SciCan Statim 2000 User manual

Latin America
• Operator’s Manual
• Manual del Operador
• Manual do Operação
STATIM 2000/5000
CASSETTE AUTOCLAVE™

1STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Table of Contents
TABLE OF CONTENTS
1. Introduction.................................................................... 2
1.1 Disclaimers.........................................................................2
1.2 How to Use this Book ........................................................3
1.3 What's in the Box...............................................................3
2. STATIM Unit Overview................................................... 4
3. Installation .................................................................... 5
3.1 Environmental Considerations...........................................5
3.2 Unit Placement ..................................................................5
3.3 Connecting the Waste Bottle.............................................6
3.4 Filling the STATIM Reservoir..............................................6
3.5 Priming the STATIM Pump ................................................6
3.6 Setting the Time and Date ................................................. 7
3.7 Language Selection ........................................................... 7
3.8 Assigning Unit Identifier Number....................................... 7
3.9 Adjusting the Cycle Drying Time........................................8
3.10 Preparing Unit for Use .....................................................8
3.11 Shipping the Unit .............................................................8
4. Instructions for Use....................................................... 9
4.1 STATIM 2000 — Using the Cassette .................................9
4.2 STATIM 5000 — Using the Cassette ...............................10
4.3 STATIM 5000—STAT-DRI Plates..................................... 11
4.4 Preparing and Loading Instruments................................. 11
4.5 Using Biological/Chemical Indicators..............................13
4.6 Instrument Weight Guide .................................................13
4.7 Cycle Profiles ...................................................................13
4.8 Running a Cycle...............................................................15
4.9 Stopping a Cycle..............................................................16
5. Maintenance.................................................................17
5.1 Cleaning the Cassette...................................................... 17
5.2 Cleaning the Water Reservoir Filter ................................. 17
5.3 Cleaning the Reservoir..................................................... 17
5.4 Cleaning the Exterior Surfaces ........................................ 17
5.5 Changing the STATIM 2000 Air Filter ..............................18
5.6 Changing the Bacteria Retentive Air Filters.....................18
5.7 Replacing the Cassette Seal............................................19
5.8 Maintaining Fluid Levels ..................................................19
5.9 Reading Water Quality.....................................................19
5.10 Preventative Maintenance Schedule .............................20
6. The Communication Port.............................................21
6.1 The RS232 Communication Port..................................... 21
6.2 Installing the SciCan Data Logger ...................................22
6.3 Cycle Printout Overview ..................................................24
7. Internal Printer ............................................................. 25
7.1 Installing Paper on the Internal Printer.............................25
7.2 Removing Internal Printer Paper Jams ............................26
8. Troubleshooting............................................................27
9. Spare Parts List........................................................... 29
10. Warranty .................................................................... 30
11. Specifications ............................................................31
12. Appendix: Cycle Profile and Capacity...................... 32

2STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Introduction
1. Introduction
Congratulations on your selection of the STATIM Cassette Autoclave® .
We are confident that you have purchased the finest equipment of its type. The STATIM®is a compact, counter-top
unit that features a number of sterilizing cycles designed to meet your needs and suitability for steam sterilization.
The details of installing, operating and servicing your STATIM are all contained within this operator’s manual.
To ensure years of safe, trouble-free service please read these instructions before operating this unit and keep them
for future reference. Operational, maintenance and replacement instructions should be followed for the product
to perform as designed. Contents of this manual are subject to change without notice to reflect changes and
improvements to the STATIM product.
The STATIM is suitable for the sterilization of dental and medical instruments designed to withstand steam sterilization.
The STATIM is not designed to sterilize liquids, cloth loads, biomedical waste or materials not compatible with steam
sterilization. The processing of such loads may result in incomplete sterilization and/or damage to the autoclave.
For more information about instrument suitability for steam sterilization, consult the manufacturers’ reprocessing
instructions.
1.1 Disclaimers
Use only steam-process distilled water in your STATIM. Deionized, demineralized, or specially filtered water should
not be used. Never use tap water.
Do not permit any person other than certified personnel to supply parts for, service or maintain your STATIM.
SciCan shall not be liable for incidental, special or consequential damages caused by any maintenance or services
performed on the STATIM by a third party, or for the use of equipment or parts manufactured by a third party,
including lost profits, any commercial loss, economic loss, or loss arising from personal injury. Never remove the
cover of the unit and never insert objects through holes or openings in the cabinetry. Doing so may damage the unit
and/or pose a hazard to the operator.
All elements of this book are common to both STATIM2000 and STATIM 5000 except when noted.
IMPORTANT: Follow local guidelines governing verification of the sterilization procedure.
Drying Performance
The STATIM 2000 and 5000 have been designed to provide a complete sterilization solution for your unwrapped
and wrapped instrument needs: rapid sterilization balanced with rapid drying, by using the SciCan Dri-Tec Drying
Technology.
To dry instruments, the STATIM 2000 uses a combination of forced filtered air and convection heat. The convection
heat is derived from utilizing the remaining heat in the system after the sterilization phase has been completed.
The heat is then captured and released into the cassette to rapidly dry a properly loaded cassette.
The STATIM 5000 also uses forced filtered air and heat generated by the sterilization phase to dry the instruments.
The heat generated by the sterilization phase is absorbed by the drying plates and then transferred directly to the
load. This then results in an accelerated, rapid drying of a properly loaded STATIM cassette.
Please refer to this operator’s manual for instructions on the proper arrangement of instruments in the cassette and
the use of STAT-DRI™ plates (STATIM 5000). By carefully following these directions on how to properly load the
cassette chamber, rapid drying of the load will be achieved.

3STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Introduction
1.2 How to Use this Book
The following symbols appear in the margins of this book.
Warning icons
A situation
which may
lead to a
mechanical
failure.
A potential
hazard to
the operator.
Important
information
Caution:
Hot Surface
and/or
Hot Steam
Caution:
Refer to manual
for details
Alternating
between
messages
Caution:
Risk of
electrical shock.
Disconnect
supply before
servicing
Cycle icons
Wrapped
Cycle
Unwrapped
Cycle
Rubber/Plastic
Cycle
Air Cycle
(STATIM 2000)
or
Heavy Duty
Unwrapped
(STATIM 5000)
STOP
Button
START
Button
1.3 What's in the Box
When you receive your STATIM packing carton, the items listed below will be included.
If any of the items are missing, contact your dealer immediately so that the situation can be corrected.
STATIM 2000/5000
CASSETTE AUTOCLAVE
™
• Operator’s Manual
• Manual del Operador
and/or
Unwrapped Instrument Rack
Cassette Tray and Lid
Wrapped Instrument Rack
(STATIM 5000)
Power Cord
Operator’s Manual
Tube Mounting Hardware
STAT-DRI PLUS Spray
Exhaust Tube
Waste Bottle and Bottle Lid
Fitting

4STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Unit Overview
Figure 1 a Figure 1 b
Figure 2 a
STATIM 2000
3
6
9
11
10
15
16
87
13
5
42
1
12
2
1
12
145
6910
16 13 15 8 7
34
STATIM 5000
1. Level indicator
2. Keypad
3. Reservoir cap/water filter
4. LCD
5. Power indicator
6. Active indicator
7. Power switch
8. Power cable port
9. Leveler feet
10. Exhaust tube port
11. Compressor
12. Cassette
13. Biological air filter
14. Optional internal printer
(STATIM5000)
15. RS232 port (not on all models)
16. Serial/Model/Number Label
Figure 2 b
2. STATIM Unit Overview

5STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Installation
3. Installation
3.1 Environmental Considerations
There are several factors that may affect the performance of your
STATIM. Please review these factors, and select a suitable location in
which to install the unit.
Temperature and Humidity
Avoid installing your STATIM in direct sunlight or close to a heat source
(e.g. vents or radiators). The recommended operating temperatures are
15-25˚C (59˚F to 77˚F) with humidity of 25-70%.
Spacing
The vents and openings on the STATIM should remain uncovered and
unobstructed. Leave a minimum of 50 mm/2˝ between the top, sides and
back of the unit and any wall or partition.
Venting
The STATIM should be operated in a clean, dust free environment.
Work Surface
The STATIM should be placed on a flat, level, water-resistant surface. Never
install and operate the unit on a sloped surface.
Electromagnetic Environment
The STATIM has been tested and meets applicable standards for
electromagnetic emissions. While the unit does not emit any radiation,
it may itself be affected by other equipment which does. We recommend
that the unit be kept away from potential sources of interference.
Electrical Requirements
Use properly grounded and fused power sources with the same voltage
rating as indicated on the label at the back of your STATIM. Avoid multiple
outlet receptacles. If using a surge suppressor power bar, plug in one
STATIM only.
3.2 Unit Placement
When placing the unit on a counter top, ensure the following:
• The level indicator bubble (1) on the front panel should be
balanced in the front right quadrant of the target (Four o'clock
position). This will ensure that the unit drains properly. Adjusting
the three leveler feet will help you move the bubble if necessary.
• The unit should be stable and all four feet should be securely
in contact with the counter surface. This will prevent the unit
from moving freely.
Figure 3
1

6STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Installation
3.3 Connecting the Waste Bottle
The waste bottle (2) is used to collect the wastewater after it has been
converted to steam and then drained from the cassette. To connect the
waste bottle to the STATIM, follow these steps (see Figure 4).
1. Insert the exhaust (3) tube into the fitting (4) on the back of the unit
and connect tightly.
2. Cut the tube to length and slide the waste bottle fitting (5) into place.
3. Place the free end of the tube into the hole in the lid of the waste bottle
and hand-tighten the fitting. Do not coil the exhaust tube.
4. Unscrew the lid and copper condenser coil (6) assembly from the
waste bottle. The lid and coil should come out together.
5. Fill the waste bottle with water to the MIN line and replace the lid and
copper condenser assembly. Empty the waste bottle often to avoid
unpleasant odors and discoloration of the contents. (A low-level
disinfectant, prepared according to the manufacturer’s instructions,
may be added to the waste bottle to remedy this situation). As a
minimum, empty the waste bottle each time you refill the reservoir.
6. Place the waste bottle near the unit. Store the bottle below the unit.
The tube can be routed through a hole, (8mm/0.3˝ in diameter) in the
counter-top and secured with the provided nylon clamps.
3.4 Filling the STATIM Reservoir
When filling the reservoir, ensure you only use steam processed
distilled water containing less than 5 ppm total dissolved solids (having
conductivity of less than 10 µS/cm). The impurities and additives in other
water sources will cause an error reading on the LCD. If you have a water
conductivity meter (available from SciCan, order number 01-103139S)
check each new water container before filling the reservoir. If your unit is
equipped with a Rev 7 PCB or higher (software SxxxR6xx), you can read
the water conductivity by refering to Section 5.9 Reading Water Quality.
To fill the reservoir, follow these steps (see Figure 5):
1. Remove the reservoir cap (2).
2. Pour steam-process distilled water into the reservoir until almost full
(a maximum of 4L/1 U.S. gal). Use a funnel to avoid spillage.
3. Replace and secure the cap.
3.5 Priming the STATIM Pump
To prime the STATIM pump, follow these steps (see Figure 6):
1. Move the unit to the edge of the work surface. The front leveler feet
should be approximately 12 mm/0.5˝ from the edge.
2. Lift the front left corner of the unit upward and remove the drain tube
(3) from the clip located on the underside of the unit.
3. Pull the drain tube outward so the free end can be positioned over a
water container.
4. Fill the reservoir with steam-process distilled water.
5. Remove the plug (4) from the end of the drain tube (3) and allow water
to drain from the tube into a container for 30 seconds. When the water
flows in a steady stream, replace the stopper.
6. Lift the front left corner of the unit upward and reinsert the tube into
the clip on the underside of the unit. Push the excess length of tubing
back into the space provided.
Make sure the plug in the drain tube is secured.
After installation, and before sterilizing any instruments, run two Wrapped cycles.
For further instructions, see Section 3.10 Preparing Unit for Use.
3
Figure 4
STATIM 2000
STATIM 5000
4
3
43
6
2
6
5
Figure 5
2
Figure 6
43
2

7STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Installation
3.6 Setting the Time and Date
To set the time and date, follow these steps and watch the blinking cursor
on the LCD:
1. Power the STATIM OFF.
2. Press and hold the UNWRAPPED cycle button.
3. While pressing the UNWRAPPED cycle button,
power the STATIM ON. The LCD display reads:
4. Use the cycle buttons to select and change the selected field’s value.
To increase a field’s value, press the UNWRAPPED cycle button.
Hold the button down to increase the value.
5. To decrease the value, press the WRAPPED cycle button.
6. To select the next field, press the RUBBERANDPLASTICS cycle button.
7. To save changes and return to the regular operating mode,
press the STOP button.
8. To quit without making changes, power the STATIM OFF.
3.7 Language Selection
The messages displayed on the LCD can be changed to a number of
different languages. To change the current language selections, follow
these steps:
1. Turn the power switch at the back of the unit OFF.
2. Press and hold the WRAPPED cycle button.
3. While depressing the WRAPPED cycle button,
turn the power switch at the back of the unit to ON.
4. Press the UNWRAPPED cycle button
to scroll to the next language selection.
5. Press the WRAPPED cycle buttonto scroll to the previous language.
6. When the desired language is displayed, press the STOP button
to save the selection and return to the regular operating mode.
3.8 Assigning Unit Identifier Number
1. Power the STATIM OFF.
2. Press and hold the RUBBER/PLASTIC cycle button.
3. While pressing the RUBBER/PLASTIC cycle button,
power the STATIM ON.
4. Using the cycle buttons, select a maximum of 3 digits to be used as
the unit’s identifier. The UNWRAPPED button will increase the selected
value and the WRAPPED cycle button will decrease it.
Use the RUBBER/PLASTIC to move to the next digit.
5. To save changes and return to the regular operating mode,
press the STOP button.
16:17 10/16/2013
HH:MM MM/DD/YYYY
Display when setting the Date / Time
Display when scrolling through languages
N.A. ENGLISH
Display when assigning unit number
UNIT # :
000

8STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Installation
3.9 Adjusting the Cycle Drying Time
The STATIM has preset dryng time of 10 minutes for Unwrapped cycles
and 30 minutes for Wrapped cycles. You can adjust the time between 5
to 60 minutes for Unwrapped cycles and 5 to 60 minutes for Wrapped
cycles.
1. Power the STATIM OFF.
2. While pressing and holding the STOP cycle
button, power the STATIM ON.
3. Using the Wrapped and Unwrapped cycle buttons scroll to DRYING
UNWRAPPED or DRYING WRAPPED and
press the RUBBER/PLASTIC button.
4. Using the Wrapped and Unwrapped cycle buttons, scroll to the desired
drying time and select it by pressing the RUBBER/PLASTIC button.
(Unwrapped Drying Time applies to Unwrapped,
Heavy Duty, and Rubber/Plastic cycles).
5. To save changes and return to the regular operating mode, press the
STOP button.
3.10 Preparing Unit for Use
Once the unit is installed and before any instruments are sterilized, run two
Wrapped cycles (see Section 4.8 Running a Cycle). Remove the cassette
once it has cooled. Clean the top (lid) and bottom (tray) sections using a
soft cloth to wipe the inside surfaces and then rinse thoroughly with tap
water. Once the cassette is clean and dry, coat the inside surfaces with
STAT-DRI.
3.11 Shipping the Unit
Before you move the unit, you will need to drain the reservoir. To do so,
follow these steps:
1. Place a water container below the unit.
2. Use the drain tube (5) to empty the contents of the reservoir into the
water container.
3. Remove any remaining water from the reservoir with a non-linting,
absorbant towel.
4. Screw-in the three leveler feet (6) found underneath the unit.
5. Repack the unit in the original packing materials and include all
accessories originally included with the unit.
6. Specify heated and insured shipping.
> DRYING UNWRAPPED
DRYING WRAPPED
> DRYING UNWRAPPED
10min
> DRYING WRAPPED
30min
or
Figure 7
4
6
6
6
5

9STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Instructions for Use
4. Instructions for Use
4.1 STATIM 2000 — Using the Cassette
When removing the cassette after a cycle, exercise caution as the metal
areas will be hot and the cassette may contain hot steam.
To open the cassette:
1. Hold the cassette handle with your thumbs facing inward on the
cassette latch.
2. Push downward on the cassette latch.
3. Raise the cassette lid upwards and disengage the hinge.
4. Rest the lid on its outer surface.
To close the cassette:
1. Align the hinge tab on the cassette lid with the hinge slot on the
rear of the bottom tray.
2. As you begin to close the lid, the hinge tab and slot will engage.
Inserting the cassette into the STATIM 2000:
1. Place the end of the cassette into the unit.
2. Gently push inward until you hear a “click ” sound.
Never push the cassette into the STATIM with force as the interior
components could be damaged.
Removing the cassette:
1. Grasp the handle with two hands and pull away from the unit.
2. Pull the cassette clear of the unit and set down on a firm surface.
Disengaging the cassette
When not in use, the cassette should be disengaged.
To disengage the cassette, grasp the handle and pull the cassette out until
there is a 15 mm to 20 mm (½ to ¾”) gap between the front of the STATIM
2000 and the cassette handle.
STAT-DRI
Treatment of the interior surfaces of the cassette with the STAT-DRI
drying agent, provided with your unit, will enhance the drying process.
(Replacement bottles are available from SciCan, order number 2OZPLUS,
8OZPLUS, 32OZPLUS).
Figure 8
Cassette Latch

10 STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Instructions for Use
4.2 STATIM 5000 — Using the Cassette
When removing the cassette after a cycle, exercise caution as the metal
areas will be hot and the cassette may contain hot steam.
To open the cassette:
1. Push the carry handle (1) into the open position.
2. Put your hands on either side of the cassette handle.
3. Insert your forefingers in the slots and place your thumbs
on the thumb pads.
4. Press down with your thumbs and pull up with your forefingers
until the lid opens.
5. Raise the cassette lid and disengage from the tray.
Rest the lid on its outer surface.
To close the cassette:
1. Align the hinge tab on the lid with the hinge slot on the tray.
2. As you begin to close the lid, the hinge tab and slot will engage.
3. Place the carry handle into the closed position.
Inserting the cassette into the STATIM 5000:
1. Hold the cassette handle in one hand and the carry handle
in the other as shown in Figure 9.
2. Place the end of the cassette into the unit
and drop the carry handle into its closed position.
3. Gently push the cassette inward until you hear a click sound.
Never push the cassette into the STATIM with force as the interior
components could be damaged.
Removing the cassette:
1. Grasp the cassette handle with one hand and pull out from the unit.
2. As the cassette emerges from the unit, grasp the carry handle with
your free hand and lift it upwards.
3. Pull the cassette clear from the unit and set down on a firm surface.
Disengaging the cassette
When not in use, the cassette should be disengaged.
To disengage the cassette, grasp the handle and pull the cassette out
until there is a 15 mm to 20 mm (½ to ¾”) gap between the front of the
STATIM5000 and the cassette handle.
STAT-DRI
Treatment of the interior surfaces of the cassette with the STAT-DRI
drying agent, provided with your unit, will enhance the drying process.
(Replacement bottles are available from SciCan, order number 2OZPLUS,
8OZPLUST, 32OZPLUS).
1
5
Figure 9
3
4
1

11 STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Instructions for Use
4.3 STATIM 5000—STAT-DRI Plates
The STATIM5000 cassette uses STAT-DRI plates to enhance the drying
process for wrapped instruments. The adjustable plates are designed for
the unwrapped instruments rack and eliminate the need for a separate
wrapped instrument rack. Up to ten plates can be arranged along the
length of the rack. Additional plates may be ordered from SciCan (SciCan
part number 01-103935).
To install and adjust a STAT-DRI plate, follow these steps:
1. Hold a plate over the desired position, tilted slightly forward with the
tabs down.
2. Insert the tabs between the mesh of the unwrapped instrument rack (1).
3. Each tab has an elongated slot. Slide the plate until the wire is at the
end of each slot.
4. Release the plate to the resting position.
5. Prepare and load instruments for sterilization (2).
4.4 Preparing and Loading Instruments
Before loading any instruments into the STATIM,
consult the manufacturer’s reprocessing instructions.
Clean Instruments
Clean and rinse all instruments before loading them into the cassette.
Disinfectant residues and solid debris may inhibit sterilization and damage
the instruments, the cassette, and the STATIM. Lubricated instruments must
be wiped thoroughly and any excess lubricant should be removed before loading.
Unwrapped Instruments
Arrange unwrapped instruments on the instrument rack in the tray so
that they do not touch one another. This ensures that steam reaches all
surfaces and will promote drying.
Instruments must not be stacked or piled in the cassettes, as this will
impede the sterilization process.
Wrapped Instruments (single wrap)
Place the instruments into single layer autoclave bags according to the
manufacturer’s instructions. Orient the instrument rack in the cassette to
ensure that wrapped instruments rest approximately 6mm/0.25” above
the cassette base. Place the wrapped instruments on the rack and arrange
them to avoid overlap. Ensure that all wrapped loads are dry before
handling and/or storage to maintain sterility.
The use of cloth wraps in the STATIM is not recommended.
Figure 10
1
2

12 STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Instructions for Use
SciCan recommends the use of plastic/paper autoclave bags such as SPS™, Medi-Plus™ and Chex All II™.
Steri-Stik™ paper/paper autoclave bags may also be used. The use of cloth wraps in the STATIM is not recommended.
Loosely pack instruments in the bags to allow steam penetration to all instrument surfaces.
The wrapped instrument rack for the STATIM 5000 is designed to hold a maximum of 12 autoclave bags. Care
must be taken to ensure that the combined weight of the loaded bags does not exceed the maximum load
capacity as stated in Appendix: Cycle Profile and Capacity.
The Unwrapped instrument rack fitted with a maximum of 10 STAT-DRI plates will hold 10 autoclave bags.
Rubber and Plastic Instruments
The following materials can be sterilized in the STATIM:
• Nylon
• Polycarbonate (Lexan™)
• Polypropylene, PTFE (Teflon™)
• Acetal (Delrin™)
• Polysulfone (Udel™)
• Polyetherimide (Ultem™)
• Silicone rubber
• Polyester
When loading rubber and plastic instruments in the tray, leave a space between the instruments and the cassette
walls. This ensures that steam reaches all surfaces, and will promote drying.
The following materials cannot be sterilized in the STATIM:
• Polyethylene
• ABS
• Styrene
• Cellulosics
• PVC
• Acrylic (Plexiglas™)
• PPO (Noryl™)
• Latex
• Neoprene
Use of these and similar materials may lead to instrument or equipment damage. If you are unsure of your
instrument’s material or construction, do not load into your STATIM until you have checked with the instrument
manufacturer.
All Instruments
The STATIM is not intended for sterilizing textiles, liquids or biomedical waste.
Instruments will remain sterile after a successful cycle until the cassette is disengaged from the unit. Unwrapped
instruments, once exposed to ambient or external conditions, cannot be maintained in a sterile state. If sterile storage
is desired, wrap the instruments to be sterilized in autoclave bags, according to the instrument manufacturer’s
instructions, and then allow the wrapped cycle to run until the air-dry phase is complete.
Best Practice: Allow instruments (wrapped or unwrapped) to dry completely prior to handling. Instruments must
not touch each other to promote drying and enable effective sterilization.
SciCan recommends the final user carefully choose the most appropriate sterilization cycle according to the
recommendations of their leading infection control authorities and local regulatory guidelines/recommendations.
Routine Monitoring
Chemical process indicators suitable for steam sterilizers should be included in or on each package or load being
sterilized. In addition, the weekly use of biological indicators, which allow you to ascertain whether the instruments
have been exposed to sterilization conditions, is recommended. SciCan recommends using the 3M Attest™
biological monitoring system for routine monitoring. This system consists of self contained biological indicators and
incubators. It is important to select the correct biological indicator for the cycle being tested.

13 STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Instructions for Use
4.5 Using Biological/Chemical Indicators
For detailed instructions on how to handle, use and dispose of both the biological and chemical indicators, please
consult the product literature accompanying the indicators or contact the manufacturer directly.
To use the indicators with the STATIM, follow these steps:
1. Place the appropriate biological indicator in the STATIM chamber.
2. Process the load in the sterilizer according to your usual practice.
3. Ensure that the message “Cycle Complete” is displayed on the LCD after the cycle is finished.
4. Recover the biological and/or chemical indicator and process further according to the literature that accompanied
the indicator.
At the first indication of a potential sterilization failure:
1. Do not process any more instruments until favourable test results have been returned.
2. Ensure the correct indicator type was chosen.
3. Ensure the cassette was not overloaded. Consult the earlier portion of this section for proper loading instructions.
4. If the results do not change, do not process any more instruments within the STATIM and contact your SciCan
dealer for further assistance.
4.6 Instrument Weight Guide
Instrument Typical Instrument Weight
Scissors 30g/0.96 oz
Dental scalers 20 g/0.64 oz
Forceps 15 g/0.48 oz
Dental handpiece 40-60 g/1.29 to1.92 oz
Wrapped instrument rack 260 g/8.35 oz
Unwrapped instrument rack 225 g/7.23 oz
Suction cannula 10 g/0.32 oz
Plastic mouth mirror 8 g/0.25 oz
Impression tray 15 to 45 g/0.48 to 1.45 oz
Plastic x-ray positioning ring 20 g/0.64 oz
NOTE: The above weights are to be used as reference only.
For exact weights of your instruments, consult the manufacturer’s specifications.
4.7 Cycle Profiles
The STATIM’s have multiple sterilization cycles, each designed to sterilize a specific type of instrument.
The instruments will remain sterile after a successful cycle until the cassette is removed from the autoclave.
At the end of each sterilization cycle, microbiologically filtered air-drying will commence.
Unwrapped instruments, once exposed to ambient or external conditions, cannot be maintained in a sterile state.
If sterile storage is desired, wrap the instruments to be sterilized in autoclave bags according to the instrument
manufacturer’s instructions, and allow the wrapped cycle to run until the air-dry phase is complete.
It is important not to overload the chamber as this can inhibit steam access to all instrument surfaces. The types
of instruments and sterilization requirements for each cycle are described over the next few pages. Consult
the Instrument Weight Guide in the previous section for information on how to make up an appropriate load for
the masses specified for individual cycles. The maximum load capacity and a graph depicting each cycle are
provided in the Appendix: Cycle Profile and Capacity.

14 STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Instructions for Use
Unwrapped Cycle
Sterilization Temperature: 134°C (273°F)
Sterilization Hold Time: 3.5 minutes
The Unwrapped Cycle is a general purpose sterilization cycle used to sterilize loads of solid metal instruments
such as pliers, burrs, scalers and forceps. Dental handpieces may be sterilized in this cycle.
Wrapped Cycle
Sterilization Temperature: 134°C (273°F)
Sterilization Hold Time: 10 minutes (STATIM 2000), 6 minutes (STATIM 5000)
The Wrapped Cycle is used to sterilize solid and hollow metal instruments which have been sealed in paper/
paper, or paper/plastic autoclave bags. Dental handpieces may be sterilized in this cycle.
If the cassette contains wrapped instruments and the wraps are not dry when the cassette is opened, the
instruments must be handled in an aseptic manner for immediate use, or resterilized.
Rubber and Plastics Cycle
Sterilization Temperature: 121°C (250°F)
Sterilization Hold Time: 15 minutes
The Rubber and Plastics Cycle is used to sterilize solid unwrapped instruments constructed of metal or the
materials listed in Section 4.4 Preparing and Loading Instruments.
Air Dry Only Cycle (STATIM 2000 ONLY)
This is not a sterilization cycle.
At the end of a cycle, if the cassette has not been removed from the autoclave, the Air Dry Only cycle may be
used to promote further drying. If the cassette has been removed from the autoclave, it may NOT be reinserted
for the Air Dry Only cycle. If the cassette contains wrapped instruments and the wraps are not dry when the
cassette is opened, the instruments must be handled in an aseptic manner for immediate use or resterilized.
Dryness is important for unwrapped instruments for corrosion prevention.
For wrapped instruments, a dry wrap is required to maintain sterility.
The Air Dry Only cycle will run for up to 60 minutes.
Heavy Duty Unwrapped Cycle (STATIM 5000 ONLY)
Sterilization Temperature: 134°C (270°F)
Sterilization Hold Time: 6 minutes
The Heavy Duty Cycle (only available in STATIM 5000) is used to sterilize larger loads of unwrapped metal
instruments. Dental hand pieces can be sterilized in this cycle. The STATIM 5000 Extended Cassette (order no.
01-104104) can be used to process loads up to 470 mm (18.5") long, such as rigid endoscopes, in this cycle.

15 STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Instructions for Use
4.8 Running a Cycle
To operate each cycle, follow these steps and watch the LCD.
Turn the power switch at the back of the unit to ON. The LCD Display reads:
Press the appropriate cycle button on the keypad.
The display will read:
Once the start button has been pressed, the amber indicator light comes on to indicate
that the cycle is in progress. During the cycle, the phases of the cycle will be displayed similar to:
Example only.
As the cycle progresses, the cycle stage and temperature of the chamber are displayed.
During sterilization, the pressure of the chamber and the time remaining for that stage is also displayed.
During the air drying phase, the time remaining is displayed.
Message will vary depending on the cycle choosen.
14:23 3/11/2001
SELECT A CYCLE
[CYCLE YOU SELECTED]
[CYCLE PROFILE]
[CYCLE YOU SELECTED]
PRESS START
and
then
[CYCLE SELECTED]
CYCLE NUMBER XXXXX
CYCLE COMPLETE
PRESS STOP TO RESET
CYCLE COMPLETE
REMOVE CASSETTE
[CYCLE YOU SELECTED] WARMING UP
A
CONDITIONING
95˚ßC
[CYCLE YOU SELECTED]
95˚ßC
B
PRESSURIZING
120.7˚ßC
[CYCLE YOU SELECTED]
120.7˚ßC
C
STERILIZING
136.3˚ßC 217kPa 3:10
[CYCLE YOU SELECTED]
136.3˚ßC 217kPa 3:10
D
VENTING
105˚ßC
[CYCLE YOU SELECTED]
105˚ßC
E
[CYCLE YOU SELECTED]
AIR DRYING: 30:00
F
LENGEND
A) Warming up D) Sterilizing
B) Conditioning E) Venting
C) Pressurizing F) Air Drying

16 STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Instructions for Use
As the cycle is running, an intermittent buzzing sound will be apparent as the pump injects water into the steam
generator. A random clicking sound will also be heard as the exhaust valve opens and closes. The buzzing noise
during the air drying stage is the compressor operating.
If a sterilization cycle is successful, the reminder tone sounds and the amber light flashes until the STOP button is
pressed, or the cassette is removed from the unit and the display will appear similar to:
Be careful. The metal parts will be hot, and the cassette will contain hot steam. After the cassette is removed
from the unit, it should be opened to hasten cooling of instruments.
If a message is displayed which gives a CYCLE FAULT code or a NOT STERILE message, the cassette contents
are not sterile. See Section 8 Troubleshooting for more information.
If the cassette contains wrapped instruments and the wraps are not dry when the cassette is opened, the
instruments must be handled in an aseptic manner for immediate use, or resterilized.
4.9 Stopping a Cycle
To stop a cycle press the STOP button.
If the STOP button is pressed, or the cassette is removed, or the unit detects a problem while operating, the
cycle will stop and the amber active light will flash.
Once a cycle has been stopped, the STOP button must be pressed before another cycle can be started.
The display reads any of the following messages:
If the display shows the message, CYCLE FAULT or NOT STERILE, the cassette contents are not sterile!
See Section 8 Troubleshooting for more information.
If the air drying stage of the cycle is interrupted, the display reads the following messages:
CYCLE COMPLETE
REMOVE CASSETTE
CYCLE COMPLETE
PRESS STOP TO RESET
CASSETTE REMOVED
NOT STERILE
CYCLE FAULT xxx
NOT STERILE
STOP BUTTON PRESSED
NOT STERILE
or or
STOP BUTTON PRESSED
LOAD NOT STERILE
STOP BUTTON PRESSED
DRYING INTERRUPTED
STOP BUTTON PRESSED
PRESS STOP TO RESET

17 STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Maintenance
5. Maintenance
5.1 Cleaning the Cassette
Keeping the STATIM cassette clean is good clinical practice and assists in the function of the unit. SciCan
recommends that the interior surface be cleaned at least once a week.
• Use dishwashing soap or a mild detergent that does not contain chlorine.
• Scrub the inside of the cassette with a cleaning pad designed for use with Teflon™ coated surfaces.
• After scouring, rinse thoroughly with water to remove all traces of the detergent.
Cleaning the inside of your cassette is very important if you regularly sterilize lubricated instruments.
Coating the entire inside surface with STAT-DRI/STAT-DRIPLUS drying agent induces water to form an even coat
on the inside surface, without beading. The water in contact with the hot cassette surfaces also evaporates much
more efficiently. Spotting is minimized and instruments dry much better.
STAT-DRI/STAT-DRI PLUS should be applied every 10 cycles, or when you notice water beading on the lid, and
after every cassette cleaning.
5.2 Cleaning the Water Reservoir Filter
The water reservoir filter should be cleaned at least once a week or when required. The filter can easily be removed
and cleaned by placing the filter upside down under running water to wash away the particles until clean, and then
placed back into the reservoir opening. If a replacement water reservoir filter is required, order part number01-109300S.
5.3 Cleaning the Reservoir
Check the reservoir for dirt or particles. The reservoir may be cleaned by draining followed by cleaning and rinsing
with steam process distilled water ONLY. Use of chemicals or cleaning agents is not reccommended and could
cause the unit damage.
5.4 Cleaning the Exterior Surfaces
Use a soft cloth moistened with soap and water to clean all exterior surfaces. Do not use harsh cleaning
chemicals or disinfectants.

18 STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Maintenance
5.5 Changing the STATIM 2000 Air Filter
The filter should be replaced every six months in order to maintain an
adequate supply of clean air during the air drying cycle.
To change the filter, follow these steps (see Figure 11):
1. Turn the power switch at the back of the unit OFF.
2. Remove and retain the screw (3) securing the filter plate (2)
to the back of the compressor.
3. Remove and discard the old foam air filter (1).
4. Install the new filter (1) (SciCan part no. 01-100207S).
5. Secure the filter plate (2) to the back of the compressor
using the screw (3) retained during the disassembly procedure.
5.6 Changing the Bacteria Retentive Air Filters
The filters should be replaced every six months or after 500 cycles to
maintain an adequate supply of clean air during the air drying cycle.
To change the bacteria retentive air filter on the STATIM 2000 and 5000,
follow these steps (see Figures 11 & 12):
1. Power the STATIM OFF.
2. Disconnect tube A (4) from the bacteria retentive filter (5) and remove
the filter from the filter bracket (6).
As you remove the filter from the bracket, note the
orientation of the arrow mark on the filter.
3. When the filter is free of the bracket,
carefully disconnect tube B (7) from the filter.
4. Before installing the replacement bacteria retentive filter (5)
(SciCan order no. 01-102119S) check that the arrow
mark on the filter matches the direction of the arrow on the bracket.
Push the left hand filter fitting into tube B (7).
5. Gently press the replacement filter into the filter bracket (6).
The arrow mark of the filter should be facing out and pointing to the left.
6. Re-connect tube A (4) to the right hand filter fitting.
Figure 11
STATIM 2000
1
2
3
5
4
6
7
STATIM 5000
7
Figure 12
45
6

19 STATIM 2000/5000 Cassette Autoclave Operator ManualSciCan Ltd. Maintenance
5.7 Replacing the Cassette Seal
To ensure optimum performance of your STATIM cassette autoclave, change
the cassette seal every 500 cycles or every six months, whichever comes first.
Replacement seals are available from SciCan (order number 01-100028S
for STATIM 2000 and 01-101649S for STATIM 5000).
To change the cassette seal, follow these steps:
1. Place the cassette lid and the new seal on a clean work surface.
Examine the position of the old seal in the cassette lid and arrange the
new seal in the same orientation, next to the lid.
2. Remove the old seal and discard. Clean any residue out of the seal
channel and flush out the channel with distilled water (13 a).
3. Lubricate the new seal with the liquid seal lubricant provided (13 b).
4. Insert the rounded edge of the seal under the round lip of the lid. Align
the holes in the new seal with the holes in the lid (13 c).
NOTE: At every corner and at the holes in the lid, two square nibs should
be visible. The nibs should fit flush with the lid’s outer surface.
5. Ensure the seal is completely inserted. Feel around the periphery to
ensure the seal is securely in place.
NOTE: During a cycle, steam may appear between the lid and the tray.
If this persists, remove the cassette and check that the seal is
correctly installed (13 d).
Be careful. The metal parts will be hot, and the cassette may contain hot steam.
5.8 Maintaining Fluid Levels
Use only steam-process distilled water containing less than 5 ppm
total dissolved solids (having conductivity of less than 10 µS/cm) in the
STATIM. To fill the reservoir, remove the cap from the top of the unit and
fill the reservoir. We recommend using a funnel to minimize spills. Each
time you refill the reservoir, empty the waste bottle and refill with water
to the MIN line. Empty the waste bottle often to avoid unpleasant odors
and discoloration of the contents. A low-level chlorine-free disinfectant,
prepared according to the manufacturer’s instructions, may be added to
the waste bottle.
5.9 Reading Water Quality
1. Power up unit while pressing the STOP button to access the User
Setup menu.
2. Using the UNWRAPPED and WRAPPED buttons,
scroll to Water Quality and select it by pressing the
RUBBERANDPLASTIC button.
Figure 13 a
Figure 13 b
Figure 13 c
Figure 13 d
>Water Quality
CD= XXuS/yyy/z.zppm
CD = Conductivity
X X = micro S. value
yyy = engineering value
z.z = parts per million value
