Scion-Tech SC38.MX88 User manual
User Manual
Version 1.1a
SC38.MX88
User ManualScion Tech SC38.MX88
8 x 8 HDMI (HDBaseT) Matrix
18G, 4K/60Hz 4:4:4, HDR
OutputScaling4K→1080P
User ManualScion Tech SC38.MX88
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
The manual is only for operational purposes, please contact a local dealer for maintenance assistance. The
functions described in this version were updated in November 2019. In the constant effort to improve this product,
we reserve the right to make functional or parameter changes without notice or obligation. Please refer to your
local dealer for the latest details.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric
shock, lighting strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend
the life of your equipment.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance
with the instructions may cause harmful interference to radio communications equipment. It has been tested and
found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a commercial installation.
Any changes or modifications not expressly approved by the manufacture would void the user’s authority to
operate the equipment.
F
E
D
E
R
A
L
C
O
M
M
U
N
I
C
A
T
I
O
N
S
C
O
M
M
I
S
S
I
O
N
-
U
S
A
-
F
User ManualScion Tech SC38.MX88
Safety Precautions
●Unpack the equipment carefully and save the packaging for possible future use.
●Follow basic safety precautions to reduce the risk of fire, electric shock and personal injury.
●Do not dismantle the housing or modify the enclosure as this may result in electric shock or personal injury.
●Using parts or components not meeting the manufactures specifications may result in damage, deterioration or
malfunction of the device.
●Refer all and any servicing to the manufacturer or local dealer.
●To prevent electric shock, do not expose this device to rain, moisture or install this product near water.
●Do not place items on the product as this may result in overheating.
●Do not open or remove the housing as this may expose you to harmful voltages or electric shock.
●Ensure the product has plenty of ventilation above and below.
●Liquid spillage over or inside the product may result in electric shock and permanent damage. In the event of
spillage remove the power immediately.
●Do not pull or twist the optical cables as this may result in damage to the optical connector.
●Do not use liquid or aerosol cleaners on the product and always remove the power before cleaning.
●Remove the power if the product is going to be left for long periods without use.
●Information on disposal for scrapped devices: do not burn or mix with general household waste and please treat
the product as normal electrical waste.
User ManualScion Tech SC38.MX88
CONTENTS
1 Introduction, Features and Package Contents--------------------------------------------------------------------- 5
2 Matrix Specifications------------------------------------------------------------------------------------------------- 6
3 Receiver Specifications----------------------------------------------------------------------------------------------- 7
4 Front Panel Description---------------------------------------------------------------------------------------------- 8
5 Rear Panel Description----------------------------------------------------------------------------------------------- 8
6 Receiver Front & Rear Panel Description------------------------------------------------------------------------- 9
7 Application Drawing-------------------------------------------------------------------------------------------------- 10
8 Front Panel Button Control------------------------------------------------------------------------------------------ 11
8.0.1 Signal Switching---------------------------------------------------------------------------- 11
8.0.2 Locking and Un-Locking Front Panel Buttons----------------------------------------- 11
8.0.3 System Status-------------------------------------------------------------------------------- 11
8.0.4 EDID Management------------------------------------------------------------------------- 12
8.0.5 Audio Settings------------------------------------------------------------------------------- 13
8.0.6 Presets---------------------------------------------------------------------------------------- 13
8.0.7 IP Address------------------------------------------------------------------------------------ 13
9 Graphic User Interface (GUI) Control----------------------------------------------------------------------------- 14
9.0.1 Signal Switching---------------------------------------------------------------------------- 14
9.0.2 Audio Settings------------------------------------------------------------------------------- 15
9.0.3 Down Scaling-------------------------------------------------------------------------------- 16
9.0.4 HDCP----------------------------------------------------------------------------------------- 16
9.0.5 EDID Copy---------------------------------------------------------------------------------- 17
9.0.6 EDID Setting-------------------------------------------------------------------------------- 17
9.0.7 CEC Control--------------------------------------------------------------------------------- 18
9.0.8 RS232 Control------------------------------------------------------------------------------ 19
9.0.9 Access---------------------------------------------------------------------------------------- 20
9.1.1 Interface-------------------------------------------------------------------------------------- 20
9.1.2 Network Settings---------------------------------------------------------------------------- 21
10 IR Remote Control---------------------------------------------------------------------------------------------------- 21
11. Maintenance and Warranty------------------------------------------------------------------------------------------ 22
1. Introduction
The SC38.MX88 matrix is packed with many features and delivers stunning Ultra HD video up to 70m over
CAT5e/6 cable. Each HDMI source and accompanied IR signal can be routed to any display simultaneously. The
CAT5e/6 output has a mirrored HDMI output which can be used for recording or simply connecting an additional
display for rooms where the source can be shared such as a bedroom with on-suite.
In addition to the HDMI mirrored outputs the matrix also provides separate switched analogue and digital audio
outputs for connecting to amplifiers supplying audio via a separate sound system. These audio outputs can be
extracted from the HDMI input signal, HDBaseT output or the audio return channel (ARC) from the receivers.
The receivers are (PoC) powered over the CAT5e/6 cable so there’s no need for additional power adaptors behind
the screens. The receivers can be connected up to 70m from the matrix and still provide zero latency, 4K/60Hz
images without requiring any adjustments.
Bi-Directional IR and RS232 is provided for controlling the source devices from the remote locations and
controlling the screens from the matrix.
Each zone simply selects the required input using the IR remote control provided and then uses the third party
remote control to control the source device. These IR signals are routed with the HDMI signal eliminating any
possibility of controlling two devices at the same time.
The matrix also has local control using either IR, the front panel buttons, RS232, CEC or logging in via a web
browser making it easy to link up with third party smart home controllers such as RTL, Crestron, Control4 and
more.
Our SC38.MX88 matrix supports the latest industry standards including HDMI 2.0, HDCP 2.2, HDR10,
4K/60Hz, YUV 4:4:4 and come with a 2 years manufactures warranty. The package includes 8 x HDBaseT
receivers and all the IR transmit and receiver cables needed to complete your installation.
Matrix package contents
1. 1 x Main Unit (SC38.MX88)
2. 2 x Rack Mount Ears
3. 8 x IR Emitters
4. 8 x IR Senders cables
5. 1 x IR Remote Control
6. 16 x 3-Pin Phoenix Terminal
7. 1 x RS232 Cable (3-Pin Phoenix to DB9)
8. 1 x Power Lead
9. User Manual
Page 5
User ManualScion Tech SC38.MX88
Key Features
●8 x 8 HDMI (HDBaseT) Matrix
●HDMI 2.0, HDCP 2.3
●ARC (audio return path)
●18G, 4K/60Hz, YCbCr 4:4:4, HDR, HDR10
●LPCM 7.1, Dolby True HD, DTS-HD
Key Features
●8 x Mirrored HDMI Outputs
●4K@40m and 1080P@70m
●Extracts analogue and digital audio
●PoC (receivers powered over CAT5e)
●Control: IR, CEC, RS232 and TCP/IP
Receiver package contents
1. 8 x Receivers (SC38.MX88-RX)
2. 8 x Rack Mount Ear Sets
3. 8 x IR Emitters
4. 8 x IR Senders cables
5. 8 x 3-Pin Phoenix Terminal
Page 6
User ManualScion Tech SC38.MX88
Connections
HDMI Input: 8 x HDMI Type A, 19-Pin Female
HDBaseT Output: 8 x RJ45 Data socket
Mirrored HDMI Output: 8 x HDMI Type A, 19-Pin Female
Digital Audio Output: 8 x Toslink Optical
Analogue L/R Audio Output: 8 x 3-Pin Phoenix Terminal
RS232 Pass-Through: 8 x 3-Pin Phoenix Terminal
Infra-Red Input: 9 x 3.5mm Jack Socket
Infra-Red Output: 9 x 3.5mm Jack Socket
Infra-Red Control: 1 x 3.5mm Jack Socket
RS232 Control: 1 x 3-Pin Phoenix Terminal
TCP/IP Control: 1 x RJ45 Data Socket
Firmware Upgrade: 1 x Mini HDMI
Power: 1 x IEC Switched Main Plug
Signal
Signal Input: HDMI
Standards: HDMI 2.0, HDCP 2.2, CEC
Bandwidth: 18Gbps
Video Resolutions: 4K/60Hz, 4:4:4
Colour Space: RGB/YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0, HDR, HDR 10+, DLD, Dolby Vision
Colour Depth: 8/10/12-bit
HDMI Audio: LPCM 7.1, Dolby Atmos™, Dolby True HD™, Dolby Digital™ Plus, DTS: X™, DTS-HD™
Master Audio™ pass through
Toslink Digital Audio: PCM, Dolby Digital, DTS, DTS-HD
L/R Stereo Audio: PCM
Infra-Red: Wide Bandwidth, Frequency 30KHz to 56KHz (940nm)
Cable Lengths
HDMI Input/Output Cable: 4K/60Hz 4:4:4@5m, 4K/60Hz 4:2:0@10m, 1080p/60Hz@15m
CAT5e/6/7 Distance: 4K/60Hz 4:4:4@40m, 1080p/60Hz@70m
Power
Input: 100~240V AC 50/60Hz
Consumption: 125 Watts
Environment
Operating Temperature: -0° to 40°C
Storage Temperature: -20° to 60°C
Operating Humidity: 20 to 90% RH (no condensation)
Dimensions: (W) 436 x (D) 88 x ( H) 440
Weight: 5.8kg
Colour: Black
ESD: Human Body - +/-8kV, (air gap discharge) & +/-4kV (contact discharge)
Safety and Emissions: CE, FCC, RoHS
Specifications
2. MATRIX
User ManualScion Tech SC38.MX88
Page 7
Specifications
3. RECEIVER
Connections
CAT5e/6/7 (HDBaseT) Input: 1 x RJ45 Data Socket
Digital Audio Input (ARC): 1 x Toslink Optical
Digital Audio Output: 1 x Toslink Optical
RS232 Pass-Through: 1 x 3-Pin Phoenix Terminal
Infra-Red Input: 1 x 3.5mm Jack Socket
Infra-Red Output: 1 x 3.5mm Jack Socket
Firmware Upgrade: 1 x Mini HDMI
Power: 1 x DC Jack (not required when used with matrix)
Signal
Signal Input: HDBaseT
Standards: HDMI 2.0, HDCP 2.2, CEC
Bandwidth: 18Gbps
Video Resolutions: 4K/60Hz, 4:4:4
Colour Space: RGB/YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0, HDR, HDR 10+, DLD, Dolby Vision
Colour Depth: 8/10/12-bit
HDMI Audio: LPCM 7.1, Dolby Atmos™, Dolby True HD™, Dolby Digital™ Plus, DTS: X™, DTS-HD™
Master Audio™ pass through
Toslink Digital Audio: PCM, Dolby Digital, DTS, DTS-HD
L/R Stereo Audio: PCM
Infra-Red: Wide Bandwidth, Frequency 30KHz to 56KHz (940nm)
Cable Lengths
HDMI Input/Output Cable: 4K/60Hz 4:4:4@5m, 4K/60Hz 4:2:0@10m, 1080p/60Hz@15m
CAT5e/6/7 Distance: 4K/60Hz 4:4:4@40m, 1080p/60Hz@70m
Power (not required when used with matrix)
Input: 24V DC 1.25A
Consumption: 12 Watts
Environment
Operating Temperature: -0° to 40°C
Storage Temperature: -20° to 60°C
Operating Humidity: 20 to 90% RH (no condensation)
Dimensions: (W) 40 x (D) 84 x ( H) 20
Weight: 290g
Colour: Black
ESD: Human Body - +/-8kV, (air gap discharge) & +/-4kV (contact discharge)
Safety and Emissions: CE, FCC, RoHS
4. Front Panel Description
User ManualScion Tech SC38.MX88
Number Name Function / Description
1 LED Display Displays the matrix status.
2 Power LED Illuminates green when powered ON and red when in standby.
3 IR LED & Sensor The LED illuminates red when a signal is being received.
4 Input Four buttons for selecting input source.
5 Output Four buttons for selecting output.
6 Menu
●LOCK: Locks and Un-Locks the front panel buttons.
●PRESET: Selects a preset setting.
●MENU: Opens menu and confirms selection “Enter”.
●UP: Move up one page.
●DOWN: Move down one page.
Page 8
3
46
1
2
PRESET
LOCK UP
DOWN
MENU
BACK
IR
PWR
1
Input
2 3 4
Output
1 2 3 4
1 2 3 4
1 2 3 4
5
8 x 8 HDMI Matrix
Scion Tech
SC38-MX88
5. Rear Panel Description
Number Name Function / Description
1 Input 8 x HDMI Inputs Type-A Female
2 IR In
4 x 3.5mm jack sockets to connect IR receivers. Each IR input is associated
with the respective HDBaseT receivers output and cannot be switched
seperatley. It makes up a Bi-Directional IR transmission with the IR OUT on
the corresponding HDBaseT receiver.
ALL IN: Transmits to all 4 x HDBaseT Receivers.
3 IR Out
8 x 3.5mm jack sockets for connecting IR emitters and attaching to IR
sensors on source devices.
ALL OUT: Common output for connecting IR emitter and attaching to a
source device.
4 Output 8 x HDBaseT (CAT5e) outputs and 8 x HDMI for local connections.
5 Audio Out / ARC
8 x Terminal block and 4 x Toslink connectors. Audio is selectable between
HDMI input and HDBaseT output. Toslink can also be used for ARC from
the HDBaseT receivers.
6 RS232 8 x Terminal block for RS232 pass-though from matrix to receivers.
7 Control RS232: 1 x Terminal block. IR: 1 x 3.5mm jack. TCP/IP: 1 x RJ45 Data
socket. FW: 1 x USB Type A (Firmware Upgrade Only).
8 Power 1 x IEC Mains Inlet (switched). AC 100 ~ 240V
Page 8
User ManualScion Tech SC38.MX88
RS232 Pass-Through
IR EYE
FW
ALL
1 2 3 4 5 6 7 8
INPUTS
Tx Rx
TCP/IP
L R
L R
ALL
1 2 3 4 5 6 7 8
1 2 3
4
5 6 7
8
1 2 3
4
5 6 7
8
Audio Matrix Out / ARC
RS232
Control IR IN IR OUT
HDMI Out
HDBaseT Out
1 2 3 4 5 6 7 8
62
73
154
8
6. Receiver Front & Rear Panel Description
User ManualScion Tech SC38.MX88
Page 9
Number Name Function / Description
1 Power LED illuminates Red when powered on.
2 ARC Mode
To enable ARC use a paper clip or small pointed object to press the switch
behind the panel, the LED will illuminate Blue when activated. When enabled
the “ARC Audio In” will be transferred to the optical connected located on the
rear of the Matrix. This can be connected to an independent audio system and
will be synced with the TV’s audio.
3 ARC Audio In Toslink connector for audio in from the TV.
4 FW Firmware upgrade port only.
5 HDMI Out Connect to HDMI input of the TV.
6 Audio Out When “ARC” is disabled the HDMI audio will be extracted and presented on
this Toslink optical connector.
7 IR In 3.5mm Jack socket for IR sender cable. (Pass-Through).
8 IR Out 3.5mm Jack socket for IR emitter cable. (Pass-Through).
9 RS232 3-Pin Phoenix terminal. (Pass-Through).
10 HDBaseT In
RJ45 Data socket. The Link LED illuminates Orange to confirm connection
with the Matrix. The HDCP LED illuminates Green when the signal contains
HDCP content.
9 DC 24V Power input (not required when used with Scion SC38.MX44 matrix)
1 2
Power ARC Mode ARC
Audio In FW
3 4 6 7 8
Tx Rx
HDMI Out Audio Out IR In IR Out RS232 HDBaseT IN DC 24V
5 9 10 11
LinkHDCP
7. Application Drawing
Page 10
User ManualScion Tech SC38.MX88
Multi Room Audio
Speakers
Local Display
Ceiling Speakers
4 x HDMI Signal Inputs
IR Out
RS232
Ethernet Control
IR Matrix Control
Display
ARC
RS232
IR Source
Control
RS232 Pass-Through
IR EYE
FW
ALL
1 2 3 4 5 6 7 8
INPUTS
Tx Rx
TCP/IP
L R
L R
ALL
1 2 3 4 5 6 7 8
1 2 3
4
5 6 7
8
1 2 3
4
5 6 7
8
Audio Matrix Out / ARC
RS232
Control IR IN IR OUT
HDMI Out
HDBaseT Out
1 2 3 4 5 6 7 8
IR Remote Screen Control
CAT5e/6
Receiver
8. Front Panel Button Control
The matrix can be controlled using the buttons on the front panel. On completion of each command the buttons
used will flash three time to confirm your selection. If the command was not accepted or failed the button will go
off immediately.
User ManualScion Tech SC38.MX88
8.0.1 Signal Switching
●Switch an input to an output
Operating: INPUT# + OUTPUT# + MENU
●Switch an input to several outputs
Operation: INPUT# + OUTPUT# + … + MENU
Note: The factory default status sets all IR outputs to the corresponding HDMI inputs. When you switch a HDMI
input the corresponding IR output will be switched synchronously.
8.0.2 Locking / Unlocking Panel Buttons
●Press and hold the “Lock” button from three seconds to lock or unlock.
8.0.3 System Status
●Press the “Menu” button to display the matrix status and use the “up/down” buttons to scroll.
IN
LINK
1
1
1
2
1
3
1
4Reports the signal switching status
IN
LINK
1
Y
2
Y
3
Y
4
YConnection status of all HDMI inputs. Y = Connected, N= No Connection
OUT
LINK
1
Y
2
Y
3
Y
4
YConnection status of all HDBaseT outputs. Y = Connected, N= No Connection
OUT
LINK
1
Y
2
Y
3
Y
4
YConnection status of all HDMI Looped outputs. Y = Connected, N= No Connection
Page 11
8.0.4 EDID Management
The extended display identification data (EDID) is used by the source device to match it’s video resolution with
the connected display. By default all four source devices invoke the fifth built in EDID: 4K/60Hz HDR 2CH.
●Enter EDID management.
Press “Menu” and scroll “Down” to the EDID Management section, then press “Menu” to confirm. Use the “UP”
and “DOWN” buttons to scroll through the choices.
▪Learn HDBaseT Output
▪Learn HDMI Output
▪Built-in EDID
●Copy the EDID from one of the HDBaseT outputs to one or several inputs. Example: Learn the EDID from the
display connected to HDBaseT output 2 and send it to inputs 1, 2, 3 and 4.
1. Select “Learn HDBT Out” and press “Menu” to confirm.
2. Select “Output 2” and “Inputs 1, 2 ,3 ,4.
3. Press “Menu” to confirm.
●Copy the EDID from one of the HDMI outputs to one or several inputs. Example: Learn the EDID from the
display connected to HDMI output 4 and send it to inputs 1 and 2.
1. Select “Learn HDMI Out” and press “Menu” to confirm.
2. Select “Output 4” and “Inputs 1, 2.
3. Press “Menu” to confirm.
●Invoke the built-in EDID
User ManualScion Tech SC38.MX88
No EDID
Video Audio
1 1080p 2CH
2 1080p HDR MultiCH
3 4K@30Hz HDR 2CH
4 4K@60Hz HDR MultiCH
5 (Default) 4K@60Hz HDR 2CH
6 4K@60Hz HDR MultiCH
Custom
Example: Input 1 and 2 invoke the built-in EDID data: 4K@30Hz HDR 2CH
1. Select “Built-in EDID” and press “Menu” to confirm.
2. Use the “UP” and “DOWN” keys to navigate to 4K@30Hz HDR 2CH and press “Input 1 and 2”.
3. Press “Menu” to confirm.
Page 12
User ManualScion Tech SC38.MX88
8.0.5 Audio Settings
The matrix can extract audio from either the HDMI inputs or the HDBaseT outputs, analogue L/R audio and
digital SPDIF. The audio source can be selected from the front panel buttons.
Audio Output Ports Audio Sources
Input Breakout Output Breakout ARC
L+R OUT 1 IN 1 Breakout OUT 1 Breakout
L+R OUT 2 IN 2 Breakout OUT 2 Breakout
L+R OUT 3 IN 3 Breakout OUT 3 Breakout
L+R OUT 4 IN 4 Breakout OUT 4 Breakout
SPDIF OUT 1 IN 1 Breakout OUT 1 Breakout OUT 1 ARC
SPDIF OUT 2 IN 2 Breakout OUT 2 Breakout OUT 2 ARC
SPDIF OUT 3 IN 3 Breakout OUT 3 Breakout OUT 3 ARC
SPDIF OUT 4 IN 4 Breakout OUT 4 Breakout OUT 4 ARC
Example: Select the HDMI input 2 audio source for the analogue L+R output 2.
1. Press “Menu” then “Down” until you see Audio Setting. Press “Menu” to enter.
2. Press “down” until you locate L+R OUT 2, press “Menu” to confirm.
3. Press “down” to select IN2 Breakout.
4. Press “Menu” to confirm.
L+R Output Volume Control
1. Press “Menu” and “Down” to locate the Audio Setting. Press “Menu” to enter.
2. Press “Down” to locate L+R OUT 2 Vol. Press “Menu” to confirm.
3. Press “Up” and “Down” to set the required volume.
4. Press “Menu” to confirm.
8.0.6 Preset Setting
The matrix supports nine presets but only 1~4 can be set or recalled using the front panel buttons. RS232 or
TCP/IP GUI should be used to set and manage all presets.
Save the current routing t a preset.
1. Press “Preset” and select Hold 3s t Store.
2. Press “Input 2” to select Preset 2.
3. Press “Menu” to confirm.
Recall a saved preset
1. Press “Preset” and select Preset Recall
2. Press “Input 2” to select Preset 2.
3. Press “Menu” to confirm.
8.0.7 Current IP Address
1. Press “Menu” and “Down” to locate IP Address
2. Press “Menu” to reveal the current system IP Address.
Page 13
User ManualScion Tech SC38.MX88
9. GUI Control
The matrix can be controlled using the TCP/IP interface. The default settings are:
IP Address: 192.168.0.178
Subnet Mask: 255.255.255.0
Type the IP address in to your web browser to enter the log-in page and enter the user name and password.
User Name: admin
Password: admin
9.0.1 Signal Switching
Switching Audio Config CEC RS232 Access Interface Network
Output 1 Output 2 Output 3 Output 4
Input 1
Input 2
Input 3
Input 4
Scene
12 3
456
78 9
Save Recall
Use the 4 x 4 button grid to to set which inputs are directed to which outputs. For example:- clicking the button
on the Input 1 row and Output 2 column, directs input 1 to output 2.
Use the 9 buttons in the Scene section to save and load presets.
●To save a layout, first click on of the numbered buttons, then click “Save”.
●To load a previously saved layout, first click one of the numbered buttons, then click the “Recall” button.
Page 14
User ManualScion Tech SC38.MX88
9.0.2 Audio Settings
Audio Config CEC RS232 Access Interface Network
Select Volume
Switching
L+R
Output 1 Audio on Input 1
L+R
Output 2
L+R
Output 3
L+R
Output 4
Audio on Input 3
Audio on Input 4
Audio on Input 2
Audio on Output 1
Audio on Output 2
Audio on Output 3
Audio on Output 4
Audio on Input 1
SPDIF
Output 1 Audio on Input 4
SPDIF
Output 2
SPDIF
Output 3
SPDIF
Output 4
Audio on Input 3
Audio on Input 4
Audio on Input 2
Audio on Output 1
Audio on Output 2
Audio on Output 3
Audio on Output 4
Audio on Input 1
There are eight possible audio sources that can be selected for analogue L+R outputs, and twelve audio sources
that can be selected for digital SPDIF outputs.
●L+R Outputs Volume Control
Audio Config CEC RS232 Access Interface Network
Select Volume
Switching
L+R
Output 1
75%
L+R
Output 2
75%
L+R
Output 3
75%
L+R
Output 4
75%
Page 15
User ManualScion Tech SC38.MX88
9.0.3 Down Scaling
Audio CEC RS232 Access Interface NetworkSwitching
HDMI Output 1
Config
HDMI Output 2
HDMI Output 3
HDMI Output 4
Enable Disable
Down-Scaling HDCP EDID Copy EDID Setting
Confirm Cancel
The matrix can downscale the video output of the mirrored HDMI outputs. When enabled a 4K input will be
downscaled to 1080p.
Audio CEC RS232 Access Interface NetworkSwitching
Output 1
Config
Output 2
Output 3
Output 4
Passive Active
Down-Scaling HDCP EDID Copy EDID Setting
Confirm Cancel
Passive - Automatically follows the HDCP data from the source device.
Active (Default) - If the input video has HDCP content, the output HDCP is version 1.4. If the input video has
no HDCP content the HDMI output has no HDCP.
Page 16
9.0.4 HDCP
User ManualScion Tech SC38.MX88
9.0.5 EDID Copy
Audio CEC RS232 Access Interface NetworkSwitching Config
1
2
3
4
Output
HDMI 1
Down-Scaling HDCP EDID Copy EDID Setting
Confirm Cancel
HDMI 2
HDMI 3
HDMI 4
HDBT 1
HDBT 2
HDBT 3
HDBT 4
Input
All
Operation:
1. Select one output port.
2. Select one or several input ports. Press ALL to select all input ports.
3. Click confirm to save or cancel to omit.
Operation:
1. Select one output port.
2. Select one or several input ports. Press ALL to select all input ports.
3. Click confirm to save.
Upload user-defined EDID.
4. Select the user-defined field.
5. Click in the Combi-Box and select a .bin file from your computer.
6. Click confirm to save.
9.0.6 EDID Setting
Audio CEC RS232 Access Interface NetworkSwitching Config
1
2
3
4
Embedded EDID
1080P 2CH
Down-Scaling HDCP EDID Copy EDID Setting
Confirm Cancel
1080P MultiCH
4K30 HDR 2CH
User-defined
4K30 HDR MultiCH
4K60 HDR 2CH
4K60 HDR MultiCH
Input
All
Apply
Bin
Page 17
User ManualScion Tech SC38.MX88
9.0.7 CEC Control
6.4.1 HDMI Input Control
Select on or several of the HDMI input source devices to be controlled and then press the function.
Audio Config RS232 Access Interface NetworkSwitching
1
2
3
4
Function
HDMI Input HDBT Output HDMI Output
Input
CEC
Vol - Menu Vol +
Back Up
Enter
Left Down Right
On Off Stop
Previous Next Pause
REW FF
Play
HDBT Input Control
Select on or several of the HDMI input source devices to be controlled and then press the function.
Audio Config RS232 Access Interface NetworkSwitching
1
2
3
4
Function
HDMI Input HDBT Output HDMI Output
Input
CEC
Vol - Vol +
On Off Mute
Page 18
User ManualScion Tech SC38.MX88
9.0.7 CEC Control
Select on or several of the HDMI input source devices to be controlled and then press the function.
Audio Config RS232 Access Interface NetworkSwitching
1
2
3
4
Function
HDMI Input HDBT Output HDMI Output
Input
CEC
Vol - Vol +
On Off Mute
9.0.8 RS232 Control
HDMI Output Control
1. Select the HDBaseT port associated with the HDBaseT receiver with the third party product to be controlled.
2. Select Baud Rate.
3. Type the RS232 commands in the Combi-Box to control the third party product. If Hex is selected the RS232
commands must be hexadecimal values.
4. Click send to complete the operation.
Audio Config CEC Access Interface NetworkSwitching
Port
Send
HDBT 2HDBT 1
RS232
HDBT 3 HDBT 4
Baud Rate
48002400 9600 19200
38400 57600 115200
Command
Hex
Page 19
Table of contents
Other Scion-Tech Matrix Switcher manuals
Scion-Tech
Scion-Tech SC04.MX22 User manual
Scion-Tech
Scion-Tech SC36.MX44 User manual
Scion-Tech
Scion-Tech SC38.MX16 User manual
Scion-Tech
Scion-Tech SC35.MX44 User manual
Scion-Tech
Scion-Tech SC04.1404 User manual
Scion-Tech
Scion-Tech SC36 MX88 User manual
Scion-Tech
Scion-Tech SC04.MX88 User manual
Scion-Tech
Scion-Tech SC04.1808 User manual
Scion-Tech
Scion-Tech SC08.MX2000 User manual
