Scotsman IS100 Guide

This parts list contains the parts available for the
IS100 and the IS150 ice dispensers.
These two models share many components, but
not all.
Check the model number, and refer to the correct
column list.
Options to the basic model of color, or a lighted
sign add to the details that may alter a part
number.
Check very carefully that the correct part is
ordered.
TABLE OF CONTENTS
MAJOR COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PAGE 2
CONTROL BOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PAGE 5
ICE DOOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PAGE 6
WIRING DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PAGE 7
IS100 and IS150 SERVICE PARTS
September 2005
Page 1

1
2
3
4
5
7
6
8
18
17 9
10
16
11
12
13
14
15
24
26
25
23
27
22
15
20
19
34
33
32
21
28
29
30
31
35
36
37
38
39
Major Components
41
IS100 and IS150 SERVICE PARTS
September 2005
Page 2

parts list continued on the next page
IS100 IS150
ITEM PART PART
NUMBER NUMBER NUMBER DESCRIPTION
1 02-3047-02 02-3062-02 Black lid
02-3047-02 02-3062-02 Gray lid
2 A34788-001 A34789-001 Upper front brace
3 A35252-003 A35252-003 Right side panel, Stainless Steel*
A35252-001 A35252-001 Right side panel, painted*
4 A35251-001 A35251-001 Side Panel Extension, painted*
A35257-004 A35257-004 Side Panel Extension, Stainless steel*
5 02-0836-00 02-0836-00 Catch
6 A35454-006 A35455-006 Upper front, black, not pushbutton, for light
A35454-002 A35455-002 Upper front, gray, not pushbutton, for light
A35454-008 A35455-008 Upper front, black, pushbutton, for light
A35454-008 A35455-004 Upper front, gray, pushbutton, for light
02-3084-01 02308401 Turn button for lighted upper front panels, above
7 15-0752-01 15-0754-01 Merch. sign for lighted panel, Coke
15-0752-02 15-0754-02 Merch. sign for lighted panel, Pepsi
15-0752-05 15-0754-05 Merch. sign for lighted panel, generic
8 A34784-002 A34784-002 Right side bracket
9 02-3071-01 02-3071-01 Bezel for Ice Switch Button
10 02-3072-01 02-3072-01 Button
11 A34799-001 A34800-001 Switch bracket
12 12-1570-01 12-1570-01 Microswitch
13 A36852-001 A36852-002 Grill
14 A36058-002 A36058-004 Sink, black
15 13-0674-13 13-0674-13 Drain tubing (1 unit = 1 ft.)
* B models only
Major Components
IS100 and IS150 SERVICE PARTS
September 2005
Page 3

IS100 IS150
ITEM PART PART
NUMBER NUMBER NUMBER DESCRIPTION
16 02-3068-01 02-3068-01 Ice Chute
17 A34797-001 A34798-001 Panel for ice chute
18 A34786-001 A34787-001 Mounting Bracket
19 12-2369-21 12-2369-21 Gearmotor Assembly
20 A34784-001 A34784-001 Left side bracket
21 A34869-001 A34870-001 Hopper
22 A34794-006 A34795-010 Upper splash panel, pushbutton
A34794-005 A34795-009 Upper splash panel, lever
23 A34790-001 A34791-001 Splash Panel
24 03-1419-22 03-141-922 Screw
25 12-2372-01 12-2372-01 Boot for microswitch
26 A34806-001 A34806-001 Lever "Push for Ice" lever models only
27 12-1570-00 12-1570-00 Microswitch
28 A32678-001 A32678-001 Leg
29 A35257-001 A35257-001 Side Panel Extension, painted*
A35257-004 A35257-004 Side Panel Extension, stainless steel*
30 A35252-004 A35252-004 Left side panel, Stainless Steel*
A35252-002 A35252-002 Left side panel, painted*
31 n/a A34985-001 Ice diverter
02-3911-01 Thumb screw for diverter
32 A34783-001 A34783-001 Access Panel, painted
A34783-002 A34783-002 Access Panel, Stainless Steel
33 A35253-001 A35254-002 Back Panel, Stainless Steel
A35253-002 A35254-001 Back Panel, Painted
34 02-3040-01 02-3040-01 Rotor
35 A34760-001 A34760-001 Hub Assembly, includes bearing and seal
02-3075-01 02-3075-01 Bearing
02-3065-01 02-3065-01 Seal
36 A34810-001 A34810-001 Mounting plate
37 A34817-001 A34817-001 Gearmotor plate
38 02-3103-01 02-3103-02 Sweep Arm
39 02-3102-01 02-3102-01 Funnel
40 03-0727-03 Thumb screw, 3/4" long
41 02-3418-01 02-3418-01 Drain top
02-2692-01 02-2692-01 Drain bottom
13-0617-11 13-0617-13 O-ring
* B models only
Major Components
IS100 and IS150 SERVICE PARTS
September 2005
Page 4

12 12
3
4
5
6
7
8
9
10
13
11
15
14
16
ITEM PART
NUMBER NUMBER DESCRIPTION
1 12-2090-02 Relay "A" or "B" up to serial numbers:
IS100, 368934-06X: IS150, 407527-10K
12-2483-01 Relay after the above serial numbers, up to these serial numbers:
IS100, 601768-07L; IS150, 622505-09L.
12-2483-02 Relay, after above serial numbers
2 12-2390-01 Transformer
3 A34889-001 Right bracket
4 12-2385-01 Bulb Holder
5 A34803-001 Control Box Cover
6 12-2377-01 Fluorescent Tube (15 watt -18") IS100
12-2377-02 Fluorescent Tube (16 watt -26") IS150
7 02-3067-01 Cover
8 13-0882-01 Rubber Mounts
9 A34890-001 Left light bracket (Optional)
10 A34873-001 Angle Bracket
11 12-2371-01 Recycling Timer
12 03-0727-06 Thumb Screw
13 02-3073-01 Spout Adaptor
14 12-2386-01 Starter
15 12-2395-01 Starter Socket
16 A34920-001 Solenoid cover, not shown
17 12-2380-01 Ballast, not shown; up to these serial numbers:
IS100, 601768-07L; IS150, 622505-09L.
12-2484-01 Ballast after the above serial numbers
18 13-0595-00 Door gasket, 5.5"
IS100 and IS150 SERVICE PARTS
September 2005
Page 5

1
2
3
4
5
6
7
8
94
10
11
2
10
10
5
ITEM PART
NUMBER NUMBER DESCRIPTION
1 A34801-001 Ice Door
2 03-0396-01 Cotter Pin
3 02-3089-01 Solenoid Link, for use without plastic bushings
02-3089-02 Solenoid link, use with plastic bushings
02-3187-01 Plastic bushing, used inside solenoid link 02-3089-02
4 02-3088-01 Long axle
5 03-1407-02 Flat Washer
6 A32685-001 Axle, Linkage
7 12-2862-01 Solenoid
8 A32690-002 Door Spring
9 A34802-001 Door Hinge
10 03-0396-08 Cotter pin
11 02-3187-01 Bushing
Ice Door And Solenoid Assembly
IS100 and IS150 SERVICE PARTS
September 2005
Page 6

Schematic Diagram
IS100 and IS150 SERVICE PARTS
October 1993
Page 7

Component Layout Diagram
IS100 and IS150 SERVICE PARTS
November 1994
Page 8
