SciCan STATIM 7000 Installation guide

Statim 7000
Field Training Manual

2
Table of Contents
Table of Contents 2
Packaging & Accessories 3
Installation 4–6
User Setup 7 – 12
Service Setup 13 – 22
CoverRemoval 23–25
ArmatureRemoval 26
RearCoverRemoval 27
ChassisParts 28–30
Cassette 31–33
Error Codes 34 – 38
Water Conductivity Circuit Calibration 39
Validation Thermocouple Calibration 40 – 41

3
Statim 7000
Packaging & Accessories
2 Water Filters
Exhaust Tubings
Stat-Dri Power Cord
Op Manual
O-ring Lube
Cassette (on bottom of box)
Condenser Bottle
Waste Bottle
Water Reservoir

4
Statim 7000 Installation
Connect the Power Cord and the Exhaust Tubings to the rear of the Statim.
Connect the Exhaust Tubings to the large fittings
on the Condenser Bottle & the small tubings to the
small fitting on the Condenser & Waste Bottles.
Push In Fitting Push In Fitting Power Cord Connection
Drain Tube
Power SwitchAir Filter
Condenser Bottle
Waste Bottle

5
Connect bottle together using Quick Disconnect
Coupling.
Direct to Drain Waste Bottle
Direct to Drain Waste Bottle Installation Instructions

6
Insert Water Filter or Bypass Cartridge.
Insert Water Reservoir
Note: The Biological Filter is accessible behind the Water Reservoir.
Biological Filter

7
Statim 7000 User Setup
User setup mode – To initially setup your Statim
Hold down the Stop button and turn the unit ON.
If unit is already ON.
Hold down the Stop Button and the Air Dry Only Button simultaneously.
Initial Display
Unit ID Setup *
Drying – Unwrapped
Drying – Wrapped
Drying – R&P
Drying - Extra
Water Quality
Last Printout *
RS232 *
End of Line CR/LF *
Serial Port Bit rate *
Printer user º char *
Steri. End buzzer
Air Filter Warning
Water Filter
Replace Filter
Save and Exit
Exit
* Only used when Statim is connected to a Printer or Data Logger
Keypad:
Unwrapped Select next item in the menu
Wrapped Select previous item in the menu
Rubber and Plastics Enter the indicated sub menu selection
Stop Exit menu to normal mode of operation
Time/Date Setup Mode – Set the proper time and date
Keypad:
Unwrapped Increase current field (the flashing value on the display)
Wrapped Decrease current field (the flashing value on the display)
Rubber and Plastics Select next field
Stop Save & exit menu to normal mode of operation
18:00 04/10/2008
HH:MM MM/DD/YYYY
>Time/Date Setup
Language Setup

8
Language Setup – Display information in your desired language
Available Languages
N. A. English (North American English)
U. K. English (United Kingdom English)
Francais (French)
Deutsch (German)
Espanol (Spanish)
Italiano (Italian)
Dansk (Danish)
Portugues
Nederlands
Japanese
Svenska (Swedish)
Polski (Polish)
Magyar (Hungarian)
Cesky (Czech)
Norsk (Norwegian)
Islenska (Iceland)
Slovencina (Slovak)
Eesti (Estonian)
Lietuviu K. (Lithuanian)
Slovenian (Slovenia)
Romana (Romanian)
Keypad:
Unwrapped Select next language
Wrapped Select previous language
Stop Save & exit menu to normal mode of operation
Unit ID Setup – Associate unit with an ID number (Used with Printer)
Keypad:
Unwrapped Decrease current field (the flashing value on the display)
Wrapped Increase current field (the flashing value on the display)
Rubber and Plastics Select next digit
Stop Save & exit menu to normal mode of operation
Unit # :
000
N. A. ENGLISH

9
Drying – Unwrapped – Set Unwrapped Cycle drying time between 0 & 30 minutes
Keypad:
Unwrapped Increase time by one minute
Wrapped Decrease time by one minute
Rubber and Plastics Save and return to main menu
Stop Save & exit menu to normal mode of operation
Drying – Wrapped – Set Wrapped Cycle drying time between 10 & 30 minutes
Keypad:
Unwrapped Increase time by one minute
Wrapped Decrease time by one minute
Rubber and Plastics Save and return to main menu
Stop Save & exit menu to normal mode of operation
Drying – R&P – Set Rubber & Plastics Cycle drying time between 0 & 30 minutes
Keypad:
Unwrapped Increase time by one minute
Wrapped Decrease time by one minute
Rubber and Plastics Save and return to main menu
Stop Save & exit menu to normal mode of operation
Drying – Extra – Sets drying time between 1 & 30 minutes for Air Dryer Only Cycle
Keypad:
Unwrapped Increase time by one minute
Wrapped Decrease time by one minute
Rubber and Plastics Save and return to main menu
Stop Save & exit menu to normal mode of operation
>Drying - Unwrapped
Time: 12 minutes
>Drying - Wrapped
Time: 12 minutes
>Drying – R&P
Time: 12 minutes
>Drying – Extra
Time: 12 minutes

10
Water Quality – Display detected water quality
Screen Representation
x.x Water conductivity in uS (micro-Siemens)
NNN Water conductivity in ADC (Analog to Digital converter) counts (0…255)
y.y Water quality in ppm (parts per million)
Keypad:
Rubber and Plastics Return to main menu
Stop Exit menu to normal mode of operation
Last Printout – Printer reprints last cycle and unit returns to normal mode of operation
(Used with Printer)
RS232 – To select which serial device to attach (Used with Printer)
Serial Printer
USB FLASH/MSD
Keypad:
Unwrapped Move to next option, second line shows the new value
Wrapped Move to previous option, second line shows the new value
Rubber and Plastics Save and return to main menu
Stop Exit menu to normal mode of operation without saving
End of Line CR/LF – Configure the printout layout (Used with Printer)
-
CR
This only needs to be set if a serial printer is attached to the serial port.
Available options:
- No line terminator is sent after each line. To be used with printer that accepts only
20 characters per line and automatically advances to next line. Should be used
with the STATprinter.
CR A <CR> is sent at the end of the line. To be used with printers that advance to
beginning of next line when a CR is received.
CR/LF A <CR><LF> is sent at the end of the line. To be used with printers that translate
advance to beginning of next line only when LF is received.
Keypad:
Unwrapped Select next option. Second line shows the new value
Wrapped Select previous option. Second line shows the new value
Rubber and Plastics Save & exit to main menu
Stop Exit and return to normal mode of operation
>RS232
N/A
>End Of Line CR/LF
CR/LF
>Water quality
CD= x.xuS/NNN/y.yppm

11
SciCan Suggested
External Printers End Of Line CR/LF Serial Port Bit Rate Printer user °char
Epson
TM-U220D (C31C515603) CR/LF 9600 248 [0xF8]
Citizen
IDP-3110-40 RF 120B CR 9600 N/A
Star Micro
SP212FD42-120 CR 9600 210 [0xd2]
Star Micro
SP216FD41-120 CR/LF 9600 210 [0xd2]
Star Micro
SP512MD42-R CR/LF 9600 210 [0xd2]
Serial Port Bit Rate – Choose bit rate for device connected to the serial port
(Used with Printer)
19200
57600
115200
1200
2400
4800
If USB FLASH/MSD is selected as the RS232 device, a Serial Port Bit Rate selection of 9600 will
be required for the Data Logger to be operational.
Keypad:
Unwrapped Select next value
Wrapped Select previous value
Rubber and Plastics Save & Return to main menu
Stop Exit without saving and return to normal mode of operation
Printer user °char – Setting to print a °C sign (Used with Printer)
32 decimal value for selected char-default 32
20 hex value for the selected char-default 20
Keypad:
Unwrapped Increase value by one
Wrapped Increase value by ten
Rubber and Plastics Select and return to main menu
Stop Exit without saving and return to normal mode of operation
Serial Port Bit Rate
9600
Printer user °char
32
[
0x20
]

12
Steri. End buzzer – Set length of time buzzer will sound a end of sterilization
15s
30s
Max
Keypad:
Unwrapped Select next value
Wrapped Select previous value
Rubber and Plastics Save & Return to main menu
Stop Save & exit menu to normal mode of operation
Air Filter Warning – Reset warning indicator when Air Filter is replaced.
Yes, Reset
Water Filter – Set Statim for Water Filter or Water Bypass Cartridge
Not Installed
Replace Filter – Reset Statim when Water Filter is replaced.
Yes, replace
Save and Exit – Saving settings and return to normal mode of operation
Upon selection, current settings are saved and unit restarts in normal mode of operation
Exit – Exit menu without saving settings
Upon selection, current settings are discarded, not saved and unit restarts in normal mode of
operation
>Steri. End buzzer
0s
>Air Filter Warning
Do not Reset
>Water Filter
Installed
>Replace Filter
Do not replace

13
Statim 7000 Service Setup
Service setup mode – To enter the Service Setup Mode, turn power switch ON while
holding down Unwrapped and Wrapped buttons.
The Service Setup Mode is password protected; a password must be entered to continue. The
default password is Unwrapped, Wrapped, Rubber and Plastics, Stop buttons pressed in this
order. If the password has been changed the backdoor password is, Unwrapped, Wrapped,
Unwrapped, Wrapped buttons pressed in this order.
Language Setup
Unit ID Setup *
Set cycle counter
Conductivity Setup
Water.Cnd Tmp. Comp
Last Printout *
Stored CF Printouts *
Clear CF Printouts *
Display last CF#
Devices Test On/Off
Temperature Offset
Validation Offset
Repeater mode
RS232 *
End of Line CR/LF *
Serial Port Bitrate *
Printer user º char *
Factory default
Drying – Unwrapped
Drying – Wrapped
Drying – R&P
Drying - Extra
Air Filter Warning
Water Filter
Replace Filter
Steri. End buzzer
Upgrade Firmware
Change Password
Backup NVRAM
Restore NVRAM
Save and Exit
Exit
Production Cycle
* Only used when Statim is connected to a Printer or Data Logger
Keypad:
Unwrapped Select next item in the menu
Wrapped Select previous item in the menu
Rubber and Plastics Enter the indicated sub menu selection
Stop Exit menu to normal mode of operation
>Calibration
Time/Date Setup

14
Calibration – Select calibration to run chamber and validation thermocouple calibration cycles
only.
Note: See page 38 for validation thermocouple calibration procedure.
Time/Date Setup Mode – Set the proper time and date
Keypad:
Unwrapped Increase current field (the flashing value on the display)
Wrapped Decrease current field (the flashing value on the display)
Rubber and Plastics Select next field
Stop Save & exit menu to normal mode of operation
Language Setup – Display information in your desired language
Available Languages
N. A. English (North American English)
U. K. English (United Kingdom English)
Francais (French)
Deutsch (German)
Espanol (Spanish)
Italiano (Italian)
Dansk (Danish)
Portugues
Nederlands
Japanese
Svenska (Swedish)
Polski (Polish)
Magyar (Hungarian)
Cesky (Czech)
Norsk (Norwegian)
Islenska (Iceland)
Slovencina (Slovak)
Eesti (Estonian)
Lietuviu K. (Lativan)
Slovenian (Slovenia)
Romana (Romanian)
Keypad:
Unwrapped Select next language
Wrapped Select previous language
Rubber and Plastics If Repeater mode is ON, this key will scroll through all the available
display messages of the chosen language.
Stop Save & exit menu to normal mode of operation
18:00 07/09/2008
HH:MM MM/DD/YYYY
N. A. ENGLISH

15
Unit ID Setup – Associate unit with an ID number (Used with Printer)
Keypad:
Unwrapped Decrease current field (the flashing value on the display)
Wrapped Increase current field (the flashing value on the display)
Rubber and Plastics Select next digit
Stop Save & exit menu to normal mode of operation
Set cycle counter – Adjust the recorded number of cycles ran
Keypad:
Unwrapped Decrease current digit
Wrapped Increase current digit
Rubber and Plastics Select next digit
Stop Save & exit menu to normal mode of operation
Conductivity Setup – To display detected water quality and adjust low and high thresholds.
Screen Representation
x.x Water conductivity in uS (micro-Siemens)
NNN Water conductivity in ADC (Analog to Digital converter) counts (0…255)
y.y Water quality in ppm (parts per million)
L “L” is displayed when water level switch is activated, "-" when the switch is
not active
R “R” is displayed when water reservoir reed switch is activated, "-" when the
water reservoir reed switch is not activated.
HH.H High value threshold (Bad water threshold) default 10uS
Values larger than this trigger “Bad water quality” error
G.GG Water conductivity circuit gain default 1.00
Note: Statim 7000 does not use the conductivity reading to trigger the “No Water, Refill
Reservoir” message. There is a float sensor for that.
Keypad:
Unwrapped Increase current field
Wrapped Decrease current field
Rubber and Plastics Move to next field
Stop Exit menu to normal mode of operation
Note: To perform Water Conductivity Circuit Calibration see page 37.
Unit # :
000
CD= x.xuS/NNN/y.yppm
L R H=HH.H G=G.GG
Cycle Number
000000

16
Water Cnd Tmp Comp - To enable or disable water conductivity temperature compensation
Off
Keypad:
Unwrapped Select next option Second line shows the new value
Wrapped Select previous option. Second line shows the new value
Rubber and Plastics Select and return to main menu
Stop Exit, without saving, to normal mode of operation
Last Printout – Printer reprints last cycle and unit returns to normal mode of operation
(Used with Printer)
Stored CF Printouts – Printer prints saved cycle fault printouts and unit returns to normal
mode of operation. (Used with Printer)
The saved CF printouts are sent to the printer or data logger only when either one is attached and
configured. The following types of errors are saved:
CF’s
Water quality or Water level low errors
Cycle interrupted due to errors (##)
Clear CF Printouts – Reset Cycle Fault printout list (Used with Printer)
Yes
Keypad:
Unwrapped Select next option Second line shows the new value
Wrapped Select previous option. Second line shows the new value
Rubber and Plastics Select and return to main menu
Stop Exit, without saving, to normal mode of operation
Display last CF# - Show the last Cycle Fault that occurred
Screen Representation
## Last recorded CF number
(######) Cycle counter number for last CF
Keypad:
Rubber and Plastics Return to main menu
Stop Exit to normal mode of operation
>Water Cnd Tmp Comp
On
>Clear CF Printouts
No
>Display last CF#
## (######)

17
Devices Test On/Off – Toggle the unit’s devices on or off
Valve Off
Compressor Off
Yellow LED Off
Extra 1L Off
Extra 2L Off
Valve 2 Off
Fan Off
Keypad:
Unwrapped Select next option. Second line shows the new value
Wrapped Select previous option. Second line shows the new value
Rubber and Plastics Toggle On/Off selected device
Stop Return to main menu
Chamber Temperature Offset – View the offset of the chamber thermocouple
Screen Representation
## Offset value
Keypad:
Rubber and Plastics Return to main menu
Stop Exit to normal mode of operation
Validation Offset – View the offset of the validation thermocouple
Screen Representation
## Offset value
Keypad:
Rubber and Plastics Return to main menu
Stop Exit to normal mode of operation
Repeater mode – Enable or disable unit to run cycles continuously
On
Keypad:
Unwrapped Select next option. Second line shows new value
Wrapped Select previous option. Second line shows new value
Rubber and Plastics Select and return to main menu
Stop Exit, without saving, to normal mode of operation
>Devices Test On/Off
Pump Off
>Temperature Offset
##
>Validation Offset
##
>Repeater mode
Off

18
RS232 – To select which serial device to attach (Used with Printer)
Serial Printer
USB FLASH/MSD
Keypad:
Unwrapped Move to next option, second line shows the new value
Wrapped Move to previous option, second line shows the new value
Rubber and Plastics Save and return to main menu
Stop Exit menu to normal mode of operation without saving
End of Line CR/LF – Configure the printout layout (Used with Printer)
-
CR
This only needs to be set if a serial printer is attached to the serial port.
Available options:
- No line terminator is sent after each line. To be used with printer that accepts only
20 characters per line and automatically advances to next line. Should be used
with the STATprinter.
CR A <CR> is sent at the end of the line. To be used with printers that advance to
beginning of next line when a CR is received.
CR/LF A <CR><LF> is sent at the end of the line. To be used with printers that translate
advance to beginning of next line only when LF is received.
Keypad:
Unwrapped Select next option. Second line shows the new value
Wrapped Select previous option. Second line shows the new value
Rubber and Plastics Save & exit to main menu
Stop Exit and return to normal mode of operation
SciCan Suggested
External Printers End Of Line CR/LF Serial Port Bit Rate Printer user °char
Epson
TM-U220D (C31C515603) CR/LF 9600 248 [0xF8]
Citizen
IDP-3110-40 RF 120B CR 9600 N/A
Star Micro
SP212FD42-120 CR 9600 210 [0xd2]
Star Micro
SP216FD41-120 CR/LF 9600 210 [0xd2]
Star Micro
SP512MD42-R CR/LF 9600 210 [0xd2]
>RS232
N/A
>End Of Line CR/LF
CR/LF

19
Serial Port Bit Rate – Choose bit rate for device connected to the serial port
(Used with Printer)
19200
57600
115200
1200
2400
4800
If USB FLASH/MSD is selected as the RS232 device, a Serial Port Bit Rate selection of 9600 will
be required for the Data Logger to be operational.
Keypad:
Unwrapped Select next value
Wrapped Select previous value
Rubber and Plastics Save & return to main menu
Stop Exit, without saving, and return to normal mode of operation
Printer user °char – Setting to print a °C sign (Used with Printer)
dd decimal value for selected char-default 32
hh hex value for the selected char-default 20
Keypad:
Unwrapped Increase value by one
Wrapped Increase value by ten
Rubber and Plastics Select and return to main menu
Stop Exit, without saving, and return to normal mode of operation
Factory default – Reset to factory default settings
Yes, Reset NVRAM!
This function resets the NVRAM to factory default settings. The chamber and voltage calibration
offsets and conductivity settings will be reset. The cycle counter will not be reset.
Keypad:
Unwrapped Select next option. Second line shows the new value
Wrapped Select previous option. Second line shows the new value
Rubber and Plastics Save and return to main menu
Stop Exit, without saving, and return to normal mode of operation
Serial Port Bit Rate
9600
Printer user °char
dd
[
0xhh
]
>Factory default
No

20
Drying – Unwrapped – Set Unwrapped Cycle drying time between 0 & 30 minutes
Keypad:
Unwrapped Increase time by one minute
Wrapped Decrease time by one minute
Rubber and Plastics Save and return to main menu
Stop Save & exit menu to normal mode of operation
Drying – Wrapped – Set Wrapped Cycle drying time between 10 & 30 minutes
Keypad:
Unwrapped Increase time by one minute
Wrapped Decrease time by one minute
Rubber and Plastics Save and return to main menu
Stop Save & exit menu to normal mode of operation
Drying – R&P – Set Rubber & Plastics Cycle drying time between 0 & 30 minutes
Keypad:
Unwrapped Increase time by one minute
Wrapped Decrease time by one minute
Rubber and Plastics Save and return to main menu
Stop Save & exit menu to normal mode of operation
Drying – Extra – Sets drying time between 1 & 30 minutes for Air Dryer Only Cycle
Keypad:
Unwrapped Increase time by one minute
Wrapped Decrease time by one minute
Rubber and Plastics Save and return to main menu
Stop Save & exit menu to normal mode of operation
>Drying - Unwrapped
Time: 12 minutes
>Drying - Wrapped
Time: 12 minutes
>Drying – R&P
Time: 12 minutes
>Drying – Extra
Time: 12 minutes
