loosening of the gripper fingers or if the
workpiece is lost.
lWear suitable protective equipment.
lDo not reach into the open mechanism or the movement area
of the product.

Basic safety notes
05.00 | JGP-P | Assembly and Operating Manual | en | 1469637 17
WARNING
Risk of injury due to electromagnetic interference!
Electromagnetic interference can cause the product to
malfunction and lead to disturbances in medical implants (e.g.
pacemakers). Unexpected movements or ejected objects can
cause serious injury or death.
lEnsure adequate shielding against magnetic fields in the
immediate vicinity of the product, so that exact limits
according to relevant standards, e.g. ENIEC61000, are not
exceeded.
lTake suitable protective measures to secure the danger zone.

Technical data
18 05.00 | JGP-P | Assembly and Operating Manual | en | 1469637
3 Technical data
Connection data
Pressure medium Compressed air, compressed air
quality according to ISO 8573‐
1:2010 [7:4:4]
Nominal operating pressure [bar] 6
Minimum pressure [bar]
without maintenance of gripping
force
2.5
Minimum pressure [bar]
with maintenance of gripping
force
4
Maximum pressure [bar]
without maintenance of gripping
force
8
Maximum pressure [bar]
with maintenance of gripping
force
6.5
Pressure range for air purge [bar] 0.5 – 1
Ambient conditions and operating conditions
Ambient temperature [°C]
min.
max.
+5
+90
Protection class IP 40
Noise emission [dB(A)] ≤ 70
More technical data is included in the catalog data sheet.
Whichever is the latest version.

Design and description
05.00 | JGP-P | Assembly and Operating Manual | en | 1469637 19
4 Design and description
4.1 Design
2-finger parallel gripper
1 Air purge connection
2 Base jaw
3 Compressed air main connection
4 Groove for magnetic switch
5 Housing
4.2 Description
Universal 2-finger parallel gripper with a high gripping force and
high maximum moments due to the use of a T-slot guidance.

Assembly and settings
20 05.00 | JGP-P | Assembly and Operating Manual | en | 1469637
5 Assembly and settings
5.1 Installing and connecting
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
l
Before starting any work on the product: Switch off the power
supply and secure against restarting.
lMake sure, that no residual energy remains in the system.
CAUTION
Damage to the gripper is possible!
If the maximum permissible finger weight or the permissible
mass moment of inertia of the fingers is exceeded, the gripper
can be damaged.
lA jaw movement always has to be without jerks and bounce.
lYou must therefore implement sufficient reduction and/or
damping.
lObserve the information in the catalog data sheet.
1. Check the evenness of the mounting surface, }5.2.1 [/21].
2. Connect the product via the hose-free direct connection.
3. OR: Connect compressed air lines to the main air
connections"A" and"B".
ðRemove the locking screws.
ðScrew in air connections (plug connections).
OR: Screw on throttle valve in order to be able to perform
sufficient throttling and/or damping.
4. Screw the product to the machine/system, }5.2.1 [/21].
ðIf necessary, use appropriate connection elements
(adapter plates).
ð Observe permissible depth of engagement and if required
strength class.
5. Connect air purge connection if necessary.
6. Attach additional structure to the product if necessary, }5.3 [/26]
7. Connect the sensor, see assembly and operating manual of the sensor.
8. Mount the sensor, }5.4 [/28].
