Scotsman SCN60 Quick start guide

Introduction
This manual includes information for the
installation, operation and maintenance of the
SCN60 residential ice machine.
The SCN60 was developed to offer fans of
Scotsman’s Nugget Ice form the ability to have that
ice in their homes. Previously Nugget Ice was only
available in commercial establishments, where it
developed a strong following because of the
chewable nature of the ice. This machine makes
authentic Nugget ice, using the same process as
the larger commercial machines.
May 2011
Page 1
SCN60
Installation and Use
Table of Contents
Product Description: ...........................................Page 2
Cabinet Dimensions ...........................................Page 3
Location Recommendations: .......................................Page 4
Familiarization ..............................................Page 5
Decorating Features: ...........................................Page 6
Door Panel Attachment ..........................................Page 7
Door Swing ................................................Page 8
Plumbing - Pump Model .........................................Page 9
Plumbing: Gravity Drain Model ......................................Page 10
Electrical and Start Up ..........................................Page 11
Use....................................................Page 12
Maintenance ...............................................Page 13
How to remove scale from the ice making system. ...........................Page 14
Outdoor Use Notice:
Keep from freezing. Severe damage will occur to the unit if left in or operated in temperatures beyond
the limits listed in this manual. That damage is NOT covered by warranty.
Keep dry. Do not locate in low lying areas where puddles will accumulate.
Provide Shade: Heat gain from the sun will reduce the unit's ability to make and store ice, and
ultraviolet radiation from the sun can potentially damage the unit's plastic components.
Water Supply: Avoid a long run of hose or tubing exposed to the sun. Plastic water supply tubing
should be rated for potable water and include UV protection. Copper tubing is recommended.
Back Flow Prevention: The unit includes back flow prevention, no additional check valve is required.
Drainage: Do Not drain into swimming pool or onto grounds.

Product Description:
This ice machine is designed to be used indoors, in
a controlled environment or outdoors within certain
limits.
The SCN60 is made up of two major systems: the
ice making system and the ice storage system. The
ice making system is a continuous flow type ice
machine, it makes ice when the ice level becomes
low and stops when it is full.
The ice storage system is an insulated chest with a
drain at the bottom for melting ice. It is not
refrigerated, insuring that the bin contains fresh ice.
Installation Information
Dimensions:
The cabinet is fourteen and seven eighths inches
wide by thirty three and three eighths to thirty four
and three eighths inches high.
Utility and Operational Requirements
•The SCN60 must be connected to a potable
water supply.
•The water supply must have a conductivity of
at least 10 microSiemens/cm.
•Minimum water pressure: 20 psi
•Maximum water pressure: 80 psi
•Minimum water temperature: 40 degrees F.
•Maximum water temperature: 90 degrees F.
It is designed to operate in wide range of air
temperatures:
•Minimum air temperature: 50 degrees F.
•Maximum air temperature: 100 degrees F.
Although the machine will function within the listed
ranges, it works best at water temperatures
between 50 and 60 and air temperatures between
60 and 80.
Note: Ice making capacity goes down as the
environmental temperatures go up, and will be
severely reduced at temperatures over 90oF.
Operating a unit outside of the limits can cause
problems that are not covered by the warranty and,
if extreme, cause damage to the unit.
Water Quality
The water to the machine must be potable, or fit for
human consumption. Beyond that, water supplies
vary in the degree of mineral content. As this ice
machine makes ice, all the water that flows into the
machine is changed into ice. That includes any
minerals that might be in the water. However,
during ice making some minerals will stick to the
ice making components. The higher the mineral
content, the more mineral build up will occur. Water
filters are a partial help, as they will remove the
suspended solids, but water treatment is needed
for the dissolved solids, which are part of the water
and cannot be filtered out.
RO Water
This machine can be supplied with Reverse
Osmosis water, but the water conductivity must be
no less than 10 microSiemens/cm. A reverse
osmosis system should include post treatment or
blending to satisfy the R.O. water’s potential
aggressiveness.
Deionized water is not recommended and could
damage the machine.
Because water softeners exchange one mineral for
another, softened water may not improve water
conditions when used with ice machines
Electrical power
The unit must be on its own 115 volt, 60 Hz, 15
amp circuit. It is equipped with a power cord and
can be plugged into a nearby outlet. Extension
cords are not allowed by most codes. Follow all
applicable codes.
Warranty Information
Warranty information is supplied separately from
this manual. Refer to it for coverage. In general, the
warranty covers defects in materials or
workmanship and does not cover corrections of
installation errors or maintenance.
May 2011
Page 2
SCN60
Installation and Use

Cabinet Dimensions
May 2011
Page 3
SCN60
Installation and Use
Scotsman Ice Systems are designed and manufactured with the highest regard for safety and
performance. They meet or exceed the standards of agencies like ETL.
Scotsman assumes no liability or responsibility of any kind for products manufactured by Scotsman that
have been altered in any way, including the use of any parts and/or other components not specifically
approved by Scotsman.
Scotsman reserves the right to make design changes and/or improvements at any time. Specifications
and designs are subject to change without notice.
14 7/8"
AIR IN
AIR OUT
3/4" SHEET METAL DOOR FRONT - IF DOOR KIT INSTALLED
.63 MIN. CABINET DOOR
22"
29 1/4"
1" LEG ADJUSTMENT
(4) PLACES
2 3/4"
2 3/8" DOOR KIT
AND HANDLE
3/4"
4"
33 3/8" MIN.
34 3/8" MAX.
LEFT SIDE SVC.
ACCESS PANEL
2 1/2"
7 1/2"
3 1/4"
2 3/4"
5 1/8"
11 5/8"
115V
POWER CORD
DRAIN ACCESS - FLEXIBLE TUBING
3/8" I.D. PUMP MODEL (INCLUDED)
5/8" I.D. GRAVITY MODEL (NOT INCLUDED)
1/4" O.D. COPPER
WATER INLET
COMPRESSION
FITTING PROVIDED
3 7/8"
20 3/8"
FLOOR DRAIN
ACCESS HOLE

Location Recommendations:
The machine can be built into a cabinet. It is an air
cooled refrigeration system and so air flows in and
out of it through the grill at the bottom front. The
grill must not be blocked by any covering door or
other obstruction.
There are two models, one is a gravity drain type
and it must have a building drain connection below
the level of the drain tube at the back of the
cabinet; the other is a pump drain model which can
force drain water up a maximum of 10 feet,
allowing it to be located where a gravity drain isn’t
available.
Kickplate Extension:In some situations the leg
levelers will be extended enough to become visible.
A kit to extend the kickplate over the legs is KKPF.
Cabinet Stability: In some free standing
installations it may be prudent to add a bracket that
secures the back of the cabinet to a wall. That kit
number is KATB.
Drain Conversion: A gravity drain model can be
converted to a drain pump model by installing a
drain pump kit. The drain pump kit consists of a
drain pump, wiring harness and associated tubing.
The part number is A39462-021.
Installation Notes
Built In Situations: If a finished floor is to be
installed in the area after the ice machine has been
built in, shims the expected thickness of the floor
should be installed under the unit to keep the
machine level with the planned floor level.
Note: The water connection is at the back and adds
a few inches to the cabinet depth. Minimum
clearance is 0 in. at the top, 2 in. at the rear and
1/8 in. at each side.
Installations on a slab: Use a pump model and
pump the water to the point of drainage. Pump
models will pump 1 story (10 feet) high.
Installations over a crawl space or basement:
Either gravity drain or pump model units may be
used, if there is not enough room behind the
machine for a drain/waste receptacle, the drain will
have to be below the floor.
Note: When installed in a corner, the door swing
may be limited due to handle contact with the wall
or cabinet face.
All models require a water supply. Water supplies
vary in the degree of mineral content. High mineral
content water will require more frequent
maintenance. Water filtration may improve the
taste of the ice as well as cut down on some of the
mineral build up.
May 2011
Page 4
SCN60
Installation and Use
Air Intake
Warm Air Out

Familiarization
The control panel is visible when the door is
opened. It has three indicator lights and two
switches.
The model and serial number plate is located on
the bottom of the control panel box. The Bin Light
and Ice Level Sensor are also visible from that
angle, as is the Ice Chute.
The Scoop Holder is located on the right side of the
ice storage bin. The normal ice level is about level
with the scoop holder.
May 2011
Page 5
SCN60
Installation and Use
Ice
Making
Check
Water
Time to
Clean
Clean
Reset
Control Panel
Scoop Holder
Ice
Making
Check
Water
Time to
Clean
Clean
Reset
Serial Number Plate
Light
Ice Level
Control
Sensor
Serial Plate

Decorating Features:
The machine ships unfinished, allowing the
attachment of a decorator door panel or a metal
panel from Scotsman.
Door Panel
The ice machine is supplied without a conventional
door covering so it can be decorated to the user’s
preference. Scotsman offers several coverings
including white, black and stainless steel. In
addition, a custom built panel can be placed onto
the door.
Door Panels: Finished door panels are available
from Scotsman for attachment to the machine, or a
custom panel can be made. The panel kits are:
Kit Number Panel Finish Handle Finish
KDFW White White
KDFWS White Stainless Steel
KDFB Black Black
KDFBS Black Stainless Steel
KDFS Stainless Steel Stainless Steel
Door Panel Attachment
To attach a Scotsman supplied panel:
Note: If door swing is to be changed, it must be
done before panel is attached.
The panel will be held on by 6 sheet
metal screws and 2 machine screws.
1. Remove the gasket and retain for
later use.
2. If the door panel is stainless steel,
remove any plastic covering the
stainless steel panel.
3. Place the panel onto the outside
of the door, and secure it to the door
using two machine screws, located
at the left center and right center.
4. Fasten the panel to the door using
the 6 sheet metal screws. In the
hinge area, use the outermost screw
holes.
5. Place the covers over the hinge areas, and
secure each cover to the door using a sheet metal
screw.
6. Insert hole plug over screw installed in step 5.
7. Return the gasket to its original position.
Custom Panel
A custom panel of wood or other material not
exceeding 15 lb can be attached to the door.
Attachment is from the ice side of the door. Holes
are provided in the door for this purpose.
See instructions in information packet to create and
attach a custom panel
May 2011
Page 6
SCN60
Installation and Use
Hole Plug Cover
Gasket

Door Panel Attachment
May 2011
Page 7
SCN60
Installation and Use
Gasket
Scotsman
Door Panel
Cover
Machine
Screw
Use Upper
Hole at the
Top
Use Lower
Hole at the
Bottom
Hole Plug

Door Swing
The door swing is reversible.
The door can be attached to open with hinges on
the left or right using new hinge brackets shipped
loose in the ice bin. Retain all screws for re-use.
To change:
1. Remove hinge cover and innermost screw
holding each hinge to cabinet, loosen the other.
2. Slide hinges to the side and remove door from
cabinet. Remove screws loosened in step 1 from
both cross braces.
3. Remove two screws securing top panel to back,
pull top panel back and remove from cabinet.
4. Remove two screws at the top and lift the upper
bracket out of the cabinet. Replace with the one
supplied loose with the machine.
Fasten it to the cabinet using the original screws.
5. Return the top panel to the cabinet and fasten it
with the original screws.
6. Remove kickplate and front service panel.
7. Remove two front screws and two bottom
screws holding the bottom door bracket to the
cabinet.
8. Replace the bracket with the one supplied loose
with the machine. Secure it using the original
screws.
9. Remove the upper hinge and move it to the
door’s opposite side, bottom location. Secure using
the original screws.
Note: If door panel is attached, it must be removed
to access hinge screws.
10. Remove the original lower hinge and move it to
the door’s opposite side, upper location. Secure
using the original screws.
11. Install a screw removed in step 2 in outermost
hole of upper and lower cross braces.
12. Attach the door to the cabinet using the original
screws.
13. Return kickplate and front service panel to their
original positions and attach to the cabinet using
the original screws.
May 2011
Page 8
SCN60
Installation and Use
Ice
Making
Check
Water
Time to
Clean
Clean
Reset
Remove Screws
Screw Below

Plumbing - Pump Model
Drains
There are two types of ice machine models, one
that drains by gravity and one that has an internal
drain pump.
Drain Pump Model drain installation
1. Locate the coil of 3/8” ID plastic drain tubing
secured to the back of the unit.
2. Route the plastic drain tube from the back of the
unit to the drain connection point.
The drain connection point can be as high as 10
feet above the ice machine. The drain pump
includes a check valve to prevent re-pumping
water in the drain hose.
IMPORTANT NOTE: Often an air gap is required
by local codes between the ice maker drain tube
and the drain receptacle.
Water Supply
The recommended water supply tubing is ¼ inch
OD copper. Stainless steel flex or reinforced PCV
tube may also be used. Install an easily accessible
shut-off valve between the supply and the unit. This
shut-off valve should not be installed behind the
unit.
The water connection is at the back of the cabinet.
Connect using a compression fitting, one is
supplied tied to the water inlet tube. When built in:
Coil enough tubing behind the machine so it can be
pushed into the cavity without kinking the tubing.
May 2011
Page 9
SCN60
Installation and Use
Connect
Water Supply
Here
Pump Drain
Discharge
Tubing

Plumbing: Gravity Drain Model
Caution: Restrictions in the drain system to the
machine will cause water to back up into the ice
storage bin and melt the ice. Gravity drain tubing
must be vented, have no kinks and slope to the
building drain. Air gaps are typically required by
local code.
1. Place the ice machine in front of the installation
opening. Adjust leveling legs to the approximate
height.
2. Remove the upper back panel if needed for
access to the drain fitting.
Note: If you are connecting a gravity drain model
and the drain opening has been located in the floor
under the base pan according to the pre install
specifications, follow steps 3 through 5 to drain the
unit through the base. If not, proceed to step 6b.
3. Remove the clamp and barbed elbow and take
off the plastic cover in the base pan below the drain
hose.
4. Connect a straight 5/8” barbed connector to the
drain hose, securing with the clamp removed in
step 3.
5. Cut an 8” piece of 5/8” ID X 7/8” OD tygon (clear
plastic) tubing. Slide one end of the tube onto the
outlet of the barbed connector and secure with a
clamp. Leave the other end of the tube lying on the
floor of the base pan until the unit is positioned
over the floor drain.
6. Route the drain tube. Either a) Insert the drain
tube through the base pan into the floor drain or b)
Route the drain tube through the hole in the lower
back panel and connect to barbed elbow and
secure with a clamp.
7. Reinstall the upper back panel.
Water Supply
The recommended water supply tubing is ¼ inch
OD copper. Stainless steel flex or reinforced PCV
tube may also be used. Install an easily accessible
shut-off valve between the supply and the unit. This
shut-off valve should not be installed behind the
unit.
The water connection is at the back of the cabinet.
Connect using a compression fitting, one is
supplied tied to the water inlet tube.
When built in: Coil enough tubing behind the
machine so it can be pushed into the cavity without
kinking the tubing.
May 2011
Page 10
SCN60
Installation and Use
Connect
Water Supply
Here
Drain Tubing
Inside Cabinet

Electrical and Start Up
The ice machine is supplied with a power cord. Do
not remove the grounding pin from the cord’s plug.
Do not use extension cords. Follow all codes.
Connect the machine to its own 115 volt, 15 amp
circuit.
1. If the electrical outlet for the ice maker is behind
the unit, plug in the unit.
2. Position the unit in the installation opening.
3. Turn on the water supply. Make sure that the ice
maker is plugged in and the power is on.
4. Slide unit into installation opening, paying careful
attention to water supply and drain connections. Do
not kink!
5. Pour a couple of quarts of water into the ice
storage bin; on drain pump equipped machines the
drain pump should start and water should pump
out. Check for leaks.
6. Replace the service access panel.
7. Level the unit as needed.
Installation check list:
1. Has the unit been connected to the proper water
supply?
2. Has the water supply been checked for leaks?
3. Has the unit been connected to a drain?
4. Has the drain been tested for flow and leaks?
5. Has the unit been connected to the proper
electrical supply?
6. Has the unit been leveled?
7. Have all packing materials been removed from
the machine?
8. Has the door covering been installed?
Initial Start Up
1. Turn on the water supply and check for leaks.
2. Switch on the electrical power.
3. Push and release the On/Off switch to start the
machine. The Ice Making light next to the On/Off
switch will glow Green.
Warm air will flow out of the left front grill.
It will take about 10 minutes for the ice machine to
begin dropping nugget ice into the storage bin. It is
normal for that ice to melt and ice will continue to
melt, but at a slower rate. It will take about6-7
hours to fill up the ice storage bin. The bin holds
about 20 lb of ice when full.
Ice level control
The ice level control for the SCN60 is an ultrasonic
sensor, located above the ice storage area. It is
automatic and there is no adjustment to make.
When ice melts or is used, and the ice level drops
below a preset distance the control turns the ice
making system back on. It makes ice until the
preset level is reached. Placing your hand in the
unit to remove ice does not affect the ice level.
May 2011
Page 11
SCN60
Installation and Use

Use
No special instructions are needed for use. Just
take as much ice as you need, the machine will
replace it. A scoop is provided, and it can be stored
in the machine using the loop of tubing on the right
side as a holder.
The machine can be shut off anytime by just
pushing and releasing the On/Off button.
What shouldn’t be done?
Never keep anything in the ice storage bin that is
not ice. Objects like wine or beer bottles are not
only unsanitary, but the labels can slip off and plug
up the drain.
Never allow the machine to operate without regular
cleaning. The machine will last longer if it is kept
clean. Regular cleaning should happen at least
once per year, and preferably twice. Some water
conditions will dictate even more frequent cleaning
of the ice making section, and some carpets or
pets will dictate more frequent cleaning of the
condenser.
Note: The Time to Clean light will switch ON after 6
months of use. It will remain ON until the ice
making system is cleaned using the process on
page 14.
Noise:
The ice machine is designed for quiet operation,
but will make some noise during the ice making
cycle.
Ice Making
During ice making, nugget ice will drop into the bin
at an irregular rate; sometimes there will be little ice
falling while at other times a group of nuggets will
fall. Some water drops may also come out with the
ice. Both conditions are normal.
May 2011
Page 12
SCN60
Installation and Use
Control Panel
On/Off Control Button Clean Button
Glows Green when
unit is switched On
Glows Yellow when
it's time to clean the
machine
Glows Red when there is no water
supplied to the machine
The machine will NOT make ice
when this light is on. It will restart
and the light will go out when the
water supply is restored.

Maintenance
Scotsman strongly recommends regular
maintenance of this ice machine. During normal
operation mineral scale that is in the water supply
will gradually build up on the ice making surfaces.
That build up can cause excessive loading of the
ice making system, which can cause premature
failure. Regular removal of the mineral scale will
lengthen the product’s life.
Suggested maintenance schedule: every 6 months.
Type of maintenance: Scale removal, water seal
check, water reservoir check, bin drain check, air
cooled condenser cleaning and storage bin
sanitation.
Condenser cleaning
The condenser is like the radiator on a car, it has
fins and tubes that can become clogged with dirt
and lint. To clean:
1. Remove the kickplate and front service panel.
2. Locate the condenser surface.
3. Vacuum the surface, removing all dust and lint.
Caution: Do not dent the fins.
4. Return the kickplate and front service panel to
their original positions. Fasten them to the cabinet
using the original screws.
Winterizing
1. Clean the ice making system per the instructions
in the Maintenance section.
2. Open the door and push and release the On/Off
switch to turn the machine off.
3. Turn off the water supply.
4. Remove the back wall of the ice storage bin.
5. Remove drain plug and drain the water reservoir,
return plug to its original position.
6. Drain pump models should have about 1/2
gallon of RV antifreeze (propylene glycol) poured
into the ice storage bin drain.
Note: Automotive antifreeze must NOT be used.
7. Switch off and unplug the machine.
May 2011
Page 13
SCN60
Installation and Use
Condenser
Surface

How to remove scale from the ice making system.
Cleaning this machine involves adding a solution of
scale remover and water to the ice machine and
continuing to add it as it makes ice. The scale
remover must be diluted to the correct ratio. A
squirt bottle will make adding the scale remover
much easier when the unit is built in. If not built in,
remove the top panel for reservoir access.
Recommended tools: Rubber gloves, squirt bottle
& scale remover. Pre-Mixed 16 oz squirt bottle of
scale remover is part number 19-0664-01.
1. Scoop out and discard all of the ice.
2. Press and release the On/Off button.
3. Open door and locate screws at upper back wall
of bin. Remove the two screws.
4. Remove the back wall of the bin by lowering it
down past the scoop holder, feel free to rotate the
scoop holder loop down to make more room.
5. Push tab on front edge of reservoir cover and
remove the cover. Note: Adjacent wires are low
voltage and are not hazardous.
May 2011
Page 14
SCN60
Installation and Use
Ice
Making
Check
Water
Time to
Clean
Clean
Reset
Screws
Float Valve
On/Off Lever
Reservoir Cover
Release Tab
Push In Tab to Release Cover
Lift Reservoir Cover to Remove
Ice
Making
Check
Wate r
Time to
Clean
Clean
Reset

6. Locate blue float valve on/off lever. Move lever
up about half way to shut water off.
7. Locate drain plug and pull the drain plug out to
drain the reservoir and evaporator. When draining
is complete, return the plug to its original position.
8. Obtain pre-mixed Scotsman Clear 1 Scale
remover solution (with squirt bottle) or mix a
solution of Clear 1 with water: 2.5 ounces of Clear
1 with 1 quart (32 oz) of warm water.
Note: Take care not to spill any scale remover on
any nearby surface. Immediately wipe any spill with
baking soda and water.
9. Fill the 16 oz squirt bottle with the diluted scale
remover.
10. Fill the reservoir with the scale remover solution
using squirt bottle or other container. That will be
about 8 ounces or half a squirt bottle.
May 2011
Page 15
SCN60
Installation and Use
Ice
Making
Check
Water
Time to
Clean
Clean
Reset
Fill Reservoir Using Squirt Bottle
Ice machine scale
remover contains acids.
Acids can cause burns.
If concentrated cleaner
comes in contact with
skin, flush with water. If
swallowed, do NOT
induce vomiting. Give
large amounts of water
or milk. Call Physician
immediately. Keep out
of the reach of children.
Ice
Making
Check
Wate r
Time to
Clean
Clean
Reset
Drain Plug
Ice
Making
Check
Water
Time to
Clean
Clean
Reset
Ice
Making
Check
Wate r
Time to
Clean
Clean
Reset
Drain Plug

11. Press and HOLD both the Clean-Reset and
On/Off buttons for 5 seconds. The Time to Clean
light will blink on and off.
12. The auger motor alone will be operating for 10
minutes, after that the compressor will start and in
about 5-8 minutes the machine will start to make
ice. The Time to Clean light will now glow steady
until the clean cycle is complete.
Caution: Keep fingers away from moving parts.
After ice making starts, continuously add scale
remover solution to the reservoir to keep it about
half full.
When all 16 oz of the the solution is used, move
the float valve lever down to the On position.
After 40 minutes the ice machine and all the control
panel lights will shut off.
13. Pull the drain plug again to drain the system,
then replace it.
14. Return the reservoir cover to its original
position.
15. Return the upper back wall of the bin to its
original position and secure it with the original
screws. Push in at bottom to snap it into place.
16. Pour a gallon of hot (95oF. – 115oF.) water into
the bin to flush out the drain and melt all ice that
was made during the cleaning process. Be sure all
ice is melted.
17. Clean the bin liner of mineral scale by using
any left over scale remover solution to scrub the
scale off of the liner. If none is left over, mix a
solution of 2.5 ounces of Clear 1 Scale Remover
and 1 quart of water.
18. Rinse the liner with hot water.
19. Sanitize the bin interior.
20. Push and release the On/Off button to restart
ice making.
The ice scoop should be washed regularly, wash it
just like any other food container.
Other Maintenance
While cleaning the system with scale remover,
check for water leaks at the bottom of the
evaporator. If any are found, call for service.
Note: It is normal for some lime scale to form on
the gear reducer cover. Wipe up any loose scale.
Check the top bearing.
The top bearing is non-metallic and requires no
lubrication. However, it should be checked for wear
occasionally. The top panel must be removed to
access the bearing.
May 2011
Page 16
SCN60
Installation and Use
Ice
Making
Check
Wate r
Time to
Clean
Clean
Reset
Press
Both

SCN60 service
This section contains information for the service
and repair of the SCN60 ice machine.
May 2011
Page 1
SCN60
Service
Service Table of Contents
SCN60 service ..............................................Page 1
Components: ...............................................Page 2
Evaporator and Auger...........................................Page 3
Control System ..............................................Page 4
Water System ...............................................Page 5
Storage ..................................................Page 6
Performance and Technical Specs ....................................Page 7
Electrical Sequence ............................................Page 8
Service Diagnosis .............................................Page 9
Service Diagnosis .............................................Page 10
Component Diagnostics..........................................Page 11
Ice Capacity ................................................Page 12
Removal and Replacement ........................................Page 13
SCN60 Gearbox Access & Removal ...................................Page 14
Water Seal Replacement .........................................Page 16
Evaporator Replacement .........................................Page 18
Drain Pump (if equipped) .........................................Page 19
Compressor replacement. ........................................Page 20
Bin and Cabinet ..............................................Page 21

Components:
•Refrigeration system, including air cooled
condenser, compressor, capillary tube and
evaporator.
•Control system, including ice level sensor,
water sensor, auger motor sensor, controller,
control pad and transformer.
•Auger drive system, including auger motor,
gear reducer and auger.
•Auger support system, including top bearing
and water seal.
•Water system, including the float and
reservoir.
•Storage system, including ice storage bin,
drain and door.
The SCN60 is a continuous flow ice machine.
When the control system senses that the storage
bin’s ice level is low, it turns on the compressor, fan
motor and auger drive motor.
During ice making the refrigeration system takes
heat from the evaporator. The evaporator is a
vertical refrigerated stainless steel tube containing
water and a slowly rotating auger. When the water
gets to the freezing point, ice begins to form. That
ice is very soft and is pushed up the evaporator
tube by the auger. As ice is made more warm
water enters at the bottom. The soft, mushy ice is
forced up to the top of the evaporator’s tube where
it is forced through nine tapered holes. As the ice is
pushed through the holes excess water is
squeezed out. The ice comes out of the holes
shaped as a rod of ice. The rods of ice are broken
off by being pushed against the tapered flange
above the holes, forming the irregular lengths of
nugget ice. The ice sweep, rotating with the auger,
moves the ice to the ice chute where it falls by
gravity into the storage bin.
May 2011
Page 2
SCN60
Service
Refrigeration System Schematic
Air Cooled
Condenser
Capillary Tube
Compressor
Evaporator
Assembly
Auger Drive
System
Liquid Line
Suction Line /
Heat
Exchange

Evaporator and Auger
May 2011
Page 3
SCN60
Service
Cut Away View
Stationary
Half of Water
Seal
Rotating Half
of Water Seal
Heat
Exchange
Tube Coil
Auger
Ice Outlet
Bearing
Foam
Insulation
Water Inlet

Control System
The control system operates the machine. The
controller operates on 12 volts AC, supplied by the
transformer. It uses an ultrasonic ice sensor to
measure ice level. The ultrasonic system transmits
sound waves into the ice storage bin and measures
the return time, when the return time is longer than
the preset time for bin full, the controller switches
the ice machine to an ice making mode. During ice
making the compressor, fan motor and auger motor
are operating.
The control system has two safeties: It will not
operate the machine without water and it will not
operate the machine if the auger motor is drawing
too much current or if it isn’t drawing any current.
The water sensor is checking the conductivity of
the water in the water reservoir. If there is no water
in the reservoir the conductivity will be zero and the
controller will either not start ice making or will stop
making ice.
The current or amps of the auger motor are
continually monitored by the controller during ice
making. If the current is too high, indicating an
overload, the controller will stop ice making. If the
current is zero, indicating an auger motor failure,
the controller will also stop ice making.
The control pad has two switches and three lights.
The left switch button is On/Off. The right switch
button is Clean/Reset. The left Ice Making light is a
status light, it is ON when the machine has been
switched to an ice making mode. The center light is
a Water light, it will be ON when the controller has
sensed that there is no water available. It will go
out when the water supply has been restored. The
right light is a Time to Clean indicator light. It is
switched ON by the controller after six months of
power connect time. It will go out after the machine
has been cleaned following the process in the
Maintenance section.
May 2011
Page 4
SCN60
Service
Control Panel
On/Off Control Button Clean Button
Glows Green when
unit is switched On
Glows Yellow when
it's time to clean the
machine
Glows Red when there is no water
supplied to the machine
The machine will NOT make ice
when this light is on. It will restart
and the light will go out when the
water supply is restored.
